Soleus Air HCB-R135-A-ID User manual

13500 BTU RV Air Conditioner
Installation and Operating Instructions
Model No.:HCB-R135-A-ID
HCB-R135-A-OD
V140804
3092402

2
Thank you for choosing a Soleus Air RV Air Conditioner. This owner’s manual will provide you
with valuable information necessary for the proper care and maintenance of your new product.
Please take a few moments to thoroughly read the instructions and familiarize yourself with all the
operational aspects of your new Soleus Air RV Air Conditioner.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the
store name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: _____________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT INSTRUCTIONS
Before installing and using your RV Air Conditioner, please read this owner’s manual carefully. Store this manual in
a safe place for future reference.
1. All wiring must be complied with local and national electrical codes. All wiring must be installed by qualified
electricians. If you have any question about the following instruction, contact a qualified electrician.
2. Check the available power supply and resolve any wiring problems BEFORE installing and operating this unit.
3. This air conditioner is designed to operate from a 115V AC, 60Hz, 1 phase power supply.
4. This air conditioner is designed for recreational vehicles. Check the roof of the vehicle to determine if it can sup-
port both the roof top unit and the ceiling assembly without additional support. Make sure the interior ceiling
amounting area will not interfere with existing structures.
5. A reinforced and framed roof hole opening must be cut (if there is no hole) or you may use existing vent holes.

3
SPECIFICATIONS
MODEL NUMBER HCB-R135-A-ID HCB-R135-A-OD
COOLING CAPACITY 13500 BTU/Hr
DEHUMIDIFYING CAPACITY 132 pts per Day
COOLING POWER USAGE Cooling 1290 Watts, 11.6 Amps
AIR FLOW VOLUME(H/M/L) 490/400/346 CFM
POWER SOURCE 115 V / 60 HZ
SOUND PRESSURE LEVEL Ceiling Assembly 50 dB(A)
Roof Top 58 dB(A)
Ceiling Assembly 50 dB(A)
Roof Top 58 dB(A)
PRODUCT WEIGHT 10lbs 92.3 lbs
OPERATING
TEMPERATURE Cooling 64.4℉-109.4℉
PRODUCT DIMENSIONS 26.25” W×19.5” D×3.625” H 41” W×22.375” D×14.5” H
REFRIGERANT R-410A

4
PRODUCT DIAGRAM
ROOF TOP
1. Roof Top Air Conditioner (1)
2. Sponge Air Duct (1)
3. Sponge Pieces (2)
4. Sponge Slip (1)
CEILING ASSEMBLY
1. Ceiling Grille (1)
2. Bolts (4)
3. Fabric Air Duct (1)
4. Air Vent Plates (2)
5. Remote Control (1)
6. Double-Sided Tape (1)
7. Remote Control Holder (1)
8. AAA Batteries (2)
9. Tapping Screws (8)
10. Remote Control Holder Screws (2)
11. Product Manual (1) (Not shown)
ROOF TOP
CEILING ASSEMBLY

5
ELECTRIC DIAGRAM
CEILING ASSEMBLY
ROOF TOP
ROOF TOP
CEILING ASSEMBLY

6
RVAC INSTALLATION INSTRUCTION
5. Fasten the Ceiling
Assembly Frame to
the base of the Roof
Top Air Conditioner with
the 4 Bolts.
4. Fasten the Fabric Air Duct to the base
of the Roof Top Air Conditioner with 4
Tapping Screws by Air Vent Plate.
2. Mount the Roof Top Air Conditioner on
top of where the opening was created.
3. Unscrew the screws and remove
Ceiling Assembly Frame from Ceiling
Grille.

7
8. Connect Ceiling Assembly and Roof Top connectors (see P9
Figure 3,4).
9. Re-screw the Ceiling Grille to the Ceiling Assembly Frame.
6. Fasten each side of the Fabric Air Duct by secur-
ing the Air Vent Plate to the Ceiling Assembly
Frame with 4 Tapping Screws. Trim any excess
fabric that may extend beyond edge of Air Vent
Plate.
7. Use the provided power supply in
Electric Box located on the side of the
Ceiling Assembly Frame for electrical
wiring (see P8 Figure 1,2).
Ceiling
Assembly
Roof Top

8
1. Route a copper with ground, supply wiring with minimum #12AWG for 13500 BTU/H unit. The wiring
from its power source to the electric box. Do not attach them at this time.
ELECTRIC WIRING
Make sure that all power supply to the unit is disconnected before starting any work on the unit to avoid the possibil-
ity of shock or injury and/or damage to the equipment. After the interior ceiling assembly frame is properly secured
to the Roof Top Air Conditioner, the following electrical connections must be performed.
3. Connect Roof Top Air Conditioner power
cord to the side of the Electric Box (see Fig-
ure 2).
4. Insert the power cord #12AWG to the other
end of the Electric box (see Figure 2).
5. Connect the power supply cord (#12AWG) to the Black, White, and Green/
Ground wires in Electric Box with a terminal board. Connect Black wire to Black
wire, White wire to White wire, and Green/Ground wire to YE/GN wire (see Figure
2).
6. Tighten the relief clamp screws to secure the supply power cord, make sure DO
NOT OVERTIGHTEN. Reinstall the Electric Box cover (see Figure 2).
2. Unscrew 2 screws and remove the Electric
Box cover (see Figure 1).

9
ELECTRIC WIRING (CONTINUED)
7. Connect the Ceiling Assembly and
Roof Top connectors (see Figure 3, 4).
(Roof Top)
(Ceiling Assembly)
Ceiling
Assembly
Roof Top

10
OPERATING INSTRUCTIONS
CONTROL PANEL BUTTONS
1) Power On and Off - Press the ON/OFF button once to manually turn the unit on. Press the ON/OFF
button once more to turn the unit off.
2) Mode Selection - Press the MODE button repeatedly to cycle between the different modes: Auto
mode, Air Conditioner mode, Dehumidifier mode, and Fan only mode.
NOTE: Auto mode indicator is not shown on control panel.
3) Temperature - Select the desired temperature by pressing either + or −key when using the unit in
Air Conditioner mode. The temperature indicator flashes to display the desired temperature setting. Af-
ter the temperature is set, the unit will display this temperature setting until it is changed by the user.
The LED display shows temperature in Fahrenheit. Press and hold + and −simultaneously for 2 sec-
onds to switch between Celsius and Fahrenheit.
4) TIMER -
Auto-On: To program the timer, when the unit is off, press the TIMER button. Once TIMER is
pressed, the TIMER indicator will light up. Press the buttons + or - to set the timer. The timer can be set
in intervals of 0.5 hours up to 10 hours, then in intervals of 1 hour up to 24 hours.
Auto-Off: To program the timer, when the unit is on, press the TIMER button. Once TIMER is
pressed, the TIMER indicator will light up. Press the buttons + or - to set the timer. The timer can be set
in intervals of 0.5 hours up to 10 hours, then in intervals of 1 hour up to 24 hours.
5) FILTER - When the filter needs to be replaced, FILTER indicator will light up. Clean the filter and
slide it back to the compartment, press FILTER button to reset the unit before operation.
6) FAN SPEED - To change fan speed, press FAN SPEED button to select desired fan speed (High, Me-
dium, Low, Auto), the associate indicator will light up.
CONTROL PANEL, DISPLAY, & OPERATING INSTRUCTIONS
CONTROL PANEL Decrease
Temperature
Button
Increase
Temperature
Button
POWER
ON/OFF
Button
Air Conditioner
Mode
Indicator
Dehumidifier
Mode
Indicator
Fan Speed
Indicators
Fan Mode
Indicator
Timer
Indicator
Mode Selection
Button
Timer Button
Filter Check
Indicator
Filter Check
Button
Fan Speed
Button
