Specialized COMO User manual

USER MANUAL
EN FR DE CZ PL SK

ENITESPTCNTCNSJP KR
CONTENTS
1. INTRODUCTION................................................................2
1.1. WARRANTY .........................................................................................................................................................................2
2. COMO COMPONENTS.........................................................3
3. GEOMETRY .................................................................... 5
4. GENERAL INFORMATION ABOUT YOUR COMO..........................7
4.1. INTENDED USE.................................................................................................................................................................. 7
4.2. PEDELEC / EPAC...............................................................................................................................................................7
4.3. STRUCTURAL WEIGHT LIMITS.......................................................................................................................................7
5. GENERAL NOTES ABOUT RIDING .........................................8
5.1. RIDING TIPS........................................................................................................................................................................8
5.2. BEFORE RIDING................................................................................................................................................................8
5.3. ENVIOLO AUTOMATIQ ACCELERATION.........................................................................................................................9
5.4. KNOW YOUR RANGE........................................................................................................................................................9
5.5. REMOVABLE YELLOW STICKER ....................................................................................................................................9
5.6. RIDING WITH KIDS ...........................................................................................................................................................9
6. GENERAL NOTES ABOUT MAINTENANCE.............................. 10
6.1. REPLACEMENT PARTS AND ACCESSORIES ...............................................................................................................10
7. GENERAL NOTES ABOUT ASSEMBLY ....................................11
7.1. HEADSET BEARINGS........................................................................................................................................................ 11
7.2. SEATPOST MINIMUM AND MAXIMUM INSERTION...................................................................................................... 11
7.3. DERAILLEUR/DROPOUT HANGER ............................................................................................................................... 12
7.4. SPEED SENSOR .............................................................................................................................................................. 12
7.5. FRONT RACKS MOUNT .................................................................................................................................................. 13
7.6. RACK ACCESSORY MOUNTS ........................................................................................................................................ 13
7.7. LIGHTING ..........................................................................................................................................................................14
7.8. INTEGRATED HANDLEBAR............................................................................................................................................ 15
7.9. MASTERMIND TCD-w MOUNTING BRACKET.............................................................................................................. 15
8. SYSTEM INTERFACE ....................................................... 16
8.1. MASTERMIND TCD-w (DISPLAY)................................................................................................................................... 16
8.2. STARTING THE SYSTEM ON THE MASTERMIND TCD-w........................................................................................... 16
8.3. HANDLEBAR REMOTES..................................................................................................................................................17
8.4. REMOTE FUNCTIONS......................................................................................................................................................17
8.5. SUPPORT MODES.......................................................................................................................................................... 18
8.6. PEDAL PACE BAR ON THE MASTERMIND TCD-w......................................................................................................19
8.7. CHANGING GEAR RATIO ON THE ENVIOLO MANUAL HUB.......................................................................................19
8.8. ENVIOLO AUTOMATIQ HUB, PEDAL PACE AND GEAR INDEX .................................................................................20
8.9. SYSTEM SETUP & CUSTOMIZING PAGES ON THE DISPLAY.................................................................................... 21
8.10. CONNECTIVITY OPTIONS............................................................................................................................................. 21
8.11. GARMIN RADAR............................................................................................................................................................. 22
8.12. ERROR MESSAGES...................................................................................................................................................... 23
8.13. PERFORMING A FACTORY RESET ON THE MASTERMIND TCD-w ........................................................................ 23
9. MISSION CONTROL ........................................................ 24
9.1. MISSION CONTROL FUNCTIONS.................................................................................................................................. 24
9.2. IN-APP HELP GUIDE...................................................................................................................................................... 25
9.3. DOWNLOAD AND INSTALL MISSION CONTROL....................................................................................................... 25
9.4. PAIRING YOUR BIKE WITH MISSION CONTROL........................................................................................................ 25
9.5. CUSTOMIZING THE MASTERMIND TCD-w DISPLAY................................................................................................. 26
10. BATTERY AND CHARGER ................................................26
10.1. INSTRUCTIONS PERTAINING TO THE RISK OF FIRE OR ELECTRIC SHOCK......................................................... 26
10.2. BATTERY DAMAGE........................................................................................................................................................27
10.3. CHARGING THE BATTERY............................................................................................................................................27
10.4. MASTERMIND TCD-w CHARGE LEVEL DISPLAY.....................................................................................................29
10.5. REMOVING & INSTALLING THE BATTERY ................................................................................................................30
10.6. CLEANING ..................................................................................................................................................................... 32
10.7. STORAGE....................................................................................................................................................................... 32
10.8. TRANSPORT ................................................................................................................................................................. 32
10.9. DISPOSAL ..................................................................................................................................................................... 32
10.10. BATTERY TECHNICAL DATA...................................................................................................................................... 33
10.11. CHARGER TECHNICAL DATA...................................................................................................................................... 33
11. SPECIFICATIONS...........................................................34
11.1. GENERAL SPECIFICATIONS.......................................................................................................................................... 34
11.2. TOOLS REQUIRED......................................................................................................................................................... 34
11.3. BOLT SIZE / TOOLS / TORQUE SPECIFICATIONS .....................................................................................................34
11.4. CUSTOMIZATION........................................................................................................................................................... 35
11.5. RECOMMENDED TIRE PRESSURES........................................................................................................................... 35
12. DRIVETRAIN WITH ENVIOLO HUB .....................................36
12.1. REMOVING AND RE-INSTALLING THE ENVIOLO EQUIPPED REAR WHEEL............................................... 36
12.2. DRIVETRAIN TENSIONING AND REAR WHEEL ALIGNMENT................................................................................. 39
12.3. SEATSTAY COUPLER..................................................................................................................................................... 41
12.4. ENVIOLO AUTOMATIQ IGH CALIBRATION................................................................................................................. 42
13. REGULATORY STATEMENTS .............................................42
14. EC/UK – DECLARATION OF CONFORMITY ............................43

1
Congratulations on the purchase of your new Specialized Turbo bike! Before we get you set up for your first ride, a few words about electric bikes.
As the name suggests, and unlike regular bicycles, Specialized electric bikes have very sophisticated and carefully engineered high-precision electrical components, including
a built-in custom motor drive unit, a high-performance battery integrated into the frame, sensors, one or more display units, and wiring throughout to make sure everything is
connected. You will also have a unique riding experience with added speed and acceleration from the motor support. Because of this, you need to treat your electric bicycle
differently from a regular bicycle and you need to be careful not to damage electrical components. This means you should not expose any electrical components to water (e.g., do
not pressure-wash your bicycle), drop or otherwise damage your battery, touch any live components, or open up or otherwise tamper with electrical components. This also means
you should be mindful your lithium-ion battery, when sufficiently charged, has enough energy stored to potentially start a fire and follow the instructions in this manual when it
comes to charging, transporting, cleaning, or storing your battery.
Not following these instructions may have serious consequences and can result in a fire, which may injure you and other people. Be sure you read this manual in its entirety and call
us if you have any questions.
WARNING! Be careful not to damage or expose electrical components to water. Do not pressure wash your battery, motor, or any other electrical components. Damaging
electrical components or exposing them to water may start a fire which can result in serious injury or even death.
WARNING! Always be present when charging your battery and disconnect it when it is fully charged. Do not leave your battery plugged in or let it charge overnight.
Immediately disconnect the battery from the charger when you encounter any problem during the charging process, e.g., when the charger or battery get extremely hot
or when the LED lights signal a problem. Failure to follow this warning can start a fire which can result in serious injury or even death.
SPECIALIZED BICYCLE COMPONENTS
15130 Concord Circle, Morgan Hill, CA95037 [phone]
0000168989_UM_R1 06/21
We may occasionally issue updates and addendums to this document. Please periodically check www.specialized.com or contact Rider Care to make sure you have the latest
information. Info: specialized.com / 877-808-8154

2
ENITESPTCNTCNSJP KR
1. INTRODUCTION
THIS USER MANUAL CONTAINS IMPORTANT INFORMATION. PLEASE READ CAREFULLY
AND STORE IN A SAFE PLACE.
This manual was drafted in the English language (Original instructions) and may have been
translated into other languages as applicable (translation of Original instructions).
This user manual is specific to your Specialized Turbo Como bicycle and should be read in
addition to the Specialized Bicycle Owner’s Manual (“Owner’s Manual”). It contains important
safety, performance, and technical information, which you should read before your first
ride and keep for reference. You should also read the entire Owner’s Manual because it has
additional important general information and instructions which you should follow. If you do
not have a copy of the Owner’s Manual, you can download it at no cost at www.specialized.
com, or obtain it from your nearest Authorized Specialized Retailer or Specialized Rider Care.
Please note all instructions and notices are subject to change and updates without notice.
Please visit www.specialized.com for periodic tech updates.
Additional safety, performance, and service information for specific components such as
suspension or pedals on your bicycle, or for accessories such as helmets or lights, may
also be available. Make sure that your Authorized Specialized Retailer has given you all the
manufacturers’ literature that was included with your bicycle or accessories. In case of a
conflict between the information in this user manual and information provided by a component
manufacturer, please contact your nearest Authorized Specialized Retailer.
The Como is classified as an EPAC (Electrically Power Assisted Cycle, otherwise known as a
Pedelec), and is referred to in this manual as a bicycle unless otherwise noted.
ADDITIONAL LANGUAGES ARE AVAILABLE FOR DOWNLOAD AT www.specialized.com.
When reading this user manual, you will note various important symbols and warnings, which
are explained below:
WARNING! The combination of this symbol and word indicates a potentially
hazardous situation which, if not avoided, could result in serious injury or
death. Many of the Warnings say “you may lose control and fall.” Because
any fall can result in serious injury or even death, we do not always repeat the
warning of possible injury or death.
CAUTION: The combination of the safety alert symbol and the word CAUTION
indicates a potentially hazardous situation, which, if not avoided, may result
in minor or moderate injury, or is an alert against unsafe practices.
The word CAUTION used without the safety alert symbol indicates a situation
which, if not avoided, could result in serious damage to the bicycle or the
voiding of your warranty.
INFO: This symbol alerts the reader to information which is particularly
important.
GREASE: This symbol means that high-quality grease should be applied as
illustrated.
TECH TIP: Tech Tips are useful tips and tricks regarding installation and use.
1.1. WARRANTY
Please refer to the written warranty provisions provided with your bicycle, or visit
www.specialized.com. A copy is also available at your Authorized Specialized Retailer.

3
2. COMO COMPONENTS
15
85 1
14
9
10
2
43 46 44
25
30
35
7
41
419 22 232021 11/12 131617
18
42 32 3336 3740 38 39
34
3
24
2.1
2.1

4
ENITESPTCNTCNSJP KR
26
4743 4546 44
29 28 25 31 30 27 28 26
42
18
6
27
ENVIOLO
AUTOMATIQ IGH
EQUIPPED
ENVIOLO MANUAL
IGH SHIFTER
1DOWN TUBE 17 DROPOUT HANGER*/
SLIDING DROPOUT* 33 FRONT BRAKE ROTOR
2SEAT TUBE 18 REAR DERAILLEUR* /
SHIFT INTERFACE* 34 REAR BRAKE CALIPER
3HEADTUBE 19 CHAINRING* /
SPROCKET* 35 REAR BRAKE ROTOR
4CHAINSTAY 20 CHAIN GUARD 36 SPOKE
5SEATSTAY 21 CHAINSTAY PROTECTOR 37 RIM
6SEATSTAY COUPLER* 22 CRANK ARM 38 HUB
7FORK 23 PEDAL 39 TIRE
8SADDLE 24 HEADSET 40 VALVE
9SEAT POST*** 25 INTEGRATED
HANDLEBAR 41 THRU-AXLE
10 SEAT POST CLAMP 26 GRIP 42 KICKSTAND
11 BATTERY LOCK
MECHANISM 27 SHIFTER* 43 REAR FENDER
12 CHARGING SOCKET 28 BRAKE LEVER 44 REAR RACK
13 BATTERY 29 REMOTE 45 PANNIER STOPPER
14 MOTOR 30 HEADLIGHT** 46 TAILLIGHT
15 MOTOR COVER 31 MASTERMIND TCD-W 47 GARMIN RADAR*
16 CASSETTE / SPROCKET* 32 FRONT BRAKE CALIPER
* Not all models are equipped with all the above components.
** Depending on the model the position of the lights may vary.
***Depending on the model the component may vary.

5
3. GEOMETRY
J
E
LG
I
D
H
C
M
K
F
N
B
A
3.1
INFO: The geometry as summarized in this manual is current as of the date this manual was written and is subject to change. Specialized reserves the right to change the
components at any time and without notice, including modifying, reducing, and/or adding features.

6
ENITESPTCNTCNSJP KR
FRAME SIZE S M L
ASTACK (mm) 644 665 676
BREACH (mm) 441 465 486
CHEADTUBE LENGTH (mm) 150 170 180
DHEADTUBE ANGLE (°) 67 67.5 68
EBB HEIGHT (mm) 275 275 275
FBB DROP (mm) 80 80 80
GTRAIL (mm) 103 99 96
HFORK LENGTH (FULL) (mm) 480 480 480
IFORK RAKE/OFFSET (mm) 44 44 44
JFRONT CENTER (mm) 732 759 779
KCHAINSTAY LENGTH (mm) 470.4 470.4 470.4
LWHEELBASE (mm) 1192 1218 1238
MSEAT TUBE LENGTH (mm) 450 450 460
NSEAT TUBE ANGLE (°) 73.8 73.3 73
CRANK LENGTH (mm) 170 170 170
HANDLEBAR WIDTH (mm) 680 680 680
SADDLE WIDTH (mm) 200 200 200
SEATPOST MAX INSERTION (mm) 220 240 250
SEATPOST MIN INSERTION (mm) 80 80 80
FORK TRAVEL (mm) 80 80 80

7
4. GENERAL INFORMATION ABOUT YOUR COMO
4.1. INTENDED USE
The Como is intended and tested for General Purpose Riding (Condition 2) use only.
CONDITION 2
Bikes designed for riding Condition 1, plus smooth gravel roads and
improved trails with moderate grades where the tires do not lose ground
contact.
INTENDED For paved roads, gravel or dirt roads that are in good condition, and bike
paths.
NOT
INTENDED
Not for off-road or mountain bike use, or any kind of jumping. Some of
these bikes have suspension features, but these features are designed
to add comfort, not off-road capability. Some come with relatively wide
tires that are well suited to gravel or dirt paths. Some come with relatively
narrow tires that are best suited to faster riding on pavement. If you ride on
gravel or dirt paths, carry heavier loads, or want more tire durability, talk to
your Authorized Specialized Retailer about wider tires.
The Como is classified as a Pedelec/EPAC. Regardless of its classification, it will provide
motor support only while pedaling. Depending on the classification, there can be different
requirements and regulations affecting your use of the bicycle.
INFO: Before using your Como bicycle, please inform yourself of all
applicable legal requirements and regulations in your country or state. There
may be restrictions on riding your Como bicycles on public roads, cycling
paths, and/or trails. There may also be applicable helmet requirements, age
restrictions or license or insurance requirements. Specialized does not, and
will not, make any promise, representation, or warranty regarding the use of
your Como bicycle. As laws and regulations regarding electric bicycles vary
by country and/or state and are constantly changing, please make sure to
obtain the latest information. You should also regularly see your Authorized
Specialized Retailer for updated information.
CAUTION: All Como bicycles have a fixed pre-set speed limit at which the
motor support will automatically shut off. Any unauthorized tampering with
the power output and/or system is prohibited and will void the warranty.
WARNING! Keep your feet on the pedals at all times during riding.
4.2. PEDELEC / EPAC
If your Como is classified as a Pedelec, your motor support will automatically shut off when you
reach a maximum assistance speed depending on the country of purchase. A driver’s license or
insurance is typically not required.
4.3. STRUCTURAL WEIGHT LIMITS
MODEL CARGO STRUCTURAL
(LB / KG)
REAR (LB / KG) FRONT (LB / KG)
ALL MODELS 59 / 27 33 / 15 300 / 136
STRUCTURAL WEIGHT LIMIT: The maximum total weight (rider and cargo) a bike is
designed and tested to support structurally.
CARGO WEIGHT LIMIT: The maximum cargo weight a bike has been designed and tested to
support structurally.
WARNING! The specified cargo weight limit applies only to compatible
front and rear racks and seat bags where indicated. In case the specified
cargo weight limit differs from the cargo weight limit specified by the rack
or seat bag manufacturer, always use the lowest limit. If you add any other
load-bearing accessories, including, but not limited to, baskets and child
carriers, you do so at your own risk in that these accessories have not been
tested for compatibility, reliability, or safety on your bicycle. Failure to follow
this warning may result in serious personal injury or death.
INFO: For more information on the intended use and structural weight limits
for the frame and components, please refer to the Owner’s Manual.

8
ENITESPTCNTCNSJP KR
5. GENERAL NOTES ABOUT RIDING
The Como motor provides pedal assistance only while you are pedaling and the bicycle is in
motion. The amount of pedal assistance will be higher or lower depending on the amount of
force applied to the pedals. If you stop pedaling, the motor will stop providing any assistance.
The Como bicycle can also be ridden like a normal bicycle without motor assistance by
switching the display to the OFF mode. The same applies if the battery charge drops below 4%.
The Como bicycle has a walk-assist mode (the motor engages without pedal force being
applied) which is designed to provide assistance when walking the bicycle up a hill, up to and
not exceeding a speed of 6 km/h (3.7 mph), so long as the (+) button is pressed down.
5.1. RIDING TIPS
Because of the electric motor assist, the Como offers a unique riding experience compared to
a bicycle without motor assist. Below are some riding tips which may also reduce component
wear and increase battery range:
Pay attention to your speed going into a corner and be sure to stop pedaling well before
entering the corner. Otherwise, you may carry too much speed when entering a corner.
Ride efficiently and look ahead. Any time braking force is applied, more energy is needed
to get the bicycle back up to speed.
Shift gears regularly to stay in an optimal cadence range and downshift before coming to a stop.
Reduce pedal force before initiating a gear shift to reduce drivetrain wear.
Braking while steering may reduce the ability to control your bicycle.
Check the tire pressure regularly. Low pressure can cause the tires to roll inefficiently.
Do not expose your bicycle to prolonged excessive heat (e.g. direct sunlight).
Only carry the cargo you need. More weight will drain the battery faster.
If your bicycle is exposed to cooler temperatures (0 °C - 32 °F), keep the bicycle stored
indoors until just before riding.
WARNING! The motor support is activated as soon as you step onto the pedals
and the bicycle is in motion. You should be seated on the bicycle and engage
at least one brake before starting to pedal. Do not put one foot on a pedal and
throw a leg over the bicycle, as it could accelerate unexpectedly. Failure to
follow this warning may result in serious personal injury or even death.
WARNING! The acceleration of an electric bicycle can be faster than
anticipated and may feel unusual at first. Before your first ride, you should
use the lowest power ECO mode and become familiar with the operation
of the electric bicycle by practicing starting and stopping, cornering, and
navigating obstacles in a safe environment away from other bicycles,
pedestrians, and/or vehicles. Due to the greater acceleration of an electric
bicycle, you should also pay particular attention to terrain conditions as you
may approach obstacles faster than expected. Please note the default motor
support mode upon startup is always SPORT (middle setting) mode.
CAUTION: The weight of your Como is significantly higher than a bicycle
without motor support. Use caution when handling the bicycle (including, but
not limited to parking, lifting, pushing, loading it into a car or onto a bicycle
carrier and unloading it).
CAUTION: Do not ride your Como without the battery installed. Riding
without a battery may damage exposed electrical components.
Make sure the battery mechanism is locked in place and the key is removed
before riding.
WARNING! Use caution when viewing or using the display while riding, as it
can be distracting and can lead to accidents. You should always stop before
changing settings or operating the various functions of the display.
5.2. BEFORE RIDING
Regardless of your experience level, you should read the “FIRST” section of your Owner’s
Manual (Bike Fit, Safety First, Mechanical Safety Check, and First Ride) and carry out all
important safety checks. In addition, make sure you are familiar with the following areas of the
bicycle that are specific to electric bicycles.
BEFORE YOUR FIRST RIDE:
BATTERY: Is the battery fully charged?
MASTERMIND TCD-w DISPLAY: Are you familiar with the function of the display features?
REMOTE: Are you familiar with the function of the buttons on the remote?

9
BEFORE EVERY RIDE:
BATTERY: Do you have sufficient battery charge?
MASTERMIND TCD-w DISPLAY: Is the display functioning correctly?
REMOTE: Do you know how to use the remote to change the motor support level from
OFF to ECO to SPORT to TURBO?
5.3. ENVIOLO AUTOMATIQ ACCELERATION
The enviolo system automatically shifts to a lower ratio when coming to a stop to ease the
required pedal force when you begin riding again. Within a few pedal strokes the pedal pace
(cadence) will then be regulated to your preset cadence.
5.4. KNOW YOUR RANGE
Know the range of your electric bicycle before you start your ride. You can calculate your range
by visiting www.specialized.com, selecting your Turbo bicycle model, then clicking on the
range calculator. In addition to the range calculator, we recommend using the Smart Control
feature in the Mission Control App to control your range.
5.5. REMOVABLE YELLOW STICKER
Your Como bicycle has a sticker adhered to the frame stating
the bicycle serial number. Remove this sticker from the
bicycle and place it on the last page of this manual for future
reference.
5.6. RIDING WITH KIDS
There are many different setups that allow you to ride with kids. Please look at the Riding
Safely section in the Owner’s Manual regarding general information and instructions on child
carriers or trailers.
If you regularly ride with kids on your bicycle, your Authorized Specialized Retailer should
conduct a periodic safety inspection.
WARNING! Riding with kids on your bicycle will affect the handling by altering
the center of gravity, weight, and balance. It may also negatively impact your
cornering ability, increase your stopping distance, and reduce your ability to
slow down and maneuver, especially at higher speeds or down a steep grade.
All of this can result in a loss of control, potentially causing serious injury and/
or death. You should also become familiar with and practice riding with the
accessory in a controlled environment away from traffic.
WARNING! Carrying a child on your Specialized bicycle is at your own risk.
If you choose to install an accessory on your Specialized bicycle such as an
axle-mounted trailer, carrier, or trailer cycle, make sure it is compatible and
refer to the manufacturer’s instructions and your Authorized Specialized
Retailer. While Specialized bicycles are generally designed and tested for
use by one person at a time, we were able to verify compatibility of certain
child-carrying devices with specific bikes when installed in accordance
with the manufacturer’s instructions. You should make sure your bicycle
is still safe to ride with the accessory installed and follow all of the safety
instructions given by the accessory manufacturer. Also, be sure to not
exceed the structural weight limit and cargo weight limit of the bicycle
if you use any bicycle-mounted child-carrying accessory except for an
axle-mounted trailer, in which case the tow limit is 132lbs / 60kg.
WARNING! Do not attach a child carrier, trailer, or similar accessory to a
composite or carbon fiber part or component, either directly or indirectly.
For example, do not attach a trailer to a rear axle when the rear triangle is
made of composite or carbon fiber. Likewise, do not attach a trailer cycle to
a composite or carbon seatpost or a child carrier to a composite or carbon
fork. Either may potentially apply unusual forces on your bicycle frame or
component which could result in damage and cause a complete failure, with
the risk of serious injury or death. If you have previously attached an accessory
to a composite or carbon fiber part or component, do not ride until you have
had your Authorized Specialized Retailer conduct a careful safety inspection.
Before riding with kids on your bicycle, please inform yourself of all
applicable legal requirements and regulations in your country and state.
There may be restrictions on riding your bicycle with certain or any
accessory(ies). This is especially true for electric and pedal-assist bicycles.

10
ENITESPTCNTCNSJP KR
6. GENERAL NOTES ABOUT MAINTENANCE
The Como is a high-performance bicycle. All regular maintenance, troubleshooting, repair, and parts
replacement must be performed by an Authorized Specialized Retailer. For general information
regarding the maintenance of your bicycle, please refer to the Owner’s Manual. In addition, routinely
perform a mechanical safety check before each ride as described in the Owner’s Manual.
Great care should be taken to not damage the frame material. Damage may result in a loss
of structural integrity, which may result in a catastrophic failure. This damage may or may
not be visible during inspection. Before each ride, and after any crash, you should carefully
inspect your bicycle for any gouging, scratches through the paint, chipping, bending, or
any other signs of damage. Do not ride if your bicycle shows any of these signs. After
any crash, and before you ride any further, take your bicycle to an Authorized Specialized
Retailer for a complete inspection.
While riding, listen for any creaks as a creak can be a sign of a problem with one or more
components. Periodically examine all surfaces in bright sunlight to check for any small
hairline cracks or fatigue at stress points, such as welds, seams, holes, and points of
contact with other parts. If you hear any creaks, see signs of excessive wear, discover any
cracks, no matter how small, or any damage to the bicycle, immediately stop riding the
bicycle and have it inspected by your Authorized Specialized Retailer.
Lifespan and the type and frequency of maintenance depends on many factors, such as
use, rider weight, riding conditions, and/or impacts. Additionally, the Como uses a power-
assisted drive system, which means more distance is covered in the same amount of
time. Components may be subject to increased wear at different rates, depending on the
component. Drivetrain and brake components are especially subject to wear. Periodically
have your Authorized Specialized Retailer inspect your bicycle and components for wear.
Exposure to harsh elements, especially salty air (such as riding near the ocean or in the winter),
can result in galvanic corrosion of components such as the crank spindle and bolts, which
can accelerate wear and shorten the lifespan. Dirt can also accelerate wear of surfaces and
bearings. The surfaces of the bicycle should be cleaned before each ride. The bicycle should
also be maintained regularly by an Authorized Specialized Retailer, which means it should be
cleaned, lubricated, and (partially) disassembled and inspected for signs of corrosion and/or
cracks . If you notice any signs of corrosion or cracking on the frame or any component, the
affected item must be replaced.
Regularly clean and lubricate the drivetrain according to the drivetrain manufacturer’s instructions.
Do not use a high pressure water spray to wash your bicycle. Even water from a garden
hose can penetrate seals and water may seep into components, such as cranks, bearings,
or electrical components, potentially causing damage. Use a clean, damp cloth and bicycle
cleaning agents (where appropriate) for cleaning.
Do not expose the bicycle to prolonged direct sunlight or excessive heat, such as inside a
car parked in the sun or near a heat source such as a radiator.
From time to time, clean the Speed Sensor magnet on the rear wheel with a soft cloth.
Depending on your ride conditions and brake pad choice, dirt and/or metal shavings can
collect on the Speed Sensor magnet, which could lead to interruptions in motor support or
wrong speed readings.
WARNING! Failure to follow the instructions in this section may result in
damage to the components on your bicycle and will void your warranty,
but, most importantly, may result in serious personal injury or death. If your
bicycle exhibits any signs of damage, do not use it and immediately bring it to
your Authorized Specialized Retailer for inspection.
WARNING! Use a repair stand to support the bicycle during assembly or
maintenance, and a bicycle rack for transportation.
When placing the frame and/or bicycle in a repair stand, clamp the stand to
the seatpost and not the frame. Clamping the frame can cause damage to
the frame that may or may not be visible, and you may lose control and fall.
WARNING! Always turn off the battery when not in use and/or when working
on the bicycle.
CAUTION: Do not open the motor assembly. The motor assembly is a
sealed maintenance-free system. Any work on the motor assembly must be
performed by a Specialized Service Center.
6.1. REPLACEMENT PARTS AND ACCESSORIES
Specialized replacement parts and accessories are available through your Authorized
Specialized Retailer.

11
7. GENERAL NOTES ABOUT ASSEMBLY
This user manual is not intended as a comprehensive use, service, repair, or maintenance guide.
Please see your Authorized Specialized Retailer for all service, repairs, or maintenance. Your
Authorized Specialized Retailer may also be able to refer you to classes, clinics, or books on bicycle
use, service, repair, and maintenance.
WARNING! Due to the complexity of the Como bicycle, proper assembly
requires a high degree of mechanical expertise, skill, training, and
specialty tools. Therefore, it is essential for your safety that the assembly,
maintenance, and troubleshooting be performed by an Authorized
Specialized Retailer. Before your first ride, make sure your components, such
as brakes and drivetrain, are assembled and adjusted in accordance with the
manufacturer’s instructions and are functioning properly.
WARNING! Many components on the Como, including, but not limited to the
motor, battery, display, and cable guides, are proprietary to the Como. Only
use originally supplied components and hardware at all times. The use of
other components or hardware will compromise the integrity and strength of
the assembly. Como specific components should only be used on the Como
and not on other bicycles, even if they fit. Failure to follow this warning could
result in serious injury or death.
WARNING! Never modify your frame or bicycle in any way. Do not sand,
drill, file, or remove parts from your bicycle. Do not install incompatible
components or hardware. Failure to follow this warning may result in serious
personal injury or death.
WARNING! Electrical components can be exposed when working on your
bicycle. Do not touch any part of the electrical system while under electric
charge. Do not expose the connections of the battery and frame to water. If
any live components or the battery are damaged, stop riding immediately and
bring your bicycle to your Authorized Specialized Retailer.
7.1. HEADSET BEARINGS
The headset uses a 1 1/8” (41.8 mm x 30.5 x 8 mm, 45 x 45°) Campagnolo Standard
compatible upper bearing and a 1.5” (51.8 mm x 40 x 8 mm, 45 x 36°) lowerbearing. Ensure
that replacement bearings are compatible with the Specialized headset specification. No tools are
needed for installation or removal of both bearings. Grease the bearing surfaces before installation.
7.2. SEATPOST MINIMUM AND MAXIMUM INSERTION
Both the frame and seatpost have minimum insertion requirements. In addition, the frame has
a maximum insertion requirement to prevent damage to the frame and seatpost.
A
B
C
7.1
Fig. 7.1
FRAME SIZE S M L
MIN INSERTION 80 mm 80 mm 80 mm
MAX INSERTION 220 mm 240 mm 250 mm

12
ENITESPTCNTCNSJP KR
MINIMUM INSERTION (A)
The seatpost must be inserted into the frame deep enough so the minimum insertion/
maximum extension (min/max) mark (C) on the seatpost is not visible. The frame requires a
minimum of 80 mm of insertion (A).
MAXIMUM INSERTION (B)
The seat tube is reamed to a specified maximum insertion depth for each frame size. This
ream depth limits the insertion depth of the seatpost. Please refer to the table under Fig. 7.1.
If the desired seat height cannot be achieved within the minimum and maximum insertion
requirements, the seatpost should be replaced with a shorter or longer one.
Once the saddle height is determined, torque the supplied seatpost collar bolt to 6.2 Nm / 55 in-lbf.
TECH TIP: The specified ream depths are listed in the table under Fig. 7.1.
The tolerance of the ream depth can vary from frame to frame. Install a
regular 34.9 seat post in the seat tube to verify the actual ream depth of the
frame.
WARNING! Failure to follow the seat post and frame insertion requirements
may result in damage to the frame and/or seat post, which could cause you
to lose control and fall.
If the seat post is cut short, the min/max mark on the seat post may no
longer be accurate. Before cutting the seat post, note the min/max depth
required by the seat post manufacturer.
WARNING! For general instructions regarding the installation of the seat
post, refer to the appropriate section in the Owner’s Manual. Riding with an
improperly tightened seat post can allow the saddle and seat post to slide
down, which can damage the frame and cause you to lose control and fall.
WARNING! Inspect the seat post and seat tube to ensure that there are
no burrs or sharp edges. Remove any burrs or sharp edges using fine-grit
sandpaper.
7.3. DERAILLEUR/DROPOUT HANGER
Non-enviolo Internal Geared Hub (IGH) equipped Como models are fitted with an Amazinger
2.1 derailleur hanger mounted directly at the rear dropout.
enviolo IGH equipped Como models have left and right adjustable sliding dropout hangers to
which the enviolo internal geared hub is mounted. These dropout hangers control the tension
of the belt and the alignment of the rear wheel.
INFO: Non-enviolo IGH equipped Como models are not compatible with an
enviolo IGH.
7.4. SPEED SENSOR
The Como is equipped with a speed sensor magnet, located on the rear hub/disc rotor
interface with either a 6 bolt rotor mounted (A) or a CenterlockTM (B) mounted version.
Dirt and/or metal debris may accumulate on the speed sensor magnet. Too much
accumulation may result in interruptions in motor support and/or inaccurate speed readings.
Regularly check your Speed Sensor magnet for an accumulation of dirt and/or metal debris, and
clean accordingly (A-B). The frequency of the cleaning depends on your riding conditions, ride
frequency, and/or brake pad material. Removing metal debris may require the use of a magnet
stronger than the speed sensor magnet.
7.2 a 7.2 b
WARNING! Be sure not to touch the speed sensor magnet while the wheel is
in motion. Also, the brake rotors may be extremely hot after riding.

13
7.5. FRONT RACKS MOUNT
An optional front rack can be fitted to the bicycle via mounts behind the faceplate on the head
tube.
C
AB
7.3
Fig. 7.3
Insert a 2.5 mm hex key into the screw hole (A) on the faceplate and loosen the bolt hidden
in the head tube (B), then remove the faceplate.
The faceplate covers 4 threaded bores (C) which are used to mount the front rack. See the
rack user manual for the proper installation procedure.
WARNING: The maximum allowed cargo weight is 27 kg for the rear rack and
15 kg for the front rack. In addition, make sure to not exceed the structural
weight limit of the bicycle as stated in the Owner’s Manual.
WARNING! Racks and baskets, especially when loaded, will affect the
handling of your bicycle by altering the center of gravity, weight, and balance.
Before your first ride, you should practice riding in a controlled environment.
WARNING! The optional front rack is attached to the front end of your
bicycle, and as a result, a proper and secure installation by your Authorized
Specialized Retailer is critical for your safety. Only use original hardware
at all times. Improper installation or adjustment may result in an accident,
which can cause serious personal injury.
WARNING! Correct tightening force on fasteners (nuts, bolts, screws) on
your bicycle is important. If too little force is applied, the fastener may not
hold securely. If too much force is applied, and the fastener can strip threads,
stretch, deform or break. Either way, an incorrect tightening force can result
in component failure, which can cause you to lose control and fall. Where
indicated, ensure that each bolt is torqued to specification. After your first
ride, and consistently thereafter, recheck the tightness of each bolt to ensure
secure attachment.
7.6. RACK ACCESSORY MOUNTS
7.4
Fig. 7.4
The rear rack is fitted with adjustable stoppers, these stoppers allow the use of a variety of
pannier bags and it stops the bag from sliding on the rail.

14
ENITESPTCNTCNSJP KR
To adjust the stopper loosen the bolts on the stopper and slide it forwards or backwards to
align with the pannier bag mounts then tighten it in the desired position.
The top plate of the rear rack offers the unique MIK HD mounting profile which allows for
easy fitment of a wide variety of accessories such as bags, baskets, and child seats fitted
with the MIK or MIK HD interface.
INFO: For more information on the MIK HD mounting system or accessories
visit the manufacturer’s website.
CAUTION: The maximum load capacity of the fitted rear rack is 27 kg,
however, the weight limit of the accessory may be lower. Always adhere to
the lower of the weight limits of either the rack or the accessory.
7.7. LIGHTING
All Como models are equipped with an LED headlight and taillight. The lights on the Como turn
on automatically when the bicycle is powered on. The light can be turned off while riding by
long pressing the (F1) button on the remote.
7.5
Fig. 7.5
The rear light is integrated into the rear rack and the headlight is mounted on the front fork.
INFO: After initiating charging, the lights automatically power off to conserve
energy.
INFO: The headlight and taillight spec and position may vary depending on
the bike model and country requirements.

15
7.8. INTEGRATED HANDLEBAR
The Como is equipped with a custom designed handlebar assembly which is setup differently
to other handlebars.
B
D
C
A
E
F
7.6
Fig. 7.6
When assembling the handlebar (A), secure the handlebar with the top cap and bolt (B)
first and then the steerer clamp (C). The steerer clamp is located behind a cover (D) on the
inside of the handlebar stem.
Align the holes in the top cap in line with the center of the bicycle (E).
Firmly seat the handlebar against the headtube before hand-tightening the top cap bolt
(B) using a 5 mm hex key. Make sure there is no play between the integrated handlebar,
handlebar spacer (F), and the headtube.
Using a T25 Torx key, lightly tighten the steerer clamp bolts (C) in an alternating pattern
until there are equal gaps on the clamp’s left and right side, then torque the bolts in an
alternating pattern to 6.2 Nm / 55 in-lbf.
7.9. MASTERMIND TCD-w MOUNTING BRACKET
The MasterMind TCD-w is permanently fitted to the bicycle and secured to the twist-lock
mount with a security screw. Removal of the display will require the removal of the entire
mounting bracket from the integrated handlebar.
B
A
E
H
I
G
D
C
F
H
7.7
Fig. 7.7
Align the base plate (A) with the top cap (B) and insert the mounting screw (C) into the rear
hole. Hand-tighten the screw using a 3 mm hex key.
Twist the adjustable base plate (D) into the base plate and insert the mounting screw (E)
through the forward hole. Hand-tighten the screw using a 3 mm hex key.
Twist the MasterMind TCD-w (F) into the twist-lock mount (G) and insert the security screw
(H) into the mount to prevent the MasterMind TCD-w from being removed. Hand-tighten
the screw using a Philips head screwdriver.
Insert the MasterMind TCD-w and twist-lock mount assembly into the adjustable base
plate. Insert the mounting screw (I) through the hole, then hand-tighten with a 3 mm hex key.

16
ENITESPTCNTCNSJP KR
8. SYSTEM INTERFACE
INFO: The functionality of the system interface as summarized in this manual
is current as of the date this manual was written and is subject to change.
Specialized reserves the right to change the functionality at any time and
without notice, including modifying, reducing, and/or adding features.
WARNING! Use caution when viewing or using the display while riding, as it
can be distracting and can lead to accidents. You should always stop before
changing settings or operating the various functions of the display. Do not
attempt to customize the pages or perform setup adjustments while riding.
8.1. MASTERMIND TCD-w (DISPLAY)
B
A
8.1
Fig. 8.1
All Como models are equipped with the MasterMind TCD-w display. The display turns on the
system and provides information on the display.
The MasterMind TCD-w is used to power the bike and on and off (A).
The USB-C port on the right side of the display (B) is for Specialized retailers and service
centers. Make sure the rubber port seal is firmly in place when the bicycle is in use.
The USB-C port can be used to charge your phone and other accessories with up to 1A current.
Do not expose the display to intense heat or sunlight for a prolonged period. This can
damage the display and/or battery.
Only use a damp or dry soft cloth to clean the display. Do not use harsh cleaning products.
Do not disassemble or drop the display.
Make sure the display and mount are firmly installed on the handlebar before riding.
8.2. STARTING THE SYSTEM ON THE MASTERMIND TCD-w
8.2
Fig. 8.2
To start the system, press and hold the POWER button located on the display until the
display turns on.
To power off the system, press the POWER button again.

17
8.3. HANDLEBAR REMOTES
B
A
C
8.3
Fig. 8.3
The handlebar remote is included on all Como models. It controls the level of motor support
and controls the functions and scrolling of the MasterMind TCD-w.
A: (+) (-) Support adjustment buttons. Navigating and setting up the MasterMind TCD-w.
Pressing and holding the (+) button activates the walk-assist mode.
B: Function buttons F1 and F2 (scrolling and setting up of the MasterMind TCD-w)
C: Compression screw (2 mm hex key 0.8 Nm / 7 in-lbf).
8.4. REMOTE FUNCTIONS
A
B
D
C
8.4
Fig. 8.4
A - F1 BUTTON:
• Toggles pages on the MasterMind TCD-w to show different fields such as odometer, speed,
and distance.
• Settings & menu navigating.
• Long press turns the lights on and off.
B - F2 BUTTON:
• ENVIOLO AUTOMATiQ HUB: Long press toggles between standard modes and Micro Tune.
• ENVIOLO AUTOMATiQ HUB: Short press toggles the enviolo cadence adjustment and
Assist / Micro Tune modes.
• STANDARD HUB: Long press toggles standard modes and Micro Tune mode.
• Settings & menu navigating.
C - (+) BUTTON:
• Short press increases the amount of support.
• Pressing and holding activates the walk-assist mode.
• ENVIOLO AUTOMATiQ PEDAL PACE: When activated, a short press increases the target
pedal pace on the enviolo hub.
D - (-) BUTTON:
• Short press decreases the amount of support.
• Long press resets the trip.
• ENVIOLO AUTOMATiQ PEDAL PACE: When activated, a short press decreases the target
pedal pace on the enviolo hub.
C&D - (-) (+) DUAL BUTTON PRESS:
• A long dual press opens the settings menu on the MasterMind TCD-w.

18
ENITESPTCNTCNSJP KR
8.5. SUPPORT MODES
The Como motor offers 6 Bike Assist Modes: TURBO, SPORT, ECO, OFF, SMART CONTROL,
and MICRO TUNE.
STANDARD BIKE ASSIST MODES:
TURBO MODE: Maximum power mode for high-speed sections and climbing.
SPORT MODE: Maximum control, with sufficient power on demand.
ECO MODE: Most efficient mode for maximum range while offering good power.
OFF MODE: The motor will not offer any assistance, but the display and lights will still
function.
SMART CONTROL MODE: The motor, while pedaling, adjusts the power output based on
the ride parameters determined in the Mission Control App.
TURBO
TURBO
SPORT
ECO
OFF
SMART
WALK
SPORT ECO
OFF WALK
SMART
8.5
Fig. 8.5
When changing support modes the color on the display will change based on the support
mode selected for quick reference.
(+) Button - Increases the amount of support.
(-) Button - Decreases the amount of support.
INFO: On the remote, after reaching the strongest or weakest mode, the system
will not continue to switch. To reduce from TURBO to SPORT to ECO to OFF, you
have to press the (-) button. To increase from OFF to ECO to SPORT to TURBO,
you have to press the (+) button.
INFO: The Smart Control mode is only accessible when the bicycle is
connected to Mission Control and Smart Control mode is turned on. When
more or less motor support is needed or desired, Smart Control can be
bypassed for a short period of time by toggling between the OFF/SMART/
TURBO modes. Smart Control will then automatically reactivate after a short
period of time. Smart Control mode can only be turned off in Mission Control.
MICRO TUNE MODE:
1
SEC
100
90
80
70
60
50
40
30
20
10
8.6
Fig. 8.6
Micro Tune mode allows you to simultaneously change the support and peak power in 10%
increments whilst riding. When activated the Micro Tune setting will show in the top left corner
of the display.
Short-pressing the F2 button on the remote will switch to Micro Tune mode.
Use the (+) (-) buttons to increase or decrease the value.
To switch out of Micro Tune and back to standard modes, short-press the F2 button.
