SPRT POS58VI User manual

POS58VI
LineThermalPrinter
User sManual
VER1.00）
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
Content
Introduction 2
Chapter1Characteristicand Specification 3
1.1Printing Specification 3
1.2PrintingPaper 3
1.3PrintingFont 3
1.4Interface 3
1.5PrintingControlCommand 4
1.6PowerSupply 4
1.7Operation Environment 4
1.8OutlineDimension 4
Chapter2Operation 4
2.1PrinterAppearance 4
2.2PaperInstallation 6
2.3InterfaceConnection 6
2.3.1ParallelInterface 6
2.3.2SerialInterface 7
2.3.3USB Interface 9
2.3.4Cashdrawer connection 9
2.4Buttons and Indicators 9
2.5Self-test 10
2.6HexadecimalDump……………………………………….10
2.7UpgradeMode……………………………………………..11
Chapter3Printing DriverInstallation 11
Appendix1Performance Index 11
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
２
Introduction
POS58VI printerisanewtype linethermalprinter,it featuresinfast
speedprint,lowprintnoise,highreliability,perfectprintqualityand ribbon
needless avoidingthe vexation of regularmaintenance.
POS58VI printer: small inoutlinedimension,simpleoperation,and
extensiveapplication,especiallysuitablefor commercialcash register,
PC-POS, bankPOSand all kinds ofreceipts print.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
３
Chapter 1Characteristicand Specification
1.1Printingspecification
●Printing method:directthermal
●
Printing paperwidth:57.5±0.5mm
●Printing density:8dots/mm, 384 dots/line
●Printing speed:approx. 75mm/s (validcontentof eachlineisn’tover25%)
●Reliability:
Printingheadlife:100km
MCBF:5million lines
Using condition:
＊Print12 ×24 ASCII characters,print50 lineseachtime,intermittent
printrepeatedly
＊Eachdot-lineprintingatthesametimeshould notexceed25%,each
character-lineand onedotverticallyprinting repeatedlyshould
notexceed11times
＊Use specifiedthermalpaper
●Validprinting width:48mm
1.2PrintingPaper
●Thermalpapermodel: TF50KS－E（Japanpaperco.ltd）
AF50KS-E(JUJOTHERMAL)
●Thermalpaper: Width－－－－－－－－ 57.5±0.5mm
OuterDiameter －－－ 80mm（max.）
InnerDiameter －－－ 13mm（min.）
Thickness 0.06-0.08mm
1.3PrintingFont
●ANK Characterset:
12×24 dots，1.25（W）×3.00（H）mm;
●GB2312-80(Chinese):
24×24 dots，3.00（W）×3.00（H）mm.
1.4Interface
●RS232interface:
DB25 socket(female), supports XON/XOFF and RTS/CTSprotocol
Baud rate:1200-115200bps adjustable.
Datastructure:onestart bit+7or 8databits +onestopbit
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
４
●Parallelinterface:
DB25 socket(male),8-bit parallelinterface,supports BUSY/ACK
handshaking protocol,TTL.
●USB interface：
Standard B typeUSB interface.
●Cash drawercontrol
DC12V，1A，6-pinRJ-11socket.
1.5PrintingControlCommand
●Characterprintcommand:supportsdoublewidthanddoubleheight
printing ofANK characters,user-definedcharacters and Chinesecharacters,
thecharacterlinespacing is adjustable.
●Graphicsprintcommand:supportsthe printingof bit mapgraphicswith
differentdensity
●GSbarcodeprintcommand:supports UPC-A、UPC-E、EAN-13、EAN-8、
CODE39、ITF25、CODABAR、CODE93、CODE128 barcodeprint.
1.6Power Supply
●DC12V±10％，2A(onecore)
1.7OperationEnvironment
●Operation environmenttemperature:0～50
Relativehumidity:10～80％
●Storagetemperature:-20～60
Relativehumidity:10～90%
1.8OutlineDimension
●205(L) X118 (W) X129(H) mm
Chapter 2Installationand Operation
2.1Printer Appearance
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
５
Fig2-1 Printerouterappearance
Fig2-1 Printerouterappearance (back)
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
６
2.2Paper Installation
POS58VIadopts 57.5±0.5mm widththermalpaper.
Thesteps of thermalpaperinstallationareasthefollowing:
1. Whenthereis nopaperintheprinthead, pls don’tpress【FEED】buttonto
avoidaffectingthelifeof printinghead. Opening openbutton toopenthe
casecoverand changepaper.
2. Afterpapercasecoveris closed, plsdo notdraw thepaperforwards or
backwards withhands.
2.3Interface Connection
2.3.1ParallelInterface Connection
TheParallelinterfaceof POS58VIprinteris compatiblewithCENTRONICS,
supports BUSYand /ACK handshakingprotocol,it usesDB25 socket(male),
thepinorderof parallelportis asbelowshows:
Pin Order ofParallelPort
Thepinassignmentof parallelinterface is shownasbelow:
PinNo. Signal Direction Description
1 /STB In Strobepulsetolatch data,
reading occursatraisingedge.
2
3
4
5
6
7
8
9
DATA1
DATA2
DATA3
DATA4
DATA5
DATA6
DATA7
DATA8
In
In
In
In
In
In
In
In
Thesesignals representthe1
st
bit to8
th bit of theparallel
interface data,eachsignalisat
HIGHT levelwhendatais
logic1,and LOWwhendatais
logic0.
10 /ACK Out
Answerpulse, LOWlevel
signalindicatesthatdatahave
alreadybeenreceivedand the
printergets readytoreceivethe
nextdata.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
７
11 BUSY Out HIGH levelsignalindicates thattheprinteris BUSY and
cannotreceivedata.
12 PEOut HIGH levelsignalindicates
thatpaperis end.
13 SELOut PullinguptoHIGH level signalbyaresistor indicates
theprinteris online.
15 /ERR Out PullinguptoHIGH level signalbyaresistor indicates
thereis no error.
14,16,17 NC --- Noconnection
18-25 GND --- Grounding logical0level
Note: （1）“In”denotesinputting tothe printer，“Out”denotesoutputting
fromtheprinter.
（2）SignallevelisTTLstandard.
Fig. PinAssignmentof ParallelInterface
2.3.2RS232 Interface Connection
TheRS232 interfaceof POS5VIprinter is compatiblewithRS232Cstandard,
supports RTS/CTS and XON/XOFF handshaking protocol,it usesDB25
socket(female), thepinorderoftheRS232 portisasbelow:
Fig. PinOrderofthe SerialPort
Thepinassignmentof RS232 interface is shownasbelow:
PinNo. SignalSource Description
2 RXD HostPrinterreceivesdatafromhost
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
８
3 TXD Printer Printertransmits controlcode
X-ON/X-OFF and
datatohost
5 CTS Printer Signal “MARK”indicatesthat
theprinteris “BUSY”and
unabletoreceivedata;
“SPACE”indicatesthatthe
printeris “READY”for
receiving data.
6 DSR printer Whenthissignalis “SPACE”,
it means theprinter “online”.
7 GND —SignalGround
8 DCD printer Samewithsignal “CTS”
Fig. Pin AssignmentofSerialInterface
Note: “Source”①denotesthesource thatsignalcomesfrom;
②Logicalsignallevelis EIA.
Thebaud rateand datastructureinRS232 interface modearesetto9600bps,
8databits, noparitybit and 1stop bit.
Theserialinterface of POS58VIcanbeconnectedwithstandard RS-232C
interface.WhenconnectedtoIBMPC or compatiblemachine, connection
canaccord tothebelow.
Fig. Connection between POS58VIS andIBMPCSerialInterface
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
９
2.3.3USB Interface
Standard B typeUSB interface
2.3.4CashDrawer Interface
Thecash drawerinterface of POS58VIis RJ-11, 6pinsocket, asbelow,
Thepinassignmentof thecash drawerinterface is asfollows:
Pin No. Signal Direction
1 Chassis Ground ---
2 Cash drawerdriversignal Out
3 Cash draweron/offstatus signal In
4 +12VDC Out
5 N.C ---
6 Cash draweron/offstatus signalground ---
2.3.5Power Connection
POS58VI usesexternalpowersupplyas12VDC±10％,2A,onecoremodel,
asbelow:
2.4ButtonsandIndicators
2.4.1Power switch
Controlon/off statusof power. is off status. Press “-”is on status.
2.4.2FeedButton
【FEED】is paper feedbutton.Printcommand canenableor disable
【FEED】status tobeon oroff. Underenablestatus, holddown【FEED】,
start paperfeeding, releasethebutton paperfeeding stops.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
０
2.4.3Opening Upper Cover Button
Holddownopening uppercoverbuttontoopenthecasecover.
2.4.4Power indicatorlight
If thepoweris on, thepowerindicator lightwill beon.
2.4.5Status Indicatorlight and Buzzer
Duringnormalworking,redSTATUSlightis off.If theworking status is
abnormal,theredindicator lightwill flickertoalarmerror.Setting Buzzer
canalsoalarmtheabnormalworking status.
Light status
Buzzerstatus
Printer Workingstatus
Off
Off
Normal
Flicker1timeand stay
1s off
Alarm1time
andstay1s off
Paper out and waitingforloading
paper
Flicker2timesand stay
1s off Alarm2times andstay1s off
Print headisoverheatedand just
waitingforbackto normal
temperature.
Flicker3timesand stay
1s off Alarm3times andstay1s off
Thermalprint headdamaged,
needs to repair.
2.5Self-test
Theself-test canchecktheconditionof printer.In theself-test,software
version,interface type,characters,etcwill beprinted.If theprinterprintsout
theself-test receiptcorrectly,it means theprinterworks normallyexceptthe
interface withhost. Otherwiseit needs torepair.
Method of self-test:Holding down 【FEED】buttonand turn onthepower,
theredindicatorlightwill flickerat1time/s,within3timesthenreleasethe
button, self-test begins automatically.
2.6HexadecimalDump
Holding down 【FEED】buttonand turnon thepower, theredindicator light
will flickerat1time/s,after3timesthenreleasethebutton,theredlightwill
go on flicker3times,thentheprinterwill printout3linesinformation as
bellow: HexadecimalDump
Toterminatehexadecimaldump,
Press FEED buttonthree times.
Underthismode,all theinputwill printoutasHexadecimaldata.Putthe
【FEED】buttonwill feedonelineeach time.3timestogetherwill printout
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
asbellow:
*** Completed***
Thenquit theHexadecimalDumpprintmode.
2.7UpgradeMode
Holding down 【FEED】buttonand turnon thepower, theredindicator light
will flickerat1time/s,after3timesthenreleasethebutton.Theprinter
enters intoModeChoosingStatus.Thenpress LFbutton5timesand the
timedistance betweentwotimesmustbewithin3s. Theindicator will flicker
at1s on and 1s offstatus.Atthis time,theprinterenters intoUpgradeMode.
Chapter3PrintingDriverInstallation
Printing driverfor POS58IVcanbedownloadedfromthecompanyof our
website.Afterdownloading,thenameof driversoftwareis DRV211.During
installingdriversoftware,chooseprintermodel “58 thermalseries”.About
otheroperation, pls refertothedetailedinstallation manual.
Appendix1Performance Index
Printmethod:Directthermal
Printwidth:57.5 ±0.5mm
Validprintwidth:48mm
Printdensity:8dots/mm, 384 dots/line
Printspeed:approx.70mm/sec.or 20 lines/sec.
Reliability:
Printheadlife:50km
MCBF:5millionlines
Using condition:
＊Print12 ×24ASCII characters,print50lineseachtime,intermittent
printrepeatedly
＊Eachdot-lineprinting atthesametimeshould notexceed25%,each
characterlineand onedotverticalprinting repeatedlyshouldnot
exceed11times
＊Usespecifiedthermalpaper
Thermalpaperroll model: TF50KS－E（Japanpaperco.ltd）
AF50KS-E(JUJOTHERMAL)
Thermalpaperroll
PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT
２
Width－－－ 57.5±0.5mm
OuterDiameter －－－ 80mm（max.）
InnerDiameter－－－ 13mm（min.）
Thickness －－－ 53～60g／m2
PrintFont
IBMCharactersetII (ANK):
12×24 dots，1.25（W）×3.00（H）mm;
GB GB2312-80(Chinese):
24×24 dots，3.00（W）×3.00（H）mm.
RS232 interface:
DB25 socket(female), supports RTS/CTSprotocol.
Baud rate:9600bps.
Datastructure:1start bit +8databits+1stopbit. no parity.
Parallelinterface:
DB25 socket(male),8-bit parallelinterface,BUSY/ACK handshaking
protocol,TTLsignallevel.
Cash drawercontrol
DC12V±10％，1A，6-pinRJ-11socket.
PowerSupply
DC12V，3.3A.
OperationEnvironment
Operation temperature:5～50
Relativehumidity:10～80％
Storagetemperature:-20～60
Relativehumidity:10～90
Warning
ThisisaclassAproduct. Inthedomesticenvironment, this
productmaycauseradiointerference, inwhichcasetheuser
maybe requiredtotakeadaptablemeasures.
PDFcreated withpdfFactorytrialversion www.pdffactory.com
