Sound Sation 4LEDKIT-DJ User manual

Please read this manual carefully and proper take care of this manual.
USER MANUAL
LED Tricolor 4-PAR Lighting Kit
4LEDKIT-DJ

Dear customer,
First of all thanks for purchasing a SOUNDSATION® product. Our mission is to satisfy
all possible needs of musical instrument, professional audio and lighting users offering
a wide range of products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we are
looking for a feedback from you about the operation of the product and possible im-
provements to introduce in the next future. Go to our website www.soundsationmusic.
com and send an e-mail with your opinion, this will help us to build instruments ever
closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation
can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
TABLE OF CONTENTS
1. 1. INTRODUCTION ....................................................................................................5
2. OVERVIEW..................................................................................................................5
3. MAIN FEATURES........................................................................................................6
4. OVERVIEW..................................................................................................................6
5. FUNCTION..................................................................................................................7
6. DMX Channel Chart ..................................................................................................9
7. MAINS CONNECTIONS ...........................................................................................11
8. DMX Operation........................................................................................................11
9. TROUBLE SHOOTING ..............................................................................................13
10. SPECIFICATIONS ......................................................................................................13
11. WARRANTY AND SERVICE .....................................................................................14
12. WARNING.................................................................................................................14

IMPORTANT SAFETY SYMBOLS
The symbol is used to indicate that some hazardous live terminals are
involved within this apparatus, even under the normal operating con-
ditions, which may be sufcient to constitute the risk of electric shock
or death.
The symbol is used in the service documentation to indicate that spe-
cic component shall be replaced only by the component specied in
that documentation for safety reasons.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned off
WARNING: Describes precautions that should be observed to prevent the danger
of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent danger of
the apparatus.
TAKING CARE OF YOUR PRODUCT
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions
Water / Moisture
The apparatus should be protected from moisture and rain and can not be used near
water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
Heat
The apparatus should be located away from heat sources such as radiators, stoves or
other appliances that produce heat.
Ventilation
Do not block areas of ventilation opening. Failure to do could result in re. Always
3
ENGLISH
4LEDKIT-DJ User manual

install according to the manufacturer’s instructions.
Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus for
safety.
Power Cord and Plug
Protect power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus. Do not defeat the safety
purpose of the polarized or grounding-type plug. A polarized plug has two poles; a
grounding-type plug has two poles and a third grounding terminal. The third prong is
provided for your safety. If the provided plug does not t into your outlet, refer to an
electrician for replacement.
Power Supply
In case of external power supply, the apparatus should be connected to the power sup-
ply only of the type as marked on the apparatus or described in the manual. Failure to
do could result in damage to the product and possibly the user. Unplug this apparatus
during lightning storms or when unused for long periods of time.
Fuse
To prevent the risk of re and damaging the unit, please use only of the recommend-
ed fuse type as described in the manual. Before replacing the fuse, make sure the unit
turned off and disconnected from the AC outlet.
Electrical Connection
Always disconnect from the power source before servicing or replacing fuse and be
sure to replace with same fuse size and type. Cut off power before moving, repairing
and cleaning the unit. Improper electrical wiring may invalidate the product warranty.
To avoid electric shock, all xtures must be connected to circuits with a suitable ground.
Do not power on and power off the xture in a short time.
DMX connection
When use DMX controller, please make sure that there is no interference sources (e.g.
intercom, high frequency radio waves and radiation source).
Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzene or alcohol.
Servicing
Do not implement any servicing other than those means described in the manual. Refer
all servicing to qualied service personnel only. Only use accessories/attachments or
parts recommended by the manufacturer.
4
ENGLISH
4LEDKIT-DJ User manual

1. 1. INTRODUCTION
Thank you for purchasing our 4LEDKIT-DJ lighting kit. Enjoy your new equipment and
make sure to read this manual carefully before operation!
This user manual is made to provide both an overview of controls, as well as informa-
tion on how to use them. In order to help you to understand the connections between
the various controls, we have gathered in groups according to their functions.
1.1. UNPACKING
Your 4LEDKIT-DJ was carefully packed to ensure safe transport. Despite this, we recom-
mend you to carefully examine the package and its contents for any signs of physical
damage, which can occur during transport. It is composed by following parts:
f1x T-bar with Carrying bag
f1x Pedal-board
f1x Light stand with Carrying bag
fIEC power cable
fUser manual
ATTENTION: Packaging bag is not a toy! Keep out of reach of children!!! Keep in
a safe place the original packaging material for future use.
1.2. ACCESSORIES
SOUNDSATION can supply a wide range of quality accessories that you can use with
your LED Kit, like Cables, Splitters, DMX controllers, and a wide range of xtures.
All products in our catalogue has been long tested with this device, so we recommend
you to use Genuine SOUNDSATION Accessories and Parts.
Ask your SOUNDSATION dealer or check out our website www.soundsationmusic.com
for any accessories you could need to ensure best performance of the product.
2. OVERVIEW
SOUNDSATION 4LEDKIT-DJ brings you a complete light system including all accessories
in only one package. It is the smartest solution for all musicians, DJs, and small rental
companies.
It comes complete with 4 compact LED spots. Each spot contains 7pcs 3Watt RGB 3in1
LEDs in order to create a complete color palette. The spots are mounted on a T-bar
which has a built-in controller unit. The T-bar can be controlled by the included ped-
al-board or by DMX.
