ST STM3240G-EVAL User manual

2 September 2011 Doc ID 022138 Rev 1 1/65
DRAFT
UM1461
User manual
STM3240G-EVAL evaluation board
Introduction
The STM3240G-EVAL evaluation board is a complete demonstration and development
platform for the STM32 F-4 series and includes an embedded STM32F407IGH6 high-
performance ARM®Cortex™-M4 32-bit microcontroller.
The full range of hardware features on the board is provided to help you evaluate all
peripherals (USB OTG HS, USB OTG FS, ethernet, motor control, CAN, MicroSD card,
smartcard, USART, Audio DAC, RS-232, IrDA, SRAM, MEMS, EEPROM… etc.) and
develop your own applications. Extension headers make it possible to easily connect a
daughter board or wrapping board for your specific application.
The in-circuit ST-LINK/V2 tool can be easily used for JTAG and SWD interface debugging
and programming.
Figure 1. STM3240G-EVAL evaluation board
www.st.com
All manuals and user guides at all-guides.com
all-guides.com

DRAFT
Contents UM1461
2/65 Doc ID 022138 Rev 1
Contents
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Demonstration software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Order code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Delivery recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Hardware layout and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Boot option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Clock source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.4 Reset source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.6 EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.7 CAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.8 RS-232 and IrDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.9 Motor control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.10 Smartcard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.11 MicroSD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.12 MEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.13 Potentiometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.14 ADC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.15 USB OTG FS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.16 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.17 USB OTG HS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.18 Camera module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.19 SRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.20 Development and debug support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.21 Display and input devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1 Daughter board extension connectors CN1, 2, 3 and 4 . . . . . . . . . . . . . . 22
All manuals and user guides at all-guides.com

DRAFT
UM1461 Contents
Doc ID 022138 Rev 1 3/65
3.2 Motor control connector CN5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.3 MicroSD connector CN6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.4 Ethernet RJ45 connector CN7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.5 USB OTG FS Micro-AB connector CN8 . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.6 USB OTG HS Micro-AB connector CN9 . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.7 CAN D-type 9-pin male connectors CN10 (CAN1 or CAN2) . . . . . . . . . . 32
3.8 Audio connector CN11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.9 Trace debugging connector CN13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.10 JTAG debugging connector CN14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.11 Camera module connector CN15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.12 RS-232 connector CN16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.13 Power connector CN18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.14 TFT LCD connector CN19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.15 Smartcard connector CN20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.16 ST-LINK/V2 connector CN21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.17 Camera extension connector CN23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.18 STM3240G-EVAL pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4 Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
All manuals and user guides at all-guides.com

DRAFT
Overview UM1461
4/65 Doc ID 022138 Rev 1
1 Overview
1.1 Features
■STM32F407IGT6 microcontroller. The MCU marking on the first boards manufactured is
STM32F457IGH6.
■16 Mbit SRAM
■1 Gbyte or more MicroSD card
■Boot from user Flash, system memory or SRAM
■Both ISO/IEC 14443 type A and B smartcard support
■I2C compatible serial interface 8 Kbytes EEPROM, MEMS and I/O expander
■IEEE 802.3-2002 compliant ethernet connector
■Two CAN 2.0 A/B channels on the same DB connector
■RS-232 communication
■IrDA transceiver
■USB OTG (HS and FS) with Micro-AB connector
■Inductor motor control connector
■I2S Audio DAC, stereo audio jack for headset
■3.2" 240x320 TFT color LCD with touchscreen
■4 color LEDs
■Camera module and extension connector for ST camera plug-in
■Joystick with 4-direction control and selector
■Reset, wakeup, tamper and user button
■RTC with backup battery
■Extension connector for daughterboard or wrapping board
■JTAG, SWD and trace debug support
■Embedded ST-LINK/V2
■Five 5V power supply options: Power jack, USB FS connector, USB HS connector,
ST-LINK/V2 or daughterboard
1.2 Demonstration software
Demonstration software is preloaded in the board's Flash memory for easy demonstration of
the device peripherals in standalone mode. For more information and to download the latest
version, please refer to STM3240G-EVAL demonstration software available on web:
www.st.com/mcu
1.3 Order code
To order the STM32F407IGT6 MCU evaluation board, use order code STM3240G-EVAL.
All manuals and user guides at all-guides.com

DRAFT
UM1461 Overview
Doc ID 022138 Rev 1 5/65
1.4 Delivery recommendations
Several verifications are needed before using the board for the first time to make sure that
nothing has been damaged during shipment and no components are unplugged and lost.
When the board is extracted from its plastic bag, please check that no component remains
in the bag. Main components to verify are:
1. The 25MHz crystals (X1 and X4) may have been removed by a shock.
2. The camera connected on socket CN15 located on the right side of the board under the
JTAG connector may be unplugged. If this is the case, please refer to the note in
Section 2.18: Camera module to make sure to replug it in the correct position.
3. The MicroSD card may have been ejected from its connector CN6 (top left corner of the
board).
The plastic protection on the camera should be removed carefully as the connection is very
fragile.
All manuals and user guides at all-guides.com

DRAFT
Hardware layout and configuration UM1461
6/65 Doc ID 022138 Rev 1
2 Hardware layout and configuration
The STM3240G-EVAL evaluation board is designed around the STM32F407IGH6 in the
UFBGA176 package. The hardware block diagram Figure 2 illustrates the connection
between STM32F407IGH6 and peripherals (Camera module, LCD, SRAM, EEPROM,
MEMS, USART, IrDA, USB OTG HS, USB OTG FS, Ethernet, Audio, CAN bus, Smart card,
MicroSD card and motor control) and Figure 3 will help you locate these features on the
actual evaluation board.
All manuals and user guides at all-guides.com
all-guides.com

DRAFT
UM1461 Hardware layout and configuration
Doc ID 022138 Rev 1 7/65
Figure 2. Hardware layout and configuration
069
670),*+
56
WUDQVFHLYHU
,U'$
WUDQVFHLYHU
6PDUWFDUG
LQWHUIDFH
9UHJXODWRU
7)7/&'
0LFUR6'
FDUG
$XGLR'$&
0&FRQWURO
FRQQHFWRU
/('V.H\
-7$*
0(06
3RWHQWLRPHWHU
6PDUWFDUG
FRQQHFWRU
,QWHJUDWHG5-
FRQQHFWRU
56
'%FRQQHFWRU
$'&
,6
*3,2
0,,50,,
86$57
,&
([WHQVLRQ
FRQQHFWRUIRU
*3,2V
3+<
86$57
&$1
&$1
WUDQVFHLYHU
&$1
'%FRQQHFWRU
0&
6',2
7UDFH
'HEXJ
27*)6 86%0LFUR$%
FRQQHFWRU
((3520
,2
H[SDQGHU
-R\VWLFN
7RXFKVFUHHQ
86%SRZHU
VZLWFK
&$1
9UHJXODWRU
9UHJXODWRU
9UHJXODWRU
'&0,
&DPHUD
PRGXOH
27*+6 86%0LFUR$%
FRQQHFWRU
86%SRZHU
VZLWFK
86%+6
3+<
'$&
)60&
65$0
67/,1.9
&DPHUDH[WHQVLRQ
FRQQHFWRU
0LFURSKRQH
$PSOLILHU
$XGLR-DFN
$'&
All manuals and user guides at all-guides.com

DRAFT
Hardware layout and configuration UM1461
8/65 Doc ID 022138 Rev 1
Figure 3. STM3240G-EVAL evaluation board layout
069
&1
0RWRUFRQWURO
&1
0LFUR6'FDUG
&1
7UDFH
&1
-7$*
8
,U'$
&1
86%27*)6
&1
86%27*+6
&1
67/,1.9
&1
&RORU/&'
&1
&DPHUDPRGXOH
&1
&DPHUDH[WHQVLRQ
FRQQHFWRU
8
-R\VWLFN
%
8VHUNH\
%
7DPSHU
&1
6PDUWFDUG
%
:DNHXS
%
5HVHW
59
3RWHQWLRPHWHU
&1
9SRZHUMDFN
&1
$XGLRMDFN
&1
86$57
&1
&$1
8
670),*+
&1
5-
FRQQHFWRU
&1&1
([WHQVLRQ
CONNECTOR $4"
All manuals and user guides at all-guides.com

DRAFT
UM1461 Hardware layout and configuration
Doc ID 022138 Rev 1 9/65
2.1 Power supply
STM3240G-EVAL evaluation board is designed to be powered by 5V DC power supply and
to be protected by PolyZen from a wrong power plug-in event. It is possible to configure the
evaluation board to use any of following five sources for the power supply:
●5V DC power adapter connected to CN18, the Power Jack on the board
●5V DC power with 500 mA limitation from CN8, the USB OTG FS Micro-AB connector
●5V DC power with 500 mA limitation from CN9, the USB OTG HS Micro-AB connector
●5V DC power with 500 mA limitation from CN21, the ST-LINK/V2 USB connector
●5V DC power from both CN1 and CN3, the extension connector for daughterboard
(DTB for daughterboard on silkscreen)
The power supply is configured by setting the related jumpers JP4, JP32, JP18 and JP19 as
described inTable 1.
Table 1. Power related jumpers and solder bridges
Jumper Description
JP4 JP4 should be fitted to enable power down reset (PDR). PDR is disabled when JP4 is not fitted.
Default setting: Fitted.
JP32
MCU_VDD is connected to 3.3V power when JP32 is closed and MCU current
consumption measurement can be done manually by multi-meter when JP32 is
open.
Default setting: Fitted.
JP18
JP18 is used to select one of the five possible power supply sources.
To select the ST-LINK/V2 USB connector (CN21) power
supply, set JP18 as shown:
(Default setting)
To select power supply jack (CN18) power supply, set
JP18 as shown:
To select daughterboard connector (CN1 and CN3) power
supply, set JP18 as shown:
HS
FS
DTB
PSU
STlk
HS
FS
DTB
PSU
STlk
HS
FS
DTB
PSU
STlk
All manuals and user guides at all-guides.com

DRAFT
Hardware layout and configuration UM1461
10/65 Doc ID 022138 Rev 1
Note: The LED LD9 is lit when the STM3240G-EVAL evaluation board is powered by the 5V
correctly.
2.2 Boot option
The STM3240G-EVAL evaluation board is able to boot from:
●Embedded User Flash
●System memory with boot loader for ISP
●Embedded SRAM for debugging
The boot option is configured by setting switch SW1 (BOOT1) and SW2 (BOOT0). The
BOOT0 can be configured also via RS-232 connector CN16.
JP18
(cont.)
To select USB OTG FS (CN8) power supply, set JP18 as
shown:
To select USB OTG HS (CN9) power supply, set JP18 as
shown:
To select power supply jack (CN18) power supply to both
STM3240G-EVAL and daughterboard connected on CN1
and CN3, set JP18 as shown (daughterboard must not
have its own power supply connected)
JP19
To connect Vbat to the battery, set JP19 as shown:
To connect Vbat to 3.3V power, set JP19 as shown:
(Default setting)
Table 1. Power related jumpers and solder bridges (continued)
Jumper Description
HS
FS
DTB
PSU
STlk
HS
FS
DTB
PSU
STlk
HS
FS
DTB
PSU
STlk
321
3
21
Table 2. Boot related jumpers
BOOT 0 BOOT 1 Boot source
0 Don’t care STM3240G-EVAL boots from User Flash (Default setting)
1 1 STM3240G-EVAL boots from Embedded SRAM
1 0 STM3240G-EVAL boots from System Memory
All manuals and user guides at all-guides.com
