Sound Sation MHL-350BS Instruction sheet

Dimensions and Weight
Length of base (including handles): 42.5 cm
Width: 28 mm cm
Height (head horizontal): 57.5 cm
Carton case size: 44.5*44.5*69.5 cm
Flight case size: 94*52*74.5 cm (2 units)
Net weight: 21.5 kg
Gross weight (carton case): 24 kg
Gross weight (flight case): 72.5 kg
We hope you are satisfied with this product we offer. As long as you can
correctly use this device strictly in accordance with this product
instruction, we can guarantee it works normally within three years.
31
Product Instruction
MHL-350BS
Beam & Spot 350
CH21
Color Speed
0-255
From fast to slow
CH22
Gobo Speed
0-255
From fast to slow
CH23
Focus Speed
0-255
From fast to slow

Welcome to use this product
Attention! For your safety, please read this instruction carefully before
the first installation.
Please open your purchased product packaging, confirm whether there
is the presence or absence due to damage caused by transport. If so, please
immediately consult your local dealer or our company and do not start
operating this product.
Please check the following accessories
whether are complete after opening the package
1
CH10
Prism
Rotation
0-127
No function
128-190
Anti-clockwise rotate, from fast to
slow
191-192
Stop
193-255
Clockwise rotate, from slow to
fast
CH11
Frost
0-11
No function
12-255
Frost
CH12
Pan
0-255
Rotate 450 degrees
CH13
Pan Fine
0-255
0--2.1 degrees
CH14
Tilt
0-255
Rotate 270 degrees
CH15
Tilt Fine
0-255
0--1.0 degrees
CH16
Pan / Tilt
Speed
0-255
No function
CH17
Zoom In
0-255
Zoom in
CH18
Focus
0-255
Focus
CH19
Reset
0-50
No function
51-100
Renew factory state
101-255
No function
CH20
Lamp Off /
Lamp On
0-50
No function
51-100
Lamp on
101-150
Lamp off
151-255
No function
30

29
Before running this device, please check
that the locking element whether is turned on
2
117-120
Stop
121-165
Anti-clockwise rotate, from slow to
fast
166-170
White shaking
171-175
Gobo1 shaking ( slow-fast)
176-181
Gobo2 shaking ( slow-fast)
182-186
Gobo3 shaking ( slow-fast)
187-191
Gobo4 shaking ( slow-fast)
192-197
Gobo5 shaking ( slow-fast)
198-202
Gobo6 shaking ( slow-fast)
203-207
Gobo7 shaking ( slow-fast)
208-214
Gobo8 shaking ( slow-fast)
215-218
Gobo9 shaking ( slow-fast)
219-223
Gobo10 shaking ( slow-fast)
224-229
Gobo11 shaking ( slow-fast)
230-234
Gobo12 shaking ( slow-fast)
235-239
Gobo13 shaking ( slow-fast)
240-245
Gobo14 shaking ( slow-fast)
246-250
Gobo15 shaking ( slow-fast)
251-255
Gobo16shaking ( slow-fast)
CH8
Prism 1
0-9
No function
10-255
Prism 1
CH9
Prism 2
0-9
No function
10-255
Prism 2

l Mounting surfaces
It is permissible to mount the fitting on normally
flammable surfaces.
l Maximum ambient temperature
Do not operate the fixture if the ambient temperature
(Ta) exceeds 40℃(104℉).
l IP20 protection rating
The fitting is protected against penetration by solid
bodies of over 12mm (0.47") in diameter (first digit
2), but not against dripping water, rain, splashes or
jets of water (second digit 0).
3
CH6
Gobo
Wheel 2
Rotation
0-127
No function
128-189
Anti-clockwise rotate, from fast to
slow
190-193
Stop
194-255
Clockwise rotate, from slow to
fast
CH7
Gobo
Wheel 1
0-6
White
7-10
Gobo1
11-14
Gobo2
15-18
Gobo3
19-22
Gobo4
23-26
Gobo5
27-30
Gobo6
31-34
Gobo7
35-38
Gobo8
39-42
Gobo9
43-46
Gobo10
47-50
Gobo11
51-54
Gobo12
55-58
Gobo13
59-62
Gobo14
63-66
Gobo15
67-71
Gobo16
72-116
Clockwise rotate, from fast to
slow
28
l Minimum distance of illuminated objects
The projector needs to be positioned so that the
objects hit by the beam of light are at least 15 meters
(49.2´) from the lens of the projector.
l Minimum distance from flammable materials
The projector must be positioned so that any
flammable materials are at least 0.20 meters (0.6´)
from every point on the surface of the fitting.

27
4
26-35
Gobo2
36-45
Gobo3
46-55
Gobo4
56-65
Gobo5
66-75
Gobo6
76-85
Gobo7
86-95
Gobo8
96-105
Gobo9
106-115
Gobo10
116-125
Gobo11
126-135
Gobo12
136-145
Gobo1 shaking ( slow-fast)
146-155
Gobo2 shaking ( slow-fast)
156-165
Gobo3 shaking ( slow-fast)
166-175
Gobo4 shaking ( slow-fast)
176-185
Gobo5 shaking ( slow-fast)
186-195
Gobo6 shaking ( slow-fast)
196-205
Gobo7 shaking ( slow-fast)
206-215
Gobo8 shaking ( slow-fast)
216-225
Gobo9 shaking ( slow-fast)
226-235
Gobo10 shaking ( slow-fast)
236-245
Gobo11 shaking ( slow-fast)
246-255
Gobo12 shaking ( slow-fast)
l Protection against electrical shock
Connection must be made to a power supply system fitted
with efficient earthling (Class I appliance according to
standard EN 60598-1).
It is, moreover, recommended to protect the supply lines of
the projectors from indirect contact and / or shorting to
earth by using appropriately sized residual current devices.
l Connection to mains supply
Connection to the electricity mains must be carried out by a
qualified electrical installer.
Check that the mains frequency and voltage correspond to
those for which the projector is designed as given on the
electrical date label.
This label also gives the input power to which you need to
refer to evaluate the maximum number of fittings to
connect to the electricity line, in order to avoid
overloading.
l Lamp
The fitting mounts a high-pressure lamp that needs an
external igniter is fitted onto the apparatus.
-Carefully read the “operating instruction” provided by the
lamp manufacturer.
-Immediately replace the lamp if damaged or deformed by
heat.

l Battery
This product contains a rechargeable lead-acid or lithium
iron tetra phosphate battery. To preserve the environment,
please dispose the battery at the end of its life according
to the regulation in force.
LVD tested:
EMC tested:
EN 60598-2-17: 1989+A2:
1991
EN 55103-1: 2009+A1:
2012
EN 60598-1: 2008+A11: 2009
EN55103-2: 2009
EN 62493: 2010
EN 61000-3-2: 2014
EN 61000-3-3: 2013
ENC 150401GZ98R1
NOT FOR RESIDENTIAL USE
5
92-95
Brown yellow
96-99
Brown yellow, cyan
100-103
Cyan
104-107
Cyan, amaranth
108-111
Amaranth
112-115
Amaranth, light bluish violet
116-119
Light bluish violet
120-123
Light bluish violet, CTB
124-127
CTB
128-190
Clockwise rotate, from fast to slow
191-192
Stop
193-255
Anti-clockwise rotate, from fast to
slow
CH2
Strobe
0-3
No brightness
4-103
From slow to fast
104-109
Open
110-207
From slow to fast
208-212
Random slow strobe
213-251
Random fast strobe
252-255
Open
CH3
Dimmer
0-255
From dark to bright
CH4
Linear
Dimmer
0-255
Linear Dimmer
CH5
Gobo
Wheel 2
0-15
White
16-25
Gobo1
26

101-150
Lamp off
151-255
No function
23 DMX Channels Description:
Channel
Function
Data
Function Description
CH1
Color
Wheel
0-15
White
16-19
White, red
20-23
Red
24-27
Red, yellow
28-31
Yellow
32-35
Yellow, blue
36-39
Blue
40-43
Blue, green
44-47
Green
48-51
Green, deep yellow
52-55
Deep yellow
56-59
Deep yellow, magenta
60-63
Magenta
64-67
Magenta, UV
68-71
UV
72-75
UV, CTO
76-79
CTO
80-83
CTO, yellow green
84-87
Yellow green
88-91
Yellow green, brown yellow
25
Safety Instructions
CAUTION！Be careful with your operations. With a dangerous voltage you
can suffer a dangerous electric shock when touching the wire!
This device has left our premises in absolutely perfect condition. In order to
maintain this condition and to ensure a safe operation, it is absolutely
necessary for the user to follow the safety instructions and warning notes
written in this product instruction.
Important statement：
Damages caused by the disregard of this product instruction are not subject
to warranty. The dealer will not accept liability for any resulting defects or
problems.
l If the device has been exposed to drastic temperature fluctuation, (e.g.
after transportation), do not open the light at once. The agglomeration
of vapor is likely destroying your product. Do not open the product
until it reach normal temperature.
l This device falls under protection class 1.The power plug must only be
plugged into a protection class 1 outlet. Never let the power cord come
into contact with other cables! Handle the power cord all connections
with the mains with particular caution!
l Make sure that the available voltage is not higher than stated on the rear
panel (100-240V)
l There may be some of the first boot smoke or gas, which is normal and
does not mean that the device has a problem.
l CAUTION: During the operation, the housing becomes very hot.
6

l Never frequently open / close the device for reducing the life span of
the lamp.
l Never look directly into the light source, because sensitive people can
cause discomfort (especially for epilepsy patients).
l Damages caused by non-observance are not subject to warranty.
l Please note that the damage caused by the user's own changing machine
is not covered by the warranty.
l Keep away children and non-professionals!
Installation Schematic Diagram
7
CH8
Prism 1
0-9
No function
10-255
Prism 1
CH9
Prism 2
0-9
No function
10-255
Prism 2
CH10
Prism
Rotation
0-127
No function
128-190
Anti-clockwise rotate, from fast to
slow
191-192
Stop
193-255
Clockwise rotate, from slow to
fast
CH11
Frost
0-11
No function
12-255
Frost
CH12
Pan
0-255
Rotate 450 degrees
CH13
Pan Fine
0-255
0--2.1 degrees
CH14
Tilt
0-255
Rotate 270 degrees
CH15
Tilt Fine
0-255
0--1.0 degrees
CH16
Pan / Tilt
Speed
0-255
No function
CH17
Zoom In
0-255
Zoom in
CH18
Focus
0-255
Focus
CH19
Reset
0-50
No function
51--100
Renew factory state
101-255
No function
CH20
Lamp Off /
Lamp On
0-50
No function
51-100
Lamp on
24

59-62
Gobo14
63-66
Gobo15
67-71
Gobo16
72-116
Clockwise rotate, from fast to
slow
117-120
Stop
121-165
Anti-clockwise rotate, from slow
to fast
166-170
White shaking
171-175
Gobo1 shaking ( slow-fast)
176-181
Gobo2 shaking ( slow-fast)
182-186
Gobo3 shaking ( slow-fast)
187-191
Gobo4 shaking ( slow-fast)
192-197
Gobo5 shaking ( slow-fast)
198-202
Gobo6 shaking ( slow-fast)
203-207
Gobo7 shaking ( slow-fast)
208-214
Gobo8 shaking ( slow-fast)
215-218
Gobo9 shaking ( slow-fast)
219-223
Gobo10 shaking ( slow-fast)
224-229
Gobo11 shaking ( slow-fast)
230-234
Gobo12 shaking ( slow-fast)
235-239
Gobo13 shaking ( slow-fast)
240-245
Gobo14 shaking ( slow-fast)
246-250
Gobo15 shaking ( slow-fast)
251-255
Gobo16shaking ( slow-fast)
23
Power Connection Schematic Diagram
Note: Make sure the power is connected correctly with fire wire, zero line
and ground, must not be connected backwards; otherwise it will cause a
short circuit and danger!
8

DMX Connection Schematic Diagram
DMX 512 Connection / Connection between Fixtures
The wires must not come into contact with each other; otherwise the
fixtures will not work at all, or will not work properly.
0nly use a shielded signal cable and 3-pin / 5-pin XLR-plugs and connectors
so that the device can connect with the controller or connect one fixture
with others.
9
196-205
Gobo7 shaking ( slow-fast)
206-215
Gobo8 shaking ( slow-fast)
216-225
Gobo9 shaking ( slow-fast)
226-235
Gobo10 shaking ( slow-fast)
236-245
Gobo11 shaking ( slow-fast)
246-255
Gobo12 shaking ( slow-fast)
CH6
Gobo
Wheel 2
Rotation
0-127
No function
128-189
Anti-clockwise rotate, from fast to
slow
190-193
Stop
194-255
Clockwise rotate, from slow to fast
CH7
Gobo
Wheel 1
0-6
White
7-10
Gobo1
11-14
Gobo2
15-18
Gobo3
19-22
Gobo4
23-26
Gobo5
27-30
Gobo6
31-34
Gobo7
35-38
Gobo8
39-42
Gobo9
43-46
Gobo10
47-50
Gobo11
51-54
Gobo12
55-58
Gobo13
22

213-251
Random fast strobe
252-255
Open
CH3
Dimmer
0-255
From dark to bright
CH4
Linear
Dimmer
0-255
Linear Dimmer
CH5
Gobo
Wheel 2
0-15
White
16-25
Gobo1
26-35
Gobo2
36-45
Gobo3
46-55
Gobo4
56-65
Gobo5
66-75
Gobo6
76-85
Gobo7
86-95
Gobo8
96-105
Gobo9
106-115
Gobo10
116-125
Gobo11
126-135
Gobo12
136-145
Gobo1 shaking ( slow-fast)
146-155
Gobo2 shaking ( slow-fast)
156-165
Gobo3 shaking ( slow-fast)
166-175
Gobo4 shaking ( slow-fast)
176-185
Gobo5 shaking ( slow-fast)
186-195
Gobo6 shaking ( slow-fast)
21
Display Schematic Diagram
Touch screen will automatically reverse
when the device is upside down
NOTE: Double-clicking to access the display, you can arbitrarily select the
function needs to be changed.
10

Battery Installation Location Schematic Diagram
NOTE: This device has been installed battery, which can be used
continuous four hours for display. You can open the display to set the
channel value or the product function in the case of no electricity. The
battery is automatically charged after the device is energized; it is without
any damage to the device. Display is with a battery. In the case of the
product is not energized, press UP button to light the screen and set the
program. The display will be intelligent dark screen after about 1 minute
without operating it.
Frost Effect Mirror
11
68-71
UV
72-75
UV, CTO
76-79
CTO
80-83
CTO, yellow green
84-87
Yellow green
88-91
Yellow green, brown yellow
92-95
Brown yellow
96-99
Brown yellow, cyan
100-103
Cyan
104-107
Cyan, amaranth
108-111
Amaranth
112-115
Amaranth, light bluish violet
116-119
Light bluish violet
120-123
Light bluish violet, CTB
124-127
CTB
128-190
Clockwise rotate, from fast to slow
191-192
Stop
193-255
Anti-clockwise rotate, from fast to
slow
CH2
Strobe
0-3
No brightness
4-103
From slow to fast
104-109
Open
110-207
From slow to fast
208-212
Random slow strobe
20

CH16
Focus
0-255
Focus
CH17
Reset
0-50
No function
51-100
Renew factory state
101-255
No function
CH18
Lamp Off /
Lamp On
0-50
No function
51-100
Lamp on
101-150
Lamp off
151-255
No function
20 DMX Channels Description:
Channel
Function
Data
Function Description
CH1
Color Wheel
0-15
White
16-19
White, red
20-23
Red
24-27
Red, yellow
28-31
Yellow
32-35
Yellow, blue
36-39
Blue
40-43
Blue, green
44-47
Green
48-51
Green, deep yellow
52-55
Deep yellow
56-59
Deep yellow, magenta
60-63
Magenta
64-67
Magenta, UV
19
Four Buttons Operation Schematic Diagram
Gobo Wheel Schematic Diagram
Note: static gobo wheel: 16 gobos plus white
Rotating gobo wheel: 12 glass gobos, with rotating and changeable gobos
12
MENU: enter the menu to select the
function you need to use
UP: up to select the menu function
DOWN: down to select the menu
function
ENTER: after modifying the menu, press
it to confirm

Color Wheel Schematic Diagram
Note: 14 colors plus white
Prism Wheel Schematic Diagram
Note: one rotating sixteen-facet prism, one rotating twenty five-facet prism,
double prisms overlapping into forty one-facet prism
13
208-214
Gobo8 shaking ( slow-fast)
215-218
Gobo9 shaking ( slow-fast)
219-223
Gobo10 shaking ( slow-fast)
224-229
Gobo11 shaking ( slow-fast)
230-234
Gobo12 shaking ( slow-fast)
235-239
Gobo13 shaking ( slow-fast)
240-245
Gobo14 shaking ( slow-fast)
246-250
Gobo15 shaking ( slow-fast)
251-255
Gobo16shaking ( slow-fast)
CH8
Prism 1
0-9
No function
10-255
Prism 1
CH9
Prism 2
0-9
No function
10-255
Prism 2
CH10
Prism
Rotation
0-127
No function
128-190
Anti-clockwise rotate, from fast
to slow
191-192
Stop
193-255
Clockwise rotate, from slow to
fast
CH11
Frost
0-11
No function
12-255
Frost
CH12
Pan
0-255
Rotate 450 degrees
CH13
Tilt
0-255
Rotate 270 degrees
CH14
Pan / Tilt
Speed
0-255
No function
CH15
Zoom In
0-255
Zoom in
18

15-18
Gobo3
19-22
Gobo4
23-26
Gobo5
27-30
Gobo6
31-34
Gobo7
35-38
Gobo8
39-42
Gobo9
43-46
Gobo10
47-50
Gobo11
51-54
Gobo12
55-58
Gobo13
59-62
Gobo14
63-66
Gobo15
67-71
Gobo16
72-116
Clockwise rotate, from fast to slow
117-120
Stop
121-165
Anti-clockwise rotate, from slow to
fast
166-170
White shaking
171-175
Gobo1 shaking ( slow-fast)
176-181
Gobo2 shaking ( slow-fast)
182-186
Gobo3 shaking ( slow-fast)
187-191
Gobo4 shaking ( slow-fast)
192-197
Gobo5 shaking ( slow-fast)
198-202
Gobo6 shaking ( slow-fast)
203-207
Gobo7 shaking ( slow-fast)
17
DMX Channels
18 DMX Channels Description:
Channel
Function
Data
Function Description
CH1
Color Wheel
0-15
White
16-19
White, red
20-23
Red
24-27
Red, yellow
28-31
Yellow
32-35
Yellow, blue
36-39
Blue
40-43
Blue, green
44-47
Green
48-51
Green, deep yellow
52-55
Deep yellow
56-59
Deep yellow, magenta
60-63
Magenta
64-67
Magenta, UV
68-71
UV
72-75
UV, CTO
76-79
CTO
80-83
CTO, yellow green
84-87
Yellow green
88-91
Yellow green, brown yellow
92-95
Brown yellow
96-99
Brown yellow, cyan
100-103
Cyan
104-107
Cyan, amaranth
14

108-111
Amaranth
112-115
Amaranth, light bluish violet
116-119
Light bluish violet
120-123
Light bluish violet, CTB
124-127
CTB
128-190
Clockwise rotate, from fast to
slow
191-192
Stop
193-255
Anti-clockwise rotate, from fast
to slow
CH2
Strobe
0-3
No brightness
4-103
From slow to fast
104-109
Open
110-207
From slow to fast
208-212
Random slow strobe
213-251
Random fast strobe
252-255
Open
CH3
Dimmer
0-255
From dark to bright
CH4
Linear
Dimmer
0-255
Linear Dimmer
CH5
Gobo Wheel 2
0-15
White
16-25
Gobo1
26-35
Gobo2
36-45
Gobo3
46-55
Gobo4
56-65
Gobo5
15 16
66-75
Gobo6
76-85
Gobo7
86-95
Gobo8
96-105
Gobo9
106-115
Gobo10
116-125
Gobo11
126-135
Gobo12
136-145
Gobo1 shaking ( slow-fast)
146-155
Gobo2 shaking ( slow-fast)
156-165
Gobo3 shaking ( slow-fast)
166-175
Gobo4 shaking ( slow-fast)
176-185
Gobo5 shaking ( slow-fast)
186-195
Gobo6 shaking ( slow-fast)
196-205
Gobo7 shaking ( slow-fast)
206-215
Gobo8 shaking ( slow-fast)
216-225
Gobo9 shaking ( slow-fast)
226-235
Gobo10 shaking ( slow-fast)
236-245
Gobo11 shaking ( slow-fast)
246-255
Gobo12 shaking ( slow-fast)
CH6
Gobo
Wheel 2
Rotation
0-127
No function
128-189
Anti-clockwise rotate, from fast to slow
190-193
Stop
CH7
Gobo
Wheel 1
0-6
White
7-10
Gobo1
11-14
Gobo2
