Solplanet ASW3K-LT-2 Pro User manual

ASW LT-G2 Pro Series
Three phase inverters 3 to 6 kW
Models:
ASW3K-LT-G2 Pro
ASW4K-LT-G2 Pro
ASW5K-LT-G2 Pro
ASW6K-LT-G2 Pro
Easy-to-install Reliable User-friendly
• Toolless DC connection via Phoenix
Contact connectors
• Quick setup and commissioning
with AiSWEI apps
• Compact wall mount design
• International quality standards
• 150 % PV array oversizing for higher
yields
• IP66 rated design for outdoor use
• User friendly app interface
• 16 A input current, ideal for bifacial
and large area PV modules
• Wide MPP voltage range
150V-1000V
Erneuerbare Energie

Technical Datasheet
ASW 3K-LT-G2 Pro ASW 4K-LT-G2 Pro ASW 5K-LT-G2 Pro ASW 6K-LT-G2 Pro
Input (DC)
Max. PV array power 4500 Wp STC 6000 Wp STC 7500 Wp STC 9000 Wp STC
Max. input voltage 1100 V
MPP voltage range / rated input voltage 150 V to 1000 V / 630 V
Min. input voltage 125 V
Initial. feed-in voltage 180 V
Max. operating input current 16 A / 16 A
Max. short circuit current 25 A / 25 A
No. of independent MPPT inputs / strings per MPPT input 2 / A :1 ; B : 1
Output (AC)
Rated power 3000 W 4000 W 5000 W 6000 W
Max. apparent AC power 3000 VA
3&4
3680 VA
3&4
4000 VA
3&4
5000 VA
3&4
AC nominal voltage
220 V / 380 V
230 V / 400 V
240 V / 415 V
AC voltage range 160 V to 300 V
AC grid frequency / range 50 Hz / 45 Hz to 55 Hz
60 Hz / 55 Hz to 65 Hz
Max. output current 4.8 A 6.4 A 8.0 A 9.6 A
Adjustable power factor range 0.8 leading to 0.8 lagging
Feed-in phases 3 / 3-N-PE
Harmonic distortion (THD) at rated output < 3 %
& Protection
98.3 % / 97.9 %
DC Switch 
Ground fault monitoring / grid monitoring / 
DC reverse polarity protection / AC short circuit protection / 
All-pole-sensitive residual-current monitoring unit 
Protection class (according to IEC 62109-1) /
overvoltage category (according to IEC 62109-1) I / AC : III ; DC : II
General data
Dimensions (W / H / D) 503 / 435 / 183 mm
Weight < 15 kg
Operating temperature range -25°C … +60°C
Self-consumption (at night) < 1 W
Topology Transformerless
Cooling concept Natural Convection
Degree of protection (according to IEC 60529) IP66
Climatic category (according to IEC 60721-3-4) 4K4H
Max. permissible value for relative humidity (non-condensing) 1
Max. operating altitude 3000 m
Features
DC connection Phoenix Contact
AC connection Plug-in connector
Mounting type Wall-mount bracket
LED indicators (Status / Fault / Communication) 
Communication interface
1&2
Wi-Fi / 4G / RS485 (Optional)
CE, EN50549, G98/99, VDE-AR-N4105, AS/NZS 4777, C10/C11, VFR 2014 & UTE C15,
IEC62109, IEC62116, IEC61727, IEC61683, IEC60068, IEC61000, NB/T 32004
Standard features / optional features / – not available
1- Zero export installations supported with 2-pin RS485 for connection to approved smart meters
2- DRED supported with RS485 communication for Australia & New Zealand
3- The overload setting is disabled as default for AS/NZS4777 grid codes
4- For European and AS/NZS4777 grid codes the max. apparent AC power is equal to the rated power
Version: March 2022

Quick Guide
Solplanet App
This document describes the activities related to the creation of a PV plant, set-up and commissioning of a Solplanet
inverter and connecting the Solplanet inverter to a WiFi network.
The contents of this quick guide apply to the following models:
•ASWx000S-S
•ASWx000-S
•ASWx000-T
•ASWxxK-LT
•ASWxxK-LT-G2
•ASW TLCx000
The firmware of the Solplanet WiFi stick should be 19B01-0021R or greater. Please contact the Solplanet service team in
your region if in doubt.
•Solplanet inverter with a WiFi stick
•WiFi stick with firmware greater than 19B01-0021R
•iOS or Android based mobile device
•Solplanet app
Please ensure the following has been completed before using this quick guide:
•A Solplanet inverter installed as per the Solplanet guidelines
•A Solplanet WiFi stick has been connected to the inverter
•The inverter has been connected to a string of solar panels of the appropriate voltage or to a DC power source
•The inverter DC switch is in the “ON” position
•Ensure the WiFi stick´s green LED is solid ON and the blue LED is OFF
If the blue LED is solid ON before your first attempt to begin, the WiFi stick may have already connected to a WiFi network.
Please contact the Solplanet service team in your region if this is the case.
There are two LED indicators on the WiFi stick, the state of each LED indicator is defined in the table below:
Solid OFF
Solid ON
Blinking
Green LED
•WiFi stick is OFF
•WiFi stick is ON
•NA
Blue LED
•Not connected to WiFi
•ASW-XXXX access point is
ON
•Connected to WiFi
•ASW-XXXX access point
is OFF
•Connected to WiFi
•ASW-XXXX access point is OFF
•Data cannot be sent to server
To download the Solplanet app, please scan the appropriate QR code below.
Android
iOS
An account can be created in the following ways:
•Tapping on “Do not have an account?” on the login screen of the app, selecting the appropriate user type and
following the prompts
•Registration is possible using either an email or a registered cellular phone number
•Log into the App after the account has been registered.
1. Tap “+”
2. Tap “Create or modify a plant”
3. Scan WiFi stick QR code or manually
enter the serial number and the
registration code
4. Tap “Create new plant”
5. Enter PV plant information in all
fields marked with a red asterix and
tap “Create”
6. Optional: turn on the App location
services
7. Tap “Add dongle to this plant”
1.About this Document
2.Items Required
1
2
3
3. Before Using the App
4. WiFi Stick LED Indicators
5.App Download
6. Account Registration
7. Create PV Plant

8. Tap ”Add to plant”
9. Tap the inverter serial number that
matches your inverter – TIP: tape
“Scan inverter” if the inverter is
displayed as “Unknown”
10. Tap “Grid” code settings”
11. Tap “Grid code settings”
12. Select the correct grid code and tap
“Save”
13. Tap return arrow three times to return
to inverter list
14. Tap “Next step”
15. To set up export power limitation or
consumption monitoring tap “Yes”
otherwise tap “Skip” and proceed to
step 21
16. Select meter type
17. Enable energy meter
18. Enable export power control
19. Enter “Export Power Limit Setpoint” in
watts (W)
20. Tap “Save”
21. Tap “Next step”
22. Tap “Continue”
23. Select WiFi network from list
24. Enter WiFi password and tape “continue”
25. Follow the prompts on the page to
confirm whether the dongle is
configured with a network. If the
BLUE LED is SOLID ON, click
"Continue". Otherwise, go back to
the previous step.
26. Setup is now completed, tap
“End process” and the PV plant
will now be shown on the PV
plant list.
If you have any technical problems with our products, please contact our service.
Provide the following information to assist in providing you with the necessary
assistance:
•Inverter device type
•Inverter serial number
•Type and number of connected PV modules
•Error code
•Mounting location
•Warranty card
•Mobile device type
SOLPLANET INTERNATIONAL
[email protected]
SOLPLANET AUSTRALIA
Service: [phone]
[email protected]
SOLPLANET BRAZIL
Support: [phone]
SOLPLANET GERMANY
Service: [phone]
[email protected]
SOLPLANET HUNGARY
Service: [phone]
[email protected]
SOLPLANET KOREA
Service: [phone]
[email protected]
SOLPLANET POLAND
Service: [phone]
[email protected]
SOLPLANET SOUTH AFRICA
[email protected]
SOLPLANET SPAIN
Service: [phone] (EN)
[email protected]
SOLPLANET SWEDEN
Service: [phone] (EN)
[email protected]
SOLPLANET THE NETHERLANDS
Service: [phone] (EN)
[email protected]
SOLPLANET TURKEY
Service: [phone]
[e-mail]
AISWEI GREATER CHINA
Service: [phone]
[e-mail]
5
9. Contact
6
8. Inverter Set-up
4
7

Erneuerbare Energie

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 1
ASW LT-G2-Pro series inverter Table of Contents
1 Notes on this Manual...................................................................... 4
1.1 General Notes ........................................................................................ 4
1.2 Area of Validity ...................................................................................... 4
1.3 Target group .......................................................................................... 5
1.4 Symbols used in this manual............................................................... 5
2 Safety .............................................................................................. 7
2.1 Intended use .......................................................................................... 7
2.2 Important safety information................................................................ 8
2.3 Symbols on the label............................................................................. 9
3 Unpacking..................................................................................... 11
3.1 Scope of delivery................................................................................. 11
3.2 Check for transport damage............................................................... 12
4 Mounting....................................................................................... 13
4.1 Requirements for mounting ............................................................... 13
4.2 Mounting the inverter.......................................................................... 17
5 Electrical connection.................................................................... 20
5.1 Safety.................................................................................................... 20
5.2 Electrical Connection Panel............................................................... 21
5.3 Electrical connection diagram with a separate DC isolator............ 22
5.4 AC Connection..................................................................................... 22
5.4.1 Conditions for the AC connection.............................................. 22

2 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
5.4.2 Grid connection............................................................................ 25
5.4.3 Additional grounding connection............................................... 27
5.5 DC connection ..................................................................................... 28
5.5.1 Requirements for the DC connetion........................................... 28
5.5.2 Assembling the DC connectors.................................................. 29
5.5.3 Disassembling the DC connectors............................................. 30
5.5.4 Connecting the PV Array............................................................. 32
5.6 Conmunication equipment connection............................................. 34
5.6.1 Mounting the WiFi or 4G Stick.................................................... 34
5.6.2 Connect the RS485 network cable ............................................. 35
5.6.3 Connect the smart meter cable................................................... 37
6 Communication ............................................................................ 38
6.1 System monitoring via WLAN............................................................ 38
6.2 Active power control with Smart meter............................................. 39
6.3 Remote firmware update..................................................................... 40
6.4 Active power control via demand response enabling device (DRED)
..................................................................................................................... 40
6.5 Communication with the third party device...................................... 41
6.6 Earth fault alarm .................................................................................. 41
7 Commissioning............................................................................. 42
7.1 Electrical check ................................................................................... 42
7.2 Mechanical check................................................................................ 43
7.3 Safety code check ............................................................................... 44
7.4 Start-up................................................................................................. 44

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 3
8 Display .......................................................................................... 46
8.1 Overview of the control panel............................................................ 46
8.2 LED indicators ..................................................................................... 46
9 Disconnecting the inverter from voltage sources...................... 48
10 Technical data............................................................................. 50
10.1 DC input data ..................................................................................... 50
10.2 AC output data................................................................................... 53
10.3 General data....................................................................................... 57
10.4 Safety regulations ............................................................................. 57
10.5 Tools and torque ............................................................................... 59
11 Troubleshooting......................................................................... 61
12 Maintenance................................................................................ 64
12.1 Cleaning the contacts of the DC-switch.......................................... 64
12.2 Cleaning the heat sink ...................................................................... 64
13 Recycling and disposal.............................................................. 65
14 EU Declaration of Conformity.................................................... 65
15 Warranty...................................................................................... 66
16 Contact........................................................................................ 66

4 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
1 Notes on this Manual
1.1 General Notes
ASW LT-G2-Pro series inverter is a three-phase transformerless string
inverter with two independent MPPTs. It converts the direct current (DC)
generated by the photovoltaic (PV) module into a three-phase alternating
current (AC) and feeds it into the utility grid.
1.2 Area of Validity
This manual describes the mounting, installation, commissioning and
maintenance of the following inverters:
ASW3K-LT-G2-Pro
ASW4K-LT-G2-Pro
ASW5K-LT-G2-Pro
ASW6K-LT-G2-Pro
ASW8K-LT-G2-Pro
ASW10K-LT-G2-Pro
ASW12K-LT-G2-Pro
ASW13K-LT-G2-Pro
ASW15K-LT-G2-Pro
ASW17K-LT-G2-Pro
ASW20K-LT-G2-Pro
Please read this manual carefully before using this product, keep it in a
convenient place and make it available at all times.

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 5
1.3 Target group
This document is for qualified electricians only, who must perform the tasks
exactly as described.
All persons installing inverters must be trained and experienced in general
safety which must be observed when working on electrical equipment.
Installation personnel should also be familiar with local requirements, rules
and regulations.
Qualified persons must have the following skills:
• Knowledge of how an inverter works and is operated
• Training in how to deal with the dangers and risks associated with installing,
repairing and using electrical devices and installations
• Training in the installation and commissioning of electrical devices and
installations
• Knowledge of the applicable laws, standards and directives
• Knowledge of and compliance with this document and all safety information.
1.4 Symbols used in this manual
Safety instructions will be highlighted with the following symbols:
DANGER indicates a hazardous situation which, if not be avoided, will
result in death or serious injury.
WARNING indicates a hazardous situation which, if not be avoided, can
result in death or serious injury.

6 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
CAUTION indicates a hazardous situation which, if not be avoided, can
result in minor or moderate injury.
NOTICE indicates a situation which, if not be avoided, can result in
property damage.
INFORMATION that is important for a specific topic or goal, but is not
safety-relevant.

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 7
2 Safety
2.1 Intended use
1. ASW LT-G2-Pro series inverter converts the direct current from the PV
arrays into grid-compliant alternating current.
2. ASW LT-G2-Pro series inverter is suitable for indoor and outdoor use.
3. ASW LT-G2-Pro series inverter must only be operated with PV arrays (PV
modules and cabling) of protection class II in accordance with IEC 61730,
application class A. Do not connect any sources of energy other than PV
modules to ASW LT-G2-Pro series inverter.
4. PV modules with a high capacity to ground must only be used if their
coupling capacity does not exceed 5.0μF.
5. When the PV modules are exposed to light, a DC voltage is supplied to this
inverter.
6. When designing the PV power plants, ensure that the values comply with
the permitted operating range of all components at all time.
7. The product must only be used in countries for which it is approved or
released by AISWEI and the grid operator.
8. Use this product only in accordance with the information provided in this
documentation and with the locally applicable standards and directives. Any
other application may cause personal injury or property damage.
9. The type label must remain permanently attached to the product.

8 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
2.2 Important safety information
Danger to life due to electric shock when live components or
cables are touched
• All work on the inverter must only be carried out by qualified
personnel who have read and fully understood all safety
information contained in this manual.
• Do not open the inverter.
• Children must be supervised to ensure that they do not play
with the inverter.
Danger to life due to high voltages of the PV array
When exposed to sunlight, the PV array generates dangerous
DC voltage which is present in the DC conductors and the live
components of the inverter. Touching the DC conductors or
the live components can lead to lethal electric shocks. If you
disconnect the DC connectors from the inverter under load,
an electric arc may occur leading to electric shock and burns.
• Do not touch non-insulated cable ends.
• Do not touch the DC conductors.
• Do not touch any live components of the inverter.
• Have the inverter mounted, installed and commissioned only
by qualified persons with the appropriate skills.
•If an error occurs, have it rectified by qualified persons only.
•Prior to performing any work on the inverter, disconnect it
from all voltage sources as described in this document (see
Section 9 "Disconnecting the Inverter from Voltage Sources").

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 9
2.3 Symbols on the label
Symbol
Explanation
Beware of a danger zone
This symbol indicates that the inverter must be additionally
grounded if additional grounding or equipotential bonding is
required at the installation site.
Risk of injury due to electric shock
Touching an ungrounded PV module or array frame can
cause a lethal electric shock.
• connect and ground the PV modules, array frame and
electrically conductive surfaces so that there is continuous
conduction.
Risk of burns due to hot enclosure parts
Some parts of the enclosure can get hot during operation.
• During operation, do not touch any parts other than the
enclosure lid of the inverter.
Damage to the inverter due to electrostatic discharge
Internal components of the inverter can be irreparably
damaged by electrostatic discharge.
• Ground yourself before touching any component.

10 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
Beware of high voltage and operating current
The inverter operates at high voltage and current. Work on the
inverter must only be carried out by skilled and authorized
electricians.
Beware of hot surfaces
The inverter can get hot during operation. Avoid contact during
operation.
WEEE designation
Do not dispose of the inverter together with the household
waste but in accordance with the disposal regulations for
electronic waste applicable at the installation site.
CE marking
The product complies with the requirements of the applicable
EU directives.
Certification mark
The product has been tested by TUV and got the quality
certification mark.
RCM Mark
The product complies with the requirements of the applicable
Australian standards.
Capacitors discharge
Before opening the covers, the inverter must be disconnected
from the grid and PV array. Wait at least 5 minutes to allow the
energy storage capacitors to fully discharge.
Observe the documentation
Observe all documentation supplied with the product

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 11
3 Unpacking
3.1 Scope of delivery
Obje
ct
Description
Quantity
A
Inverter
1 piece
B
Wall bracket
1 piece
C
DC connector
2 pairs(3-10K), 3 pairs(12-
15K), 4 pairs(17-20K)
D
AC connector
1 piece
E
Documentation
1 piece
F
Screw accessory
1 piece
G
4G/ WiFi Stick
1 piece
H
Communication Cover
2 pieces
Please carefully check all the components in the carton. If anything is missing,
contact your dealer at once.

12 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
3.2 Check for transport damage
Thoroughly inspect the packaging upon delivery. If you detect any damage to
the packaging which indicates the inverter may have been damaged, inform
the responsible shipping company immediately. We will be glad to assist you if
required.

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 13
4 Mounting
4.1 Requirements for mounting
1. Be sure that the inverter is mounted out of the reach of children.
2. Mount the inverter in areas where it cannot be touched inadvertently.
3. Ensure good access to the inverter for installation and possible service.
4. The ambient temperature should be below 40°C to ensure optimal
operation.
5. Observe the minimum clearances to walls, other inverters, or objects as
follows to ensure sufficient heat dissipation.
Danger to life due to fire or explosion
Despite careful construction, electrical devices can cause fires.
• Do not mount the inverter on flammable construction materials.
• Do not mount the inverter in areas where flammable materials are
stored.
•Do not mount the inverter in areas where there is a risk of explosion.

14 User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622
Clearances for one inverter
Clearances for multiple inverters
6. In order to avoid power reduction caused by overheating, do not mount
the inverter in a location that allows long-term exposure to direct sunlight.
7. Ensure optimum operation and extend service life, avoid exposing the
inverter to direct sunlight, rain and snow.
Direction
Min. clearance (mm)
above
500
below
500
sides
300

User Manual UM0014_ASW 3K-20K-LT-G2 PRO_EN_V02_0622 15
8. The mounting method, location and surface must be suitable for the
inverter's weight and dimensions.
9. If mounted in a residential area, we recommend mounting the inverter on
a solid surface. Plasterboard and similar materials are not recommended
due to audible vibrations when in use.
10.Don’t put any objects on the inverter. Do not cover the inverter.
11.Mount the inverter vertically or tilted backward by max.15°.
