Spirit Inspire ZE20 User manual

PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE
OPERATING YOUR NEW ELLIPTICAL!
Z100 / Z300 Z500 Z700
OWNER’S MANUAL

ZE20
1
Product Registration………………………………………………………….. 2
Important Safety Instructions………………………………………………… 3
Important Electrical Information…………………..……………………………4
Important Operation Instructions…………..…………………………………..4
Assem ly Instructions………………………………..…………………………5
Transport…………………………………………………………………………8
Operation of Your New Elliptical…………………..…………………………...9
Manufacturer’s Limited Warranty…………………………………..………….13
ATTENTION- THIS ELLIPTICAL IS INTENDED FOR RESIDENTIAL USE
ONLY AND IS WARRANTED FOR THAT APPLICATION. ANY OTHER
APPLICATION OIDS THIS WARRANTY IN ITS ENTIRETY.
Table of Contents

ZE20
2
Thank you for your purchase of this quality elliptical from Spirit Manufacturing, Inc.
Your new elliptical was manufactured y one of the leading fitness manufacturers
in the world and is acked y one of the most comprehensive warranties
availa le. Through your dealer, Spirit will do all we can to make your ownership
experience as pleasant as possi le for many years to come. The local dealership
where you purchased this elliptical is your administrator for all Spirit warranty and
service needs. Their responsi ility is to provide you with the technical knowledge
and service personnel to make your experience more informed and any
difficulties easier to remedy.
Please take a moment at this time to record the name of the dealer, their
telephone num er, and the date of purchase elow to make any future, needed
contact easy. We appreciate your support and we will always remem er that you
are the reason that we are in usiness. Please complete and mail your
registration card today and enjoy your new elliptical.
Yours in Health,
Spirit Manufacturing, Inc.
Name of Dealer______________________________________
Telephone Number of Dealer___________________________
Purchase Date_______________________________________
RECORD YOUR SERIAL NU BER
Please record the Serial Num er of this fitness product in the space provided elow.
Serial Number_______________________________________
REGISTER YOUR PURCHASE
The self-addressed product registration card must e completed in full and returned to
Spirit Manufacturing, Inc or visit www.spiritfitness.com to register online.
CONGRATULATIONS ON YOUR
NEW ELLIPTICAL AND WELCOME
TO THE SPIRIT FAMILY!
Product Registration
ZE25-E07 0509/S1

ZE20
3
WARNING - Read all instructions before using this appliance.
■ Do not operate elliptical on deeply padded, plush or shag carpet. Damage to oth
carpet and elliptical may result.
■ Keep children away from the elliptical . There are o vious pinch points and other
caution areas that can cause harm.
■ Keep hands away from all moving parts.
■ Never operate the elliptical if it has a damaged cord or plug. If the elliptical is not
working properly, call your dealer.
■ Keep the cord away from heated surfaces.
■ Do not operate where aerosol spray products are eing used or where oxygen is
eing administered. Sparks from the motor may ignite a highly gaseous
environment.
■ Never drop or insert any o ject into any openings.
■ Do not use outdoors.
■ To disconnect, turn all controls to the off position, then remove the plug from the
outlet.
■ Do not attempt to use your elliptical for any purpose other than for the purpose it is
intended.
■ The pulse sensors are not medical devices. Various factors, including the user’s
movement, may affect the accuracy of heart rate readings. The pulse sensors are
intended only as exercise aids in determining heart rate trends in general.
■ Wear proper shoes. High heels, dress shoes, sandals or are feet are not suita le
for use on your elliptical . Quality athletic shoes are recommended to avoid leg
fatigue.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
Important Safety Instructions

ZE20
4
WARNING!
● NEVER remove any cover without first disconnecting AC power supply.
● If voltage varies y ten percent (10%) or more, the performance of your elliptical may
e affected. Such conditions are not covered under your warranty. If you suspect
the voltage is low, contact your local power company or a licensed electrician for proper
testing.
● NEVER expose this elliptical to rain or moisture. This product is NOT designed for
use outdoors, near a pool or spa, or in any other high humidity environment.
● NEVER operate this elliptical without reading and completely understanding the
results of any operational change you request from the computer.
● Understand that changes in resistance do not occur immediately. Set your desired
level on the computer console and release the adjustment key. The computer will
o ey the command gradually.
● NEVER use your elliptical during an electrical storm. Surges may occur in your
household power supply that could damage elliptical components.
● Use caution while participating in other activities while using your ZE20; such as
watching television, reading, etc. These distractions may cause you to lose alance;
which may result in serious injury.
● Always hold on to a handrail or hand ar while making control changes.
Do not use excessive pressure on console control keys. They are precision set to
function properly with little finger pressure. Pushing harder is not going to make the unit
go faster or slower. If you feel the uttons are not functioning properly with normal
pressure, contact your Spirit dealer.
Important Electrical Information
Important Operation Instructions

ZE20
5
ASSEMBLY PACK CHECK LIST
■
■■
■ M8x20mm Button Head Socket Screw (4pcs)
■
■■
■ M8x15mm Hex Head Screw (6pcs)
■
■■
■ M8x50mm Button Head Socket Screw (2pcs)
■
■■
■ M8x45mm Button Head Socket Screw (4pcs)
■
■■
■ M4x30mm Self Tapping Screw (4pcs)
■
■■
■ 5/16” x 19 x 1.5T Curve Washer (6pcs)
■
■■
■ 5/16”x23x1.5T Flat Washer (8pcs)
■
■■
■ M8 Nylon Nut (2pcs)
■
■■
■ 13/14mm N Wrench (1pc)
■
■■
■ M5 Allen Wrench (1pc)
■
■■
■ Screwdriver(1pc)
Assembly
■
■■
■STEP 1
Install the Front and rear sta ilizer into the Frame Base Support with 4pcs of M8x45m/m
Hex Head Screws and 4pcs of 5/16”x23x1.5T Flat Washers. Then tightly fasten 4pcs of
M5x38m/m Self Tapping Screws of the Front and rear Sta ilizer Cover y using the
13/14mm N Allen Wrench and Screw Driver.
(As shown in Fig.1~7)
■
■■
■STEP 2
Connect the Computer Ca le (Upper) with Computer Ca le (Lower).
(As shown in Fig. 8)
■
■■
■STEP 3
Install the Front Post into the Main Frame with 6pcs of M8x15m/m Hex Head Screws
and 6pcs ofψ5/16”xψ19 x2T Curve Washers y using the 13/14mm N Allen Wrench .
(As shown in Fig. 9)
■
■■
■STEP 4
Connect the Computer Ca le (Upper) with the Hand Pulse Ca le. Install the Console
with 4pcs of M5x15m/m Button Head Socket Screws y using the Screw Driver.
(As shown in Fig. 10~11)
Assembly Instructions

ZE20
6
■
■■
■STEP 5
1. Install the Handle Bar Cover Front onto the Front Post with 1pc of M5x15m/m Button
Head Socket Screws.
(As shown in Fig. 12)
2. Take the Fix Handle Bar through the Hand Bar Cover Front and install it onto plate with
2pcs of M8x20m/m Button Head Socket Screws.
(As shown in Fig. 13)
3. Install the Handle Bar Cover Back onto the Front Post with 1pc of M5x15m/m Button
Head Socket Screws.
(As shown in Fig. 14)
■
■■
■STEP 6
Install the Lower Swing Bar into the Left and Right Swing Bar Upper and fix it y using
the Tension Adjuster.
(As shown in Fig. 15)
■
■■
■STEP 7
Install the Plastic Insert For Swing Bar (Lower End) into the Front Post and install Left
and Right Swing Bar Upper with 2pcs of M8x20m/m Button Head Socket Screws and
2pcs of 5/16”x23x1.5T Flat Washers y using the M5 Allen Wrench.
(As shown in Fig. 16~18)
■
■■
■STEP 8
Install the Left and Right Pedal Bar into the U Shape Plate For Pedal with 2pcs of
M8x50m/m Button Head Socket Screws, 2pcs of 5/16”x23x1.5T Flat Washers and
2pcs of M8 Nylon Nuts y using the N Wrench and the M5 Allen Wrench.
(As shown in Fig. 19)
■
■■
■STEP 9
Install the Swing Bar Upper Cover Front and the Swing Bar Upper Cover Back into the
Front Post with 4pcs of M4x30m/m Self Tapping Screws. And plug the two Hand Pulse
Ca les into the Socket at ack of Console.
(As shown in Fig. 20~21)
■
■■
■STEP 10
Install the Drink Bottle Holder onto the Front Post with 2pcs of M5x15m/m Socket Head
Cap Screws.
(As shown in Fig. 22)

ZE20
7
■
■■
■ PLEASE LOCK DOWN ALL HARDWARE AFTER THE
ACCESSSORIES HAVE BEEN ASSE BLED.
Assembly Photos

ZE20
8

ZE20
9
The elliptical is equipped with two transport wheels which are engaged when rear of
ZE20 is lifted.
Transport

ZE20
10
Getting familiar with the control panel
■ Console
Operation of Your Elliptical

ZE20
11
Power up
The elliptical is supplied with a wall mount power supply. When power is connected to the
elliptical, the console will automatically power up. If there is no input to the console for 4
minutes the console will go to stand- y mode. In stand- y mode the console display will
turn off. All work out data will e saved in stand- y mode.
When initially powered on the large display will light. The data windows will show zero and
the program choices will e linking in the large window. If the console is in stand- y mode,
pressing any key or eginning your exercising will wake the console up.
Starting a program
Quick Start
After the console powers up you may press the Start key to egin, this will initiate the Quick
Start mode. In Quick Start the Time will count up from zero and the workload may e
adjusted manually y pressing the Up/Down uttons. Distance and Calories will accrue,
starting from zero.
The Calorie window will switch etween Calories and Watts every 5 seconds. The Calorie
reading shows total Calories urned and is an approximate num er. The Watt reading
indicates how much work you are doing. If the Watt reading is 100, this means you are
doing enough work to light a 100 watt light ul .
The ottom left data window will switch etween RPM and Speed every 5 seconds. RPM is
your actual pedal rotation speed, and the Speed readout is in KPH, indicating approximate
road speed as if pedaling a icycle in 7
th
gear.
The Distance window shows distance traveled, ased on pedal speed, in miles. The Pulse
window will display your heart rate in eats per minute if you are holding the heart rate
hand sensors, or wearing a chest strap transmitter.
anual
Using the Up/Down keys, highlight the Manual icon at the top of the display and press
Mode key. The profile will e linking and you may use the Up/Down keys to adjust the
program work level and then press Mode. The Time window will now e linking. Use the
Up/Down keys to adjust the program Time and then press Mode. The Distance window will
now e linking and you can adjust a target Distance using the Up/Down keys then press
Mode. Calories will now e linking, repeat the same process as a ove to set, then press
Mode. The Watt icon will e linking. If you choose to set the Watts then the machine will
automatically adjust the workload to maintain continuous work. What this means is that if
you set the Watt to 100 the machine will try to keep you working at a rate of work that
equals 100 Watts (or working at a rate that will keep a 100 Watt light ul urning). Watts
are determined y the amount of work you are doing. On the elliptical this means the speed
you are pedaling at com ined with the workload of the machine. In Watt mode, if you
change your speed the machine will automatically change the workload to maintain the
same Watt level. If you pedal faster the workload will decrease and if you pedal slower the
workload increases.
After adjusting all the parameters, press Start to egin your workout.

ZE20
12
Preset Programs
There are 12 preset programs to choose from. After power up, or reset, press the Up/Down
keys to highlight the Program icon. Press the Mode key to enter the program mode. The
display will show P1, for two seconds, then change to the P1 program profile. You may
keep pressing the Up/Down keys to scroll through the 12 programs. When you see a
program you want, press the Mode key to enter. At this point you may press start to egin
the program with the default settings or you may customize the program.
To customize the work level, press the Up key. You will see the profile increase in size.
When the work level is where you like it press the Mode key (If you do not want to
customize the profile, just press the Mode key to ypass).
The Time window will now e linking. Use the Up and Down keys to adjust the workout
time and then press Mode.
The Distance window will now e linking. Repeat the same process to set the distance to
count down, if desired, and press Mode.
The Calorie window will now e linking. Repeat the same process then press Mode.
The Pulse window will now e linking. Entering a Pulse num er will set an alarm that will
eep when your heart rate reaches the programmed num er to let you know you have
reached your target.
Once you have set the data you may press Start to egin the program. You may also press
Start at any time during the programming to egin. Any data that is not programmed at that
point will count up from zero.
When the program ends there is a series of audi le eeps. You may press Start to restart
the program or press Reset to return to the start-up screen.
User Program
This mode allows you to uild and save your own custom program.
Press the Up or Down key until the User icon at the top of the display is linking then press
Mode. The first column of the profile will e linking. Use the Up/Down keys to adjust the
work level then press Mode. The second column will now e linking. Repeat the same
process as a ove and press Mode. Repeat this process until all the columns are adjusted
to your liking. All the settings will e saved as a custom program.
Target HR
This program allows you to set a target heart rate and the machine will automatically adjust
the work load to safely reach the target and maintain that target.
Use the Up/Down keys to select the Target HR program and press Mode. The display will
show a num er and the age icon at top will e linking. Use the Up/Down keys to adjust
the age and press Mode. The display will now show a linking percent num er or the
letters THR.
You may use the Up/Down keys to choose either 55%, 75%, 90% or THR. The percentage
choices will automatically set the target to a percent of your maximum heart rate, ased on
your age. This is why it is important to adjust the age properly. The console will use a
formula to determine the correct percentage: 220 – age = maximum HR. For example a 30
year old persons’ Max HR is 190 BPM (220 – 30 = 190 BPM). If the 30 year old wants to
work at 75%, their target HR will e 142BPM.

ZE20
13
If you want to choose to work at 75% - for example - then use the Up/Down arrows to
highlight 75% and press mode. Now the Time window will e linking and you can program
it and other data the same as other programs. If you want to set your own custom Target
HR then use the Up/Down arrow to highlight THR and press mode. The Pulse window will
now e linking. Use the Up/Down arrows to set your own Target HR and press Mode to
continue.
Recovery
Used to measure how fast your heart rate (HR) recovers from exercise. The faster your HR
returns to normal from exercise level, the etter aero ic shape you are in. Pressing the
recovery utton will start a 60 second count down. Hold the hand pulse sensors and do not
exercise during the count down. At the end of the 60 seconds a score will e displayed
ranging from F1 to F6 with F1 eing the highest score and F6 eing the lowest.
WINDOW DISPLAY
TI E: Count up: accumulates training time from zero to 99:59.
Count down: counts down from preset time to zero.
SPEED/ RP : Automatically toggles etween SPEED and RPM every 6 seconds.
Speed is in miles per hour (or kilometers per hour)
DISTANCE: Count up: accumulates training distance from 0.00 to 99.99 miles.
Count down: counts down from preset distance to zero.
CALORIES: Accumulates calories urned from 0 to 9999. This is an estimated
num er only to e used from workout to workout to compare your
progress. Actual calorie urn cannot e measured accurately on any
consumer exercise equipment ecause every individual urns calories
at a different rate.
WATTS: Indicates the amount of work eing done in Watts.
PULSE: Displays your current heart rate when you grasp the hand sensors or
wear the chest strap transmitter.
LEVEL: Shown next to the workout profile. Indicates the level of work eing done
from 1 to 16.

ZE20
14
Effective October 15, 2004
ELLIPTICAL WARRANTY
Spirit Manufacturing Inc. warrants all its elliptical parts for a period of 2 years from the date of retail sale, as determined y sale receipt,
or eighteen (18) months from the original factory shipping date, whichever comes first. Spirit’s responsi ilities include providing new or
remanufactured parts, at Spirit’s option, and technical support to our independent dealers and servicing organizations. In the a sence of
a dealer or service organization, these warranties will e administered y Spirit directly to a consumer. An extended warranty period
applies to the following components:
NOR AL RESPONSIBILITIES OF THE CONSU ER
This warranty applies only to products in ordinary household use, and the consumer is responsi le for the items listed elow:
1. The warranty registration card must e completed and returned to the address listed on the card within 10 days of the original
purchase to validate the manufacturer’s limited warranty.
2. Proper use of the elliptical in accordance with the instructions provided in this manual
3. Proper installation y an authorized Spirit service company in accordance with instructions provided with the elliptical and with all local
electric codes.
4. Proper connection to a grounded power supply of sufficient voltage, replacement of lown fuses, repair of loose connections or defects
in house wiring.
5. Expenses for making the elliptical accessi le for servicing, including any item that was not part of the elliptical at the time it was
shipped from the factory.
6. Damages to the elliptical finish during shipping, installation or following installation.
EXCLUSIONS
This warranty does not cover the following:
1. CONSEQUENTIAL, COLLATERAL, OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES
RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allo the exclusion or limitation of incidental or consequential damages, so this limitation or
exclusion may not apply to you.
2. Service call reim ursement to the consumer. Service call reim ursement to the dealer that does not involve malfunction or
defects in workmanship or material, for units that are eyond the warranty period, for units that are eyond the service call
reim ursement period, for elliptical not requiring component replacement, or elliptical not in ordinary household use.
3. Damages caused y services performed y persons other than authorized Spirit service companies; use of parts other than original
Spirit parts; or external causes such as alterations, modifications, a use, misuse, accident, improper maintenance, inadequate power
supply, or acts of God.
4. Products with original serial num ers that have een removed or altered.
5. Products that have een sold, transferred, artered, or given to a third party.
6. Products that do not have a warranty registration card on file at Spirit Mfg. Spirit reserves the right to request proof of
purchase if no warranty record exists for the product.
7. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE.
SERVICE
Keep your ill of sale. Twelve (12) months from the date on the ill of sale or eighteen (18) months from the date of factory
shipping as determined y the serial num er esta lishes the warranty period should service e required. If service is performed,
it is in your est interest to o tain and keep all receipts. This written warranty gives you specific legal rights. You may also have
other rights that vary from state to state. Service under this warranty must e o tained y following these steps, in order:
1. Contact your selling authorized Spirit dealer. OR
2. Contact your local authorized Spirit service organization.
3. If there is a question as to where to o tain service, contact our service department at [phone].
4. If no local service is availa le, Spirit will repair or replace the parts, at Spirit’s option, within the warranty period at no charge
for parts. All transportation costs, oth to our factory and upon return to the owner, are the responsi ility of the owner. The owner is
responsi le for adequate packaging upon return to Spirit. Spirit is not responsi le for damages in shipping. Make all freight damage
claims with the appropriate freight carrier. DO NOT SHIP ANY UNIT TO OUR FACTORY WITHOUT A RETURN AUTHORIZATION
NUMBER. All units arriving without a return authorization num er will e refused.
5. For any further information, or to contact our service department y mail, send your correspondence to:
Spirit anufacturing, Inc.
P.O. Box 2037
Jonesboro, AR 72402-2037
Product features or specifications as descri ed or illustrated are su ject to change without notice. All warranties are made y
Spirit Manufacturing, Inc. This warranty applies only in the 50 states of the U.S.A. and Canada.
ZE20
La or 1 Year
Frame Weldments Lifetime
All Other Components 2 Years
Manufacturer’s Limited Warranty
