ST SPC58XXADPT144S REV.B User manual

Introduction
The SPC58XXADPT144S rev. B evaluation board supports STMicroelectronics SPC58xGxxE5, SPC58xCxxE5 and
SPC58xBxxE5 microcontrollers in eTQFP144 package with exposed pad down.
Figure 1. SPC58XXADPT144S rev. B
Note: Picture not contractual
SPC58XXADPT144S rev. B evaluation board
UM2827
User manual
UM2827 - Rev 1 - February 2021
For further information contact your local STMicroelectronics sales office.
www.st.com

1Overview
The SPC58XXADPT144S rev. B "mini module" is an evaluation board supporting STMicroelectronics
SPC58xGxxE5, SPC58xCxxE5 and SPC58xBxxE5 microcontrollers in eTQFP144 package with exposed pad
down.
The "mini module" is designed to be connected onto the SPC58xxMB motherboard, offering a mechanism for
easy customer evaluation of the supported devices, and to facilitate hardware and software development.
The "mini module" may be used as a stand-alone unit granting access to the MCU, but no access to the I/O pins
as any motherboard peripherals.
The "mini module" is configured by default for SPC58xB and SPC58xC easily supports also SPC58xG by simply
changing the following 3 TH jumper: JR14, JR18 & JR19, with the only drawback that some ports are not
mapped/aligned properly.
Figure 2. Overview of SPC58XXADPT144S rev. B "mini module" - top
UM2827
Overview
UM2827 - Rev 1 page 2/25

Figure 3. Overview of SPC58XXADPT144S rev. B "mini module" - bottom
1.1 Package contents
An SPC58XXADPT144S rev. B adapter package includes the following item:
• SPC58XXADPT144S rev. B "mini module"
1.2 Supported devices
The SPC58XXADPT144S rev. B "mini module" supports the following STMicroelectronics family of
microcontrollers in eTQFP144 package with exposed pad down:
• SPC58xBxxE5
• SPC58xCxxE5
• SPC58xGxxE5
UM2827
Package contents
UM2827 - Rev 1 page 3/25

2License agreement
The packaging of this evaluation board was sealed with a seal stating, " by breaking this seal, you agree to the
terms and conditions of the evaluation board license agreement, the terms and conditions of which are available
at https://www.st.com/resource/en/evaluation_board_terms_of_use/evaluationproductlicenseagreement.pdf ".
Upon breaking the seal, you and STMicroelectronics entered into the evaluation board license agreement, a
copy of which is also enclosed with the evaluation board for convenience.
Attention: This evaluation board only offers limited features for evaluating ST products. It has not been tested for use
with other products and is not suitable for any safety or other commercial or consumer application. This
evaluation board is otherwise provided “AS IS” and STMicroelectronics disclaims all warranties, express or
implied, including the implied warranties of merchantability and fitness for a particular purpose.
UM2827
License agreement
UM2827 - Rev 1 page 4/25

3Handling precautions
Please take care to handle the package contents in a manner such as to prevent electrostatic discharge.
Before the EVB is used or power is applied, please fully read the following sections on how to correctly configure
the board. Failure to correctly configure the board may cause irreparable component, MCU or EVB damage.
UM2827
Handling precautions
UM2827 - Rev 1 page 5/25

4Hardware description
4.1 Hardware features
The SPC58XXADPT144S rev. B "mini module" board has the following features:
• Connector for external power supplies input (5.0 V, 3.3 V, 1.25 V) used in stand-alone mode
• Reset button with driver and led indicator
• Socket for device in eTQFP144 package with exposed pad down
• Debug ports:
– 38-pin Mictor connector for Nexus level 3+
– 14-pin header connector for JTAG port
– 10-pin header connector for JTAG/DigRF port (LFAST)
• 40 Mhz crystal main oscillator with jumpers to optionally disconnect it
• 8 Mhz oscillator with jumpers to optionally disconnect it
• Clock input through SMA connector to optionally disconnect it
• 2 X SAMTEC QSH series, 240 way connector to connect "mini module" to motherboard
4.2 Hardware dimension and PCB component view
The "mini module" has the following dimensions:
• PCB area: 127 mm x 114.3 mm
• Top components height: 16.5 mm max
• Bottom components height: 3.5 mm max
• PCB thickness: 1.6 mm
UM2827
Hardware description
UM2827 - Rev 1 page 6/25

5Power and system configuration
5.1 Power supplies
When the "mini module" is plugged onto the motherboard, power is supplied directly by the motherboard. In this
setup, the external power supply input available on the "mini module" should NOT be used.
When the SPC58XXADPT144S rev.B "mini module" is used as a stand-alone board, external power supplies
must be used (5 V, 3.3 V, 1.25 V).
The following jumpers are used to configure the power supply:
Table 1. Supply related jumpers
Jumper Description Default Position
J1
VDD_HV_ADR_D voltage configuration,
select from 5.0V_LR (linear), 3.3V_SR
(switching) or 5.0V_SR (switching) (used
only for SPC58xGxxE5).
1-2 (5.0V_LR) Figure 4. SPC58XXADPT144S rev. B "mini module" -
top - D3
J3 Jumper to enable the use of supply
3.3V_SR Closed Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D3
J4 Jumper to enable the use of supply
5.0V_SR Closed Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D3
J5 Jumper to enable the use of supply
1.25V_SR Closed Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
J6
VDD_HV_ADR_S voltage configuration,
select from 5.0V_LR (linear), 3.3V_SR
(switching) or 5.0V_SR (switching)
1-2 (5.0V_LR) Figure 4. SPC58XXADPT144S rev. B "mini module" -
top - D2
J7
VDD_HV_ADV_S voltage configuration,
select from 5.0V_LR (linear), 3.3V_SR
(switching) or 5.0V_SR (switching)
1-2 (5.0V_LR) Figure 4. SPC58XXADPT144S rev. B "mini module" -
top - D2
J8 VDD_HV_IO_MAIN voltage configuration,
select from 5.0V_SR or 3.3V_SR 1-2 (5.0V_SR) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D3
J9 VDD_HV_IO_FLEX voltage configuration,
select from 5.0V_SR or 3.3V_SR 1-2 (5.0V_SR) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D3
J10 VDD_LV voltage configuration, select from
1.25V_SR or from ballast circuit 1-2 (1.25V_SR) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
J11 Ballast supply voltage configuration, select
from VDD_HV_IO_MAIN or from 5.0V_SR 1-2 (5.0V_SR) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C4
JP1
VDD_HV_FLA voltage configuration:
connect or disconnect VDD_HV_FLA from
VDD_HV_IO_MAIN
Closed Figure 5. SPC58XXADPT144S rev. B "mini module" -
bottom - C3
UM2827
Power and system configuration
UM2827 - Rev 1 page 7/25

5.2 System clock configuration
The "mini module" supports the usage of crystal clock sources as well as external clock source:
Table 2. Clock configuration jumpers
Jumper Description Default Position
J15 40 MHz crystal clock source enable
for pin EXTAL 1-2 (XT1 pin2) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B2
J17 40 MHz crystal clock source enable
for pin XTAL 1-2 (XT1 pin1) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B2
J19 Enable 8 MHz oscillator power
supply Open Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B1
J21 External clock source from 8 MHz
oscillator or SMA connector
1-2 (8 MHz
oscillator)
Figure 4. SPC58XXADPT144S rev. B "mini module" - top -
B2
5.3 Reset circuit
The "mini module" supports different ways to reset the microcontroller.
To use and perform the reset driving there are different jumpers and switches:
Table 3. Reset configuration jumpers
Jumper Description Default Position
SW1 Reset push button Open Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D1
J22
Connect the external reset to the reset
driver for
ESR0 and PORST pins
Close Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D1
J20 Connect the external reset to ESR0 pin Close Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D1
J25 Connect the external reset to PORST pin Close Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D2
UM2827
System clock configuration
UM2827 - Rev 1 page 8/25

5.4 Port configuration
The following jumpers need to configure the ports:
Table 4. Ports related jumpers
Jumper Description Default Position
JP13 TESTMODE settings Close (10 KΩ pull-
down) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A2
J13
RSTIN configuration
• 1-2: ESR0
• 2-3: PORST
2-3
(PORST) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B2
JP2
JTAG/DigRF pin 9 configuration
• 1-2: EVTO
• 2-3: ESR0
1-2
(EVTO) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
JP3
PIN26 configuration
• 1-2: PG1
• 2-3: EVTI (SPC582B)
Closed 1-2 Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C2
JP4
EVTI SWITCH configuration
• 1-2: to JP3 (SPC582B)
• 2-3: to JP5 (SPC58xG)
Closed 1-2 Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C3
JP5
PM5/EVTI configuration
• 1-2: PM5
• 2-3: EVTI (SPC58xG)
Closed 1-2 Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C3
JP6
PIN27 configuration
• 1-2: PG2
• 2-3: EVTO (SPC582B)
Closed 1-2 Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C3
JP7
EVTO SWITCH configuration
• 1-2: to JP6 (SPC582B)
• 2-3: to JP8 (SPC58xG)
Closed 1-2 Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C3
JP8
PIN130 configuration
• 1-2: PM6
• 2-3: EVTO (SPC58xG)
Closed 1-2 Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C3
UM2827
Port configuration
UM2827 - Rev 1 page 9/25

5.5 SPC58xG configuration
The following jumpers need to configure the board for support the SPC58xG:
Table 5. SPC58xG configuration related jumpers
Jumper Description Default Position
JR2 Device pin 134 port
configuration
1-2
(closed with PCB trace for connect
pin 134 to PC[13] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
JR3 Device pin 133 port
configuration
1-2
(closed with PCB trace for connect
pin 133 to PC[14] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
JR4 Device pin 132 port
configuration
1-2
(closed with PCB trace for connect
pin 132 to PC[15] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
JR5 Device pin 40 port
configuration
1-2
(closed with PCB trace for connect
pin 40 to PI[7] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR6 Device pin 34 port
configuration
1-2
(closed with PCB trace for connect
pin 34 to PI[5] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR7 Device pin 32 port
configuration
1-2
(closed with PCB trace for connect
pin 32 to PI[3] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR8 Device pin 30 port
configuration
1-2
(closed with PCB trace for connect
pin 30 to PI[1] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR9 Device pin 20 port
configuration
1-2
(closed with PCB trace for connect
pin 20 to PI[8] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
JR10 Device pin 39 port
configuration
1-2
(closed with PCB trace for connect
pin 39 to PI[6] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR11 Device pin 33 port
configuration
1-2
(closed with PCB trace for connect
pin 33 to PI[4] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR12 Device pin 31 port
configuration
1-2
(closed with PCB trace for connect
pin 31 to PI[2] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B2
JR15 Device pin 141 port
configuration
1-2
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
(Closed with PCB trace for connect
pin 141 to PM[2] )
JR16 Device pin 140 port
configuration
1-2
(closed with PCB trace for connect
pin 140 to PM[0] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
JR17 Device pin 135 port
configuration
1-2
(closed with PCB trace for connect
pin 135 to PK[14] )
Figure 5. SPC58XXADPT144S rev. B "mini
module" - bottom - B3
JR14
Device pin 98 port
configuration / function
configuration
1-2
(connect pin 98 to ESR0 )
Figure 4. SPC58XXADPT144S rev. B "mini
module" - top - A3
JR18
Device pin 25 port
configuration / function
configuration
1-2
(connect pin 25 to AGND )
Figure 4. SPC58XXADPT144S rev. B "mini
module" - top - C2
UM2827
SPC58xG configuration
UM2827 - Rev 1 page 10/25

Jumper Description Default Position
JR19
Device pin 24 port
configuration / function
configuration
1-2
(connect pin 24 to
VDD_HV_ADR_D )
Figure 4. SPC58XXADPT144S rev. B "mini
module" - top - C3
5.6 Test points
The "mini module" has several test points. Below all test points description:
Table 6. Test points
Test point Description Position
GT1 GND test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A4
GT2 GND test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C4
GT3 GND test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C2
GT4 GND test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A1
GT5 GND test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D1
GT6 AGND test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B2
GT7 VSS_OSC test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
TP1 TCK test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A2
TP2 TMS/Txp test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
TP3 TDI/Txn test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
TP4 TDO/Rxp test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
TP5 JCOMP/Rxn test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
TP6 J23A, QSH connector, pin10 (PA5) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A4
TP7 J23A, QSH connector, pin11 (PA6) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A4
TP8 J23A, QSH connector, pin12 (PA7) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
TP9 J23A, QSH connector, pin13 (PA8) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
TP10 J23A, QSH connector, pin14 (PA9) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
TP11 J23A, QSH connector, pin19 (PA14) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
TP12 J23A, QSH connector, pin49 (PE4) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
TP13 J24B, QSH connector, pin210 (PD6) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C1
TP14 J24B, QSH connector, pin209 (PD7) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C1
TP15 J24B, QSH connector, pin207 (PD9) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C1
TP16 J23A, QSH connector, pin53 (PE8) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - B4
TP17 J24B, QSH connector, pin183 (PF13) test point Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C1
UM2827
Test points
UM2827 - Rev 1 page 11/25

5.7 Connectors
The "mini module" has the following connectors:
Table 7. Connectors
Connectors Description Position
J18 38-pin Mictor connector for Nexus level 3+ Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A1
J14 14-pin header connector for JTAG interface Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A3
CN1 10-pin header connector for JTAG/DigRF
port Figure 4. SPC58XXADPT144S rev. B "mini module" - top - A2
J12 Fault collection and control unit (FCCU) pin,
for failure notification Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C2
J23, J24
2 X SAMTEC QSH series, 240 way
connector to connect "mini module" to
motherboard
Figure 5. SPC58XXADPT144S rev. B "mini module" - bottom -
A1/A4
J2 External power supplies input (5 V, 3.3 V,
1.25 V) Figure 4. SPC58XXADPT144S rev. B "mini module" - top - D4
J26 SMA connector for external clock input Figure 4. SPC58XXADPT144S rev. B "mini module" - top - C2
UM2827
Connectors
UM2827 - Rev 1 page 12/25

6Layout overview
Figure 4. SPC58XXADPT144S rev. B "mini module" - top
1
2
3
4
ABCD
UM2827
Layout overview
UM2827 - Rev 1 page 13/25

Figure 5. SPC58XXADPT144S rev. B "mini module" - bottom
1
2
3
4
ABCD
UM2827
Layout overview
UM2827 - Rev 1 page 14/25

7BOM
Table 8. BOM
Item QTY Reference Manufacturer code Value Part description
1 8 C1, C4, C10, C28,
C31, C46, C47, C50 2.2 uF Mult. cer. cap. 16V 0805 - automotive series - not mounted
2 11
C2, C5, C8, C11,
C13, C15, C17, C19,
C21, C29, C32
100 nF Mult. cer. cap. 50V 0603
3 15
C3, C6, C9, C22,
C23, C24, C25, C26,
C27, C30, C33, C42,
C43, C44, C45
10 nF Mult. cer. cap. 50V 0603
4 7 C7, C34, C36, C38,
C40, C48, C49 2.2 uF Mult. Cer. cap. 16V 0805 - Automotive Series
5 5 C12, C14, C16, C18,
C20 4.7uF Mult. cer. cap. 16V 0805
6 4 C35, C37, C39, C41 47 nF Mult. cer. cap. 50V 0603
7 1 C51 47 pF DNP Mult. cer. cap. 50V SMD 0603 - Not
mounted
8 1 C52 27 pF Mult. cer. cap. 50V SMD 0603
9 2 C53, C55 10 pF DNP Mult. cer. cap. 50V SMD 0603 - not
mounted
10 2 C54, C57 DNM Mult. cer. cap. 50V SMD 0603 - not
mounted
11 1 C56 100 nF Mult. cer. cap. 50V SMD 0603
12 1 C58 27 pF Mult. cer. cap. 50V SMD 0603
13 1 CN1 TFM-105-02-L-D-WT SAMTEC
TFM-105-02-L-D-WT
SAMTEC 5x2 TFM connector - 1.27 mm
pitch - SMD - with weld tabs
14 1 DUT1 OTQ-144SG-0.5-003
CHORUS - device under test
- eTQFP144(X6) - ENPLAS
OTQ-144SG-0.5-003
15 7
GT1, GT2, GT3,
GT4, GT5, GT6,
GT7
TEST2 PCB test point - raised loops
16 3 J1, J6, J7 STRIP3PM +
STRIP1PM
Male strip 4 poles see mech part (close pin
1 and 2)
17 1 J2 MC-31072104 METZ CONNECT wire-to-board terminal
block, 5 mm, 4 Ways
18 4 J3, J4, J5, JP13 STRIP2PM Male strip 2 poles see mech part - normally
closed
19 15
J8, J9, J10, J11,
J15, J17, J21, JP2,
JR14, JR18, JR19,
JP3, JP5, JP6, JP8
STRIP3PM Male Strip 3 poles see mech part (close pin
1 and 2)
20 1 J12 STRIP2PM Male strip 2 poles
21 3 J13, JP4, JP7 STRIP3PM Male strip 3 poles see mech part (close pin
2 and 3)
22 1 J14 N2514-6002RB 3M conn flat male 14 pins, straight - pitch
2.54 mm
UM2827
BOM
UM2827 - Rev 1 page 15/25

Item QTY Reference Manufacturer code Value Part description
23 1 J18 5767054-1 Conn. SMD TYCO , vertical, female, 38P
MICTOR - GND pin lenght 2.74 mm
24 1 J19 STRIP2PM Malestrip 2 poles see mech part - OPEN
25 3 J20, J22, J25 STRIP2PM Male strip 2 poles see mech part - CLOSE
26 2 J23, J24 SAMTEC
QSH-120-01-L-D-A
SAMTEC 0.5 mm pitch high speed SMD
socket
27 1 J26 BNC-SMA-FEM-180 Conn. RF SMA 180°
28 1 JP1 Jumper SMD - CLOSE with a solder drop
29 14
JR2, JR3, JR4, JR5,
JR6, JR7, JR8, JR9,
JR10, JR11, JR12,
JR15, JR16, JR17
0R Resistor Jumper - Pin 1 and 2 default
closed with a PCB trace
30 1 LD1 KP-2012SYC Yellow Led diode yellow SMD 0805
31 1 LD2 KP-2012SRC-PRV Red Led diode red SMD 0805
32 1 OSC1 ECS-3953M-080-BN-
TR 8 MHz Hybrid quartz osc SMD ECS 3953M
33 1 Q1 NJD2873T4G NJD2873 NPN plastic power transistor DPAK
34 2 R1, R2 0R Resistor 1/10W 5% 0805
35 7 R3, R5, R23, R27,
R28, R29, R30 0R Resistor 1/10W 1% 0603
36 1 R4 0R1 Resistor 1/2W 1% 1206
37 2 R6, R9 4K7 Resistor 1/10W 1% 0603
38 2 R7, R11 10K DNP Resistor 1/10W 1% SMD 0603 - Not
mounted
39 1 R8 10K Resistor 1/10W 1% 0603
40 1 R10 0R DNP Resistor 1/10W 1% SMD 0603 - not
mounted
41 4 R12, R14, R15, R18 10K Resistor 1/10W 1% SMD 0603
42 1 R13 0R Resistor 1/10W 1% SMD 0603
43 2 R16, R17 560R Resistor 1/10W 1% SMD 0603
44 2 R19, R21 220R Resistor 1/10W 1% SMD 0603
45 1 R20 4K7 Resistor 1/10W 1% SMD 0603
46 1 R22 49R9 Resistor 1/16W 1% 0603
47 1 R24 100R Resistor 1/10W 1% 0603 - not mounted
48 2 R25, R26 DNM Resistor 1/16W 1% SMD 0603 - not
mounted
49 1 SW1 B6110-0 Pushbutton Pushbutton NO B6110-0
50 17
TP1, TP2, TP3, TP4,
TP5, TP6, TP7, TP8,
TP9, TP10, TP11,
TP12, TP13, TP14,
TP15, TP16, TP17
TESTPOINT Testpoint SMD - not mounted
51 1 U1 74LVC125AMTR 74LVC125AMTR I.C. Quad bus buffers SO14
52 1 U2 74V1G08STR 74V1G08STR I.C. Single 2-input and gate - SMD
SOT23-5L
53 1 XT1 NX5032GA 40MHz Quartz 40MHz SMD NX5032GA XTAL
NDK
UM2827
BOM
UM2827 - Rev 1 page 16/25

8Schematics
Figure 6. Power and decoupling
J3
default CLOSED
J4
default CLOSED
J5
default CLOSED
0603
100nF
50V
X7R
C5
VDD_HV_ADR_S
0603
10nF
50V
X7R
C6
AGND AGND
0603
100nF
50V
X7R
C8
VDD_HV_ADV_S
0603
10nF
50V
X7R
C9
AGND AGND
1-2 CLOSED
DEFAULT
2
1 3
J8
0603
100nF
50V
X7R
C29
0603
10nF
50V
X7R
C30
GND GND
0805
2.2uF
16V
X7R
C28
GND
N.M.
default CLOSE
JP1
0805
2.2uF
16V
X7R
C36
0603
47nF
50V
X7R
C37
0603
10nF
50V
X7R
C43
GND GND GND
0805
2.2uF
16V
X7R
C38
0603
47nF
50V
X7R
C39
0603
10nF
50V
X7R
C44
Pin 79
GND GND GND
0805
2.2uF
16V
X7R
C40
0603
47nF
50V
X7R
C41
0603
10nF
50V
X7R
C45
GND GND GND
Pin 58
0805
2.2uF
16V
X7R
C34
0603
47nF
50V
X7R
C35
0603
10nF
50V
X7R
C42
Pin 22
GND GND GND
Pin 99
NJD2873
Q1
Thermal plane
0805
2.2uF
16V
X7R
C48
0805
2.2uF
16V
X7R
C49
0805
2.2uF
16V
X7R
C50
N.M.
0805
2.2uF
16V
X7R
C46
N.M.
0805
2.2uF
16V
X7R
C47
N.M.
GND
for power 2W/3W
1-2 CLOSED
GNDGND
0R1
1/2W
1206
R4
2
13
J11
VDD_HV_IO_M AIN
5.0V_SR
1-2 CLOSED
DEFAULT
2
13
J10
VDD_LV
1-2 CLOSED
DEFAULT
2
1 3
J9
0603
100nF
50V
X7R
C32
0603
10nF
50V
X7R
C33
GND GND
VDD_HV_IO_FLEX
VDD_HV_IO_FLEX
VDD_LV
DEFAULT
AGND
N.M.
0805
2.2uF
16V
X7R
C4
0805
2.2uF
16V
X7R
C7
AGND
5.0V_SR3.3V_SR 1.25V_SR
BCTRL
5.0V_LR
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
5.0V_SR
5.0V_SR
2
1
3
4
J7
2
1
3
4
J6
0805
2.2uF
16V
X7R
C31
GND
N.M.
Pin 125
0805
4.7uF
16V
X7R
C12
GND
0603
100nF
50V
X7R
C13
0603
10nF
50V
X7R
C23
GND GND
Pin 23
0805
4.7uF
16V
X7R
C14
GND
0603
100nF
50V
X7R
C15
0603
10nF
50V
X7R
C24
GND GND
Pin 59
0805
4.7uF
16V
X7R
C16
GND
0603
100nF
50V
X7R
C17
0603
10nF
50V
X7R
C25
GND GND
Pin 78
0603
100nF
50V
X7R
C11
0603
10nF
50V
X7R
C22
VSS_OSC VSS_OSCVSS_OSC
N.M.
0805
2.2uF
16V
X7R
C10
Pin 83
0805
4.7uF
16V
X7R
C18
GND
0603
100nF
50V
X7R
C19
0603
10nF
50V
X7R
C26
GND GND
Pin 115
0805
4.7uF
16V
X7R
C20
GND
0603
100nF
50V
X7R
C21
0603
10nF
50V
X7R
C27
GND GND
Pin 142
VDD_HV_IO_MAIN
VDD_HV_IO_M AIN
0R
1/10W
0805
R2
GND
Pin 136
1
2
3
4
MC-31072104
J2
5.0V_SR3.3V_SR1.25V_SR
GND
GT1
TEST2
GT2
TEST2
GT3
TEST2
GT4
TEST2
GT5
TEST2
RING -HEADED FOR PROBE HOOK
AGND
GT6
TEST2
0R
1/10W
0603
R5
VSS_OSC GND
1/10W
0603
AGND GND
VSS_OSC
GT7
TEST2
0603
100nF
50V
X7R
C2
0603
10nF
50V
X7R
C3
AGND AGNDAGND
N.M.
0805
2.2uF
16V
X7R
C1
1-2 CLOSED
DEFAULT
5.0V_SR
2
1
3
4
J1
0R
1/10W
0805
R1
VDD_HV_ADR_D
Used only for CHORUS 6M
VDD_HV_ADR_D
VDD_HV_FLA
ADC
OSC & JTAG (3.3V or 5V)
I/O (3.3v - 5V)
MCU CORE LOGIC (1.25V)
SPC58xGxxE5 /
SPC58xCxxE5 /
SPC58xBxxE5
Power Pins
VDD_HV_ADR_S 42
VDD_HV_ADV_S 44
VDD_HV_JTAG_OSC 8 3
VDD_HV_N2 142
VDD_HV_IO_W0 23
VDD_HV_FLA 125
VDD_LV_W2 22
EPAD
145
EPAD
146
EPAD
147
EPAD
148
VDD_LV_S1 58
VDD_LV_E1 79
VDD_HV_N1 115
VDD_LV_E2 99
VDD_HV_IO0_S0 59
VDD_HV_IO0_E0 78
VSS_HV_ADR_S
41
VSS_HV_ADV_S
43
VSS_HV_OSC
80
I/O (3.3v - 5V)
Power Bar
FLEXRAY I/O (3.3V or 5V)
FLASH DECOUPLING
VDD_HV_IO_FLEX 136
Power Bar
BCTRL 124
DUT1A
AGND
VSS_OSC
GND
GND
0R
R3
UM2827 - Rev 1 page 17/25
UM2827
Schematics

Figure 7. Signals
4K7
1/10W
0603
R9
VDD_HV_IO_MAIN
ESR0 ESR0 PM14
Jumper setting
2-3 : Chorus 6M
1-2 : All others
PI[0..15]
PI[0..15]
PM4
Jumper setting
2-3 : Chorus 6M
1-2 : All others
Jumper setting
2-3 : Chorus 6M
1-2 : All others
PIN 140
PIN 141
PM0PM2 PF4PF5
PM[0..15]
PM[0..15]
PM2
PM4
PM5
PM6
PL8
Jumper setting
2-3 : Chorus 6M
1-2 : All others
PK14PC13
Jumper setting
2-3 : Chorus 6M
1-2 : All others
PK1
Jumper setting
2-3 : Chorus 6M
1-2 : All others
PK0
PIN 24
PIN 25
PIN 135
PM14
PI8PE4 PI6PG7 PI4PB12 PI2PB14
PI7PG8 PI5PB5 PI3PB13
PIN 20
PIN 30
PIN 31
PIN 32
PIN 33
PIN 34
PIN 39
PIN 40
PI9
PI1PB15
MDO0
PI1
PI2
PI3
PI4
PI5
PI6
PI7
PI8
PI9
PH[0..15]
PH[0..15]
PH0
PH1
PH2
PH4
PG[0..15]
MDO1
MCKO
PG[0..15]
PG3
PG4
PG5
PG6
PG9
PG10
PG11
PG12
PG13
PG14
PG15
MDO11
MDO10
PF[0..15]
PF[0..15]
MDO7
MDO8
PF0
PF1
PF2
PF3
PF6
PF7
PF8
PF9
PF10
PF11
PF12
PF13
PF14
PF15
PE[0..15]
PE[0..15]
MDO3
MDO4
MDO6
PE0
PE1
PE2
PE3
PE5
PE6
PE7
PE8
PE9
PE10
PE11
PE12
PE13
PE14
PE15
EXTAL
XTAL
PORST
JP13
default CLOSED
10K DNP
1/10W
0603
R7
10K
1/10W
0603
R8
GND
VDD_HV_IO_MAIN
NOT MOUNTED
PD[0..15] PD[0..15]
MDO9
PD0
PD1
PD2
PD4
PD5
PD6
PD7
PD8
PD9
PD10
PD11
PD12
PD13
PD14
PD15
PC[0..15] PC[0..15]
PC0
PC1
PC2
PC3
PC4
PC5
PC6
PC7
PC8
PC9
PC10
PC11
PC12
PC13 PC14 PC15
STRIP2PM
J12
FCCU_F1 LABEL ON PCB
FCCU_F0 LABEL ON PCB
PA[0..15] PA[0..15]
PA0
PA1
PA2
PA3
PA4
PA10
PA11
PA12
PA13
PA14
PA15
JCOMP/Rxn
TDO/Rxp
TDI/Txn
TMS/Txp
TCK
TP5TP4TP3TP2TP1
2-3 CLOSED
DEFAULT 2
1 3
J13 RSTIN
PORST
ESR0
Jumper setting
2-3 : PORST
1-2 : ESR0
PA[0]
113
PA[1]
110
PA[2]
109
PA[3]
68
PA[4]
96
TCK / PA[6]
92
TMS / PA[7]
89
TDI / PA[8]
88
TDO / PA[9]
90
PA[10]
118
PA[11]
119
PA[12]
111
PA[14]
87 PA[13]
112
PA[15]
72
PB[0]
57
PB[1]
56
PB[6] / MDO2
38
PB[7]
37
PB[8]
67
PB[9]
66
PB[10]
65
PB[11] / FCCU_F0
64
PD[0]
128
PD[1]
127
PD[2]
126
PD[4]
105
PD[5]
106
PD[6]
86
PD[7]
85
PD[8]
69
PD[9] / MDO9
62
PD[10]
63
PD[11]
53
PD[12]
17
PD[13]
18
PF[1] / MDO7 60
PF[2] 144
PF[3] 143
PF[6] / MDO10 70
PF[7] 71
PF[8] / MDO11 73
PF[9] 74
PF[10] 75
PF[12] 77
PF[13] 84
PF[14] 93
PF[15] 95
PG[1] / EVTI 26
PG[2] / EVTO 27
PG[3] / MCKO 28
PG[4] 29
PG[5] / MDO1 35
PG[6] 36
PG[9] 45
PG[10] 46
PG[11] 47
PG[12] 48
PG[13] 100
PG[14] 101
PG[15] 114
PE[0] 14
PE[1] 15
PE[2] 16
PE[3] / CLKOUT 19
PE[5] 102
PE[6] 103
PE[7] 104
PE[8] 107
PE[9] 108
PE[10] 121
PE[11] 122
PE[12] 131
PE[13] / MDO6 52
PE[14] / MDO4 50
PE[15] / MDO3 49
PORST
97
TESTMODE
94
XTAL
82
EXTAL
81
SPC58xGxxE5 / SPC58xCxxE5 / SPC58xBxxE5 Port Pins
PB[2]
55
PB[3]
54
PB[4] / MDO5
51
PC[0]
13
PC[1]
12
PC[6]
6
PC[7]
5
PC[8]
4
PC[9]
3
PC[10]
139
PC[11]
138
PC[12]
137
PC[13]
134
PC[14]
133
PC[15]
132
PC[2] / FCCU_F1
11
PC[3]
9
PC[4]
8
PC[5]
7
PD[14]
1
PD[15]
2
PF[11] 76
PF[0] / MDO8 61
PH[0] 116
PH[1] 117
PH[2] 120
PH[4] 123
PI[9] 21
PL[8] 10
PM[0] 140
PM[2] / RDY 141
PM[4] 129
PM[14] 98
JCOMP / PA[5]
91
PI[8] 20
PI[7] 40
PI[6] 39
PI[5] / MDO0 34
PI[4] 33
PI[3] 32
PI[2] 31
PI[1] 30
PK[0] / MSEO0 24
PK[1] / MSEO1 25
PK[14] 135
PM[6] 130
DUT1B
1
2
3
JR2
RESISTOR JUMPER
Jumper setting
2-3 : Chorus 6M
1-2 : All others
PC15PC14
PM0
PIN 132
PIN 133
PIN 134PC13
PC14
PC15
4K7
1/10W
0603
R6
VDD_HV_IO_MAIN
PE4
PG7
PG8
PB[0..15] PB[0..15]
PB0
PB1
PB2
PB3
PB4
PB6
PB7
PB8
PB9
PB10
PB11
MDO2
MDO5
PB5
PB12
PB13
PB14
PB15
PK[0..15]
PK[0..15]
PK1
PK14
PK0
PF4
PF5
VDD_HV_ADR_D
AGND
CLKOUT
1
2
3
JR3
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR4
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR5
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR6
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR7
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR8
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR9
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR10
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR11
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR12
Jumper setting
2-3 : Chorus 6M
1-2 : All others
1
2
3
JR15
1
2
3
JR16
1
2
3
JR17
RDY
MSEO0MSEO1
1/10W
0603
R23
2
13
JR14
1-2 CLOSED
DEFAULT
2
13
JR18
1-2 CLOSED
DEFAULT
2
13
JR19
1-2 CLOSED
DEFAULT
2
13
JP3
2
13
JP4
2
1 3
JP5
PG1
PG2
PIN26
PIN27
PIN26
PG1
EVTI EVTI
EVTI_CHO1MEVTI_CHO6M
PM5
2
13
JP6
2
13
JP7
2
1 3
JP8
PIN27
PG2
EVTO EVTO
EVTO_CHO1MEVTO_CHO6M
PIN130
PM6
PIN130
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
PM5/EVTI
PM5/EVTI
RESISTOR JUMPER RESISTOR JUMPER
RESISTOR JUMPER RESISTOR JUMPER RESISTOR JUMPER
RESISTOR JUMPER
RESISTOR JUMPER RESISTOR JUMPER RESISTOR JUMPER RESISTOR JUMPER
RESISTOR JUMPER RESISTOR JUMPER RESISTOR JUMPER
TESTMODE
UM2827 - Rev 1 page 18/25
UM2827
Schematics

Figure 8. JTAG, JTAG/LFast LVDS INTERFACE, reset and crystal
EXTAL
XTAL
EVB-EXTAL
ESR0
PORST
RST-MCU
OSC-MOD
EVB-EXTAL
EXTAL-SMA
RST-SW
VCC
GND
2 3
14 1
7
74LVC125AMTR
U1A
I2
5O2 6
OE2 4
74LVC125AMTR
U1B
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
3.3V_SR
VDD_HV_IO_MAIN
XTAL
EXTAL
ESR0
PORST
RST-SW
GND
GND
GND
GND
GND
GND
GND
GND
(MCU Crystal Input)
(MCU Crystal Output)
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
default OPEN
1-2 CLOSED
DEFAULT
GND
default CLOSED
default CLOSED
default CLOSED
REMOVE XTAL jumper when driving EXTAL from
Oscillator Module or External Source (PLL Enabled)
Connect XTAL jumper to GND when driving EXTAL from
Oscillator Module or External Source (PLL Bypass Mode)
Note - External 3.3V
regulator MUST be
enabled when using
oscillator module
Note - Internal
Pull-Up on Pin 1
SMA style
Connector
USER RESET LED
External Clock Input
MCU RESET LED
RESET
SO14
I3
9O3 8
OE3 10
74LVC125AMTR
U1C
SO14
SO14
NOT MOUNTED
NOT MOUNTED
2
13
STRIP3PM
J17
0R
1/10W
0603
R13
1 2
40MHz
NX5032GA
XT1
0603
10pF DNP
50V
COG/NP0
C53
0603
10pF DNP
50V
COG/NP0
C55
0603
100nF
50V
X7R
C56
STRIP2PM
J19
2
13
STRIP3PM
J21
49R9
1/16W
0603
1%
R22
EN
1
GND
2OUT 3
+Vs 4
8MHz
7x5
OSC1 10K
1/10W
0603
R18
560R
1/10W
0603
R16
4K7
1/10W
0603
R20
STRIP2PM
J22
Yellow
0805
LD1 STRIP2PM
J20
STRIP2PM
J25
220R
1/10W
0603
R19
220R
1/10W
0603
R21
560R
1/10W
0603
R17
Red
0805
LD2
2
1 3
STRIP3PM
J15
1
2
BNC-SMA-FEM-180
J26
ENABLE
GND
VCC
1
2
4
53
74V1G08STR
SOT23-5L
U2
Nexus level 3+ support
GND
RSTIN
TDO
TCK
TMS
TDI
ESR0
EVTI
MDO3
MDO2
MDO1
MDO0
EVTO
MCKO
MSEO0
10K
1/10W
0603
R14
GND
N/C
1
N/C
3
MDO09
5
VSTBY
37 ToolIO0
35 VBatt
33 VBatt
31 ToolIO1
29 TDET/WDTC
27 RSTOUT
25 MDO11
23 JCOMP
21 TDI
19 TMS
17 TCK
15 MDO10
13 TDO
11 RSTIN
9BootCFG
7
N/C 2
N/C 4
CLKOUT 6
MSEO0 38
MSEO1 36
MCKO 34
EVTO 32
MDO0 30
MDO1 28
MDO2 26
MDO3 24
MDO4 22
MDO5 20
MDO6 18
MDO7 16
RDY 14
VTREF 12
EVTI 10
MDO08 8
GND 39
GND 40
GND 41
GND 42
GND 43
5767054-1
J18
EVTI
EVTO
RSTIN
TDI
TDO
TCK
JCOMP
TMS
EVTI
EVTO
GND GND
GND
NOT MOUNTED
Jtag interface
TDI, TDO, TCK, TMS & JCOMP are not connected to
daughter card.
PORST, ESR0, EVTI and EVTO are connected to daughtercard
JTAG Connector
NOT MOUNTED
NOT MOUNTED
GND
1 2
3 4
5 6
7 8
9 10
11 12
13 14
N2514-6002RB
J14
10K
1/10W
0603
R12
10K DNP
1/10W
0603
R11
0R DNP
1/10W
0603
R10
0603
27pF
50V
COG/NP0
C52
0603
47pF DNP
50V
COG/NP0
C51
JCOMP
MDO9
MDO10
MDO11
MSEO1
MDO4
MDO5
MDO6
MDO7
RDY
MDO8
CLKOUT
10K
1/10W
0603
R15
Pushbutton
SW1
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VSS_OSC
JCOMP/Rxn
TCK
TDI/Txn
TDO/Rxp
TMS/Txp
EVTI
GND GND
GND
GND
DNM
1/16W
0603
R26
DNM
1/16W
0603
R25
0603
DNM
X7R
C54
0603
DNM
X7R
C57
0603
27pF
50V
COG/NP0
C58
SAMTEC TFM-105-02-L-D-WT
1 2
3 4
5 6
7 8
9 10
CN1
JTAG/DigRF LVDS INTERFACE
10 Pin Version
NOT MOUNTED !!!
J TAG, J TAG/Di g RF LVDS INT E RF ACE , Ne x u s Le ve l 3 +
Re s e t a n d Cr ys t a l Os c i lla t or
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
RSTIN
differential signals for DigiRF
0R
1/10W
0603
R30
0R
1/10W
0603
R29
0R
1/10W
0603
R28
0R
1/10W
0603
R27
JCOMP TMS TDI TDO
100R
1/10W
0603
R24
1-2 CLOSED
DEFAULT
ESR0
EVTO
2
13
JP2
UM2827 - Rev 1 page 19/25
UM2827
Schematics

Figure 9. Motherboard connectors
PA8
PA14
PG4
PG6
PG8
PG10
PG12
PG14
5.0V_SR
PE2
PE4
PE6
PE8
PE0
PE10
PE12
PE14
1.25V_SR
PC0
PC2
PC4
5.0V_SR
PC6
PC8
PC10
PC12
PC14
3.3V_SR
1.25V_SR
PA0
PA2
PA4
PA10
PA12
5.0V_SR
1.25V_SR
3.3V_SR
1.25V_SR
5.0V_SR
PA9
PG3
PG5
PG7
PG9
PG11
PG13
PG15
5.0V_SR
PE1
PE11
PE13
PE15
1.25V_SR
PE5
PE7
PE9
PE3
PC1
PC5
PC7
PC3
PC9
PC11
PC13
PC15
3.3V_SR
1.25V_SR
PA3
PA1
PA11
PA13
PA15
5.0V_SR
5.0V_SR
1.25V_SR
3.3V_SR
5.0V_SR
1.25V_SR
VDD_HV_I O_MAIN
5.0V_LR
5.0V_LR
3.3V_SR
3.3V_SR
5.0V_SR
5.0V_SR
1.25V_SR
1.25V_SR
VDD_HV_I O_MAIN
VDD_HV_I O_MAIN
5.0V_LR
5.0V_LR
VDD_HV_I O_MAIN
3.3V_SR
3.3V_SR
5.0V_SR
5.0V_SR
1.25V_SR
1.25V_SR
PE12
PF2
PG6
PG9
PG10
PG11
PG12
PH4
PC0
PC1
PC12
PC13
PC14
PC15
PA0
PA1
PA2
PA3
PA4
PA10
PA11
PA12
PA13
PA15
PB0
PB1
PB8
PB9
PB10
PB11
PD0
PD4
PD5
PD8
PD10
PD11
PD12
PD13
PD14
PD15
PE0
PE1
PE2
PE3
PE5
PE6
PE7
PE9
PE10
PE11
1.25V_SR
5.0V_LR
3.3V_SR
5.0V_SR
VDD_HV_I O_MAIN
PB15
1.25V_SR
5.0V_SR
3.3V_SR
1.25V_SR
3.3V_SR
PD7
PF13
1.25V_SR
1.25V_SR
PH3
PH1
3.3V_SR
PF1
PF11
PF15
PF3
PF5
PF7
PF9
5.0V_SR
PD1
PD3
PD5
PD9
PD11
PD13
PD15
3.3V_SR
PB1
PB3
PB5
PB7
PB9
PB11
PB13
PD6
3.3V_SR
PH0
PH2
PH4
1.25V_SR
PF0
PF10
PF12
PF14
3.3V_SR
PF2
PF4
PF6
PF8
5.0V_SR
PD0
PD2
PD4
PD8
PD10
PD12
PD14
1.25V_SR
PB0
PB2
PB4
PB6
PB8
PB10
PB12
PB14
1.25V_SR
5.0V_SR
3.3V_SR
1.25V_SR
3.3V_SR
5.0V_LR
1.25V_SR
1.25V_SR
5.0V_SR
5.0V_SR
3.3V_SR
3.3V_SR
VDD_HV_I O_MAIN
5.0V_LR
VDD_HV_I O_MAIN
5.0V_LR
1.25V_SR
1.25V_SR
5.0V_SR
5.0V_SR
3.3V_SR
3.3V_SR
VDD_HV_I O_MAIN
5.0V_LR
VDD_HV_I O_MAIN
RST-SW
PD6
PD7
PF13
3.3V_SR1.25V_SR 5.0V_LR5.0V_SR VDD_HV_IO_MAIN
RST-SW
PortE
GND
GND
GND
TP11
TP6
TP13 TP14
TP17
PA[0..15] PB[0..15] PC[0..15] PD[0..15] PE[0..15] PF[0..15] PG[0..15] PH[0..15]
PA[0..15] PB[0..15] PC[0..15] PD[0..15] PE[0..15] PF[0..15] PG[0..15] PH[0..15]
PortA PortB PortC PortD PortF PortG PortH
1
1
3
3
5
5
7
7
9
9
11
11
13
13
15
15
17
17
19
19
21
21
23
23
25
25
27
27
29
29
31
31
33
33
35
35
37
37
39
39
41
41
43
43
45
45
47
47
49
49
51
51
53
53
55
55
57
57
59
59
61
61
63
63
65
65
67
67
69
69
71
71
73
73
75
75
77
77
79
79
81
81
83
83
85
85
87
87
89
89
91
91
93
93
95
95
97
97
99
99
101
101
103
103
105
105
107
107
109
109
111
111
113
113
115
115
117
117
119
119
22
44
66
88
10 10
12 12
14 14
16 16
18 18
20 20
22 22
24 24
26 26
28 28
30 30
32 32
34 34
36 36
38 38
40 40
42 42
44 44
46 46
48 48
50 50
52 52
54 54
56 56
58 58
60 60
62 62
64 64
66 66
68 68
70 70
72 72
74 74
76 76
78 78
80 80
82 82
84 84
86 86
88 88
90 90
92 92
94 94
96 96
98 98
100 100
102 102
104 104
106 106
108 108
110 110
112 112
114 114
116 116
118 118
120 120
SAMTEC QSH-120-01-L-D-A
J23A
SH1
SH1
SH2
SH2
SH3
SH3
SH4
SH4
SH5
SH5
SH6
SH6
SH7
SH7
SH8
SH8
SH9 SH9
121
121
123
123
125
125
127
127
129
129
131
131
133
133
135
135
137
137
139
139
141
141
143
143
145
145
147
147
149
149
151
151
153
153
155
155
157
157
159
159
161
161
163
163
165
165
167
167
169
169
171
171
173
173
175
175
177
177
179
179
181
181
183
183
185
185
187
187
189
189
191
191
193
193
195
195
197
197
199
199
201
201
203
203
205
205
207
207
209
209
211
211
213
213
215
215
217
217
219
219
221
221
223
223
225
225
227
227
229
229
231
231
233
233
235
235
237
237
239
239
SH16 SH16
SH15 SH15
SH14 SH14
SH13 SH13
SH12 SH12
SH11 SH11
SH10 SH10
122 122
124 124
126 126
128 128
130 130
132 132
134 134
136 136
138 138
140 140
142 142
144 144
146 146
148 148
150 150
152 152
154 154
156 156
158 158
160 160
162 162
164 164
166 166
168 168
170 170
172 172
174 174
176 176
178 178
180 180
182 182
184 184
186 186
188 188
190 190
192 192
194 194
196 196
198 198
200 200
202 202
204 204
206 206
208 208
210 210
212 212
214 214
216 216
218 218
220 220
222 222
224 224
226 226
228 228
230 230
232 232
234 234
236 236
238 238
240 240
SAMTEC QSH-120-01-L-D-A
J23B
11
33
55
77
99
11 11
13 13
15 15
17 17
19 19
21 21
23 23
25 25
27 27
29 29
31 31
33 33
35 35
37 37
39 39
41 41
43 43
45 45
47 47
49 49
51 51
53 53
55 55
57 57
59 59
61 61
63 63
65 65
67 67
69 69
71 71
73 73
75 75
77 77
79 79
81 81
83 83
85 85
87 87
89 89
91 91
93 93
95 95
97 97
99 99
101 101
103 103
105 105
107 107
109 109
111 111
113 113
115 115
117 117
119 119
2
24
46
68
810
10 12
12 14
14 16
16 18
18 20
20 22
22 24
24 26
26 28
28 30
30 32
32 34
34 36
36 38
38 40
40 42
42 44
44 46
46 48
48 50
50 52
52 54
54 56
56 58
58 60
60 62
62 64
64 66
66 68
68 70
70 72
72 74
74 76
76 78
78 80
80 82
82 84
84 86
86 88
88 90
90 92
92 94
94 96
96 98
98 100
100 102
102 104
104 106
106 108
108 110
110 112
112 114
114 116
116 118
118 120
120
SAMTEC QSH-120-01-L-D-A
J24A
SH1 SH1
SH2 SH2
SH3 SH3
SH4 SH4
SH5 SH5
SH6 SH6
SH7 SH7
SH8 SH8
SH9
SH9
121 121
123 123
125 125
127 127
129 129
131 131
133 133
135 135
137 137
139 139
141 141
143 143
145 145
147 147
149 149
151 151
153 153
155 155
157 157
159 159
161 161
163 163
165 165
167 167
169 169
171 171
173 173
175 175
177 177
179 179
181 181
183 183
185 185
187 187
189 189
191 191
193 193
195 195
197 197
199 199
201 201
203 203
205 205
207 207
209 209
211 211
213 213
215 215
217 217
219 219
221 221
223 223
225 225
227 227
229 229
231 231
233 233
235 235
237 237
239 239
SH16
SH16
SH15
SH15
SH14
SH14
SH13
SH13
SH12
SH12
SH11
SH11
SH10
SH10
122
122 124
124 126
126 128
128 130
130 132
132 134
134 136
136 138
138 140
140 142
142 144
144 146
146 148
148 150
150 152
152 154
154 156
156 158
158 160
160 162
162 164
164 166
166 168
168 170
170 172
172 174
174 176
176 178
178 180
180 182
182 184
184 186
186 188
188 190
190 192
192 194
194 196
196 198
198 200
200 202
202 204
204 206
206 208
208 210
210 212
212 214
214 216
216 218
218 220
220 222
222 224
224 226
226 228
228 230
230 232
232 234
234 236
236 238
238 240
240
SAMTEC QSH-120-01-L-D-A
J24B
PA5
PA7PA6
PG0
PI0
PH5
PH6 PH7
PH8 PH9
PH10 PH11
PH12 PH13
PH14
VDD_HV_I O_FLEX
VDD_HV_I O_FLEXVDD_HV_I O_FLEX
PH15
PI3
VDD_HV_I O_FLEX
VDD_HV_IO_FLEX
TP7 TP8
TP10TP9
PB2
PB3
PC2
PC3
PC4
PC5
PC8
PC9
PC10
PC11
PC6
PC7
PF3
PI[0..15] PI[0..15]
PortI
PI1
PI2
PI3
PI4
PI6
PI7
PortM
TP15
TP12
TP16
PI1
PI2
PI4
PI7
PI5
PI6
PM4
PM6
PM14
PA14
PB4
PB5
PB6
PB7
PB12
PB13
PB14
PB15
PD9
PD1
PD2
PE4
PE8
PE13
PE14
PE15
PF0
PF1
PF4
PF5
PF6
PF7
PF8
PF9
PF10
PF11
PF12
PF14
PF15
PG3
PG4
PG5
PG7
PG8
PG13
PG14
PG15
PH0
PH1
PH2
PI8 PI9
PI5
PI8
PI9
PK[0..15]
PK1
PK14
PK0
PK[0..15]
PK0 PK1
PK14
PL8
PM[0..15]
PM2
PM4
PM5
PM6
PM14
PM0
PM[0..15]
PM0
PM2
PM5
PG1
PG2
PG1
PG2
UM2827 - Rev 1 page 20/25
UM2827
Schematics
