1 Notes on this Manual
1.1 General Notes
Solplanet inverter is a transformerless solar inverter with three independent
MPP trackers. It converts the direct current (DC) from a photovoltaic (PV)
array to grid-compliant alternating current (AC) and feeds it into the grid.
1.2 Area of validity
This manual describes the mounting, installation, commissioning and
maintenance of the following inverters:
ASW5000-S
ASW5000-S-A
ASW6000-S
ASW6000-S-A
ASW8000-S
ASW8000-S-A
ASW10000-S
ASW10000-S-A
Observe all documentation that accompanies the inverter. Keep them in a
convenient place and available at all times.
1.3 Target group
This manual is for qualified electricians only, who must perform the tasks
exactly as described.
All persons installing inverters must be trained and experienced in general
safety which must be observed when working on electrical equipment.
Installation personnel should also be familiar with local requirements, rules
and regulations.
Qualified persons must have the following skills:
• Knowledge of how an inverter works and is operated

UM0012_ASW 5-10k Series_EN_V03_0522 5
• Training in how to deal with the dangers and risks associated with installing,
repairing and using electrical devices and installations
• Training in the installation and commissioning of electrical devices
• Knowledge of all applicable laws, standards and directives
• Knowledge of and compliance with this document and all safety information
1.4 Symbols used in this manual
Safety instructions will be highlighted with the following symbols:
DANGER indicates a hazardous situation which, if not be avoided, will
result in death or serious injury.
WARNING indicates a hazardous situation which, if not be avoided, can
result in death or serious injury.
CAUTION indicates a hazardous situation which, if not be avoided, can
result in minor or moderate injury.
NOTICE indicates a situation which, if not be avoided, can result in
property damage.

6 UM0012_ASW 5-10k Series_EN_V03_0522
2 Safety
2.1 Intended use
1. The inverter converts the direct current from PV array into grid-compliant
alternating current.
2. The inverter is suitable for indoor and outdoor use.
3. The inverter must only be operated with PV arrays (PV modules and
cabling) of protection class II, in accordance with IEC 61730, application
class A. Do not connect any sources of energy other than PV modules to
the inverter.
4. PV modules with a high capacitance to ground must only be used if their
coupling capacitance is less than 1.0μF.
5. When the PV modules are exposed to sunlight, a DC voltage is supplied to
the inverter.
6. When designing the PV system, ensure that the values comply with the
permitted operating range of all components at all times.
7. The product must only be used in countries for which it is approved or
released by AISWEI and the grid operator.
8. Use this product only in accordance with the information provided in this
documentation and with the locally applicable standards and directives. Any
other application may cause personal injury or property damage.
9. The type label must remain permanently attached to the product.
10. The inverters shall not be used in multiple phase combinations.
INFORMATION that is important for a specific topic or goal, but is not
safety-relevant.

UM0012_ASW 5-10k Series_EN_V03_0522 7
2.2 Important safety information
Danger to life due to electric shock when live components or cables are
touched
• All work on the inverter must only be carried out by qualified personnel
who have read and fully understood all safety information contained in this
manual.
Danger to life due to high voltages of the PV array
When exposed to sunlight, the PV array generates dangerous DC voltage
which is present in the DC conductors and the live components of the
inverter. Touching the DC conductors or the live components can lead to
lethal electric shocks. If you disconnect the DC connectors from the
inverter under load, an electric arc may occur leading to electric shock and
burns.
• Do not touch non-insulated cable ends.
• Do not touch the DC conductors.
• Do not touch any live components of the inverter.
• Have the inverter mounted, installed and commissioned only by qualified
persons with the appropriate skills.
•If an error occurs, have it rectified by qualified persons only.
•Prior to performing any work on the inverter, disconnect it from all voltage
sources as described in this document(see Section 9 "Disconnecting the
Inverter from Voltage Sources").

8 UM0012_ASW 5-10k Series_EN_V03_0522
Risk of injury due to electric shock
Touching an ungrounded PV module or array frame can cause a lethal
electric shock.
• connect and ground the PV modules, array frame and electrically
conductive surfaces so that there is continuous conduction.
Risk of burns due to hot enclosure parts
Some parts of the enclosure can get hot during operation.
• During operation, do not touch any parts other than the enclosure lid of
the inverter.
Damage to the inverter due to electrostatic discharge
Internal components of the inverter can be irreparably damaged by
electrostatic discharge.
• Ground yourself before touching any component.

UM0012_ASW 5-10k Series_EN_V03_0522 9
2.3 Symbols on the label
Symbol Explanation
Beware of a danger zone
This symbol indicates that the product mus be additionally grounded if
additional grounding or equipotential bonding is required at the installation site.
Beware of high voltage and operating current
The inverter operates at high voltage and current. Work on the inverter must
only be carried out by skilled and authorized electricians.
Beware of hot surfaces
The inverter can get hot during operation. Avoid contact during operation.
WEEE designation
Do not dispose of the product together with the household waste but in
accordance with the disposal regulations for electronic waste applicable at the
installation site.
CE marking
The product complies with the requirements of the applicable EU directives.
Certification mark
The product has been tested by TUV and got the quality certification mark.
RCM Mark
The product complies with the requirements of the applicable Australian
standards.
Capacitors discharge
Before opening the covers, the inverter must be disconnected from the grid and
PV array. Wait at least 5 minutes to allow the energy storage capacitors to fully
discharge.

10 UM0012_ASW 5-10k Series_EN_V03_0522
Observe the documentation
Observe all documentation supplied with the product
3 Unpacking
3.1 Scope of delivery
Object Description Quantity
A Inverter 1 piece
B Wall mounting bracket 1 piece
C Wall anchors and hexagon bolts (3×)
M5 screw (2×) 1 set
D DC connector 3 pairs
E AC Plug connector 1 piece
F WiFi stick 1 piece
G RS 485 COM plug 2 pieces
H Documentation 1 set
I Smart meter terminal 1 piece
A B C D E
F G H I
Carefully check all components. If anything is missing, contact your dealer.

UM0012_ASW 5-10k Series_EN_V03_0522 11
3.2 Checking for transport damage
Thoroughly inspect the packaging upon delivery. If you detect any damage to
the packaging which indicates the inverter may have been damaged, inform
the responsible shipping company immediately. We will be glad to assist you if
required.
4 Mounting
4.1 Ambient conditions
1. Be sure the inverter is installed out of the reach of children.
2. Mount the inverter in areas where it cannot be touched inadvertently.
3. Ensure good access to the inverter for installation and possible service.
4. Make sure that heat can dissipate, observe the following minimum
clearance to walls, other inverters, or objects:
5. The ambient temperature is recommended below 40°C to ensure optimal
operation.
6. Recommend to mount the inverter under the shaded site of the building or
mount an awning above the inverter.
7. Avoid exposing the inverter to direct sunlight, rain and snow to ensure
optimal operation and extend service life.
Direction Min. clearance
（mm）
above 500
below 500
sides 300

12 UM0012_ASW 5-10k Series_EN_V03_0522
8. The mounting method, location and surface must be suitable for the
inverter's weight and dimensions.
9. If mounted in a residential area, we recommend mounting the inverter on
a solid surface. Plasterboard and similar materials are not recommended
due to audible vibrations when in use.
10. Do not put any objects on the inverter.
11. Do not cover the inverter.
4.2 Selecting the mounting location
Danger to life due to fire or explosion
• Do not mount the inverter on flammable construction materials.
• Do not mount the inverter in areas where flammable materials are
stored.
• Do not mount the inverter in areas where there is a risk of explosion.

UM0012_ASW 5-10k Series_EN_V03_0522 13
1. Mount the inverter vertically or tilted backward by a maximum of 15°.
2. Never mount the inverter tilted forward or sideways.
3. Never mount the inverter horizontally.
4. Mount the inverter at eye level to make it easy to operate and to read the
display.
5. The electrical connection area must point downwards.
4.3 Mounting the inverter with the wall bracket
Mounting procedures:
1. Use the wall bracket as a drilling template and mark the positions of the drill
holes. Drill 2 holes with a 10 mm drill. The holes must be about 70 mm
deep. Keep the drill vertical to the wall, and hold the drill steady to avoid
tilted holes.
Risk of injury due to the weight of the inverter
•When mounting, be careful that the inverter weighs approx.:18.5kg.
7.5kg.

14 UM0012_ASW 5-10k Series_EN_V03_0522
2. After drilling holes in the wall, place three screw anchors into the holes, then
attach the wall mounting bracket to the wall using the self-tapping screws
delivered with the inverter.
3. Position and hang the inverter onto the wall bracket ensuring the two studs
located on the outer ribs of the inverter are slotted into the respective slots
in the wall bracket.
Risk of injury due to the inverter falls down
•Before inserting the wall anchors, measure the depth and distance of the
holes.
•If the measured values do not meet the hole requirements, redrill holes.

UM0012_ASW 5-10k Series_EN_V03_0522 15
4. Check both sides of the heat sink to ensure that it is securely in place. insert
one screw M5x12 each into the lower screw hole on both sides of the
inverter anchorage bracket respectively and tighten them.
If a second protective conductor is required in installation site, ground the
inverter and secure it so that it cannot drop from the housing (see section
5.4.3 “Second protective grounding connection”).
Dismante the inverter in reverse order.

16 UM0012_ASW 5-10k Series_EN_V03_0522
5 Electrical Connection
5.1 Safety
Danger to life due to high voltages of the PV array
When exposed to sunlight, the PV array generates dangerous DC voltage
which is present in the DC conductors and the live components of the
inverter. Touching the DC conductors or the live components can lead to
lethal electric shocks. If you disconnect the DC connectors from the
inverter under load, an electric arc may occur leading to electric shock
and burns.
• Do not touch non-insulated cable ends.
• Do not touch the DC conductors.
• Do not touch any live components of the inverter.
• Have the inverter mounted, installed and commissioned only by qualified
persons with the appropriate skills.
• If an error occurs, have it rectified by qualified persons only.
• Prior to performing any work on the inverter, disconnect it from all
voltage sources as described in this document(see Section 9
"Disconnecting the Inverter from Voltage Sources").
Risk of injury due to electric shock
• The inverter must be installed only by trained and authorized electricians.
• All electrical installations must be done in accordance with the National
Wiring Rules standards and all locally applicable standards and
directives.

UM0012_ASW 5-10k Series_EN_V03_0522 17
5.2 System layout of units without integrated DC switch
Local standards or codes may require that PV systems are fitted with an
external DC switch on the DC side. The DC switch must be able to safely
disconnect the open-circuit voltage of the PV array plus a safety reserve of
20%.
Install a DC switch to each PV string to isolate the DC side of the inverter. We
recommend the following electrical connection:
Damage to the inverter due to electrostatic discharge
Touching electronic components can cause damage to or destroy the
inverter through electrostatic discharge.
• Ground yourself before touching any component.

18 UM0012_ASW 5-10k Series_EN_V03_0522
5.3 Overview of the connection area
A B C D E F G
Objec Description
A DC SWITCH: switch on or off for PV-load.
B DC input: plug-in connector to connect the strings.
C COM: Network port with protective cap.
D Connector for meter.
E WiFi: transmit and Wi-Fi signal.
F Connection point for an additional grounding.
G AC OUTPUT: plug-in connector, connect the grid.
5.4 AC connection
Danger to life due to high voltages in the inverter
• Before establishing the electrical connection, ensure that the miniature
circuit-breaker is switched off and cannot be reactivated.

UM0012_ASW 5-10k Series_EN_V03_0522 19
5.4.1 PE connection
Procedure:
1. Insert the grounding conductor into the suitable terminal lug and crimp the
contact.
2. Align the terminal lug with the grounding conductor on the screw.
3. Tighten it firmly into the housing (screwdriver type: PH2, torque: 2.5 Nm).
Information on grounding components:
Object Description
M5 screw Screwdriver type: PH2, torque: 3Nm
Bootlace ferrule Customer provided, type: M5
Grounding cable Copper conductor cross-section: >=16mm
2
In case of operation on a Delta-IT Grid type, in order to ensure safety
compliance in accordance with IEC 62109, the following step should be
taken:
The second protective earth/ground conductor, with a diameter of at least
10 mm
2
and be made from copper , should be connected to the designated
earth point on the inverter.
