Sony VCT-1170RM User manual

VCT-1170RM
AEP Model
REMOTE CONTROL TRIPOD
SPECIFICATIONS
Ver 1.1 2004 04
SERVICE MANUAL

VCT-1170RM
— 2 —
Sony EMCS Co. 2004D1600-1
©2004.4
Published by DI Technical Support Section
9-929-812-11
1 3-063-115-01 STRAP
2 3-972-177-01 KNOB, BALL LEVELLER FIXED
*3 3-972-267-01 HEAD, MAIN ASSY
4 3-061-693-01 SCREW, SHAFT FIXED
5 X-3950-700-1 LOCK ASSY, PAN HANDLE
6 A-7096-167-A REMOTE CONTROL ASSY, PAN HANDLE
7 3-972-173-01 SHOE, QUICK
8 3-972-174-01 TABLE (ASSY), CAMERA (WITH FIXED LEVER,
HEXAGON SOCKET BOLT)
9 3-972-175-01 SCREW, TILT FIXED
10 3-972-176-01 SCREW, PAN FIXED
11 3-972-179-01 LEG
12 7-683-457-04 BOLT, HEXAGON SOCKET 6X20
13 7-688-006-02 W6, SMALL
14 3-972-178-01 RETAINER
Ref. No. Part No. Description Ref. No. Part No. Description
15 3-972-181-01 SCREW, STAY FIXED
16 3-972-180-01 STAY
17 3-972-182-01 RUBBER, FERRULE (WITH E WASHER 6)
18 3-062-983-01 RING, TRANSPORT
ACCESSORIES
************
3-061-695-12 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH,KOREAN)
3-061-695-21 MANUAL, INSTRUCTION (GERMAN, DUTCH,
SWEDISH, ITALIAN)
3-061-695-31 MANUAL, INSTRUCTION (PORTUGUESE,
RUSSIAN, ARABIC, TRADITIONAL CHINESE)
3-972-167-01 BAG, TRIPOD
NOTE :
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
EXPLODED VIEWS
• The mechanical parts with no reference
number in the exploded views are not
supplied.
z A
z B
z B
z B
4
5
17
not
supplied
17
17
18
1
2
3
67
8
14
12 12
12
12
12
13
12
15
15
11
(Including z A)
11
(Including z A)
16
(Including
z B)
15
13
13
13
13
13
10
9
z A
z A
z A
11
(Including z A)

Sony EMCS Co.
SERVICE MANUAL
2004D1600-1
©2004.4
Published by DI Technical Support Section
9-929-812-82
SUPPLEMENT-1
File this supplement-1 with the Service Manual.
(PV04-001)
VCT-1170RM
Ver 1.1 2004. 04
VCT-1170RM
AEP Model
• Addition of service part
: Added portion : Changed portion
Page Before change After change
2
Ref. No. Part No. Description
19 1-696-933-81 CORD, CONNECTION
Ref. No. Part No. Description
4
5
3
67
10
9
4
5
3
6
19
7
10
9

Revision History
992981212.pdf
Reverse
Ver.
1.0
1.1
Date
2000.04
2004.04
History
Official Release
Supplement-1
Contents
—
Addition of service part
S.M. Rev.
issued
—
No
