ST STEVAL-IHM017V1 User manual

April 2008 Rev 1 1/39
UM0522
User manual
100 W 3-phase inverter for BLDC sensorless motor
evaluation board
Introduction
The 100 W 3-phase inverter for the BLDC sensorless motor evalaluation board (for brevity
also referred with its order code STEVAL-IHM017V1) is a complete development platform
for BLDC sensorless motor application with nominal power up to 100 W. It is based on a
cost-effective, flexible and open design, including a three-phase inverter bridge based on
the STD5NK52ZD-1 Power MOSFET in IPAK package and an ST7MC 8-bit microcontroller
with 16 Kbyte internal Flash memory.
The system has been designed to drive a three-phase brushless motor with permanent
magnet rotor exploiting trapezoidal sensorless control.
The STEVAL-IHM017V1 features complete hardware for developing motor control
applications based on ST7MC peripherals including motor control peripheral (MTC). The
STEVAL-IHM017V1 uses an in-circuit communication (ICC) standard interface to connect to
the host PC via In-circuit debuggers/programmers such as the inDART-STX board from
Softec. The board is designed to support 230 Vac of bus voltage up to 100 W of input power.
It also includes a power supply stage with VIPer12A-E as the buck converter to generate
voltage reference for the driver and the microcontroller.
Figure 1. STEVAL-IHM017V1 evaluation board
www.st.com
www.BDTIC.com/ST

Contents UM0522
2/39
Contents
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 System architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Safety and operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Evaluation board intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 Evaluation board installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Electronic connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.5 Evaluation board operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 ST7FMC2S4T6 microcontroller functions . . . . . . . . . . . . . . . . . . . . . . . 10
4.1 Main features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 STD5NK52ZD-1 characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6 Board electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 Board architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.2 Power stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7.3 ICC connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.4 Board schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8 Motor control operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8.1 Environmental considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8.2 Hardware requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8.3 Software requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
8.3.1 Installing the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
STEVAL-IHM017V1 - GUI installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
3rd party software installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Installation note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
www.BDTIC.com/ST

UM0522 Contents
3/39
8.4 Board setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.5 Firmware description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.6 Configuring the firmware using GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.7 Motor type selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8.8 "3-phase BLAC/DC (trapezoidal)" settings . . . . . . . . . . . . . . . . . . . . . . . . 22
8.9 “3-phase BLAC/DC (trapezoidal)" advanced settings . . . . . . . . . . . . . . . . 24
8.10 Changing the maximum current allowed by GUI . . . . . . . . . . . . . . . . . . . 26
8.11 Compiling the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.12 Programming firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.13 Setup option byte . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.14 Board connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.15 Changing the maximum current level allowed . . . . . . . . . . . . . . . . . . . . . 31
8.16 Driving the BLDC motor (trapezoidal - sensorless) . . . . . . . . . . . . . . . . . 32
8.17 LED behavior after power-on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
8.18 Potentiometers functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9 Bill of material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
11 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
www.BDTIC.com/ST

List of figures UM0522
4/39
List of figures
Figure 1. STEVAL-IHM017V1 evaluation board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 2. Motor control system architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 3. STD5NK52ZD-1, package and internal schematic diagram . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4. Board architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 5. Power supply architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 6. Gate driving network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 7. Board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 8. ICC connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 9. Board schematic - control block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 10. Board schematic - power block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 11. STVD7 for InDART-STX toolset configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 12. Motor type choice window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 13. "3-phase BLAC/DC (trapezoidal)" settings basic parameters window . . . . . . . . . . . . . . . . 22
Figure 14. “3-phase BLAC/DC (trapezoidal)" advanced parameters window . . . . . . . . . . . . . . . . . . . 25
Figure 15. ST7VD active project configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 16. System setup for programming phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 17. Option byte settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 18. Programming option auto window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Figure 19. System setup for running phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
www.BDTIC.com/ST

UM0522 List of tables
5/39
List of tables
Table 1. ST7FMC2S4T6 functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 2. Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 3. Board electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 4. Configuration “.h” files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table 5. "3-phase BLAC/DC (trapezoidal)" basic parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Table 6. "3-phase BLAC/DC (trapezoidal)" advanced parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Table 7. Potentiometer functionality based on open/closed loop driving strategy . . . . . . . . . . . . . . 32
Table 8. Bill of materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Table 9. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
www.BDTIC.com/ST

Overview UM0522
6/39
1 Overview
1.1 Features
●Input voltage 220 - 230 Vac
●Maximum power 100 W
●Power MOSFET STD5NK52ZD-1 - 4.4 A 520 V included
●15 V auxiliary power supply connector
●Programming and debug support via 10-pin ICC connector
●Three potentiometers for runtime settings
●Start/stop button
●Reset button
1.2 Applications
●Refrigerator compressors
●Dishwasher pumps
www.BDTIC.com/ST

UM0522 System architecture
7/39
2 System architecture
A generic motor control system can be basically schematized as the arrangement of four
main blocks (see Figure 2):
●A control block whose main tasks are to accept user command and motor drive
configuration parameters and to provide digital signals to implement the proper motor
driving strategy
●A power block that makes a power conversion from DC bus transferring it into the motor
by means of a three-phase inverter topology
●The motor itself. The STEVAL-IHM017V1 board is able to drive a three-phase
brushless motor with permanent magnet rotor exploiting trapezoidal sensorless control.
●The power supply block is able to accept 230 Vac input voltage and provide the proper
levels to supply both the control block and power block devices.
Figure 2. Motor control system architecture
The system proposed by STEVAL-IHM017V1 includes all the above hardware blocks (apart
the motor) plus a software GUI that allows configuring the motor drive. Moreover, an open
source C code is available, derived from the ST7MC motor control libraries, allowing easy
customization and extension of control algorithms. The core of the control block is
constituted of an ST7MC MCU that provides the driving signals to the power block according
to a driving strategy, the latter one closely related to the motor type and characteristics.
Driving signals are constituted of 3 complementary PWM signals (in the range of 0-5 V) for
providing logic inputs for high/low side gate driver belonging to the power block. In the
system proposed, three legs are present (3-phase inverter). The power block, based on the
gate drivers L6386 and Power MOSFET (STD5NK52ZD-1), converts the control signals
from ST7MC MCU to power signals for the three phase inverter in order to drive the motor.
The board can be supplied by an AC power supply of 230Vac with a maximum input power
of 100 W. Please refer to Section 7: Board architecture on page 14 for more details on
system architecture.
With the included Power MOSFET device STD5NK52ZD-1, the maximum rating of rectified
voltage is 520 V and the maximum continuous current is 4.4 A at 25°C.
Control
Block
Power
Block
Power
Supply Motor
www.BDTIC.com/ST

Safety and operating instructions UM0522
8/39
3 Safety and operating instructions
3.1 General
Warning: During assembly and operation, STEVAL-IHM017V1
evaluation board poses several inherent hazards, including
bare wires, moving or rotating parts, and hot surfaces. There
is danger of serious personal injury and damage to property,
if the kit or its components are improperly used or installed
incorrectly.
All operations involving transportation, installation and use, as well as maintenance are to
be carried out by skilled technical personnel (national accident prevention rules must be
observed). For the purposes of these basic safety instructions, "skilled technical personnel"
are suitably qualified people who are familiar with the installation, use, and maintenance of
power electronic systems.
3.2 Evaluation board intended use
The STEVAL-IHM017V1 evaluation board is a component designed for demonstration
purposes only, and shall not be used for electrical installation or machinery. The technical
data as well as information concerning the power supply conditions shall be taken from the
documentation and strictly observed.
3.3 Evaluation board installation
The installation and cooling of the demonstration kit boards shall be in accordance with the
specifications and the targeted application (see Section 8: Motor control operations on
page 19).
The motor drive converters shall be protected against excessive strain. In particular, no
components are to be bent, or isolating distances altered during the course of transportation
or handling.
No contact shall be made with other electronic components and contacts.
The boards contain electrostatically sensitive components that are prone to damage through
improper use. Electrical components must not be mechanically damaged or destroyed (to
avoid potential health risks).
3.4 Electronic connections
Applicable national accident prevention rules must be followed when working on the main
power supply with a motor drive. The electrical installation shall be completed in accordance
with the appropriate requirements (e.g., cross-sectional areas of conductors, fusing, PE
connections; for further information, see Section 8: Motor control operations on page 19).
www.BDTIC.com/ST

UM0522 Safety and operating instructions
9/39
3.5 Evaluation board operation
A system architecture which supplies power to the STEVAL-IHM017V1 evaluation board
shall be equipped with additional control and protective devices in accordance with the
applicable safety requirements (e.g., compliance with technical equipment and accident
prevention rules).
Warning: Do not touch the board after disconnection from the voltage
supply, as several parts and power terminals which contain
possibly energized capacitors need to be allowed to
discharge.
www.BDTIC.com/ST

ST7FMC2S4T6 microcontroller functions UM0522
10/39
4 ST7FMC2S4T6 microcontroller functions
4.1 Main features
●TQFP44 package
●16 Kbyte dual voltage Flash program memory with read-out protection capability
●768 bytes RAM (256 stack bytes)
●Clock, reset and supply management with:
– enhanced reset system
– enhanced low voltage supervisor (LVD) for mains supply and auxiliary voltage
detector (AVD) with interrupt capability
– clock sources: crystal/ceramic resonator oscillators and bypass for external clock,
clock security system
– four power-saving modes: halt, active-halt, wait and slow
●Configurable window watchdog timer
●Nested interrupt controller with 14 interrupt vectors
●Two 16-bit timers
●One 8-bit auto-reload timer
●Serial peripheral interface (SPI) (not used in this evaluation board)
●Serial communication interface (LINSCI™) (not used in this evaluation board)
●Motor controller (MTC) peripheral with:
– 6 high sink pulse width modulator (PWM) output channels
– asynchronous emergency stop
– analog inputs for rotor position detection
– permanent magnet motor coprocessor including: multiplier, programmable filters,
blanking windows and event counters
– Operational amplifier and comparator for current limitation
●10-bit analog-to-digital converter (ADC) with 11 inputs
●In-circuit communication interface (ICC, debug)
Table 1. ST7FMC2S4T6 functions
Function I/O name Description
(depends on embedded software)
MTC
MCO0 PWM outputs high side phase A
MCO1 PWM outputs low side phase A
MCO2 PWM outputs high side phase B
MCO3 PWM outputs low side phase B
MCO4 PWM outputs high side phase C
MCO5 PWM outputs low side phase C
MCIA, MCIB, MCIC Analog or digital input for position sensor or
B.E.M.F. detection
www.BDTIC.com/ST

UM0522 ST7FMC2S4T6 microcontroller functions
11/39
MTC
MCVREF Not used in this evaluation board
NMCES Emergency stop
OAP Operational amplifier positive input
OAN Operational amplifier negative input
OAZ Operational amplifier output
MCCREF Current limitation reference
MCPWMV PWM output V user for current reference
MCZEM Not used in this evaluation board
MCDEM Not used in this evaluation board
SPI
MISO Master in/slave out data - not used in this
evaluation board
MOSI Master out/slave in data - not used in this
evaluation board
SCK Serial clock - not used in this evaluation board
LINSCI™
RDI Received data input - not used in this evaluation
board
TDO Transmit data output - not used in this evaluation
board
10-bit ADC
AIN12 Trimmer R63 reading input
AIN11 Trimmer R62 reading input
AIN7 Trimmer P61 reading input
ICC
ICCCLK Output serial clock
ICCDATA Input/output serial data
ICCSEL/Vpp Programming voltage input
Other I/O PE2 Start/stop pushbutton
PB7 LED management
Table 1. ST7FMC2S4T6 functions (continued)
Function I/O name Description
(depends on embedded software)
www.BDTIC.com/ST

STD5NK52ZD-1 characteristics UM0522
12/39
5 STD5NK52ZD-1 characteristics
The STD5NK52ZD-1 is a n-channel Power MOSFET in the IPAK package (520 V - 1.22 Ω-
4.4 A) Zener-protected, SuperMESH™.
Figure 3. STD5NK52ZD-1, package and internal schematic diagram
Stresses above the limit shown in Table 2 may cause permanent damage to the device.
Table 2. Absolute maximum ratings
Symbol Parameter Value Unit
VDS Drain-source voltage (VGS = 0) 520 V
VDGR Drain-gate voltage (RGS = 20 kΩ)520V
VGS Gate-source voltage ± 30 V
IDDrain current (continuous) at TC= 25°C 4.4 A
IDDrain current (continuous) at TC= 100°C 2.7 A
IDM (1)
1. Pulse width limited by safe operating area
Drain current (pulsed) 17.6 A
PTOT Total dissipation at TC= 25°C 70 W
3
2
1
IPAK
www.BDTIC.com/ST

UM0522 Board electrical characteristics
13/39
6 Board electrical characteristics
Stresses above the limit shown in Table 3 may cause permanent damage to the devices
present inside the board. This is a stress rating only and functional operation of the device
under these conditions is not implied. Exposure to maximum rating conditions for extended
periods may affect device reliability. 15 V bias current measurement can be useful to check
the working status of the board. If measured value is considerably greater than typical value,
it means that some damage has occurred in the board. Supply the control board using a
15 V power supply connected to CON2 observing the polarity.
Table 3. Board electrical characteristics
Board parameters STEVAL-IHM017V1 Unit
Min Max
15 V auxiliary supply range – CON2 12 15 V
15 V bias current (typical) 23 23 mA
VBUS – J9 30 270 Vac
www.BDTIC.com/ST

Board architecture UM0522
14/39
7 Board architecture
The STEVAL-IHM017V1 can be schematized as in Figure 4
Figure 4. Board architecture
The heart of the evaluation board is the ST7MC microcontroller with a dedicated peripheral
included to drive the three-phase brushless motor with permanent magnet rotor exploiting
trapezoidal sensorless control. The board is provided with three potentiometers (R61, R62,
R63) used for tuning, in real time, some parameters related to the drive. See Section 8:
Motor control operations on page 19.
Two LEDs (green/red) are used to get information about the status of the system. Their
behavior is related to the drive. See Section 8: Motor control operations on page 19.
In normal functionality it is expected that the board is supplied by VBUS connector J9 but an
auxiliary supply connector CON2 is included on the board to feed the drivers and the
microcontroller. This auxiliary supply can be useful for safety reasons, for example it should
be used to program or debug the device without feeding the board with high voltage.
One communication system can be established with the microcontroller:
●ICC used for programming/debugging purposes
7.1 Power supply
The power supply is able to address a wide range of AC input voltage voltages from 30 Vac
up to 270 Vac. The alternate current input is rectified by a diodes bridge and bulk capacitor
to generate a direct current bus voltage approximately equal to Vac minus the voltage
drop on the bridge and ripple.
Then we have used a VIPer12A-E based buck converter to generate voltage reference for
driver 15 V and a linear voltage regulator L7805 to generate the microcontroller voltage
reference (see Figure 5).
ST7MCST7MC
Power
Supply
Power
Supply
PWMs
ICCICC LEDsLEDs
5V
Potentiometers
and button
Potentiometers
and button
V Bus
MM
L6386L6386
L6386L6386
L6386L6386
Vdriver
R
SENSE
2
www.BDTIC.com/ST

UM0522 Board architecture
15/39
Figure 5. Power supply architecture
7.2 Power stage
The power stage is based on six power MOSFETs in full 3-phase bridge configuration. In
the board there are six STD5NK52ZD-1s in an IPAK package. Each device contains the
freewheeling Zener diode. Three L6386 have been used to drive the Power MOSFETs gates
and for hardware current protection. For each Power MOSFET in the 3-phase bridge the
network shown in Figure 6 (default configuration) has been used as the starting
configuration.
Figure 6. Gate driving network
In this default configuration the gate of the Power MOSFET is turned on by means of R1 and
D22 while the turnoff is performed very fast by means of the Q1 transistor. It is also possible
to use the alternate configuration of the network (See Figure 6). To set this configuration
transistor Q1, resistor R5 and C13 must be removed from each network (6). The direction of
the diode D22 must be inverted and a resistor R20 must be mounted. In this alternate
configuration the gate of the Power MOSFET is turned on by means of R1 and R20 while
the turnoff is performed by means of R1 and D22.
RectifierRectifier
Vac Vdc = Vac
2
Vbus
Buck converter
VIPer 12 +15V +5V
Linear regulator
L7805
Vdrivers
15V auxiliary
supply CON2
D22
R21
22R
R1
100R R5
220R
C13
100pF
Q1
R20
D22
R21
22R
R1
100R
Default configuration Alternate configuration
Turn on
Turn off
Turn on
Turn off
www.BDTIC.com/ST

Board architecture UM0522
16/39
Figure 7. Board layout
7.3 ICC connector
The ICC connector (J7) is used to establish ICC communication for programming/debugging
purposes. The pinout is shown in Figure 8. This connector is compatible with Softec's
inDART-STX board (not included in the package).
Figure 8. ICC connector
www.BDTIC.com/ST

UM0522 Board architecture
17/39
7.4 Board schematic
Figure 9. Board schematic - control block
+5V
D23
STTH1L06A
GNDBB1
R36 N.M.
BC2
R20 N.M.
R37 22R
R47 N.M.
R26
N.M.
D24
STTH1L06A
BA2
BC1
D26
STTH1L06A
D22
STTH1L06A
+5V
R21 22R
GNDBD1
BA1
+15V
+15V
+15V
R61
R19 1K
GNDBF1
C18 N.M.
LIN
1
SD
2
HIN
3
VCC
4
DIAG
5
CIN
6
GND
7
VBOOT 14
HVG 13
OUT 12
NC 11 NC 10
LVG 9
GND 8
IC3 L6386D
BD2
LIN
1
SD
2
HIN
3
VCC
4
DIAG
5
CIN
6
GND
7
VBOOT 14
HVG 13
OUT 12
NC 11 NC 10
LVG 9
GND 8
IC4 L6386D
LIN
1
SD
2
HIN
3
VCC
4
DIAG
5
CIN
6
GND
7
VBOOT 14
HVG 13
OUT 12
NC 11 NC 10
LVG 9
GND 8
IC5 L6386D
R31 22R
R23 12K
C11
2.2uF -16V
R62
NC 11 NC 10
LVG 9
GND 8
IC3 L6386D
BD2
LIN
1
SD
2
HIN
3
VCC
4
DIAG
5
CIN
6
GND
7
VBOOT 14
HVG 13
OUT 12
NC 11 NC 10
LVG 9
GND 8
IC4 L6386D
LIN
1
SD
2
HIN
3
VCC
4
DIAG
5
CIN
6
GND
7
VBOOT 14
HVG 13
OUT 12
NC 11 NC 10
LVG 9
GND 8
IC5 L6386D
R31 22R
R23 12K
C11
2.2uF -16V
R62
C12
2.2uF -16V
C7
2.2uF -16V
LS+5V
R63
R1 100R R5
220R
C13100pF
3
2
1
Q1 BC807 -25
C14
100pF
3
2
1
Q2 BC807 -25R6 100R
R7 220R
C15
100pF
C17
1nF
3
2
1
Q3 BC807 -25
R8 100R
R9
220R
A C
D12
LED
C16
100pF
AC
D13
LED
3
2
1
Q4
BC807 -25
R11 100R
R14
220R
D27
STTH1L06A
Not Mount
Not Mount
S2 SW PUSH
C19
100pF
+5V
3
2
1
Q5 BC807 -25
R44 2.7K
R30 100R R32
220R
C20
100pF
3
2
1
Q6 BC807 -25
R33 100R
R45 2.7K
R34
220R
C39
1nF
C28
100nF
X1
CSTCE16MOV53 - RO
C49 10nF
+5V
D25
STTH1L06A
BE2
R43 27K
R38 100K
IP
RBC
+5V C20
100pF
3
2
1
Q6 BC807 -25
R33 100R
R45 2.7K
R34
220R
C39
1nF
C28
100nF
X1
CSTCE16MOV53 - RO
C49 10nF
+5V
D25
STTH1L06A
BE2
R43 27K
R38 100K
IP
RBC
+5V
C22
1nF
C30 10nF
2
4
6
8
10
1
3
5
7
9
J7
ICC connector : HE10 male type
+5V
C23
470nF
25V
C24
470nF
25V
C25
470nF
25V
R39 10K
+5V
R40
100K
C34
470nF
R41 10K
R42 10K
BB2
R46
1.5K
MCO3 (HS)
1
OSC1
5
OSC2
6
Vss_1
7
Vdd_1
8
PA3/PWM0/AIN0
9
PA5/ARTIC1/AIN1
10
PB0/MCVREF
11
PB1/MCIA
12
PB2/MCIB
13
PB3/MCIC
14
PB4/MISO
15
PB5/MOSI/AIN3
16
MCO5 (HS)
3MCO4 (HS) 2
MCES
4
PB6 (HS)/SCK
17
PB7 (HS)/SS/AIN4
18
PC2/OAP
19
PC3/OAN
20
OAZ/MCCFI1/AIN6
21
PC4/MCCREF
22 PC7/MCPWMW/AIN7 23
VAREF 24
VSSA 25
VSS_0 26
VDD_0 27 RESET 28
PD0/OCMP2_A/AIN11 29
PD2/ICAP2_A/MCZEM/AIN12 31
PD1 (HS)/OCMP1_A/MCPWMV/MCDEM 30
PD3/ICAP1_A/AIN13 32
PD4/EXTCLK_A/AIN14/ICCCLK 33
PD5/AIN15/ICCDATA 34
PD6 (HS)/RDI 35
PD7 (HS)/TDO 36
PEO (HS)/OCMP2_B 37
PE1/OCMP1_B 38
PE2/ICAP2_B 39 PE3/ICAP1_B 40
VPP 41
MCO0 (HS) 42 MCO1 (HS) 43 MCO2 (HS) 44
IC6 ST7FMC2S4T6 -TQFP44
+5V
R35 N.M.
R51 56K
R52 47K
R53 t.b.d.
+5V
R54
PB0/MCVREF
11
PB1/MCIA
12
PB2/MCIB
13
PB3/MCIC
14
PB4/MISO
15
PB5/MOSI/AIN3
16
MCO5 (HS)
3MCO4 (HS) 2
MCES
4
PB6 (HS)/SCK
17
PB7 (HS)/SS/AIN4
18
PC2/OAP
19
PC3/OAN
20
OAZ/MCCFI1/AIN6
21
PC4/MCCREF
22 PC7/MCPWMW/AIN7 23
VAREF 24
VSSA 25
VSS_0 26
VDD_0 27 RESET 28
PD0/OCMP2_A/AIN11 29
PD2/ICAP2_A/MCZEM/AIN12 31
PD1 (HS)/OCMP1_A/MCPWMV/MCDEM 30
PD3/ICAP1_A/AIN13 32
PD4/EXTCLK_A/AIN14/ICCCLK 33
PD5/AIN15/ICCDATA 34
PD6 (HS)/RDI 35
PD7 (HS)/TDO 36
PEO (HS)/OCMP2_B 37
PE1/OCMP1_B 38
PE2/ICAP2_B 39 PE3/ICAP1_B 40
VPP 41
MCO0 (HS) 42 MCO1 (HS) 43 MCO2 (HS) 44
IC6 ST7FMC2S4T6 -TQFP44
+5V
R35 N.M.
R51 56K
R52 47K
R53 t.b.d.
+5V
R54 47K
C36 N.M
C50 1uF
R55 68K
C40 100nF
R56 33K
C37
47pF N.M
C38
47pF N.M
C41
47pF N.M
BF2
C51 10nF
C42
100nF
25V
+5V
C52
47K
C36 N.M
C50 1uF
R55 68K
C40 100nF
R56 33K
C37
47pF N.M
C38
47pF N.M
C41
47pF N.M
BF2
C51 10nF
C42
100nF
25V
+5V
C52 10nF
R60 100R
BE1
R22
N.M.
BEMFA BEMFB BEMFC
LSCS
C48
1nF
R59 10K
www.BDTIC.com/ST

Board architecture UM0522
18/39
Figure 10. Board schematic - power block
R25
100K -1/2W
1
23
Q7 STD5NK52ZD -1
HV Monitoring
BE2
1
23
Q8 STD5NK52ZD -1
1
23
Q9 STD5NK52ZD -1
BF2
1
23
Q10 STD5NK52ZD -1
1
23
Q11 STD5NK52ZD -1
1
23
Q12 STD5NK52ZD -1
Phase C Phase B
Phase A
R2
680K
R25
100K -1/2W
1
23
Q7 STD5NK52ZD -1
HV Monitoring
BE2
1
23
Q8 STD5NK52ZD -1
1
23
Q9 STD5NK52ZD -1
BF2
1
23
Q10 STD5NK52ZD -1
1
23
Q11 STD5NK52ZD -1
1
23
Q12 STD5NK52ZD -1
Phase C Phase B
Phase A
R2
680K
R4
12K
C6
1uF/16V 16V
GNDBD1
TR1
transil
1 2 3 J8
CON3
GNDBF1
+5V
BA1
+15V
120/230 - Vac
1 2
D6
BZX85C16
12
D5
BZX85C5V1
1 2
D19 STTH106
1 2
D18 STTH106
1 2
D20 STTH106
C2
2.2uF/25V
C4
22nF/50V
R24
100K -1/2W
C1
BE1
15 - 5A
R64 1.2K R65 1.2K R66 1.2K
Neutral - Main
Phase - Main
+15V
1
2
J9
230VAC
1 2
CON2
+15V
Vin
3
GND
2
Vout 1
IC2
L78L05ACZ
LSCS
1 2
D2
STTH106
R10 0.1R -2.5W
-+
D21 BRIDGE_2KPB**
C5
100uF/25V
C8
22nF/400V
D7
STTH108
t
NTC
R13 82K
R12 82K
R18 82K
R17 82K
R16 82K
R15 82K
C9
100nF/50V
1 2
D3
BZX84C15
D2
STTH106
R10 0.1R -2.5W
-+
D21 BRIDGE_2KPB**
C5
100uF/25V
C8
22nF/400V
D7
STTH108
t
NTC
R13 82K
R12 82K
R18 82K
R17 82K
R16 82K
R15 82K
C9
100nF/50V
1 2
D3
BZX84C15
L1
1mH/350mA
1 2
D1
1N4148
2
4
5
6
7
8
1
3
VDD DRAIN
SET RES
- +
0.23V
SOURCE
FB
IC1
VIPER12ADIP
Not mounted
TOKO 00499
BEMFC
GNDBB1
BEMFB
C3 10uF/35V
35V
C10 CAP NP 0.22uF 275V -X2
F1 FUSE 3A
BEMFA
BA2 BC1 BB2 BC2
R3 330K
BD2
220uF/450V
www.BDTIC.com/ST

UM0522 Motor control operations
19/39
8 Motor control operations
8.1 Environmental considerations
Warning: The STEVAL-IHM015V1 evaluation board must only be used
in a power laboratory. The voltage used in the drive system
presents a shock hazard.
The kit is not electrically isolated from the DC input. This topology is very common in motor
drives. The microprocessor is grounded by the integrated ground of the DC bus. The
microprocessor and associated circuitry are hot and MUST be isolated from user controls
and communication interfaces.
Warning: Any measurement equipment must be isolated from the main
power supply before powering up the motor drive. To use an
oscilloscope with the kit, it is safer to isolate the DC supply
AND the oscilloscope. This prevents a shock occurring as a
result of touching any SINGLE point in the circuit, but does
NOT prevent shocks when touching two or more points in the
circuit.
An isolated AC power supply can be constructed using an isolation transformer and a
variable transformer. A schematic of this AC power supply is in the application note, "AN438,
TRIAC + microcontroller: safety precautions for development tools." (Although this
application note was written for TRIAC, the isolation constraints still apply for switching
semiconductor devices such as MOFSETs.)
Note: Isolating the application rather than the oscilloscope is highly recommended in any case.
8.2 Hardware requirements
To set up the STEVAL-IHM017V1 evaluation board system, the following items are required:
●The board: STEVAL-IHM017V1
●High-voltage insulated AC power supply up to 230 Vac
●Softec inDART-STX (not included in the package)
●Softec ICC isolation board (not included in the package)
●Two 10-pin flat cables (not included in the package)
●3-phase brushless motor with permanet magnet rotor (not included in the package)
●Insulated oscilloscope (as needed)
●Insulated multimeter (as needed)
www.BDTIC.com/ST

Motor control operations UM0522
20/39
8.3 Software requirements
To customize, compile, and download the motor control firmware, the following software
must be installed:
●"STEVAL-IHM017V1 - GUI" (included in the CD-ROM)
●STVD7 for inDART-STX V.3.11 (also called "ST7 Toolset" downloadable from Softec's
website: www.softecmicro.com)
●Cosmic compiler - ST7 C compiler 16 Kbyte free version - 4.5c (downloadable from
Cosmic's website: www.cosmic-software.com).
8.3.1 Installing the software
STEVAL-IHM017V1 - GUI installation
Insert the CD-ROM provided with the kit and execute Setup.exe.
3rd party software installation
Follow the instructions of the related software to install and configure STVD7 for
inDARTSTX and cosmic compiler.
Installation note
1. Install the Cosmic compiler first. Use the default installation folder: "C:\Program
Files\COSMIC\CXST7_16Kbite". Registration is required before using the product. You
can perform this procedure at any time by running the "lmreg16k.exe" file inside
Cosmic's installation folder. Complete the form and click on the "Register by email"
button. You will receive a license file "license.lic" that must be copied inside the
installation folder under the "license" folder.
2. Then install STVD7 for inDART-STX. During the first run of the software after
installation, a prompt for the configuration of the toolset should appear. The toolset can
be configured at any time by opening "tools options" inside STVD7. To do this, click
"toolset", and select the "toolset" menu tab, select "ST7Cosmic" and configure as in
Figure 11.
Figure 11. STVD7 for InDART-STX toolset configuration
www.BDTIC.com/ST
