SPECIALIZED TURBO CREO SL
SERVICE & REPAIR WORKBOOK

Dear Specialized Retailer and Specialized Employee,
we are excited to present the all-new Turbo Creo SL! We’re going to flatten your climbs. We’re going to make you laugh at headwinds, ride farther, and go faster than you
ever imagined. That’s what our first Turbo road bike is all about. Because, let’s be honest, riding faster is just more fun.
Turbo Creo SL –It`s you, only faster.
About This Workbook
SBCU developed this Workbook to help you efficiently service Specialized Turbo Creo SL bicycles. In addition to this workbook, SBCU also offers you these resources:
•Workbook ‘Turbo SL Technology System: Features & Benefits’ -overs the Turbo SL Technology in detail
•Workbook ‘Turbo Creo SL: Features, Benefits & Guidelines’ -covers the Creo bike family in detail
•Resources on the Service Website -cover specific aspects around service & repair
•SBCU.com product videos -cover key product knowledge
•‘Turbo Creo SL Quick Start Guide’ -covers key usage tips (rider-facing)
Please refer to your market contacts for these assets in your language and go to the Service Website to access all technical documentation.
Our Asks For Using This Workbook
1. Keep it and its value within your business -this document is meant to be a source of knowledge exclusively for Turbo Retailers and Specialized staff
2. Save this PDF to all your PCs for quick access
3. Go through it at least once in its entirety so that you know the content
4. Use the clickable table of contents to find your desired topic
5. Use the search function (Ctrl+f) to scan the document for key words
6. Use it to host product presentations to your teams and colleagues
We are confident this Workbook quickly turns into a key element for lasting success in your environment.
-The Specialized Turbo Team
Disclaimer: The content of this Workbook was compiled according to best knowledge and with greatest care. Yet, all data is subject to change. Regular corrections and additions will make sure the content stays up-to-date.

CREO SL SERVICE & REPAIR WORKBOOK: INDEX
CREO SL SYSTEM COMPONENTS
UNBOXING & BIKE BUILDING
WIRING & CABLING SCHEME
TURBO CONNECT UNIT
SPEED SENSOR SYSTEM
REPLACING NON-TURBO CABLING
CHARGE PORT & MAIN HARNESS
BASIC THEORY OF OPERATION
MOTOR & INTERNAL BATTERY
DIAGNOSTICS & TROUBLESHOOTING
MAINTENANCE & CLEANING TIPS
FIRMWARE UPDATES
SERVICE PARTS
BIKE PREP FOR RIDER HANDOVER
REPLACING ELECTRONIC COMPONENTS
EXPERIENCE & MODELS
FOLLOW-UP CHECKLIST
NORMAL SYSTEM BEHAVIOR

EXPERIENCE & MODELS
CREO SL: SERVICE & REPAIR

TURBO CREO SL: EXPERIENCES
ENDURANCE ROAD (NON-EVO MODELS)GRAVEL (EVO MODEL)

TURBO CREO SL: EXPERIENCES
ENDURANCE ROAD (NON-EVO MODELS) GRAVEL (EVO MODEL)

TURBO CREO SL: MODEL OVERVIEW
MODEL FRAME FORK FUTURE
SHOCK MOTOR INT. BAT. RE BAT. UI DRIVETRAIN BRAKES WHEELS TIRES
SEATPOST
CREO SL SW
CARBON
FACT 11r
Disc FACT,
Full Carbon
Future Shock
Damped w/
lockout, 20 mm
travel
Specialized
SL 1.1 SBC-B15
320 WH
Included
(w/ Zee Cage,
retention strap,
Y-charge
cable) Turbo Connect
Unit (TCU) in
top tube
Dura-Ace Di2 Dura-Ace BR-
R9170
Roval Rapide CLX
50 Disc Boost
Turbo SW,
700x28
S-Works FACT
carbon
CREO SL
EXPERT
CARBON EVO
Not
included
(compatible)Ultegra Di2 Ultegra BR-
R8070
Roval C38 Disc
Boost
Pathfinder
Pro 2BR,
700x38
X-Fusion,
Manic, 50mm
Travel
CREO SL
EXPERT
CARBON
Turbo Pro,
700x28
S-Works FACT
carbon
MODEL OVERVIEW
1. THIS IS AHIGH-LEVEL OVERVIEW
2. FOR ALL SPECIFICATION DETAILS REFER TO THE CREO SL WORKBOOK

CREO SL SYSTEM COMPONENTS
CREO SL: SERVICE & REPAIR

CREO SL: SERVICE & REPAIR

Main Harness
Connects battery, motor, TCU and charge/RE port
Range Extender Battery (RE)
160 Wh, 48V
Sits in bottle cage
Connects to charge/RE port
Turbo SL 1.1 Motor
180% Rider Amplification, 2x Yo u
240 W nominal & peak power
35 Nm max. torque
1.95 kg
48V
Speed Sensor System
Frame and centerlock integration
TCU
Identical part as Levo2
Shows soc for both batteries
SL Charger
48V
Dedicated connector
Internal Battery
320 Wh, 48V
Integrated in
downtube
CREO SL: SYSTEM COMPONENTS

BASIC THEORY OF OPERATION
CREO SL: SERVICE & REPAIR

What happens when pressing
the TCU on-button?
• Switch in TCU closes circuit
• Wakeline activates battery
• Battery sends 48V to the
motor
• Battery sends 12V to the TCU
• TCU starts, LED display lights
up
• SL system is active

CREO SL: BASIC THEORY OF OPERATION
THREE COMPONENTS ARE PART OF THE CAN BIKE SYSTEM COMMUNICATION (COMPONENTS 'TALK' TO EACH OTHER)
1. TCU (MASTER WITHIN BIKE; CAPABLE OF INTERNAL AND EXTERNAL COMMUNICATION)
2. MOTOR
3. BATTERIES (INTERNAL AND/OR RANGE EXTENDER)
(SPEED SENSOR ACTS AS SWITCH, NOT PART OF THE CAN BIKE COMMUNICATION)
THIS HAPPENS WHEN TCU IS SWITCHED ON
•SWITCH IN TCU CLOSES WAKE LINE
•WAKE LINE ACTIVATES BATTERY (WAKE LINE GOES FROM TCU TO BATTERY)
•BATTERY SENDS 48V TO MOTOR AND 12V TO TCU (12V COME DIRECTLY FROM BATTERY)
•TCU STARTS, LEDS LIGHT UP (EVEN IF MOTOR IS NOT CONNECTED)
•SL SYSTEM IS ACTIVE
DIFFERENCE VERSUS LEVO2
ON A CREO, THE TCU ALSO STARTS WITHOUT A CONNECTED MOTOR (‘MOTOR NOT FOUND’ ON TCU), WHEREAS THE TCU OF A LEVO2 WOULD NOT
POWER ON WITH A DISCONNECTED MOTOR.
