Toshiba RBC-AX31U-UL User manual

TOSH|BA
Carrier
REMOTE CONTROLLER FOR AIR CONDITIONER (SPLIT TYPE)
Owner's Manual
Remote Controller
Model name:
Wireless remote controller kit
RBC-AX31U(W)-UL
Wireless remote controller
Generic model name and signal receiving unit
RBC-AX31U(W)-UL WX-TA01UES
(Wireless remote controller
model name)
Wireless remote controller
(WX-TA01 UES)
i:%'_oO
D o*
Signal receiving
unit
Owner's Manual
Remote controller for air
conditioner (Split type) 1
Manuel du proprietaire
Telecommande pour climatiseur
(Type split) 17

Wirelessremotecontrollerkit Owner'sManual
Thank you very much for purchasing TOSHIBA/Carrier Remote controller for Air
Conditioner.
Please read this owner's manual carefully before using your Remote controller for Air
Conditioner
• Be sure to obtain the "Owner's manual" and "Installation manual" from constructor (or
dealer).
Request to constructor or dealer
• Please clearly explain the contents of the Owner's manual and hand over it.
Contents
1 PRECAUTIONS FOR SAFETY ........................... 2
2 PART NAMES AND FUNCTIONS ......................... 3
3 CORRECT USAGE .................................... 7
4 TIMER OPERATION .................................... 9
5 HOW TO ADJUST AIR DIRECTION ...................... 10
6 SLIDE SWITCH ...................................... 11
7 HOW TO INSERT BATTERIES .......................... 11
8 HOW TO HANDLE THE REMOTE CONTROLLER ........... 12
9 HOW TO USE THE REMOTE CONTROLLER CORRECTLY... 13
10 ADDRESS .......................................... 14
11 HOW TO PERFORM EMERGENCY OPERATION ........... 15
12 BEFORE ASKING FOR REPAIR WORK .................. 16
-1-

Wireless remote controller kit Owner's Manual
1PRECAUTIONS FOR SAFETY
WARNING
WARNINGS ABOUT INSTALLATION
•Make sure to ask the qualified installation professional in electric work to install the
remote controller.
If the remote controller is inappropriate installed by yourself, it may cause electric shock
or fire, etc.
• Make sure to install the air conditioner specified by TOSHIBA/Carrier and ask the
exclusive dealer when installing. Ifthe air conditioner is installed by yourself, it may cause
electric shock or fire, etc.
WARNINGS ABOUT OPERATION
• Prevent any liquid from falling into the remote controller.
Do not spill juice, water or any kind of liquid.
It may cause malfunction, electric shock or fire, etc.
• When you are aware of any error with the air conditioner (smells like something burning,
etc.), immediately turn off the circuit breaker to stop the air conditioner, and make contact
with the dealer.
If the air conditioner is continuously operated with an error, it may cause malfunction,
electric shock or fire, etc.
WARNINGS ABOUT MOVEMENT AND REPAIR
• Do not repair any unit by yourself.
Whenever the air conditioner needs repair, make sure to ask the dealer to do it.
If it is repaired imperfectly, it may cause electric shock or fire, etc.
• When reinstalling the air conditioner, contact with the dealer.
If the installation is insufficient, it may cause electric shock or fire, etc.
Z_ CAUTION
CAUTIONS ABOUT INSTALLATION
• Do not install the remote controller in a place where its signals do not reach the indoor unit.
• Do not install the remote controller in the place under the direct sunlight and close to any
heat source. It may cause malfunction.
• The fluorescent lamp with rapid start system or inverter system may disturb the signal
reception. For details, contact with the dealer of the air conditioner you have purchased.
CAUTIONS ABOUT OPERATION
• Do not drop or apply strong shock to the air conditioner.
It may cause malfunction of the remote controller.
• Use batteries that meet the specifications.
- 2 - 2-EN

Wirelessremotecontrollerkit Owner'sManual
2PART NAMES AND FUNCTIONS
•Remote Controller (WX-TA01UES)
•Up to 8 indoor units in a group can be controlled by one remote controller. (See page 14)
Illustration of LCD shown below is for explanation.6
1 ,__-__ 11 7
I! _'U_OFI I 9
II _1 ........I.......
13 lO
4 11
17 12
7!--18
813
1Transmitting unit 15
2ON/OFF button
Starts and stops the air conditioner
alternately. 16
3Mode button 17
Selects desired operation mode.
4Fan speed button
5Timer set button
Used to setup the timer. (See page 9)
It may differ from the actual LCD.
Filter button
No function
ACL button
Used after batteries are replacedor the slide
switch is switched. (See page 11)
Slide switch (See page 11)
Battery compartment (See page 11)
Cover
Slide the cover downward holding its both
sides.
Remote controller sensor
Senses the ambient temperature when the
remote controller is selected with the sensor
button.
LCD
Displays the air conditioner operation mode.
(This illustration shows all display contents.)
AUTO louver display differs
according to the installed unit.
(See page 10)
Setup temperature button
Adjust the set point.
Set a desired set point by pushing _ @ or
@.
Swing/air direction button
(See page 10)
Address button (See page 14)
Ventilation button
Use this when a ventilation fan or other unit,
purchased on the market, has been
connected.
3-EN -3-

Wireless remote controller kit Owner's Manual
18 Sensor button
Selects the temperature sensor of the remote
controller.
The temperature sensor of the indoor unit is
selected by default. While the indoor unit
temperature sensor is selected, _ is
displayed on the display.
• Signal Receiving Unit
•The signal receiving unit is attached to the
indoor unit.
•Hereinafter, all remote controller button
names are indicated with respective
symbols displayed on the remote
controller.
Example: ON/OFF button _
[FIR [4
5
6
2
3
1Emergency operation button
(See page 15)
2Signal receiving unit
Receives signals from the remote controller.
3Display lamp
Any of these lamps flashes while an error
OCCUrs.
When an lamp flashes, see "BEFORE
ASKING FOR REPAIR WORK" on page 16.
4_ lamp
This lamp illuminates when unit is on.
5C) lamp
This lamp illuminates while the timer is
reserved.
6_lamp
• Illuminates in the heating mode at the
beginning of operation or during defrosting
or when the temperature controller is
activated.
• Flashes during an error state.
/_ CAUTION
Even if you push _, _ or _ when
remote controller operation is disabled
by the central control or other means, "pi"
isheard 5times and the button operation
is not accepted.
- 4 - 4-EN

Wireless remote controller kit Owner's Manual
• Display section
All indicators are shown in the right and the lower figures for the
explanation.
Only selected contents are display in actual operation. l isplay
section
Operation
section
1
2
4
3
1Transmitting indication
Displayedwhile operating the switches of the
remote controller.
2Operation mode
The selected operationmode isdisplayed.
3Fan speed display
The selectedfan speed is displayed.
(AUTO) X@
(HIGH) R_
(MED.) X{
(LOW)
4Ventilation display
This appears while the ventilation fan is
operating.
5Remote control sensor display
This appearswhen the remotecontrol sensor
is used.
6Set up temperature display
The selected set point is displayed.
7Louver position display
Displays louver position.
8Swing display
Displayed during up/down movement of the
louver.
9Timer display
Time of the timer is displayed.
10 Timer mode display
When pushing the Timer SET IN button, the
display of the timer is selected in order of
[OFF] _ --> C.'_ _ repeat OFF timer
-->[ON] _ -->No display.
5-EN -5-

Wireless remote controller kit Owner's Manual
•Operation section
Push each button to select a desired operation.
•The details of the operation needs to be set up once, afterward, the air conditioner can be
used by pushing L!Ponly.
3
4
1Mode button 6
Selects the desired operation mode.
2Fan speed button
Selects a fan speed.
3Timer set button
Used to setup the timer. (See page 9) 7
4ACL button
Use this button after battery exchange.
5Setup temperature button
Adjusts the set point.
Set the desired set point by pushing @ or @.
ON/OFF button
When the button is pushed, the operation
starts, and it stops by pushing the button
again.
When the operation has stopped, the
operation lamp and all the displays disappear.
Filter button
No function.
OPTION :
Remote controller sensor
Usually the temperature sensor of the indoor
unit senses the temperature.
The temperature on the surrounding of the
remote controller can also be sensed.
For details, contact the dealer from which
you have purchased the air conditioner.
- 6 - 6-EN

Wireless remote controller kit Owner's Manual
3CORRECT USAGE
• Auto ®, Heat -_, Dry 6,
Cool ®, Fan x
Power
Turn on the power supply switch 12 hours
before starting operation.
* The remote controller is disabled for approx.
1minute after the indoor unit has been
powered on. This is normal. (The signal from
the remotecontroller is received,but the
receive data is discarded.)
1Push I(_ (ON/OFF button).
2Push _ (Mode button) to select an
operation mode.
• Select Auto, Heat, Dry, Cool, or Fan.
3Push R (Fan speed button) to select
afan speed.
• When the Auto mode is selected, the fan
speed changes automatically. The fan
speed does not change automatically in
the Fan mode.
4Push either @or @to select the
desired temperature.
•Temperature setting is not available for the
Fan speed.
5Stop
Push d,D (ON/OFF button).
When the operation is stopped with the
remote controller, the outdoor unit fan keeps
running in some cases even after the
compressor of the outdoor unit has stopped.
• If the room is notwell heatedwith FAN
Bduring heating, change the fan
speed to FAN XJ_or FAN XJ.
Although selected fan speed is displayed,
some indoor unit types are not provided
with the air volume change function. (Fan
speed is constant.)
•If the unit operation cannot be stopped
in the usual manner, turn off the circuit
breaker and contact the dealer from
whom you purchased the air
conditioner,
•Automatic Cooling/Heating
When all indoor units in the same refrigerant
system are under the group control, heating
or cooling operation is automatically
performed according to the difference
between the setup temperature and the
room temperature.
7-EN - 7 -

Wireless remote controller kit Owner's Manual
•Dry operation
•Dry function may not be provided
depending on the using indoor unit, even
if Dry (0) is displayed on the LCD of the
remote controller. (The same to Cooling
operation)
• When the room temperature approaches
the setup temperature, it automatically
repeats running and stop operation.
• In order to not return humidity to the room
as possible, the mode of indoor fan
changes to LOW when the operation has
stopped.
• The fan speed may not be adjustable
depending on the indoor unit that you use
or the room temperature.
• The Dry mode may not be used
depending on the using indoor unit when
the outdoor temperature is 59 °F (15 °C)
or lower.
• Self cleaning
The self cleaning operation starts
automatically after running the cooling/dry
mode (10 minutes or more) to keep the
inside of the indoor unit clean.
(For details, refer to the Owner's Manual of
the indoor unit.)
To stop self cleaning forcibly, push dO twice
quickly.
- 8 - 8-EN

Wireless remote controller kit Owner's Manual
4TIMER OPERATION
•After the timer has been set, put the
remote controller at a position where
signals of the remote controller can reach
the signal receiving unit on the indoor unit.
The timer operation signal is transmitted
from the remote controller.
•Set the timer while an operation mode is
displayed as follows:
Use the timer in the following
cases
To stop the air conditioner OFF
when the preset time has timer
passed
To stop the air conditioner Repeat
each time when the OFF
preset time has passed timer
To operate the air
conditioner when the ON timer
preset time has passed
Mode
displayed
Timer period
The setup time increases by 0.5 hours
(30 minutes) each time you push [_3.
The maximum setup time is 72.0 hours.
The setup time decreases by 0.5 hours
(30 minutes) each time you push [2_.
The minimum setup time is 0.5 hours.
Timer display
Each time you push Timer [_3, the timer
display changes as follows:
_8OO F
No di_la
P Y"_-_
<Usage Examples>
• Setting OFF timer
(Example) To stop operation in 30 minutes
1Push Timer I-_-I.
andthe time flash on the display.
2Set the time to 0.5 with TIME [_ or
12El.
3Push _ and [_ go on timer.
•Setting repeat timer
(Example) To stop operation in every
2.5 hours
1Push Timer _twice.
_"_ _ and the time flash on the display.
2Set the time to 2.5 with TIME [_ or
12El.
3Push _ and _"_ i_ go on timer.
The OFF timer is activated and the operation
stops in 2.5 hours. When you push (I.L)again
to restartthe operation, it stops in 2.5 hours.
• Setting ON timer
(Example) To start operation in 8 hours
1Push Timer _three times.
andthe time flash on the display.
2Set the time to 8.0 with TIME [_ or
I-_q.
3Push _.
The operationmode disappears, and
andthe time stop flashing.
• Canceling timer operation
Push t_. The timer display disappears.
9-EN -9-

Wireless remote controller kit Owner's Manual
5HOW TO ADJUST AIR DIRECTION
•Never move the louver (air direction up/down adjusting plate) which is operated on the
remote controller with hands except a case of cleaning the louver.
• While the air conditioner is not working, the louver (air direction adjusting plate) is closed
automatically.
• During the preparation for heating, the louver isdirected upward and it starts swinging after
the preparation for heating is canceled though the automatic louver display on the remote
controller shows swinging even during this period.
To set air direction
Push _ during operation. Air direction
changes each time you push the button.
To start swinqing
Push _ to set the louver direction to the
lowest, and then push _ again. Louver
swinging appears on the display and air
direction automatically changes up and
down.
Heating mode
Keep the louver pointed downward so that
discharged hot air reaches the floor.
F
\•
" %r-._Initial setting
Cooling/dry mode
Keep the louver pointed upward. Otherwise,
dew drop may form around the discharge
port and drop from the unit.
.\ Initial setting
To stop swinging
Push _ once again while the louver is
swinging. The louver can be stopped at a
desired position. Then air direction can be
set again from the uppermost by pushing _.
*The louver does not stop while it is pointed
downward during coolingor drying. Even if you
attempt to stop the louverwith the louver
pointed downward during swinging, it stops at
the third position from the uppermostdirection.
Fan mode
••_
Initial setting
Swing mode
;4..._./Swing
Continuous
operation
Display when swinging is stopped
P F
Heating/fan mode Cooling/dry mode
This remote controller has no function to
set air direction individually or power-
saving operation or to change the swing
mode that are described in the Owner's
Manual of the indoor unit.
-10-

Wireless remote controller kit Owner's Manual
6SLIDE SWITCH
1Louver display switch
Louver display ofthe
remote controller
Slide switch position
The settings of operation mode display and air direction display vary as follows depending
on the indoor unit in use.
Use a fine-tipped tool to change the switch setting.
Push the ACL button after the switch setting is changed.
Do not change setting of the slide switch because a malfunction occurs by other settings.
SKN
* Set the slide switch to "S." Otherwise the air direction
adjustment and louver display are disabled.
2Operation mode switch
Operation mode display of
the remote controller
Slide switch position
View with the cover removed
12
ACL button
C_ZZZZZD
AHC
• Before using the air conditioner, check that the slide switch is set as shown in this table.
For details of slide switch setting, contact the dealer from whom you purchased the air
conditioner.
7HOW TO INSERT BATTERIES
1Slide and remove the cover downward while
holding both sides of the cover.
2Insert two AAA alkaline batteries correctly
matching the (+) and (-) polarities with the
indication.
3Push the ACL button with a fine-tipped tool and
attach the cover.
•Replace batteries when the display on the remote controller has
become dim or when signals from the remote controller cannot
be received atthe normal distance from the signal receiving unit.
Alkaline batteries should be replaced once a year.
• Replace two batteries at the same time with new ones of the
same type.
• When you do not use the remote controller for a long time,
take out the batteries.
• Discard exhausted batteries at a designated place.
ACL
button
Cover
-11-

Wireless remote controller kit Owner's Manual
8HOW TO HANDLE THE REMOTE
CONTROLLER
•Point the transmitting unit of the remote controller at the signal receiving unit of the indoor
unit. When a signal is received normally, "pi" sound is heard once. ("Pi, pi" is heard only at
the beginning of operation.)
•The standard signal receivable distance from the signal receiving unit of the indoor unit is
approx. 23' (7 m). The distance varies somewhat with the battery capacity or other
conditions.
• Do not put anything that blocks signals between the remote controller and the signal
receiving unit of the indoor unit.
• Do not put the remote controller at a place exposed to direct sunlight or air from the indoor
unit or near a heater.
• Do not drop or throw the remote controller or wipe it with water.
• Signals from the remote controller may not be accepted in a room equipped with a rapid
start-type or inverter-type fluorescent light. For details, contact the dealer from whom you
purchased the air conditioner.
• To set the Remote Controller on the Wall
•Push _ at the installation position on the wall to check that the signal from the remote
controller is received correctly.
• To take the remote controller out of the holder, pull it toward you.
Fix the remote controller
holder with screws.
Mounting screw
Truss tapping
J
f
Remote controller
holder
Setting the remote
controller into the holder
Put on.
@
Push
-12-

Wireless remote controller kit Owner's Manual
9HOW TO USE THE REMOTE CONTROLLER
CORRECTLY
•Put the remote controller within the specified distance from the signal receiving unit of the
indoor unit.
Failure to do so may result in malfunction.
Be sure to put the remote controller in a room where the indoor unit is installed.
•When pushing a button on the remote controller, point the remote controller at the signal
receiving unit of the indoor unit. When the signal receiving unit has correctly received a
signal, it emits a "pi" sound.
• Do not put the remote controller behind a curtain or the like.
-13-

Wireless remote controller kit Owner's Manual
10 ADDRESS
When two or more indoor units controlled by the same wireless remote controller are
installed in a room, a unique address can be set for each indoor unit to prevent
interference.
Up to 6 indoor units can be controlled independently by the remote controller by
matching the address switch setting of the signal receiving unit with the address
displayed on the remote controller. From the seventh indoor unit onwards, address
setting is necessary from wired remote controller. The signal receiving unit (inside the
ceiling panel) has address switches for receiving addresses, and the remote controller
has an address button for transmitting addresses.
For details, contact the dealer from whom you purchased the air conditioner.
•Checking Addresses
Push IZ_ on the remote controller. The current address appears on the display.
When this address equals the address of the address switch in the signal receiving unit
(inside the ceiling panel), the buzzer sounds. When the address on the display is "ALL," the
buzzer sounds and the remote controller is enabled regardless of the address switch setting
in the signal receiving unit.
Transmit signals while pointing the remote controller at the signal receiving unit of the indoor
unit to be controlled.
•Matching Addresses
Address setting on the remote controller
1. Push _ for at least 4 seconds. _ lights up on the display and the current address blinks.
2. Each time you push I_], addresses change cyclically like ALL -->1 -->2 -->3...--> 6 -->ALL. Select
an address that matches the address switch setting in the signal receiving unit of the indoor unit to
be controlled.
3. Push i_£f]. The blinking address changes to lighting and is displayed for 5 seconds. When this
address equals the address switch setting in the signal receiving unit, the buzzer sounds.
Address displayed on
the remote controller
(The location of _ is
shown on page 3.)
Address switch setting
in the signal receiving
unit (inside the ceiling
panel or indoor unit)
Remove the screw on
the back of the signal
receiving unit and
remove the cover.
Address
RL L
* Any setting is
OK.
Address I
@
4-6 1"-3K
32 ]
oJ 6 54 K
Address .....
2
4-6 1-3r<
3 2 ]
o6 54 K
Address S
4-6 1-3 K
3 2 1
ca6 54 r<
Set S001 to the right position (for addresses 1, 2, and 3) or to the left
position (for addresses 4, 5, and 6).
Set S002 to the right position (for addresses 1 and 4), to the center (for
addresses 2 and 5), or to the left position (for addresses 3 and 6).
-14-

Wireless remote controller kit Owner's Manual
11 HOW TO PERFORM EMERGENCY
OPERATION
In the event of an emergency shown below, push emergency operationeon the signal
receiving unit (inside the ceiling panel) for emergency operation.
•The batteries of the remote controller have been exhausted.
• The remote controller is out of order.
• The remote controller has been lost. %
i
1
-2
1Start
Push emergency operation.
(Whenthe emergency operationis started at aroom temperature of 75°F (24°C) or more, the air
conditioner enters the cooling mode. When the emergency operation isstarted at a room
temperature below 75°F (24°C),the air conditioner enters the heating mode.)
2stop
Push emergency operation once again.
z_ CAUTION
When the emergency operation does not work, confirm that all the bits of DIP switch
S003 on the P.C. board of the receiver unit are set OFF. If any of these bits are set ON,
turn them all OFF.
-15-

Wireless remote controller kit Owner's Manual
12 BEFORE ASKING FOR REPAIR WORK
Check the following before asking for repair work.
Check again
Phenomenon Possible cause Measures
Operation does The air conditioner is not working or a power failure Push ON/OFF on the remote controller
not start even if has occurred, again. (See page 7)
the switch is
turned on. The power switch is not turned on. Turn on the power switch if it is off.
(See page 7)
The air conditioner is in the ON timer operation. Cancel the timer operation.
(See page 9)
The batteries of the remote controller have been Replace the batteries.
exhausted. (See page 11)
The LEDs on the signal receiving unit are not in Change the operation mode.
normal state or operation mode is not correct. (See page 7)
Is not the sate of the display lamp "Disagreement of _8 (cool) and {_,_ Change the slide switch setting of the
(heat)" or "No -,_ "? remote controller. (See page 11 )
Dual swing, cycle swing, individual louver position, or power-saving This type of remote controller cannot set
cannot be set. such functions.
Contact the dealer from whom you purchased the air conditioner.
Phenomenon Possible cause
The LEDs flash. (_) (_ _ Communication error between signal receiving unit and indoor unit
or address setup error when the wired remote controller is used
\1/
DOc Q O
-,,I /Communication error between indoor unit and outdoor unit
® ® ->OC
\ I /-,, I /The protective device of the indoor unit is activated.
\ I /\ I /The protective device of the outdoor unit is activated.
\ I /\ I /Temperature sensor error
\ I /The compressor of the outdoor unit is protected.
® _Oq- ®
j ,1 o_,Ijo_ toTheoFFairconditionerispe.ormingatestrunSetthetestrunswitch
>']"\ /I"" /I\
\/, ,
LEDs on thesignalreceivingunit•: OFF >o_:Bhnklng(atintervalsof0.5seconds)
LED color (.I):Green C): Green _: Orange
Check theseitems.Ifanyoftheseproblemsstillremains,stoptheoperation,turnoffthepower,and
then notifiesthe dealer from whom you purchased the air conditioner of the model name and details
of the error (including LED flashing state). Never repair any unit by yourself as it is dangerous.
-16-

TOSHIBA CARRIER CORPORATION
23-17, TAKANAWA 3-CHOME, MINATOKU, TOKYO 108-0074, JAPAN
EH99677301
