AVP 870-0
Operating Instructions
for end users
Access video panel

2
Contents
These operating instructions supple-
ment/are supplemented by:
• Access video panel product infor-
mation
• Access system manual
The relevant current edition is
located in the download area on
www.siedle.com
Subject to printing errors.
We reserve modications depending
on technical improvements.
Safety remarks
Electrical voltage 3
Electrostatic charging 3
Commissioning requirements 3
Application 3
Intended application 3
Operating remarks 3
Care instructions 3
Legal notice 3
General information
Functional scope 4
Scope of supply 4
Video memory 4
SD card 4
Servicing 4
Product overview 5
Speech button – Functions 6
Door release button – Function 6
Touchscreen – Operation
Accessing menus 7
Accessing functions 7
Moving tiles 7
Changing pages – Start screen 8
Overview of menus and symbols
Menu structure User interface 9
Explanation of symbols 10
Status displays 11
Display symbols – Status
change 11
Display navigation
Navigation bar 12
Start – Drop-down menu 13
Cameras 13
Switching –
Drop-down menu 14
Door call images 14
Calls list 14
Settings 15
ECO mode 15
Operation
Door call 16
Call/Internal call 17
Calling a contact 18
Dialling a contact using
the start screen 18
Dialling a contact using
the Contacts menu 18
Missed calls – Callback 18
Selecting a door station 18
Changing the display mode 18
Accessing building automation 18
Dening the image view 19
Cleaning the display 19
Reset to as-delivered status 19
General information
Disposal 20
Index 21

3
Safety remarks
Electrical voltage
Mounting, installation and servicing
work on electrical devices may only
be performed by a suitably qualied
electrician.
Mounting
During installation, where applicable
ensure that the surface is protected
from damage.
Electrostatic charging
As a result of electrostatic charging,
direct contact with the circuit board
can result in destruction of the
device. Direct contact with the circuit
board must therefore be avoided.
Commissioning requirements
• The device must be powered
via PoE (Power over Ethernet;
IEEE802.3af or 802.3at).
• To operate an Access video panel,
an Access server release from ver-
sion 2.1 is required. Access servers
with a lower release status must be
updated with an upgrade. This can
give rise to additional costs.
The Access commissioning instruc-
tions and the Access planning and
system manual can be found in the
download area.
Application
Access video panel with touchscreen
17.8 cm for the Access system,
made of high-grade plastic. The
panel is a system product with a
low-prole surface-mount housing
for wall and table-top mounting.
It provides ergonomically designed
intuitive user prompting with gesture
control.
Intended application
The panel is part of a door commu-
nication system and may only be
used exclusively within this system.
Siedle does not accept any liability
for damage caused as a result of
using the equipment for any other
than its intended purpose.
Operating remarks
In order to avoid damage to the
panel, please note the following:
The touchscreen and the buttons
can be damaged by using sharp-
edged or pointed objects such as
ballpoint pens or keys.
Only ever use your nger to operate
the panel.
When restarting the Access video
panel or the Access server, the
Access video panel is restarted step
by step. Depending on the system
size, a complete restart can take sev-
eral minutes. During this period, the
Access video panel shows various
statuses in English. The Access video
panel is not ready for operation
until the start screen is continuously
displayed.
Care instructions
Dry, aggressive cleaning agents and
abrasive detergents can damage the
surface!
Only ever clean your indoor device
using a soft damp cloth.
Please ensure that no moisture ever
penetrates the housing.
Legal notice
Photographs of individuals taken
without their knowledge may not be
published or stored in publicly
accessible video memory facilities.
Individuals who have been
photographed without their
knowledge are entitled to request
that pictures be deleted based on
the right of persons to their own
likeness. Never store pictures of
persons you do not know in social
networks or send them by email
to others/public groups. This will
infringe their personal rights.
If stored images are used as part of
private / criminal law proceedings or
in a police investigation, this requires
prior clarication with a lawyer or
the responsible police authority.

4
Scope of supply
• AVP870-… (Base plate and
housing with circuit board)
• RJ45 plug 2 x
• Dummy card for SD card insert
• Operating instructions for the
end user
• This product information
Video memory
Pictures are stored centrally on the
server. There are currently no plans
to allow pictures to be stored on
SD card.
Similar to photographs, saved
images are subject to copyright.
SD card
There is a dummy card inserted in an
SD card slot at the top of the device
which is used as a dust protector.
When upgrading with new func-
tions, this slot can be used to install
a memory card.
General information
Functional scope
With the functions calling, speech,
vision, door release, light, remote
switching and call silencing.
Performance features:
• Individual crafted design concept
offering a wide choice of varied fea-
tures and nishes
• Display offers graphic scope for
individual operation
• 17.8cm (7") touchscreen, resolu-
tion 800x480 Pixel
• Brilliant image reproduction
• Excellent audio quality (dual loud-
speaker technology)
• Input for storey call
• Output freely programmable
• Additional inputs and outputs
with Access input/output accessory
AZIO870-…
• Call differentiation between door
calls, storey calls, and internal calls
• Switching functions
• Video memory function
• Can be used with table-top acces-
sory AZTVP 870-… as a table-top
device
• Update capability using the Access
server
• from Access-ServerV 3.1…:
AVP with KNX link to the JUNG
FacilityPilotServer
Servicing
Statutory warranty conditions apply.
If the device requires servicing,
contact your specialist dealer or elec-
trical installer.
Access Service Center in the
Furtwangen factory
Tel. [phone]
[email protected]

5
1 Display with touch function
(touchscreen)
2 Speech button with LED display
and rocker switch for setting the
speech volume
3 Loudspeaker
4 Door release button
5 Microphone
6 Status displays
7 Display of the start menu, time
and date (standard conguration)
8 Content area
9 Navigation bar
10 Card slot for SD card
11 Number of pages and displayed
page
The Access video panel is charac-
terized by its generously dimen-
sioned touchscreen. Two buttons
are assigned to the basic functions
Speech/Regulate volume and
Door release. Other functions are
actuated at the display.
10:10
12 1 20.05.2013
1
4
3
2
8
9
5
3
10
11
Entrance
Ringtone Study Study
Front door Entrance Kitchen Study
Kitchen Study Hallway
Start 08:00 | 16.12.2014
Entrance Basement
Living room
Hallway
Clear symbols, intuitive operation:
The most important button is also
the biggest. The unmistakable
mouth symbol clearly indicates what
the button is for: to accept calls.
The call tone is accompanied by par-
allel ashing of the mouth symbol,
guiding the hand of the operator to
the correct place. Once the call has
been accepted, the mouth symbol
lights up continuously. The door
release button clearly stands out –
this enhances security as it cannot
be confused or actuated by mistake.
Product overview

6
Product overview
Speech button – Functions
Accepting a call In the case of a door call, you can pick up the call within 60 seconds of the
last ring tone. If an internal call is in progress, you can accept the call within
120 seconds after the last ring.
During an active call, the speech button lights up.
Press the speech button in order to accept the call.
The panel only transmits speech in one direction and automatically switches
over.
Setting the call volume The call volume can be set in ve steps – both during a call and also without
an active call.
If you have set the minimum volume, only the +on the call button will
respond. If you have already set the maximum volume, only the –on the
call button will respond. The set volume will be adopted for future calls.
During an existing call:
• Increasing the volume: Press +on the call button, until the graphic
control for the call volume appears, and hold down + until the call volume
has reached the required value.
• Reducing the volume: Press –on the call button, until the graphic con-
trol for the call volume appears, and hold down – until the call volume has
reached the required value.
If there is no active call:
1. Open the menu settings> Audio> Call volume
2. Using the controller, adjust the call volume.
3. The set volume will be adopted for future calls.
Ending a call During an active call, the speech button lights up.
Press the speech button in order to terminate the call.
Missed calls In the event of missed door calls/telephone calls, the mouth symbol on the
call button ashes, provided this function has been set up.
This signalling function is set using the menu Settings > ECO mode >
Call display > Speech button ashes to indicate a missed call.
Door release button – Function Press the door release button.
The door release is actuated for 3 seconds.
Using the door release button, you can also always actuate the door release
from the door from which the last door call came without the need for a
preceding call.
Note: In the as-delivered status, the initiation period for the door release is
pre-set to 3 seconds. This can be changed in the Access server.

7
Touchscreen – Operation
Accessing menus
1 Tap on the required symbol.
10:10
12 1 20.05.2013
Start08:00 | 16.12.2014
TimPaul
Lili
Accessing functions
1 Tap on the required tile.
10:10
12 1 20.05.2013
Start08:00 | 16.12.2014
TimPaul
Lili
Moving tiles
1 Using any nger, touch the tile
you wish to move on the start
screen. The tile briey changes
colour.
2 Drag the tile using your nger to
a free space on the start screen.
10:10
12 1 20.05.2013
Start08:00 | 16.12.2014
Paul
Lili
Tim

8
Touchscreen – Operation
Changing pages – Start screen
1 Use any optional nger to swipe
the start screen horizontally using
the touchscreen to change pages.
If you are on the rst or last page,
the swipe movement will only work
back in the opposite direction.
The number of existing pages is
indicated by dot for each. The
dots are located in the centre at
the lower part of the screen. The
current page is highlighted from the
others in colour. The start screen
comprises several pages which can
be changed by swiping.
10:10
12 1 20.05.2013
Start
08:00 | 16.12.2014
Lili

9
Overview of menus and symbols
Menu structure User interface
Start Call forwarding
Ringtone
Doormatic
Contacts All
Concierge
Internal
External
Groups
Doors
Cameras Standard screen mode
Full screen mode
Switching All switching functions
Doors
General
Light
Status display
Mail notication system
Building automation * (Accessing building automation)
Door call images Standard screen mode
Full screen mode
Delete all images
Calls list Delete all entries
Settings Audio Phone volume
Ringtone volume
Display Brightness
Language Language selection
Image view Standard screen mode
Full screen mode
Design Design Light/Dark
Position of menu prompting and
navigation bar Left/Right
ECO mode Call display
Idle status
Cleaning the display
System User information
Device information
Licence information
Reset Factory setting
ECO mode *
* A maximum of 8symbols can be
displayed in the navigation bar of
the AVP. If the Building automation
symbol is displayed, the ECO mode
symbol is omitted.
The ECO mode can be used over the
Settings menu.
The Building automation symbol
is only displayed on your AVP if the
connection to the
JUNG FacilityPilotServer has been
congured in the Access server.

10
Overview of menus and symbols
Explanation of symbols
Start/Start screen Building automation * Full screen mode
Drop-down menu – Open Door call images Standard screen mode
Drop-down menu – Close Delete all images Accepting a call
Call forwarding On Delete image Microphone off
Ringtone Off Settings Reject call/Ending a call
Doormatic On Audio Storey call
Contacts Volume – Missed calls/Calls list
Call silencing Volume +
Contact – Concierge Display
Contact – Internal Brightness –
All contacts/Contact –
External
Brightness +
Contact – Groups Language
Doors Image view
Cameras / Door station Design
List ECO mode
Standard screen mode Cleaning the display
Full screen mode System information
Charging… Reset
All switching functions/
Switching
ECO mode *
Switching Internal call / Audio door
stations / External call
Light switching Save picture
* A maximum of 8symbols can be
displayed in the navigation bar of
the AVP. If the Building automation
symbol is displayed, the ECO mode
symbol is omitted.
Mail notication system Light switching
Status display Door release
