1. INTRODUCTION
IMPORTANT:
This user manual is specific to your Specialized Turbo VADO bicycle (the VADO) and should be read in addition to the
Specialized Bicycle Owner’s Manual (“Owner’s Manual”). It contains important safety, performance and technical
information, which you should read before your first ride and keep for reference. You should also read the entire Owner’s
Manual, because it has additional important general information and instructions which you should follow. If you do
not have a copy of the Owner’s Manual, you can download it at no cost at www.specialized.com, or obtain it from your
nearest Authorized Specialized Retailer or Specialized Rider Care.
Additional safety, performance and service information for specific components such as suspension or
pedals on your bicycle, or for accessories such as helmets or lights, may also be available. Make sure that your
Authorized Specialized Retailer has given you all the manufacturers’ literature that was included with your bicycle
or accessories. In case of a conflict between the information in this user manual and information provided by a
component manufacturer, please contact your nearest Authorized Specialized Retailer.
Depending on the model, the VADO is either a Pedelec (Pedal Electric Cycle), EPAC (Electrically Pedal Assisted
Cycle) or L1e S-Pedelec (Speed Pedelec), and is referred to in this manual as a bicycle unless otherwise noted.
ADDITIONAL LANGUAGES ARE AVAILABLE FOR DOWNLOAD AT www.specialized.com.
When reading this user manual, you will note various important symbols and warnings, which are explained
below:
WARNING! The combination of this symbol and word indicates a potentially hazardous
situation which, if not avoided, could result in serious injury or death. Many of the Warnings
say “you may lose control and fall.” Because any fall can result in serious injury or even death,
we do not always repeat the warning of possible injury or death.
CAUTION: The combination of the safety alert symbol and the word CAUTION indicates a
potentially hazardous situation, which, if not avoided, may result in minor or moderate injury,
or is an alert against unsafe practices.
The word CAUTION used without the safety alert symbol indicates a situation which, if not
avoided, could result in serious damage to the bicycle or the voiding of your warranty.
INFO: This symbol alerts the reader to information which is particularly important.
TECH TIP: Tech Tips are useful tips and tricks regarding installation and use.
GREASE: This symbol means that high quality grease should be applied as illustrated.
CARBON FRICTION PASTE: This symbol means that carbon friction paste should be applied as
illustrated to increase friction.
TORQUE: This symbol highlights the correct torque value for a specific bolt. In order to achieve
the specified torque value, a quality torque wrench must be used.
1.1. WARRANTY
Please refer to the written warranty provisions provided with your bicycle, or visit www.specialized.com. A copy is
also available at your Authorized Specialized Retailer.

2
2. VADO COMPONENTS
24 22
20 2319
27 25 21
26
8
9
45
41
35
3
18
4
2
37
34
39
38
42
7
44
46
47
6
43
13
14
5
12
11
36
40
10
15 16 17
1
29
33
29
30
32
31
28
1. Top tube
2. Down tube
3. Seat tube
4. Head tube
5. Chainstay
6. Seatstay
7. Fork
8. Saddle
9. Seatpost
10. Seatpost clamp
11. Cassette
12. Derailleur hanger
13. Rear derailleur
14. Chain
15. Chainring
16. Crank arm
17. Pedal
18. Motor
19. Handlebar
20. Grip
21. Shifter
22. Brake lever
23. Remote**
24. Mirror*
25. Headlight
26. Display
27. Stem
28. Headset
29. Battery
30. Charging socket
31. Lock
32. Power switch
33. Front brake caliper
34. Front brake rotor
35. Rear brake caliper
36. Rear brake rotor
37. Spoke
38. Rim
39. Tire
40. Hub
41. Valve
42. Quick-release
43. Kickstand
44. Rear rack
45. Taillight
46. License plate*
47. Fender
* 45 km/h VADO version only
** Left side on 25 km/h (20 mph USA) VADO version only

3
3. GENERAL INFORMATION ABOUT YOUR VADO
3.1. INTENDED USE
The VADO is intended and tested for General Purpose Riding (Condition 2) use only. For more information on intended
use and structural weight limits for the frame and components, please refer to the Owner’s Manual.
The VADO is classified either as a Pedelec/EPAC or an S-Pedelec. Regardless of its classification, it will provide
motor support only while pedaling. Depending on the classification, there can be different requirements and
regulations affecting your use of the bicycle.
Before using your VADO bicycle, please inform yourself of all applicable legal requirements and
regulations in your country or state. There may be restrictions on riding your VADO bicycles on
public roads, cycling paths, and/or trails. There may also be applicable helmet requirements,
age restrictions or license or insurance requirements. Specialized does not, and will not, make
any promise, representation, or warranty regarding the use of your VADO bicycle. As laws and
regulations regarding electric bicycles vary by country and/or state and are constantly changing,
please make sure to obtain the latest information. You should also regularly see your Authorized
Specialized Retailer for updated information.
CAUTION: All VADO bicycles have a fixed pre-set speed limit at which the motor support will
automatically shut off. Any (attempted) tampering with the power output and/or system is
prohibited and will void the warranty.
3.2. PEDELEC / EPAC
If your VADO is classified as a Pedelec, your motor support will automatically switch off when you reach a maximum
speed of 25 km/h (15.5 mph) or 20 mph in the US. A driver’s license or insurance is typically not required.
3.3. L1e S-PEDELEC (SPEED PEDELEC)
If your VADO is classified as a S-Pedelec, your motor support will automatically switch off when you reach a
maximum speed of 45 km/h (28 mph). A driver’s license or insurance may be required.
In many countries, S-Pedelecs are considered motor vehicles and may require an operating license and insurance.
There may also be requirements for tire tread depth, use of rear view mirrors, license plates, head and tail lights.
3.4. STARTING THE SYSTEM
80-100%
60-79%
40-59%
20-39%
0-19%
1
To start the system, press and hold the power button
(fig.1) located on the top of the battery, until the LEDs
glow green. The number of LEDs that glow green will
depend on the level of charge in the battery.
To turn the battery (and support) off again, press and
hold the power button until the LEDs turn off.

4
4. GENERAL NOTES ABOUT ASSEMBLY
This user manual is not intended as a comprehensive use, service, repair or maintenance guide. Please see your
Authorized Specialized Retailer for all service, repairs or maintenance. Your Authorized Specialized Retailer may
also be able to refer you to classes, clinics or books on bicycle use, service, repair, and maintenance.
WARNING! Due to the complexity of the VADO bicycle, proper assembly requires a high degree of
mechanical expertise, skill, training and specialty tools. Therefore, it is essential for your safety that
the assembly, maintenance and troubleshooting be performed by an Authorized Specialized Retailer.
WARNING! Do not sand, drill, file or remove parts from your bicycle. Do not install incompatible
components or hardware. Failure to follow this warning may result in serious personal injury or death.
WARNING! Electrical components can be exposed when working on your bicycle. Do not touch
any part of the electrical system while under electric charge. Do not expose the connections of
the battery and frame to water. If any live components or the battery are damaged, stop riding
immediately and bring your bicycle to your Authorized Specialized Retailer.
4.1. BOTTOM BRACKET
Your VADO frame does not require any bottom bracket or head tube pre-installation preparation. All surfaces are
already prepared from the factory.
4.2. HEADSET
The VADO frames use a 1 1/8” (41.8mm x 8mm x 45°) Campagnolo Standard compatible top and bottom bearing.
Ensure that replacement bearings are compatible with the Specialized headset specification. No tools are needed
for installation or removal of both bearings. Grease bearing surfaces before installation.
4.3. SPEED SENSOR
When assembling the rear brake disc, the Speed Sensor Magnet must be installed on the rotor (fig.2). Four of the
six bolts are standard rotor bolts. The remaining two bolts (M5 x 0.8 pitch x 15mm length, with countersunk flat
head) attach the Speed Sensor Magnet to the rotor.
2
STANDARD
ROTOR
BOLTS
FLAT HEAD
M5 x 15mm
SPEED SENSOR MAGNET
DISC BRAKE ROTOR

5
4.4. SEATPOST
When inserting the seatpost into the seat tube, the seatpost must not extend out of the seat tube beyond the
minimum insertion/maximum extension line (min/max) on the seatpost. If the seatpost is at the min/max line and
the saddle is not high enough, the seatpost must be replaced with a longer one. For general instructions regarding
the installation of the seatpost, refer to the appropriate section in the Owner’s Manual.
The VADO frames have a 30.9mm seatpost diameter and require that the seatpost have a tolerance of 30.78mm to
30.95mm.
WARNING! Failure to follow seatpost related min/max requirements may result in damage to the
frame and/or seatpost, which could cause you to lose control and fall.
If the seatpost is cut short, the min/max mark on the seatpost may no longer be accurate. Before
cutting the seatpost, note the min/max depth required by the seatpost manufacturer.
WARNING! Riding with an improperly tightened seatpost can allow the saddle to turn or move and
cause you to lose control and fall.
CAUTION: Inspect the seatpost and seat tube to ensure that there are no burrs or sharp edges.
Remove any burrs or sharp edges using fine grit sandpaper.
4.5. REPLACEMENT PARTS AND ACCESSORIES
Specialized replacement parts and accessories are available through your Authorized Specialized Retailer.

6
5. GENERAL NOTES ABOUT RIDING
The VADO motor provides pedal assistance only while you are pedaling and the bicycle is in motion. The amount
of pedal assistance will be higher or lower depending on the amount of force applied to the pedals. If you stop
pedaling, the motor will stop providing any assistance.
The VADO bicycle can also be ridden as a normal bicycle without motor assistance by switching the display to the
OFF mode. The same applies if the battery charge drops below 1%.
The VADO bicycle has a walk-assist mode (the motor engages without pedal force being applied) which is designed
to provide assistance when walking the bicycle up a hill, up to a speed of 6 km/h (3.7 mph), so long as the + button
is pressed down.
5.1. RIDING TIPS
Because of the electric motor assist, the VADO offers a unique ride compared to a bicycle without motor assist.
Below are some riding tips which may also reduce component wear and increase battery range:
Pay attention to your speed going into a corner and be sure to stop pedaling well before entering the corner.
Otherwise you may carry too much speed as you enter the corner.
Ride efficiently and look ahead. Any time braking force is applied, more energy is needed to get the bicycle back
up to speed.
Shift gears regularly to stay in an optimal cadence range and downshift before coming to a stop.
Reduce pedal force before initiating a gear shift to reduce drivetrain wear.
Check the tire pressure regularly. Low pressure can cause the tires to roll inefficiently.
If your bicycle is exposed to cooler weather, keep the battery stored indoors until just before riding.
Do not expose your bicycle to prolonged excessive heat (e.g. direct sunlight).
Only carry the cargo you need. More cargo weight requires more energy to move.
WARNING! The acceleration of an electric bicycle can be faster than anticipated and may feel
unusual at first. Before your first ride, you should use the lowest power ECO mode and become
familiar with the operation of the electric bicycle by practicing starting and stopping, cornering
and navigating obstacles in a safe environment away from other bicycles, pedestrians and/or
vehicles. Please note the default motor support mode upon startup is always SPORT mode.
WARNING! The motor support is activated as soon as you step onto the pedals and the bicycle
is in motion. You should be seated on the bicycle and engage at least one brake before starting
to pedal. Do not put one foot on a pedal and throw a leg over the bicycle, as it could accelerate
unexpectedly. Failure to follow this warning may result in serious personal injury or even death.
WARNING! Since the motor support allows for greater speeds and acceleration, you should pay
particular attention to terrain conditions, other riders, pedestrians, and/or cars when riding. You
may approach obstacles much faster than expected.
CAUTION: The weight of your VADO is significantly higher than a bicycle without motor support.
Use caution when handling the bicycle (including, but not limited to parking, lifting, pushing,
loading it into a car or onto a bicycle carrier and unloading it).
CAUTION: During extended rides up steep grades, the motor may become very hot. Let it cool
down before touching it.
CAUTION: Do not ride your VADO without the battery installed. Riding without a battery may
damage exposed electrical components.

7
5.2. BEFORE YOUR FIRST RIDE
Regardless of your experience level, you should read the “FIRST” section of your Owner’s Manual (Bike Fit, Safety
First, Mechanical Safety Check and First Ride) and carry out all important safety checks. In addition, make sure you
are familiar with the following areas of the bicycle that are specific to electric bicycles.
BEFORE EVERY RIDE
Battery
• Are all connections plugged in correctly?
• Do you have sufficient battery charge?
• Is the battery properly inserted and locked in the frame?
Display
• Is the display functioning correctly?
BEFORE YOUR FIRST RIDE
Battery
• Is the battery fully charged?
Display
• Are you familiar with the function of the display features?
Remote
• Are you familiar with the function of the buttons on the remote?
• Do you know how to use the remote to change the motor support level from ECO to SPORT to TURBO?
WARNING! If your battery, charger or other component exhibits any signs of damage, do not use
the bicycle and immediately bring it to your Authorized Specialized Retailer for inspection.
5.3. RIDING WITH KIDS
There are many different setups that allow you to ride with kids. Please look at the Riding Safely section in the
Owner’s Manual regarding general information and instructions on child carriers or trailers.
WARNING! Specialized bicycles are only designed and tested for use by one person at a time.
Carrying a child on your Specialized bicycle is at your own risk. If you choose to install an
accessory on your Specialized bicycle such as a trailer, carrier, or trailer cycle, make sure it is
compatible and refer to the manufacturer’s instructions and your Authorized Specialized Retailer.
You should make sure your bicycle is still safe to ride with the accessory installed. Be sure to not
exceed the structural weight limit of the bicycle if you use a trailer, trailer cycle or child carrier.
Also make sure not to exceed the maximum cargo weight if you use a child carrier.
If you regularly ride with kids on your bicycle, your Authorized Specialized Retailer should conduct a periodic safety
inspection.
WARNING! Riding with kids on your bicycle will affect the handling by altering the center of gravity,
weight and balance. It may also negatively impact your cornering ability, increase your stopping
distance and reduce your ability to slow down and maneuver, especially at higher speeds or down
a steep grade. All of this can result in a loss of control, potentially causing serious injury and/or
death. You should also become familiar with and practice riding with the accessory in a controlled
environment away from traffic.
Before riding with kids on your bicycle, please inform yourself of all applicable legal requirements
and regulations in your country and state. There may be restrictions on riding your bicycle with
certain or any accessory(ies). This is especially true for electric and pedal-assist bicycles.
WARNING! Do not attach a child carrier, trailer or similar accessory to a composite or carbon
fiber part or component, either directly or indirectly. For example, do not attach a trailer to a rear
axle when the rear triangle is made of composite or carbon fiber. Likewise, do not attach a trailer
cycle bicycle to a composite or carbon seatpost or a child carrier to a composite or carbon fork.
Either may potentially apply unusual forces on your bicycle frame or component which could
result in damage and cause a complete failure, with the risk of serious injury or death. If you have
previously attached an accessory to a composite or carbon fiber part or component, do not ride
until you have had your Authorized Specialized Retailer conduct a careful safety inspection.

8
6. GENERAL NOTES ABOUT MAINTENANCE
The VADO is a high performance bicycle. All regular maintenance, troubleshooting, repair and parts replacement
must be performed by an Authorized Specialized Retailer. For general information regarding maintenance of your
bicycle, please refer to the Owner’s Manual. In addition, routinely perform a Mechanical Safety Check before each
ride, as described in the Owner’s Manual.
• Great care should be taken to not damage carbon fiber or composite material. Any damage may result in a loss of structural
integrity, which may result in a catastrophic failure. This damage may or may not be visible in inspection. Before each ride,
and after any crash, you should carefully inspect your bicycle for any fraying, gouging, scratches through the paint, chipping,
bending, or any other signs of damage. Do not ride if your bicycle shows any of these signs. After any crash, and before you
ride any further, take your bicycle to an Authorized Specialized Retailer for a complete inspection.
• Lifespan and the type and frequency of maintenance depends on many factors, such as frequency and type of use, rider
weight, riding conditions and/or impacts. Additionally, the VADO uses a power-assisted drive system, which means more
distance is covered in the same amount of time. Components may be subject to increased wear at different rates, depending
on the component. Drivetrain and brake components are especially subject to wear. Periodically have your Authorized
Specialized Retailer inspect your bicycle and components.
• Exposure to harsh elements, especially salty air (such as riding near the ocean or in the winter), can result in galvanic
corrosion of components, which can accelerate wear and shorten the lifespan. Dirt can also accelerate wear of surfaces
and bearings. The surfaces of the bicycle should be cleaned before each ride. Proper care and regular maintenance can help
increase the longevity of components. If you notice any signs of corrosion or cracking on the frame or any component, the
affected item must be replaced.
• While riding, listen for any creaks, as a creak can be a sign of a problem with one or more components. Periodically examine
all surfaces in bright sunlight to check for any small hairline cracks or fatigue at stress points, such as welds, seams, holes,
and points of contact with other parts. If you hear any creaks or discover any cracks, no matter how small, or any damage
to components, immediately stop riding the part and have it inspected by your Authorized Specialized Retailer. The bicycle
should also be maintained regularly by an Authorized Specialized Retailer, which means it should be cleaned, inspected
for signs of corrosion and/or cracks and lubricated. Regularly clean and lubricate the drivetrain according to the drivetrain
manufacturer’s instructions.
• Do not use a high pressure water spray directly on the bearings. Even water from a garden hose can penetrate bearing seals
and crank interfaces, which can result in increased bearing and crank wear, which can affect the normal function of the
bearings. Use a clean, damp cloth and bicycle cleaning agents for cleaning.
• Do not expose the bicycle to prolonged direct sunlight or excessive heat, such as inside a car parked in the sun or near a
heat source such as a radiator.
WARNING! Failure to follow the instructions in this section may result in damage to the components
on your bicycle and will void your warranty, but, most importantly, may result in serious personal injury
or death. If your bicycle exhibits any signs of damage, do not use it and immediately bring it to your
Authorized Specialized Retailer for inspection.
CAUTION: Do not open the motor assembly. The motor assembly is a sealed maintenance-free
system. Any work on the motor assembly must be performed by a Specialized Service Center.
Your bicycle should be inspected and serviced by your Authorized Specialized Retailer on a regular
basis, depending on use. The first inspection should be performed within 200 km / 120 miles. See
detailed service schedule on page 28.
WARNING! Always turn off the battery when not in use and/or when working on it.

9
7. REPLACING PARTS ON YOUR L1e S-PEDELEC
The VADO bicycle, as originally spec’d, is approved as a Pedelec or an L1e S-Pedelec. If you change components
on the bicycle, it may no longer be approved by your local regulatory authority Below is a general summary of
components that may affect governmental approval if changed.
Make sure to consult with your local regulatory authority when making any modifications. Refer also to the
appropriate section in the Owner’s Manual about changing components or adding accessories.
S-PEDELEC ONLY: The following parts are type approved and need to carry an e-mark:
LIGHTS REAR VIEW MIRROR RETRO REFLECTORS
HORN
PEDELEC AND S-PEDELEC: The following parts must only be replaced with original components:
FRAME ELECTRIC CONTROLLERS FENDERS
FORK ELECTRIC WIRING BRAKES
MOTOR UNIT HANDLEBAR REMOTE BRAKE PADS
BATTERY DISPLAY BRAKE HOSES
CHARGER CRANKSET
SENSORS REAR RACK
The following parts do not require type approval:
CHAINRINGS BOTTOM BRACKET STEM
CHAIN WHEELS HANDLEBAR
PEDALS (IF NOT WIDER) HUBS GRIPS
CASSETTE TIRES (IF ETRTO IS FOLLOWED) KICKSTAND
DERAILLEURS RIM TAPES SADDLE
SHIFTERS SPOKES SEATPOST
SHIFTING CABLES TUBES
SHIFTING HOUSINGS HEADSET

10
8. SYSTEM INTERFACE
Depending on the model, the VADO is equipped with either an LCD display or a TFT touch-enabled display.
WARNING! Use caution when viewing or using the display while riding, especially if the touch
controls are enabled, as it can be distracting and can lead to accidents. You should always stop
before changing settings or operating the various functions of the display.
The display must be connected when operating the bike. If it is removed from the mount, the motor will not work.
The handlebar remote (fig.3) controls certain functions of the display and the level of motor support.
-
+
25 km/h VADO: LIGHT
45 km/h VADO: HORN
SET
3
SET BUTTON: Allows for the user to toggle through the functions (trip distance, available range, ride time and
odometer). Also allows for the clock and unit (metric/imperial) to be adjusted.
+ BUTTON: Increases the amount of support. Pressing and holding activates the walk-assist mode.
- BUTTON: Decreases the amount of support.
LIGHT/HORN: Turns the light on/off (25 km/h or 20 MPH USA VADO models) or activates the horn (45 km/h
VADO models).
8.1. SUPPORT MODES
The VADO motor support is available in three different drive settings - TURBO, SPORT and ECO.
TURBO MODE: The motor, while pedaling, provides maximum (100%) support.
SPORT MODE: The motor, while pedaling, provides 50% support (default).
ECO MODE: The motor, while pedaling, provides 20% (default).
OFF MODE: The motor will not offer any assistance, but the display and lights will still function.
You can change between the different support modes (TURBO, SPORT and ECO) by pressing the +/- buttons on
the handlebar remote (fig.3).
To switch into a different support mode, press the +or -button on the remote. After reaching the strongest or
weakest mode, the system will not continue to switch. To reduce from TURBO to SPORT to ECO, you have to press
the -button. To increase from ECO to SPORT to TURBO, you have to press the +button.
The support modes affect how much support the motor delivers based on your pedaling input.
Generally, more support provides faster acceleration and easier climbing at the expense of shorter
range and greater chance of wheelspin. Lower power modes that provide less support result in
longer battery run times, longer range, and more control in situations where traction is limited. You
should experiment with the power settings that work best for your riding style and conditions.

11
8.2. DISPLAY FUNCTIONS (LCD DISPLAY)
HEADLIGHT
SPEED BATTERY
WARNING
TRIP DISTANCE
RIDE TIME
ODOMETER
METRIC / IMPERIAL
CLOCK (12/24hr)
BLUETOOTH
WALK-ASSIST
METRIC / IMPERIAL
- TRIP DISTANCE
- RIDE TIME
- ODOMETER
SUPPORT LEVEL
SETTING THE TIME / UNIT
To set the time, long-press the SET button once. When the
time is blinking, press the + and - buttons to adjust the time.
To set the unit (metric or imperial), long-press the SET
button twice, then toggle between the two units to choose
miles/12hr or kilometers/24hr.
To lock in the unit and time, press SET, wait or pedal the bike.
CHOOSING THE FUNCTION
To toggle between the different functions, press
and release the SET button.
• Trip distance
• Odometer
• Ride time
NOTE: The trip related functions automatically reset when the
system is shut off, but can be accessed through the app at any time.

12
OFF
ECO
SPORT
TURBO
ADJUSTING THE MOTOR SUPPORT
Press the “+” or “-” button to increase or decrease the level of
motor support.
TURNING THE LIGHT ON AND OFF
Press and release the light button to turn the light on or off.
ACTIVATING THE WALK-ASSIST MODE
To activate the walk-assist mode, press and hold the “+” button
at any time. Once released, the walk-assist will shut off.
The maximum speed of the walk-assist mode is 6 km/h (3.7 mph).

13
8.3. DISPLAY FUNCTIONS (TFT DISPLAY)
20
12:34
km/h
99km TURBO
BLUETOOTH
SPEED
METRIC / IMPERIAL
SUPPORT LEVEL
MENU
HOME
CLOCK (12/24hr)
HEADLIGHT
METRIC / IMPERIAL
RANGE
REMAINING CHARGE
HISTORY / BACK
GPS
WALK-ASSIST
The display is controlled using the buttons on the handlebar remote (fig.3), as well as the three touch buttons below
the display and the touch-enabled display itself. The touch screen can be navigated using touch, swipe, pinch and
spread gestures.
The TFT display is equipped with a highly adjustable operating system that may improve over
time. Make sure you periodically visit your Authorized Specialized Retailer for potential software
updates to make sure you have the latest software and features.
20
12:34
km/h
99km TURBO
SETTING THE TIME / UNIT
The time and unit of measure can be set for 24hr / km/h or
12hr / mph.
To set the time and unit of measure, press the Menu button
and choose the desired function you wish to update.
The time can also be set automatically with the dealer
tool.

14
20
12:34
km/h
99km TURBO
TURBO
ECO
SPORT
OFF
ADJUSTING THE MOTOR SUPPORT
The VADO is equipped with several levels of motor support.
Press the “+” or “-” button on the remote to increase or decrease
the level of motor support.
25
22
70
WATT CADENCE
km/h
99km TURBO
12:34
POWER SCREEN
In addition to the Home screen information, the Power screen shows:
A graph illustrating the distribution of power between the rider
(left) and motor (right).
Current rider watt-input and cadence.
22
12:34
km/h
99km TURBO
1987 45
CLIMB SLOPE
o/o
ENVIRONMENT SCREEN
In addition to the Home screen information, the Environment screen
shows:
A graph illustrating the elevation profile for the last 5km (3 miles).
Current meters or feet climbed.
Current slope.
1

15
MAP SCREEN
In addition to the Home screen information, the Map screen shows:
The rider’s current position.
A trace of the distance covered or a planned route.
The rider can interact with the map by:
Pinching and spreading to zoom in and out.
Swiping to move the map.
Change between North-facing and Direction-facing.
Centering the map (when not centered).
20
12:34
km/h
99km TURBO
12:34
MENU
Trips 234
Settings
FUNCTIONS/MENU
The menu, accessed by
pressing the square icon
below the screen provides
access to the following
functions:
Trips: Records trips from
when the power is turned
on to turned off.
Settings: Adjusts settings
for unit of measure, time,
battery display, language.
12:34
TRIPS
2.4.16
16:45 1,5 km
3.4.16
06:32 63,5 km
6.4.16
12:02 13 km
TRIP ARCHIVE
Saved trips can be accessed in sequential order, based on when
the ride took place.
Trips are started when the bike is powered up and stops when
the bike is powered down.
When accessing an archived trip, a screen similar to the Stop
Screen is shown (without battery information).

16
TRIP
40 km 03:30
TIME
12:34
27.10.2016
Delete this trip
ØSPEED
23 km/h
MAX SPEED
54 km/h
CLIMB
582 m1024 km
MAX HEIGHT
ARCHIVED TRIP
A user profile is created when a rider logs in and creates an
account by connecting to the bike via a smartphone.
All archived trips are associated to this account. The profile shows
the following information:
Date
Trip distance
Ride time
Route map
Total elevation gain
Maximum elevation reached
Ride profile graph
Average speed
Maximum speed
12:34
MENU
Touch Control
Battery
Units
Language
Bike
SETTINGS
The Settings menu provides access to the following functions:
Touch Control
Battery
Units
Language
Bike

17
12:34
TOUCH CONTROL
Always obey the traffic laws
and pay attention to traffic.
Standstill
Always
TOUCH CONTROL
Standstill: The setting means touch screen functionality is
disabled when riding (default).
Always: The setting means touch screen functionality is enabled
when riding.
12:34
BATTERY
Percent
Battery
100 o/o
BATTERY
The remaining charge of the battery can be displayed as:
Icon showing a visual of the remaining charge
Percent of the remaining charge
12:34
UNITS
Imperial
Metric
km & 24:00
UNITS
The rider can choose between Metric and Imperial units:
Km & 24:00hr
Miles & 12:00hr
