“OPEN-R” is the standard interface for the entertainment robot
system that Sony is actively promoting. This interface expands the
capability of the entertainment robot through a flexible combination
of hardware and interchangeable software to suit various applications.
The “AIBO” ERS-210 series and “AIBO-ware” ERF-210AW06E
conform to OPEN-R version 1.1.3.
“AIBO,” the AIBO logo , “OPEN-R” and the OPEN-R logo are registered
trademarks of Sony Corporation.
“Memory Stick,” “ ” and “ ” are trademarks of Sony
Corporation.
In this manual, the “™” and “®” marks have been omitted.
Other information about AIBO is available on the Internet at the following site:
http://www.aibo.com/
Reproduction in whole or in part without written permission is prohibited. All
rights reserved.

7
First of all, check that you have
the following items.
AIBO-ware “Memory Stick” User’s Guide (this manual)
Quick Guide End-User License Agreement
Self-charge markers Markers for the AIBO Self-charging
(green marker, blue marker, Function (Operating Instructions)
front marker base, rear marker
base, pink ball)

8
Table of Contents
Getting Started
Welcome to “AIBO Recognition”! ............................................................. 12
Emotions and instincts of AIBO ..................................................... 13
Modes and conditions of AIBO .................................................................. 14
Preparations ................................................................................................ 16
Living with AIBO
ChargingAIBO’s battery pack ................................................................... 22
When you want to charge AIBO..................................................... 22
AIBO charges on its own (self-charge) .......................................... 24
If AIBO is not charged.................................................................... 31
Sleeping and waking up.............................................................................. 32
Communicating with AIBO
Teaching AIBO its new name ..................................................................... 34
Teaching AIBO to recognize you ............................................................... 36
From you to AIBO ...................................................................................... 39
Communicating by touch, visually and by voice............................ 39
Communicating for training AIBO ................................................. 40
HavingAIBO take a photo ......................................................................... 41

9
Additional Information
Notes on use ............................................................................................... 46
Troubleshooting .......................................................................................... 48
Reference Materials
Words apprehensible to AIBO .................................................................... 52
For more information about “AIBO” ERS-210 series (name of parts, settings,
“Memory Stick” use, safety precautions, etc.), refer to the “AIBO” ERS-210
series Operating Instructions.

Getting Started
Welcome to“AIBO Recognition”!
“AIBO Recognition”is AIBO-ware for the AIBO ERS-210 series.
This chapter explains how to get AIBO ready to use “AIBO
Recognition.”
* In this manual, “AIBO Recognition ERF-210AW06E”is
referred to as “AIBO Recognition”hereinafter.

12
Welcome to “AIBO Recognition”!
“AIBO Recognition”is AIBO-ware that gives AIBO a gentle and intelligent
character.
When AIBO is loaded with AIBO Recognition, it acts on its own volition as it
learns about you and its environment.
AIBO can recognize your face
(page 36)
AIBO has the ability to recognize your face and
the sound of your voice. AIBO remembers the
faces of those people it is closest to. The
special affection AIBO shows these people is
unique.
AIBO never runs out of energy because
it knows how to self-charge!
(page 24)
Whenever battery power is low, AIBO returns to
the Station and charges itself. When charging is
complete, AIBO leaves the Station and resumes
its former activity.
In order for AIBO to self-charge, the Energy Station ERA-210P1 (optional) is required.

13
Getting Started
AIBO loves communication!
When you call or play with AIBO... it is happy! If you
communicate frequently withAIBO, it will repay you
with growing expressions of affection.
AIBO also loves to take
naps
If you leave AIBO alone, it will enjoy a
peaceful nap without disturbing you.
However, while AIBO dozes, it is
always waiting for you to call.
Emotions and instincts of AIBO
When AIBO is loaded with AIBO Recognition, it displays emotions such as joy
and sadness, as well as desires such as wanting to play or to sleep.
These emotions and desires will change in response to a variety of conditions that
affect the behavior of AIBO, including interaction with people and its
surroundings.
AIBO is an autonomous robot that acts on its own initiative, according to its
emotions, its desires, and the information it collects from its surroundings through
its built-in camera and microphone.

14
Modes and conditions of AIBO
With AIBO Recognition, AIBO can enter
the following modes and conditions.
•
When
y
ou
p
ress
the
p
ause
AIB
O
’
s
c
hes
t.
•WhenAIBO has
been active for
an extended
period.
Au
t
onomou
s
mode
Pause mo
de
A
c
tive
c
ondition
To turn AIBO off, press the Pause
bu
tt
on lo
c
a
t
ed on i
t
s
c
hes
t.
Pla
c
e AIBO in
t
his mode before
changing or replacing the battery
or “Memory Stick.”
AIBO moves around on i
t
s own
.
AIBO acts on its own volition
,
based on its emotions
,
its instincts
,
throu
g
h its built-in camera,
se
n
so
r
s.
When
y
ou
p
ress
the
p
ause button
o
n AIB
O
’
s
c
hes
t.
e
chest li
g
ht
h
ts
g
reen
.
•
Do not place AIBO in an
y
location where
it mi
g
ht fall or be subjected to vibration,
or on an
y
unstable surface
.
•Do not place anything near AIBO that
may hinder its movement.
g
oes off
.
•
AIBO re
t
urns
to the
S
tation
on i
t
s own
.
•You place
AIBO on the
Station while it
is operating.
S
ometimes
To wake u
p
or
t
alk
t
o i
t.

15
Getting Started
Pick u
p
AIBO
quickl
y.
Put down AIBO.
P
ick-u
p
c
ondition
An object is
caught in any
one of AIBO’s
joints.
Press the
head sensor
for 3 seconds.
Jam
c
ondition
If an ob
j
ect becomes
j
ammed in any
o
n
e
o
f AIB
O
’
s
j
oints, AIBO
g
oes limp,
and all of its
j
oints become loose. This
condition prevents you from getting
your fingers caught between AIBO’s
joints and injuring them.
Note
When two or more of AIBO’s paw sensors
are pressed, it thinks it has been placed on
the floor and returns to Autonomous mode.
AIBO may start walking after returning to
Autonomous mode, so be careful not to
touch an
y
of its paw sensors when
y
ou
hold it.
WhenAIBO is
p
icked u
p
, it moves
into the Pick-u
p
condition. This is to
preventAIBO from makin
g
movements that mi
g
ht surprise the
person picking it up, possibly causing
them to drop it in consequence.
AIBO takes a nap or even sta
y
s
awake while char
g
in
g.
The Ener
g
y Station ERA-210P1 is an
o
p
tional accessor
y.
•AIBO moves
from the
Station on its
own.
•You remove
AIBO from the
Station.
Station mo
de
g
oes off
.
The mode indi
c
a
t
or
The mode indi
c
a
t
or

16
Slide the lid toward the b mark.
Preparations
Let’s get AIBO ready to use AIBO Recognition.
Note
IfAIBO is loaded with any other AIBO-ware “Memory Stick,”place AIBO in the Pause
mode (the chest light goes off) before switching the “Memory Stick.”To place AIBO in
the Pause mode, press the pause button on AIBO’s chest.
1 GraspAIBO securely by the body, turn it upside down, and open the
cover.
Notes
•Lift AIBO by its body, and not by its extremities.
•If your hands are comparatively small, you may
drop AIBO when grasping or turning it upside
down. Be careful to holdAIBO.
•Do not touch AIBO’s charging terminal with your hand. Doing so may soil the
terminal and cause poor contact.
2 Remove the “Memory Stick” from its case.

17
Getting Started
3 Check that you are holding the “Memory Stick” in the right direction,
and insert it intoAIBO.
With the Vmark pointing down and the
label facing the direction of the battery slot,
insert the “Memory Stick”until you hear it
click into place.
Notes
•Make sure that you orient the “Memory Stick”correctly.
If you insert it incorrectly oriented, you may damage the
“Memory Stick”or AIBO.
•Do not set the safety switch of the “Memory Stick”to
“LOCK.”Doing so will make it impossible for AIBO’s
learning and taking photo functions to work.
Label side
Battery slot

18
4 After checking that the battery pack is correctly oriented, insert it, and
then close the cover.
Hold the battery pack with the connector facing downward, and insert it into the slot
until you hear it click into place.
5 Charge up the battery pack.
Refer to the “AIBO”ERS-210 series Operating Instructions for how to charge up
the battery pack.
Push here. Attach the cover as shown in the
illustration.

19
Getting Started
6 Place AIBO on the floor as shown on the right.
Place AIBO on a flat, non-slippery surface, such as a carpet
with a short nap.
And choose a quiet place to place AIBO so that it can hear
whatever you say to it.
Notes
•On a slippery floor or a carpet with a long nap, AIBO may
fall down or carpet may be caught between its joints, so it
may not move forward.
•Be sure to place AIBO on the floor as shown above. This will
prevent AIBO from moving unexpectedly and being damaged
when you press the pause button.
7 Press the pause button on AIBO’s chest.
The chest light lights up green.
After a while, AIBO will begin moving automatically.
Note
If its eyes flash red when you press the pause button, the “Memory Stick’s”write protect
switch is in the “LOCK”position. Press the pause button once more to putAIBO in the
Pause mode, then unlock the write protect switch on the “Memory Stick.”
