Speco DVR-16TS/750 User manual

240/480fps Triplex Digital ideo Recorder
Family with Network/DDNS ideo Server
Specifications subject to change
For more information contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: [phone] or 631-957-3880
D R-16TS/750*
16 Channel Triplex MPEG-4 D R
240fps
D R-16TT/750*
16 Channel Triplex MPEG-4 D R
480fps - features real time recording
EZ Record: set the number of days you want to record and the D R takes care of the rest
EZ Copy: auto copy what you are playing onto a CD/RW or USB flash drive
EZ Set-Up: for quick Installation
ss Features
• Recording Rates: 240 & 480fps
• Free DDNS server for use with
dynamic P addresses
• Email notification of alarm event
• MPEG-4 high quality compression,
5~10 times smaller than MJPEG
• Triplex operation enabling simultaneous view
live or playback while continuing to record &
network transfer
• Remote monitoring, recording, playback,
change system settings and dome camera
control via Ethernet and/or nternet
• Jog shuttle for easy operation
• Real Time live display (DVR-16TT only)
• R Remote control included
• 1 Channel in out for audio recording
• 1 Optical drive + up to 3 internal HDD
• Extended storage up to 3TB
• Built-in CD-RW or DVD+RW for
video clip exporting
• USB 2.0 port for video clip exporting,
supports USB thumb drive
• Easy software upgrade via Network,
USB Thumb Drive, or CD-RW
• Configurable normal and event recording
frame rate & picture quality per channel
or globally via EZ record
• Multiple built-in dome camera protocol
(through RS485): including Pelco D,
Pelco P, AD422, Fastrax, DynaColor, JVC
• Automatic camera detection (Plug & Play)
• Digital Zoom 2 x 2 in live mode
• Covert camera operation provides
enhanced security and administrator control
• Dynamically programmable recording priority, motion
detection, alarms, and scheduling
• Programmable call-monitor switching sequence
• Up to 30 sec pre-alarm recording
• USB mouse support for user-friendly operation
• Multiple language on-screen menus
• Password to secure installation authorization
• Network software supports static P, DHCP,
PPPoE and DDNS
• Network hardware supports 10/100M bps
• Dimensions: 4 7/8" X 17 1/4" X 16 3/4"
• Weight: 18.45 lbs with 1 HDD (HDD weigh 1 Lbs)
• Power Consumption: Start up @ 90 Watts,
Running @ 60 Watts
• Heat Dissipation: 3.42 BTU/Minute
• HDD size: 750GB, 1.5TB, 2.25TB )
• Operating temperature: 14° F to 120° F
* Standard DVR comes with a 750GB HDD. Other configurations available up to 2.25 TB internal
DVR
User Manual
Software CD-ROM
Power Supply
3 Year Limited Warranty
R Remote Control
Package Includes:
Supercharged!
Turbo!

MODEL NAME D R-16TS/750 D R-16TT/750
Operation System Embedded ( Linux )
Video Standard NTSC/PAL switch
Video Operation Triplex+( Live, Record, Playback , Remote, and nternet access )
Resolution – Live Video NTSC: 720 x 480 pixels
nput
Video
Outputs
VGA Output 800 x 600, 1024 x 768, 1280 x 1024 pixels @ 60Hz
Live Picture Refresh Rate NTSC: 480 PPS(16CH)
Digital Zoom 2 x 2
Camera nstallation Plug & Play
nput RCA x 1, Line- n
Output RCA x 1, Line-Out
Recording Mode Always Real Time Record, Synchronized w/ Video
Audio Compression Method ADPCM, G.726
File Size 8KB/Sec
Operation Remote + VCR mode
Playback Only for Video Original Speed
Compression Method MPEG-4 Advanced Simple Profile
Recording Mode Continuous, Schedule, Alarm, Motion Detection
Pre-Alarm 0~30 sec
720x480: 60 pps
720x240: 120 pps
Recording 360x240: 240 pps
720x576: 50 pps
720x288: 100 pps
360x288: 200 pps
Recording Quality 8 levels presets, adjustable
mage Size 2K to 20K Byte/picture
Storage Mode Linear/Circular
Playback Play, Stop, Pause, Rewind, Forward, Search
Playback Playback Speed Adjustment Yes 1X, 2X…32X
Retrieve Date/Time, Event
Data Life Time Yes (Programmable)
Built-in Storage X2 ATA 133 / UDMA 133 DE, HDD/CD-RW/DVD+RW
Storage Built-in HDD Up to 3 built-in HDDs
External Storage NAS 1GB Ethernet Port
Export X3 USB2.0 ports, support ThumbDrive®, CD-RW, or DVD+RW
Alarm nput X16, Terminal Block
Alarm Detection N.C./N.O., Programmable
Alarm Auditory Alert Built-in Buzzer
Motion Detection 21 X 13(NTSC), 21 X 16(PAL) Grid Array,
Sensitivity, Trig Level Adjustable
Video Loss Detection Programmable
Alarm Relay Output X2, Terminal Block, 1.0A/24V (Programmable)
Network Connectivity Ethernet RJ-45 connector, 10/100Mbps, supports DHCP/PPPoE/DDNS
Remote Control Software nternet Explorer
Communication Access Control 2 Level Password
Remote Operation Monitoring, Playback, Recording, System Setup, Dome Camera Control
RS232C D-sub 9 pin female
RS485 Terminal Block
Dome Control Protocol DynaColor, Pelco P, Pelco D, AD422, Fastrax, JVC, DynaColor
Specifications: 16 Channel Triplex Digital ideo Recorder Family with network/DDNS ideo Server
BNC x 16,
1.0Vp-p/75
ohm
Main Monitor
Call Monitor
Loop
BNC x 1, S-Video x 1, 1.0Vp-p/75 ohm
BNC x 1, 1.0Vp-p/75 ohm
BNC x 16,
1.0Vp-p/75
ohm
Resolution
& Rate
NTSC
PAL
For more information contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: [phone] or 631-957-3880
120 pps
240 pps
480 pps
100 pps
200 pps
400 pps
