Speco HT-7715DNV User manual

Color Day/Night Weatherproof Camera
Specifications
ImageSensor ..................1/3” Sony ExView* CCD
Resolution ....................470 lines
Minimum Illumination .............0.03 lux (IR off) 0.00 lux (IR on)
Lens ........................DC Auto iris, 4mm-9mm (Varifocal)
CDS Sensor ...................Photoconductive cells - adjustable
Electronic Shutter ...............1/60 - 1/100,000 seconds
Video Output ..................1.0 Vp-p into 75 ohms composite
TV System ....................NTSC
Scanning System ................2:1 Interlace
Sync System...................Line locked/ adjustable V-phase
Line lock/internal on-off
S/N Ratio ....................More than 60 dB
Gamma Characteristic ............0.45
Power Supply ..................24 Volts AC, 12 Volts DC- dual voltage
Power Consumption ..............600mA
Operating Temperature ............-20˚F to 122˚F - RH 95%
Dimensions ...................2.4”W x 2.25”H x 7”L
Weight ......................1lb.
*ExView is a trademark of the Sony Corporation
**Depending on scene reflection
Specifications subject to change
For moreinformation contact us at:
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: [phone] or 631-957-3880
Package Includes:
Features
•1/3" SONY ExView* CCD sensor - 470 lines of resolution • Split Glass Technology to avoid IR reflections
•Auto iris DC Vari-Focal Lens (4mm-9mm)
•LUX level dip switch adjusts day/night settings to your requirements
•Dual voltageoperation • Built-in 11 IR LEDs (60’ Range**) & CDS sensor for day/night performance
• Controls for BLC, ELC, F/L and L/L • Video Test Connector for easy installation
•Built-in heater extends operating range and avoids condensation • Weatherproof operation
•Excellent low light level performance - 0.03 Lux in existing light, 0.0 Lux with IR LEDs
HT-7715DNV
HT-7715DNV Camera Instructions Video Test Cable
Mounting Hardware Warranty card
