ST STM32429I-EVAL User manual

May 2021 UM1667 Rev 3 1/59
1
UM1667
User manual
STM32429I-EVAL evaluation board for STM32F429 MCUs
Introduction
The STM32429I-EVAL evaluation board is a complete demonstration and development
platform for STMicroelectronics Arm®Cortex®-M4 core-based STM32F429NIH6
microcontrollers. It features three I2C, six SPI with two muxed full-duplex I2S, SDIO, four
USART, four UART, two CAN, three 12-bit ADC, two 12-bit DAC, one SAI, 8- to 14-bit digital
camera module interface, internal 256+4 Kbyte SRAM and 2-Mbyte Flash memory, USB HS
OTG and USB FS OTG, Ethernet MAC, FMC interface, JTAG debugging support. This
evaluation board can be used as a reference design for user application development but it
is not considered as a final application.
The full range of hardware features on the board helps the user to evaluate all peripherals
(such as USB OTG HS, USB OTG FS, Ethernet, motor control, CAN, microSD™ card,
USART, Audio DAC and ADC, digital microphone, IrDA, CAN, RF-EEPROM, SRAM, NOR
Flash memory, SDRAM, 4.3" TFT LCD with a resistive touch panel, and others) and develop
his own applications. Extension headers make it possible to easily connect a daughterboard
for specific applications development.
The integrated ST-LINK/V2 provides an embedded in-circuit debugger and programmer for
the STM32 MCU.
Figure 1. STM32429I-EVAL evaluation board
Picture is not contractual.
www.st.com

Contents UM1667
2/59 UM1667 Rev 3
Contents
1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Codification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Development environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Development toolchains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Demonstration software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Delivery recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Hardware layout and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.1 Development and debug support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3 Clock source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4 Reset source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5 Boot option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.6 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.7 USB OTG1 FS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.8 USB OTG2 HS and FS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.9 RS-232 and IrDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.10 microSD™ card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.11 RF-EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.12 CAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.13 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.14 Extension connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.15 Memories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.16 Analog input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.17 Camera module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.18 Display and input devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.19 Motor control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

UM1667 Rev 3 3/59
UM1667 Contents
4
5 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.1 Motor control connector CN1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.2 Extension connector CN2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.3 RF-EEPROM daughterboard connector CN3 . . . . . . . . . . . . . . . . . . . . . 28
5.4 Analog input connector CN4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.5 Camera module connector CN5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.6 Daughterboard extension connector CN6 and CN7 . . . . . . . . . . . . . . . . . 30
5.7 RS-232 connector CN8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.8 USB OTG2 HS Micro-AB connector CN9 . . . . . . . . . . . . . . . . . . . . . . . . 35
5.9 Ethernet RJ45 connector CN10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.10 Memory connectors CN11 and CN12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.11 ETM trace debugging connector CN13 . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.12 USB OTG1 FS Micro-AB connector CN14 . . . . . . . . . . . . . . . . . . . . . . . . 40
5.13 USB OTG2 FS Micro-AB connector CN15 . . . . . . . . . . . . . . . . . . . . . . . . 40
5.14 JTAG/SWD connector CN16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.15 microSD™ connector CN17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.16 Power connector CN18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.17 ST-LINK/V2 programming connector CN19 . . . . . . . . . . . . . . . . . . . . . . . 42
5.18 TFT LCD connector CN20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.19 ST-LINK/V2 USB Type B connector CN21 . . . . . . . . . . . . . . . . . . . . . . . . 43
5.20 CAN D-type 9-pin male connector CN22 . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.21 Audio jack CN23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.22 Audio terminal CN24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.23 ST-LINK/V2 programming Tag-connector CN25 . . . . . . . . . . . . . . . . . . . 44
6 STM32429I-EVAL evaluation board information . . . . . . . . . . . . . . . . . . 45
6.1 Product marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.2 STM32429I-EVAL product history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.2.1 Product identification STM32429I-EVAL1/ . . . . . . . . . . . . . . . . . . . . . . . 46
6.2.2 Product identification VA32F429I$AX1 . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.3 Board revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.3.1 MB1045 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.3.2 MB1046 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.3.3 MB1066 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Contents UM1667
4/59 UM1667 Rev 3
6.3.4 MB1020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.4 Board known limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4.1 MB1045 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4.2 MB1046 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4.3 MB1066 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4.4 MB1020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Appendix A STM32429I-EVAL I/O assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Appendix B Mechanical dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Appendix C Federal Communications Commission (FCC)
and ISED Canada Compliance Statements . . . . . . . . . . . . . . . . . . . 56
C.1 FCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
C.2 ISED Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Appendix D CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

UM1667 Rev 3 5/59
UM1667 List of tables
5
List of tables
Table 1. Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 2. Codification explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 3. Power related jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 4. 32.786 kHz crystal X1 related solder bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 5. 25 MHz crystal X2 related solder bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 6. Boot related switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table 7. Audio related jumpers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 8. USB OTG2 configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 9. RS-232 and IrDA related jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 10. CAN related jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 11. Ethernet related jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 12. Ethernet related solder bridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 13. NOR Flash memory related jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table 14. LCD modules connector (CN20). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Table 15. Motor control related solder bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Table 16. Motor control connector CN1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Table 17. Extension connector CN2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Table 18. RF-EEPROM daughterboard connector CN3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table 19. Analog input-output connector CN4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table 20. Camera module connector CN5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Table 21. Daughterboard extension connector CN6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Table 22. Daughterboard extension connector CN7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Table 23. RS-232 connector CN8 with ISP support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Table 24. USB OTG HS Micro-AB connector CN9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Table 25. RJ45 connector CN10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 26. Memory connector CN11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 27. Memory connector CN12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Table 28. ETM trace debugging connector CN13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Table 29. USB OTG1 FS Micro-AB connector CN14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Table 30. USB OTG2 FS Micro-AB connector CN15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Table 31. JTAG/SWD debugging connector CN15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Table 32. microSD™ connector CN17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table 33. USB type B connector CN21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 34. CAN D-type 9-pin male connector CN22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 35. Audio terminal CN24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table 36. STM32429I-EVAL I/O assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Table 37. Mechanical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Table 38. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

List of figures UM1667
6/59 UM1667 Rev 3
List of figures
Figure 1. STM32429I-EVAL evaluation board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 2. Hardware block diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 3. Evaluation board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 4. Orientation setting of 4.3 inch LCD daughterboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 5. PCB underside rework for motor control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 6. PCB topside rework for motor control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 7. Motor control connector CN1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 8. Extension connector CN2 top view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 9. RF-EEPROM daughterboard connector CN3 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 10. Analog input-output connector CN4 (top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 11. Camera module connector CN5 (top view). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 12. RS-232 connector (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 13. USB OTG2 HS Micro-AB connector CN9 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 14. Ethernet RJ45 connector CN10 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 15. ETM trace debugging connector CN13 (top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 16. USB OTG1 FS Micro-AB connector CN14 (front view). . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 17. USB OTG2 FS Micro-AB connector CN15 (front view). . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 18. JTAG/SWD debugging connector CN16 (top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 19. microSD™ connector CN17 (front view). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 20. Power supply connector CN18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 21. USB type B connector CN21 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Figure 22. CAN D-type 9-pin male connector CN22 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Figure 23. Audio terminal CN24 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Figure 24. Mechanical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

UM1667 Rev 3 7/59
UM1667 Features
58
1 Features
•STM32F429NIH6 microcontroller based on the Arm®Cortex®-M4 core(a)
•4.3-inch 480 × 272 pixel TFT LCD with resistive touch panel
•Camera module
•SAI Audio DAC
•Stereo MEMS microphone
•IEEE-802.3-2002 compliant Ethernet
•USB OTG HS and FS
•2-Gbyte (or more) SDIO interface microSD™ card
•RF-EEPROM on I2C compatible serial interface
•RS-232 communication
•CAN2.0A/B compliant connection
•IrDA transceiver
•8 M × 32-bit SDRAM, 1 M × 16-bit SRAM, 8 M × 16-bit NOR Flash memory
•Joystick with 4-direction control and selector
•Reset, WakeUp, Tamper or key button
•4 user color LEDs
•RTC with backup battery
•Potentiometer
•Board connectors:
– microSD™ card
– 3× USB Micro-AB and 1× USB Type-B
– Audio terminal connector for external speakers
– 3.5 mm stereo audio jack
– Motor control
–2×RS-232
– RJ45
– Extension connectors and memory connectors for daughterboard or wrapping
board
•Six 5 V power supply options: power jack, ST-LINK/V2, User USB HS, User USB FS1,
User USB FS2, daughterboard
•Debug with JTAG/SWD, ETM trace, and on-board ST-LINK/V2 debugger/programmer
•Comprehensive free software libraries and examples available with the STM32CubeF4
MCU Package
•Support of a wide choice of Integrated Development Environments (IDEs) including
IAR Embedded Workbench®, MDK-ARM, and STM32CubeIDE
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.

Ordering information UM1667
8/59 UM1667 Rev 3
2 Ordering information
To order the STM32429I-EVAL evaluation board, refer to Table 1. Additional information is
available from the datasheet and reference manual of the target STM32.
2.1 Codification
The meaning of the codification of the evaluation board is explained in Table 2.
Table 1. Ordering information
Order code Board reference Target STM32
STM32429I-EVAL
MB1045
MB1046(1)
MB1066(2)
MB1020(3)
1. Mounted LCD screen.
2. Mounted camera daughteroard
3. Mounted ANT7-M24LR-A dual-interface EEPROM board.
STM32F429NIH6
Table 2. Codification explanation
STM32XYYZ-EVAL Description Example: STM32429I-EVAL
XMCU series in STM32 32-bit
Arm Cortex MCUs STM32F4 Series
YY MCU product line in the series STM32F429
ZSTM32 Flash memory size:
– I for 2 Mbytes 2 Mbytes
EVAL Board type Evaluation board

UM1667 Rev 3 9/59
UM1667 Development environment
58
3 Development environment
3.1 System requirements
•Windows®OS (7, 8 and 10), Linux® (a) 64-bit, or macOS® (b) (c)
•USB Type-A or USB Type-C®to Type-B cable
3.2 Development toolchains
•IAR Systems®- IAR Embedded Workbench®(d)
•Keil®- MDK-ARM(d)
•STMicroelectronics - STM32CubeIDE
3.3 Demonstration software
Demonstration software is preloaded in the Flash memory of the board for easy
demonstration of the device peripherals in stand-alone mode. For more information and to
download the latest version, refer to the STM32429I-EVAL demonstration software on
www.st.com.
3.4 Delivery recommendations
Some verifications are needed before using the board for the first time to make sure that
nothing was damaged during shipment and that no components are unplugged or lost.
When the board is extracted from its plastic bag, please check that no component remains
in the bag.
The main components to verify are:
1. The 25 MHz crystal (X2) and 25 MHz crystal (X4), which may have been removed by a
shock from their sockets.
2. The microSD™ card, which may have been ejected from the connector CN17 (right
side of the board).
3. The dual-interface EEPROM board, which may have been unplugged from the
connector CN3 (top left corner of the board).
4. The camera module on the camera daughterboard (MB1066), which may have been
unplugged.
Warning: There is a risk of explosion if the battery is replaced by an
incorrect one. Make sure to dispose of used batteries
according to the instructions.
a. Linux®is a registered trademark of Linus Torvalds.
b. macOS®is a trademark of Apple Inc. registered in the U.S. and other countries.
c. All other trademarks are the property of their respective owners.
d. On Windows®only.

Hardware layout and configuration UM1667
10/59 UM1667 Rev 3
4 Hardware layout and configuration
The STM32429I-EVAL evaluation board is designed around the STM32F429NIH6 (216-pin
TFBGA package).
The hardware block diagram Figure 2 illustrates the connection between the
STM32F429NIH6 and peripherals (SDRAM, SRAM, NOR Flash memory, camera module,
color LCD, USB OTG connectors, motor control connector, USART, IrDA, Ethernet, audio,
CAN, RF-EEPROM, microSD™ card and embedded ST-LINK). Figure 3 helps the user to
locate these features on the actual evaluation board.
Figure 2. Hardware block diagram
MS32865V1
GPIO
OTG2 FS
I2C1
USART1
JTAG
Potentiometer
Joystick
LEDs
Key button
RF EEPROM
connector
RS-232
transceiver
IrDA
transceiver
RS-232
connector
Color TFT LCD
4.3’ WQVGA
SPI3
SAI1 Audio
Codec
Embedded
ST-LINK/V2
USB TypeB
connector
JTAG & trace
connector
Extension
connectors
for GPIOs
Digital microphone
STM32F429NIH6
CAN driver
& connector CAN
Motor control
connector
Comparator
SDRAM
SDIO
MicroSD
card
FMC
MII PHY Integrated RJ45
connector
OTG2 HS
ULPI
RGB
GPIO
IO
expandor
USB Micro-AB
connector
USB power
switch
SRAM
NOR Flash
USB Micro-AB
connector
OTG1 FS USB Micro-AB
connector
USB power
switch
Audio terminal
connector
Memory
connectors
DCMI
I2C1
Camera
Extension
connector
2.8 V regulator
1.8 V regulator
3.3 V regulator
= I/O shared with motor control
