Sound Sation SCENEMAKER 2416 User manual

Please read this manual carefully and proper take care of this manual.
USER MANUAL
Intelligent Lighting Controller
Leggete questo manuale e conservatelo per future consultazioni!
MANUALE utente

Dear customer,
First of all thanks for purchasing a SOUNDSATION® product. Our mission is to satisfy
all possible needs of musical instrument, professional audio and lighting users offering
a wide range of products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we are
looking for a feedback from you about the operation of the product and possible im-
provements to introduce in the next future. Go to our website www.soundsationmusic.
com and send an e-mail with your opinion, this will help us to build instruments ever
closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation
can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
Gentile Cliente,
Grazie per aver scelto un prodotto SOUNDSATION®. La nostra missione è quella di
offrire ai nostri utenti una vasta gamma di strumenti musicali ed apparecchiature audio
e lighting con tecnologie di ultima generazione.
Speriamo di aver soddisfatto le vostre aspettative e, se voleste collaborare, saremmo
lieti di ricevere un vostro feedback sulla qualità del prodotto al ne di migliorare co-
stantemente la nostra produzione. Visitate il nostro sito www.soundsationmusic.com ed
inviateci una mail con la vostra opinione, questo ci aiuterà a sviluppare nuovi prodotti
quanto più vicini alle vostre esigenze.
Un’ultima cosa, leggete il presente manuale al ne di evitare danni alla persona ed al
prodotto, derivanti da un utilizzo non corretto.
Il Team SOUNDSATION

TABLE OF CONTENTS
1. 1. INTRODUCTION ....................................................................................................6
1.1. Unpacking.................................................................................................................................................................6
1.2. Accessories...............................................................................................................................................................7
2. OVERVIEW..................................................................................................................7
3. MAIN FEATURES........................................................................................................7
4. OVERVIEW..................................................................................................................8
4.1. Front Panel................................................................................................................................................................8
4.2. Rear Panel ...............................................................................................................................................................10
4.3. Common Terms.....................................................................................................................................................10
5. OPERATION GUIDE..................................................................................................11
5.1. Setting up the system ........................................................................................................................................11
5.2. Fixture Addressing...............................................................................................................................................11
5.3. PAN and TILT Channels......................................................................................................................................11
5.4. Resetting The System.........................................................................................................................................12
5.5. Copy Scanner.........................................................................................................................................................12
5.6. Fade Time Assign.................................................................................................................................................12
6. OPERATION..............................................................................................................13
6.1. Manual Mode........................................................................................................................................................13
6.2. Review Scene Or Chase .....................................................................................................................................13
7. PROGRAMMING......................................................................................................14
7.1. Entering Program Mode....................................................................................................................................14
7.2. Create a Scene ......................................................................................................................................................14
7.3. Running a Program.............................................................................................................................................15
7.4. Checking a Program ...........................................................................................................................................15
7.5. Editing a Program................................................................................................................................................15
7.6. Copy a Program....................................................................................................................................................15
8. CHASE PROGRAMMING .........................................................................................16
8.1. Create a Chase......................................................................................................................................................16
8.2. Running a Chase ..................................................................................................................................................16
8.3. Checking a Chase.................................................................................................................................................16
8.4. Edit a Chase............................................................................................................................................................17
8.5. Delete all CHASE Programs..............................................................................................................................18
9. SCENE PROGRAMMING..........................................................................................18
9.1. Insert a Scene........................................................................................................................................................18
9.2. Copy a Scene.........................................................................................................................................................19
3
ENGLISH

9.3. Delete a Scene ......................................................................................................................................................19
9.4. Delete all Scenes ..................................................................................................................................................19
10. PLAYBACK ................................................................................................................20
10.1. Running in Sound Mode...................................................................................................................................20
10.2. Running in Auto Mode......................................................................................................................................20
10.3. Blackout...................................................................................................................................................................20
11. MIDI OPERATION ....................................................................................................21
12. APPENDIX ................................................................................................................21
12.1. DMX Introduction................................................................................................................................................21
12.2. Building a Serial DMX Chain............................................................................................................................22
12.3. DMX Terminator ...................................................................................................................................................22
12.4. 3-Pin vs 5-Pin DMX cables...............................................................................................................................23
13. SPECIFICATIONS ......................................................................................................23
14. WARRANTY AND SERVICE .....................................................................................24
15. WARNING.................................................................................................................24
4
ENGLISH

IMPORTANT SAFETY SYMBOLS
The symbol is used to indicate that some hazardous live terminals are
involved within this apparatus, even under the normal operating con-
ditions, which may be sufcient to constitute the risk of electric shock
or death.
The symbol is used in the service documentation to indicate that spe-
cic component shall be replaced only by the component specied in
that documentation for safety reasons.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned off
WARNING: Describes precautions that should be observed to prevent the danger
of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent danger of
the apparatus.
TAKING CARE OF YOUR PRODUCT
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions
Water / Moisture
The apparatus should be protected from moisture and rain and can not be used near
water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
Heat
The apparatus should be located away from heat sources such as radiators, stoves or
other appliances that produce heat.
Ventilation
Do not block areas of ventilation opening. Failure to do could result in re. Always
5
ENGLISH
SCENEMAKER 2416 User manual

install according to the manufacturer’s instructions.
Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus for
safety.
Power Supply
In case of external power supply, the apparatus should be connected to the power sup-
ply only of the type as marked on the apparatus or described in the manual. Failure to
do could result in damage to the product and possibly the user. Unplug this apparatus
during lightning storms or when unused for long periods of time.
Electrical Connection
Improper electrical wiring may invalidate the product warranty.
Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzene or alcohol.
Servicing
Do not implement any servicing other than those means described in the manual. Refer
all servicing to qualied service personnel only. Only use accessories/attachments or
parts recommended by the manufacturer.
1. 1. INTRODUCTION
Thank you for purchasing our SCENEMAKER 2416 Intelligent Lighting Controller. Enjoy
your new equipment and make sure to read this manual carefully before operation!
This user manual is made to provide both an overview of controls, as well as informa-
tion on how to use them. In order to help you to understand the connections between
the various controls, we have gathered in groups according to their functions.
1.1. Unpacking
Your SCENEMAKER 2416 controller was carefully packed to ensure safe transport. De-
spite this, we recommend you to carefully examine the package and its contents for any
signs of physical damage, which can occur during transport. It is composed by follow-
ing parts:
f1x SCENEMAKER 2416 unit
f1x External Power Adapter
f1x USB goose-neck lamp
fThis User Manual
6
ENGLISH
SCENEMAKER 2416 User manual

ATTENTION: Packaging bag is not a toy! Keep out of reach of children!!! Keep in
a safe place the original packaging material for future use.
1.2. Accessories
SOUNDSATION can supply a wide range of quality accessories that you can use with
your DMX controller, like Cables, Splitters, Stands, and a wide range xtures.
All products in our catalogue has been long tested with this device so we recommend
to use Genuine SOUNDSATION Accessories and Parts.
Ask your SOUNDSATION dealer or check out our website www.soundsationmusic.com
for any accessories you could need to ensure best performance of the product.
2. OVERVIEW
SCENEMAKER 2416 is a universal intelligent lighting controller. It allows you to manage
up to 24 xtures composed of 16 channels each (384 channels in total), and up to 240
programmable scenes.
6 chases can contain up to 240 steps composed by the saved scenes (the steps) and in
any order. Programs can be triggered by music, MIDI, automatically or manually.
On the surface you will nd various programming tools such as 16 universal channel
sliders, quick access scanner and scene buttons, and a LED display indicator for easier
navigation of controls and menu functions.
3. MAIN FEATURES
f24 Fixtures with 16 DMX Channels each; 384 Channels in total
f30 banks of 8 programmable scenes, 240 scenes total
f6 chases of 240 programmed scenes from 30 bank
fExecute multiple chases simultaneously
f16 Sliders for direct control of channels
fAuto Mode controlled by Speed and Fade Time
fMaster Blackout
fBuilt-in microphone for Music triggering
fUSB LED Goose-neck Lamp
fLED Display for easy navigation of menus
fMIDI control over banks, chases and Blackout
fPlastic end housing
7
ENGLISH
SCENEMAKER 2416 User manual

4. OVERVIEW
4.1. Front Panel
4
1
23 5 6
9
10
11 1213 14 15
7 8
16 1718
1. Scanner Buttons (1-12 or 13-24): 12 x 2 pages scanners of 16 DMX channels &
fader control. Press a scanner button to turn on manual fader control. Press the
scanner button again to turn off fader control.
Scanners DMX channels Fader control LED
1 1-16 Off/On Off/On
2 17-32 Off/On Off/On
3 33-48 Off/On Off/On
4 49-64 Off/On Off/On
5 65-80 Off/On Off/On
6 81-96 Off/On Off/On
7 97-112 Off/On Off/On
8 113-128 Off/On Off/On
9 129-144 Off/On Off/On
10 145-160 Off/On Off/On
11 161-176 Off/On Off/On
12 177-192 Off/On Off/On
13 193-208 Off/On Off/On
14 209-224 Off/On Off/On
15 225-240 Off/On Off/On
16 241-256 Off/On Off/On
17 257-272 Off/On Off/On
18 273-288 Off/On Off/On
19 289-304 Off/On Off/On
20 305-320 Off/On Off/On
8
ENGLISH
SCENEMAKER 2416 User manual

21 321-336 Off/On Off/On
22 337-352 Off/On Off/On
23 353-368 Off/On Off/On
24 369-384 Off/On Off/On
2. Scanner Indicator LEDs: The LED next to the button lights up or goes out to indi-
cate your selection.
3. Scene Select Buttons: Press the scene buttons to load or store your scenes. There
are a maximum of 240 programmable scenes.
4. Channel Faders: These faders are used to control the intensity of channel 1-16.
5. Program Button: Used to enter Program mode.
6. Music/Bank Copy: Activates Music mode or copies a bank of scenes.
7. LED Display: Shows current activity or programming state.
8. Mode indicator LEDs: Provides operating mode status (Manual, Music or Auto).
9. Bank Up: Selects target bank from the available 30 banks.
10. Bank Down: Selects target bank from the available 30 banks.
11. Tap/Display: This is a Tap-Sync during playback, and commutes DMX value chang-
es displayed in the LCD panel to percentages during programming.
12. Blackout button: Sets all channel to “0”.
13. MIDI/Add Button: Activates MIDI external control and is also used to conrm the
record/save process.
14. Auto/Del Button: Used to activate Auto mode and as delete function during
programming.
15. Chase Buttons (1-6): These buttons are used to activate chases of programmed
scenes.
16. Speed fader: This will adjust running time of a scene or a step within a chase.
17. Fade-Time fader: Also considered a cross-fade, sets the interval time between two
scenes in a chase.
18. Page Select Button: In manual mode, press to toggle between pages of control.
Both LEDs on will allow control of both lower and upper range channel.
9
ENGLISH
SCENEMAKER 2416 User manual

4.2.Rear Panel
MADE IN CHINA
DC Input
9V-1000mA
DMX
Output
MIDI LAMP POWER
DMX
Input
19 20 21
22
23
19. MIDI IN: For triggering of Banks/Chases using a MIDI device
20. DMX Out/In: These connectors send and receive your DMX values, DMX scanners
or DMX packs.
21. DC Input: DC 9 -12V, 500mA min.
22. USB Port: Used to connect a USB goose-neck lamp.
23. Power Switch: This switch turns On/Off the console.
4.3.Common Terms
The following are common terms used in intelligent light programming.
Blackout is a state by where all lighting xtures light output are set to 0 or off, usually
on a temporary basis.
DMX-512 is an industry standard digital communication protocol used in entertain-
ment lighting equipment. For more information read Sections “12.1. DMX Introduction”
at page 21 and “12.2. Building a Serial DMX Chain” at page 22 in the Appendix.
Fixture refers to your lighting instrument or other device such as a moving head or
dimmer of which you can control.
Programs are a bunch of scenes stacked one after another. It can be programmed as
either a single scene or multiple scenes in sequence.
Scenes are static lighting states.
Sliders, also known as faders.
Chases can also be called programs. A chase consists of a bunch of scenes stacked one
after another.
Scanner refers to a lighting instrument with a Pan and Tilt mirror; however, the SCEN-
EMAKER 1216 PRO USB controller it can be used to control any DMX-512 compatible
10
ENGLISH
SCENEMAKER 2416 User manual

device as a generic xture.
MIDI is a standard for representing musical information in a digital format. A MIDI
input would provide external triggering of scenes using MIDI device such as a MIDI
keyboard or sequencer.
Stand Alone refers to a xture’s ability to function independently of an external con-
troller and usually in sync to music, due to a built in microphone.
Fade slider is used to adjust the time between scenes within a chase.
Speed slider affects the amount of time a scene will hold its state. It is also considered
a waiting time.
Shutter is a mechanical device in the lighting xture that allows you to block the light
path. It is often used to lessen the intensity of the light output and to strobe.
5. OPERATION GUIDE
5.1. Setting up the system
1. Connect this xture to electric power via the supplied DC adapter.
2. Plug in DMX cable(s) to your intelligent lighting as described in the xtures respec-
tive manual. For a quick introduction on DMX see the “12.1. DMX Introduction” at
page 21 section in the Appendix of this manual.
5.2.Fixture Addressing
SCENEMAKER 2416 is programmed to control 16 channels of DMX per xture, therefore
the xtures you wish to control with the corresponding “SCANNER” buttons on the unit,
must be spaced 16 channels apart. Please refer to your individual xture’s manual for
DMX addressing instructions.
5.3.PAN and TILT Channels
Because not all lighting xtures are alike or share same control attributes, this Control-
ler allows the user to re-assign physical faders to xture DMX channels so that the user
can combine or unify control of similar or the same attributes across different types of
xtures.
1. Press and hold PROGRAM & TAP/SYNC. Faders are given a channel buttons
together (1) time to access the number and are labeled on the surface of the chan-
nel assignment mode.
2. Press a SCANNER button or PAGE SELECT button that represents the xture
11
ENGLISH
SCENEMAKER 2416 User manual

whose faders you would like to reassign.
3. Move one fader of 16 channel to select the pan channel.
4. Press the TAP/SYNC DISPLAY button to select Pan/Tilt.
5. Move one fader of 16 channel to select the tilt channel.
6. Press and hold PROGRAM & TAP/SYNC DISPLAY buttons to exit and save
setting. All LEDs will blink.
NOTE: All Pan/Tilt can be re-assigned to output on different DMX channels.
Press AUTO/DEL button to delete the channel assignment mode.
5.4.Resetting The System
Warning: This will reset the controller to its factory defaults and will erase all
programs and settings.
1. Turn off the unit.
2. Press and hold BANK UP and AUTO/DEL.
3. Turn on power to the unit (while still holding BANK UP and AUTO/DEL).
5.5.Copy Scanner
Example: Copying Scanner 1 into Scanner 2
1. Press and hold SCANNER button 1.
2. While holding button 1press scanner button 2.
3. Release SCANNER button 1 rst before releasing SCANNER button 2and LED
indicator of SCANNER 2will ON.
4. All SCANNER LED indicators will ash to conrm successful copy.
NOTE: To save time, you can copy the settings of one Scanner button to an-
other.
5.6.Fade Time Assign
You can choose whether fade time during scene execution is implemented broadly
to all output channels, or only to the Pan & Tilt movement channels. This is relevant
because often you will want gobos and colors to change quickly while not affecting the
movement of the light.
12
ENGLISH
SCENEMAKER 2416 User manual

1. Turn OFF the controller
2. Hold the BLACKOUT and TAP SYNC/DISPLAY buttons simultaneously.
3. Turn on the controller.
4. Press the TAP/DISPLAY button to toggle between the two modes. Either ALL CH
(A) or Pan & Tilt only (P).
5. Press BLACKOUT and TAP SYNC/DISPLAY to save settings. All LEDS will
blink to conrm setting.
6. OPERATION
6.1. Manual Mode
Manual mode allows direct control of all scanners. You are able to move them and
change attributes by using channel faders.
1. Press the AUTO/DEL button repeatedly until the MANUAL LED is lit.
2. Select a SCANNER button.
3. Move the faders to change xture attributes.
4. TAP/DISPLAY button: Press to toggle the output indicator on LCD display be-
tween DMX values (0-255) or percentage (0-100).
NOTES: All changes made while in Manual Mode are temporary and will not
be recorded.
6.2.Review Scene Or Chase
This instruction assumes that you have already recorded scenes and chases on the con-
troller. Otherwise, please skip this section and go to programming.
SCENE Review
1. In manual mode, select one of the 30 banks by pressing the BANK UP/DOWN
buttons.
2. Select a SCENE button (1to 8) to review.
3. Move wheels and faders to change xture attributes.
CHASE Review
1. In manual mode, press any one of the 6 CHASE buttons.
13
ENGLISH
SCENEMAKER 2416 User manual

2. Press TAP/DISPLAY button to view step number on display.
3. Press BANK UP/DOWN buttons to review all scenes in the chase.
NOTES: Make sure you are still in MANUAL mode.
7. PROGRAMMING
A program (bank) is a sequence of different scenes (or steps) that will be called up one
after another. In the SCENEMAKER 2416 30 programs can be created of 8 scenes in
each.
7.1. Entering Program Mode
1. Press Program button around 2 seconds until its LED blinks.
7.2. Create a Scene
A scene is a static lighting state. Scenes are stored in banks. There are 30 bank memo-
ries on the controller, and each bank can hold 8 scene memories. The console can save
240 total scenes.
1. Press the PROGRAM button until the LED blinks.
2. Position SPEED and FADE/TIME sliders all the way down.
3. Select the SCANNERS you wish to include in your scene.
4. Compose a look by moving the sliders and wheels.
5. Tap MIDI/REC button to prepare save.
6. Choose a BANK (1 - 30) to change if necessary.
7. Select a SCENES button to store.
8. Repeat steps 3 through 7 as necessary. 8 scenes can be recorded in a Program.
9. To exit program mode, hold the PROGRAM button.
Notes: De-select Blackout if LED is lit. You can select more than one xture.
There are 8 scenes available in every bank.
All LEDs will ash to conrm. The LED display will now indicate the Scene
number and Bank number used.
14
ENGLISH
SCENEMAKER 2416 User manual

7.3. Running a Program
1. Use BANK UP/DOWN buttons to change Program banks if necessary.
2. Press the AUTO/DEL button repeatedly until the AUTO LED turns on.
3. Adjust PROGRAM speed via the SPEED fader and the loop rate via the FADE
TIME fader.
4. Alternatively you can tap the TAP/DISPLAY button twice (also called Tap-
Sync). Time between two taps sets the time between SCENES (up to 10 min-
utes).
NOTE: De-select Blackout if LED is lit.
7.4. Checking a Program
1. Press and hold Program button until the LED blinks.
2. Use the BANK UP/DOWN buttons to select the PROGRAM bank to review.
3. Press the SCENES buttons to review each scene individually.
7.5. Editing a Program
Scenes will need to be modied manually.
1. Press and hold the PROGRAM button until the LED blinks.
2. Use BANK UP/DOWN buttons to change Program banks if necessary.
3. Select the desired xture via the SCANNERS button.
4. Adjust and change xture attributes using the channel faders and wheel.
5. Press the MIDI/Add button to prepare the save.
6. Select the desired SCENES button to save.
NOTE: De-select Blackout if LED is lit.
7.6. Copy a Program
1. Press and hold the PROGRAM button until the LED blinks.
2. Use BANK UP/DOWN buttons to select the PROGRAM bank you will copy.
3. Press the MIDI/Add button to prepare the copy.
15
ENGLISH
SCENEMAKER 2416 User manual

4. Use BANK UP/DOWN buttons to select the destination PROGRAM bank.
5. Press the MUSIC/Bank Copy button to execute the copy. All LEDs on the con-
troller will blink.
NOTE: All 8 scenes in a Program bank will be copied.
8. CHASE PROGRAMMING
A chase is created by using previously created scenes. Scenes become steps in a chase
and can be arranged in any order you choose. It is highly recommended that prior to
programming chases for the rst time; you delete all chases from memory. See “8.5.
Delete all CHASE Programs” at page 18 for instructions.
8.1. Create a Chase
A chase can contain 240 scenes as steps. The term steps and scenes are used inter-
changeably.
1. Press PROGRAM button until the LED blinks.
2. Press CHASE (1 - 6) button you wish to program.
3. Change BANK, if necessary, to locate a scene.
4. Select the SCENE to insert.
5. Tap the MIDI/Add button to store.
6. Repeat steps 3 - 5 to add additional steps in the chase. Up to 240 steps can be
recorded.
7. Press and hold the PROGRAM button to save the chase.
8.2. Running a Chase
1. Press a CHASE button then press the AUTO/DEL button.
2. Adjust Chase speed by tapping TAP/DISPLAY button twice at a rate of your
choosing.
NOTE: The time between 2 taps will set chase speed (up to 10 minutes).
8.3.Checking a Chase
1. Press and hold Program button until the LED is lit.
16
ENGLISH
SCENEMAKER 2416 User manual

2. Select the desired CHASE button.
3. Press the TAP/DISPLAY button to switch the LED display to steps.
4. Review each scene/step individually by using the BANK UP/DOWN buttons.
8.4.Edit a Chase
Copy a Bank into A Chase
1. Press and hold the PROGRAM button to enter programming mode.
2. Press the desired CHASE button.
3. Select the BANK to be copied using the BANK UP/DOWN buttons.
4. Press MUSIC/BANK COPY button to prepare copy.
5. Press MIDI/Add button to copy the bank. All LEDs will blink.
Copy A Scene Into A Chase
1. Press and hold the PROGRAM button to enter programming mode.
2. Press the desired CHASE button.
3. Select the BANK that contains the scene to be copied using the BANK UP/
DOWN buttons.
4. Press the SCENE button that corresponds to the scene to be copied.
5. Press MIDI/Add button to copy the scene. All LEDs will blink.
Insert A Scene Into A Chase
1. Press and hold the PROGRAM button to enter programming mode.
2. Press the desired CHASE button.
3. Press the TAP/DISPLAY to switch the LED display to steps view.
4. Use the BANK UP/DOWN buttons to navigate steps and locate the insert point
of the new scene. The display will read the step number (for example: to insert a
scene between Step 05 and 06, navigate using BANK buttons until the display
reads STEP 05).
5. Press MIDI/Add button to prepare the insert.
6. Use the BANK UP/DOWN button to locate the SCENE.
7. Press the SCENE button that corresponds to the scene to be inserted.
17
ENGLISH
SCENEMAKER 2416 User manual

8. Press MIDI/Add button to insert the scene. All LEDs will blink.
Delete a Scene in a Chase
1. Press and hold the PROGRAM button to enter programming mode.
2. Press the desired CHASE button that contains the scene to be deleted.
3. Press the TAP/DISPLAY button to switch the LCD display to steps.
4. Select the scene/step to be deleted using the BANK UP/DOWN buttons.
5. Press AUTO/DEL button to delete the step/scene. All LEDs will blink.
Delete a Chase
1. Press and hold the PROGRAM button to enter programming mode.
2. Press the desired CHASE button (1 - 6) to be deleted.
3. Press and hold AUTO/DEL button and target CHASE button to delete the chase.
All LEDs will blink.
8.5.Delete all CHASE Programs
CAUTION! This procedure will result in irrevocable loss of chase step memo-
ry. The individual scenes and program banks will be preserved.
1) Turn the SCENEMAKER 2416 off.
2) Press and hold the BANK DOWN button and the AUTO/DEL button while turning
on the controller.
3) All LEDs will blink.
9. SCENE PROGRAMMING
9.1. Insert a Scene
1. Press and hold the PROGRAM button to enter programming mode.
2. Press the desired CHASE button (e.g.: to insert a scene between Steps 05 and 06,
navigate using BANK buttons until the display reads STEP05).
3. Press the TAP/DISPLAY to switch the LCD display to steps view.
4. Use the BANK UP/DOWN buttons to navigate steps and locate the insert point
of the new scene. The display will read the step number.
18
ENGLISH
SCENEMAKER 2416 User manual

5. Press MIDI/Add button to prepare the insert.
6. Use the BANK UP/DOWN button to locate the SCENE.
7. Press the SCENE button that corresponds to the scene to be inserted.
8. Press MIDI/Add button to insert the scene. All LEDs will blink.
9.2. Copy a Scene
1. Press and hold the PROGRAM button to enter programming mode.
2. Select the BANK that contains the scene to be copied using the BANK UP/
DOWN buttons.
3. Press the SCENE button that corresponds to the scene to be copied.
4. Press MIDI/Add button to copy the scene.
5. Select the destination BANK that contains the scene memory to record onto using
the BANK UP/DOWN buttons.
6. Press the desired SCENE button to complete copy. All LEDs will blink.
9.3.Delete a Scene
1. Press and hold the PROGRAM button to enter programming mode.
2. Select the BANK that contains the scene to be deleted by using the BANK UP/
DOWN buttons.
NOTE: When deleting a scene the physical location is not removed, however,
all 384 DMX channels available to the scene will be set to value 0.
3. Press and hold the AUTO/DEL button.
4. Press the SCENE button that corresponds to the scene you want to delete. All
LEDs will blink.
9.4.Delete all Scenes
Turn off the console.
Press and hold the PROGRAM button and the BANK DOWN button while turning
on power to the controller.
CAUTION! This process is irreversible. All scenes with data will be set to 0.
19
ENGLISH
SCENEMAKER 2416 User manual

10. PLAYBACK
10.1. Running in Sound Mode
1. Press the MUSIC/BANK COPY button until the MUSIC LED turns on.
NOTE: In the Sound mode, programs will be triggered by the sound using its
built-in microphone.
2. Select the program BANK to run in sound active mode using the BANK UP/
DOWN buttons.
3. Alternatively you can press a single CHASE button (1 - 6) or several CHASE but-
tons in sequence and all selected chases will loop in the selected order.
NOTE: Multiple chases selected will loop and run in the order originally se-
lected.
4. You can adjust the duration time using the FADE TIME fader.
10.2. Running in Auto Mode
1. Press the AUTO/DEL button until the AUTO LED turns on.
NOTE: In the Auto mode, programs will be triggered by controllers fade and
speed time as set on the faders.
2. If a CHASE button is not pressed the controller will automatically run a BANK
program.
3. Change BANK programs by using BANK UP/DOWN buttons.
4. Alternatively you can press a single CHASE button (1- 6) or several CHASE but-
tons in sequence and all selected chases will loop in the order selected.
NOTE: Multiple chases selected will loop and run in the order originally se-
lected.
5. You can adjust the time between steps by moving the SPEED fader and the dura-
tion of the step by moving the FADE TIME fader.
10.3. Blackout
1. Blackout button brings all lighting output to 0 or off.
20
ENGLISH
SCENEMAKER 2416 User manual
