Specifications
ECM-CG50BP Recording Characteristics
Polar Pattern Sound Chart Frequency Response Sound Chart
-55
-60
-65
-50
-45
-40
-35
-30
10 100 1000
Normal mode
10000 100000
level (dB)
frequency (Hz)
Low Cut mode
ECM-CG50BP
Mode Monaural
Capsule type Electret condenser
Directivity Super-cardioid
Power supply Approx. 900 hours with one alkaline AA battery or plug-in power
from audio jack of compatible camcorder
Frequency response 40 Hz ~ 20 kHz
Sensitivity (at 1 kHz) -48 dB/Pa±4 dB
*Specially tuned to be used with the camcorders AGC function
Dynamic range 80 dB or more
Signal-to-noise ratio 76 dB or more
Inherent noise 18 dBspl (Average)
Maximum input sound
pressure level
100 dBspl or more
Power requirements Approx. 0.5 mW
Dimensions Approx. 27/32 in × 10 3/8 in. (21 mm x 261 mm)
(excluding cord)
Weight Approx. 3 oz. (85 g) (excluding battery)
Output jack 3.5 gold coating L type stereo mini plug cable length
Approx. 13 7/8 in. (35 cm)
Operating temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage temperature -4 °F to +140 °F (-20 °C to +60 °C)
Supplied Accessories Shotgun microphone (1), Wind screen (1), Microphone holder (1),
Microphone spacer(1), Set of printed documentation
*Design and specifications are subject to change without notice.
