Stahl 6418/11 Series User manual

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 1 - of 22
Operating instructions
For Additional languages www.stahl-
ex.com
Emergency Sheet steel light fittings for
Fluorescent Lamps
Series 6418/11

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 2 - of 22
Contents
1 General Information ...........................................................................................................................................................................................- 3 -
1.1 Manufacturer ........................................................................................................................................................................................- 3 -
1.2 Information regarding the operating instructions ..................................................................................................................................- 3 -
1.3 Conformity to Standards .......................................................................................................................................................................- 3 -
2. Explanation of symbols ......................................................................................................................................................................................- 3 -
2.1 Symbols in these operating instructions ................................................................................................................................................- 3 -
2.2 Warning notes .......................................................................................................................................................................................- 4 -
2.3 Symbols on the device .........................................................................................................................................................................- 4 -
3 Safety Notes .......................................................................................................................................................................................................- 4 -
3.1 Operating instruction storage ...............................................................................................................................................................- 4 -
3.2 Safe Use ...............................................................................................................................................................................................- 5 -
3.3 Intended Use .........................................................................................................................................................................................- 5 -
3.4 Modification and Alterations .................................................................................................................................................................- 5 -
4 Function and Device Design ..............................................................................................................................................................................- 6 -
4.1 Function ................................................................................................................................................................................................- 6 -
4.2 Device design .......................................................................................................................................................................................- 6 -
5 Technical Data ...................................................................................................................................................................................................- -
6 Transport and Storage .......................................................................................................................................................................................- 8 -
6.1 General .................................................................................................................................................................................................- 8 -
6.2 Batteries ...............................................................................................................................................................................................- 8 -
Mounting & Installation Notes ............................................................................................................................................................................- 9 -
.1 Dimensions / fastening dimensions ......................................................................................................................................................- 9 -
.2 Mounting / dismounting, operating position ........................................................................................................................................- 10 -
.3 Installation ..........................................................................................................................................................................................- 10 -
.3.1 Opening and Closing of the Enclosure ..........................................................................................................................................- 10 -
.3.2 Opening and closing the reflector plate .........................................................................................................................................- 11 -
.3.3 Electrical Connections ...................................................................................................................................................................- 11 -
.3.3.1 Connection terminals ................................................................................................................................................................- 12 -
.3.3.2 Type of Connections for Different Operations: ..........................................................................................................................- 12 -
.3.3.3 Emergency light blocking ..........................................................................................................................................................- 13 -
.3.4 Cable Entries .................................................................................................................................................................................- 14 -
.3.5 Complete Charging and discharging of NiCd battery ....................................................................................................................- 14 -
.3.6 LED Indication and System Status ................................................................................................................................................- 15 -
8. Commissioning .................................................................................................................................................................................................- 15 -
9. Operations ........................................................................................................................................................................................................- 16 -
9.1 Operations ..........................................................................................................................................................................................- 16 -
9.1.1 Operating Modes ...........................................................................................................................................................................- 16 -
9.1.2 Function and capacity test .............................................................................................................................................................- 1 -
9.2 Trouble shooting .................................................................................................................................................................................- 19 -
10. Maintenance, repair & returning of the device (as per EN600 9-1 & as per EN600 9-19) ...........................................................................- 19 -
10.1 Maintenance .......................................................................................................................................................................................- 19 -
10.1.1 Replacement of lamps ........................................................................................................................................................................- 20 -
10.1.2 Replacement of Battery ......................................................................................................................................................................- 20 -
10.1.3 Cleaning ...................................................................................................................................................................................................- 22 -
10.2 Returning the device ...........................................................................................................................................................................- 22 -
11 Disposal ...........................................................................................................................................................................................................- 22 -
12 Accessories and Spare Parts ...........................................................................................................................................................................- 22 -

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 3 - of 22
1 General Information
1.1 Manufacturer
R. Stahl Schaltgeräte GmbH R. STAHL (P) LTD., Plot No. – 5
Am Bahnhof 30 Malrosapuram Road, Sengundram Indl. Area
4638 Waldenburg Singaperumal Koil, Kancheepuram Dist.,
Germany Tamil Nadu – 603 204, INDIA
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
Internet: www.stahl-ex.com Internet: www.rstahl.net
E-mail: in[email protected] E-mail: sa[email protected]
1.2 Information regarding the operating instructions
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01
The original instructions are the English edition.
They are legally binding in all legal affairs.
1.3 Conformity to Standards
See certificates and EC Declaration of Conformity: www.stahl-ex.com.
The device has IECEx approval. See IECEx homepage: http://iecex.iec.ch/ Further national certificates can be
downloaded via the following link: http://www.r-stahl.com/downloads/certificates.html.
2. E planation of symbols
2.1 Symbols in these operating instructions
Tips and recommendations on the use of the device
 Information sign: Describes notes and recommendations.
Warning symbol; danger due to energized parts!
Warning symbol: danger due to explosive atmosphere!
Warning symbol; danger due to hot surfaces!
Warning symbol: general hazard / General danger

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 4 - of 22
2.2 Warning notes
Warning notes must be observed under all circumstances, in order to minimize the risk
due to construction and operation. The warning notes have the following structure:
•Signaling word: DANGER, WARNING, CAUTION, NOTICE
•Type and source of danger/damage,
•Consequences of danger
•Taking countermeasures to avoid the danger/damage
DANGER
Danger for persons
Non-compliance with the instruction results in severe or fatal injuries to persons.
WARNING
Danger for persons
Non-compliance with the instruction can result in severe or fatal injuries to persons.
CAUTION
Danger for persons
Non-compliance with the instruction can result in minor or light injuries to persons.
NOTICE
Avoiding material damage
Non-compliance with the instruction can result in material damage to the device and/or its environment.
2.3 Symbols on the device
Symbol
Meaning
CE marking according to the currently applicable directive.
According to marking, device approved for hazardous areas.
3
Safety Notes
3.1 Operating instruction storage
• Read these operating instructions carefully and store them near the installation place.
• Observe applicable documents enclosed in this delivery and the operating instructions of the devices to be connected.

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 5 - of 22
3.2 Safe Use
• Read and observe the safety notes in these operating instructions!
• Observe characteristic values and rated operating conditions on the rating and data plates!
• Observe additional information plates on the device!
• Use the device in accordance with its intended and approved purpose only!
• We cannot be held liable for damage caused by incorrect or unauthorized use or by non-compliance with these operating
instructions.
• Before installation and commissioning, make sure that the device is not damaged!
• Work on the device (installation, maintenance, overhaul, repair) may only be carried out by appropriately authorized and
trained personnel.
Safety Notes - Warnings
Use the devices only for their intended purpose!
We cannot be held liable for damage caused by an incorrect or unauthorized use or by non-observance of
these operating instructions.
Use the device only if it is undamaged.
The mounting arrangements must be secured with lock washers or self-locking nuts and bolts.
Any unauthorized work on the device is prohibited!
Installation, maintenance, overhaul and repair may only be carried out by appropriately authorized and
trained personnel. Non-compliance to this could be fatal or could result in damage to the property

Avoiding material damage
Non-compliance with the instruction can result in material damage to the device and/or its environment
3.3 Intended Use
The light fitting 6418 is equipment
• for lighting areas, work spaces and objects
• can be used indoor / Outdoor
• for stationary mounting
• for use in Zones 2, 21 & 22 and in the safe area
3.4 Modification and Alterations
WARNING
Dange
r
du
e
t
o
modifi
c
ation
s
an
d
alterat
i
on
s
t
o
th
e
device! Explosio
n
protectio
n
i
s
impaired!
Non-compliance results in severe or fatal injuries.
• Do not modify or change the device.
No liability or warranty for damage resulting from modifications and alterations.

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 6 - of 22
4
Function and Device Design
DANGER
Explosion
Hazard due to imprope
r
use!
Non-compliance results in severe or fatal injuries.
• Use the device only according to the operating conditions described in these operating instructions.
4.1 Function
DANGER
Explosion Hazard due to imprope
r
use!
Non-compliance results in severe or fatal injuries.
• Use the device only according to the operating conditions described in these operating instructions.
• for lighting areas, work spaces and objects
• switching off the equipment by means of a central lock (standard version) when the luminaire is opened
• For lighting areas, work spaces and objects
• Pharma, Chemical, Oil & Gas Platforms, Marine, Food & Beverage and other Clean room Applications.
• The device can be used in hazardous areas of Zones 2, 21 & 22.
4.2 Device design
1
Luminaire Glass
8
Blind Rivet
M6
–
Provision for
Wall
Mounting arrangements
2
Reflector Plate
9
Battery Compartment
3
Luminaire enclosure
10
Connector for the Battery
4
Ballast
11
Hinges to Hold the Glass in open position
5
Center Lock
12
Lamp Holders
6
Connection
terminals
(right standard, left with through
wiring).
13
Quarter turn screws to lock the Reflector Plate
Cable glands
14
Green Marking for the Lamp “ON” in Emergency Mode

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - - of 22
5Technical Data
E plosion Protection Certificats ATEX, IEC E , PESO,
Zone Classification Zone 2, 21 & 22
E plosion Protection Type Equipment protection by type of protection “n”, Equipment dust ignition protection by enclosure “t”
IECE IECE BVS 15.0073
Ex nA IIC T4 Gc OR Ex tb IIIC T80°C Db
Ex tc IIIC T80°C Dc
ATEX BVS 15 ATEX E 083
II 3G Ex nA IIC T4 Gc
II 3D Ex tc IIIC T80°C Dc
BVS 15 ATEX E 082
II 2D Ex tb IIIC T80°C Db
Electrical Data
Ballast
Lamp Start Warm start
Voltage 220 ... 240 V AC + 10%
Frequency 50 … 60 Hz
Lamp standard IEC 60081
Lamp power 18, 36 W
Nominal current 2x 18 W 180 mA 2x 36 W 350 mA
Emergency
light
service
time
Battery
Type Variants Battery capacity
Emergency
light service
time
Emergency lighting power
Lights 18 W Lights 36 W
Ni-Cd-
Battery
6418/1
1
..
-
....
-
.6..
-
..
6418/11..-....-. ..-.. 6V/4Ah 1.5 h 64% 32%
6418/11..-....-.4..-..
6418/11..-....-.5..-..
6V/ Ah 1.5 h 100% 60%
6V/ Ah 3 h 60% 30%
Emergency Mode In emergency mode, when operated on battery only one fluorescent lamp will be driven
(the one which is marked with a Green Dot – refer section 4.2 of this manual).
Power factor cos
∅
Cos ∅ > 0.93
Ambient Operating Temp. (Ta)
Normal Operation -20 °C ≤ T
amb
≤ +50 °C
Emergency light Operation -20 °C ≤ T
amb
≤ +50 °C
During charging -05 °C ≤ T
amb
≤ +40 °C
Mechanical data
Degree of protection IP 65
IP66 for Light Fitting with Frame
IP 64 with breathing gland 8162
acc. IEC 60598
Protection class I (with internal PE connection)
Material
Enclosure Sheet steel powder coated
Stainless steel SS304 (V2A | 1.4301) brushed
Stainless steel SS316L (V4A | 1.4404) brushed
Colour White, similar RAL 9016
Lamp Cover Toughened Glass.
Gasket Silicon foam gasket in the luminaire enclosure
Luminaire locking Central locking can be opened/closed using a socket key M5 Hex socket head driver
Mounting / Installatione
Cable glands 2x M20/M25 left and 1x M20/M25 right, 1x cable glands, 1x cable glands + red plug and 1 stopping plugs as standard

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 8 - of 22
Technical Data
Connection Standard: Spring clamp terminal up to 4 mm
2
6-pole (2x L1, L2, L3, 2x L
I
, 2X N, 2x PE)
Special: Screw terminal up to 6 mm
2
6-pole (2x L1, L2, L3, 2x L
I
, 2X N, 2x PE)
Through Wiring Max, 12A
Switch-off
Standard With separate Disconnect Switch for Lamp and Battery Compartments
Due to the faulty lamps
If lamp is faulty, power supply is automatically switched off by the electronic ballast.
Due to opening of the light fi ture
Power to ballast is disconnected; switching element with 2 NC contacts in positive opening operation, they can only be switched on
again when the lamp cover and the central locking system are closed.
Light technical data
Lamps Two-pin fluorescent lamps; 26 mm diameter; for holder G13
2 x 18 W; 2 x 36 W
Installation notes
Looping through of cables There are cable entries on either side for looping through of connection cable.
Through wiring
Standard Luminaires Without Through Wiring
Optional: Luminaires are equipped with internal through wiring Incoming and outgoing leads, can be connected on the opposite sides.
Terminals: see Technical data:
Standard with: 4 mm
2
termination with 2.5 mm
2
wire,
Special with: (Dv6 - 6 mm
2
termination with 2.5 mm
2
wire
Assembly
Recessed light fitting Ceiling Mounting option is available with the Bracket.
Wall Mounting is also possible with a special mounting bracket.
Emergency Mode In emergency mode, when operated on battery only one fluorescent lamp will be driven.
Battery Full Charging Time 25 Hours (Only First time charging for the new battery).
Consecutive charging time will be less than 24 Hours, depending on the discharge level.
6 Transport and Storage
6.1 General
• Transport and storage are only permitted in the original packaging.
• Store the device in a dry place (no condensation) and vibration-free.
• Do not drop the device.
6.2 Batteries
• Do not transport together with other materials!
• Handle with care!
• Store protected from fire, sources of dust, harmful gases and liquids!
• Store in a dry and cool location!

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 9 - of 22
Recommendation:
•Store battery at an ambient temperature of + 5 °C to + 25 °C and a relative humidity of 65 ± 5 %. The storage period is reduced of up to
one month if stored outside this temperature range..
•To Avoid Deep-Discharge of the Battery, disconnected the battery from the supply, through the connector provided in the battery
compartment, when the light fixture is not in use for a period longer than four weeks.
NOTE
Risk of deep battery discharge due to exceeded storage!
Non-compliance can result in material damage!
•The battery should be charged within 26 weeks from date of production by means of operating the luminaire.
7Mounting & Installation Notes
DANGER
Explosion hazard due to incorrect installation of the device!
Non
-compliance results in severe or fatal injuries.
• Carry out installation strictly according to the instructions and national safety and accident prevention regulations to maintain the explosion
protection.
• Select and install the electrical device so that explosion protection is not affected due to external influences, i.e. pressure conditions,
chemical, mechanical, thermal and electric impact such as vibration, humidity and corrosion (see IEC/EN 600 9-14).
• The device must only be installed by trained qualified personnel who is familiar with the relevant standards.
7.1 Dimensions / fastening dimensions
(All Dimensions in mm [inch]) - Subject to Alterations
2 - M8 Threaded hole for fixing
2X18W
2X36W
L1
913
1643
L2
500
1250
L3
280
280

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 10 - of 22
7.2 Mounting / dismounting, operating position
•This device is mainly designed for indoor use.
•The luminaire is been developed for Wall / Ceiling or Pendent mounting.
•Different Mounting options are possible like:
Pendent Mounting : With the help of Ring bolt M8
Recessed Mounting : With Flushing Frame or Without Flushing Frame.
Wall Mounting : With Mounting Accessory 6.1.for 280mm width
WARNING
Serious risk of injury
Use the device only in hazardous areas for which it is approved.
Observe all information on the rating plate, such as:
Approved hazardous areas
Temperature of use / temperature class / surface temperature
Degree of protection (cable entries)
DO NOT OPEN WHEN ENERGIZED
Danger due to inadmissible heating.
Explosion protection is impaired!
External heat sources and/or direct sunlight may affect the temperature class and the maximum permissible surface temperature.
 Danger due to electrostatic discharge! Explosion protection is impaired!
Do not install within arm's reach!
Ensure that no electrostatic charging may occur. For example: 1). due to accidental friction,
2). with particle streams
3). by cleaning with a dry cloth,
WARNING
Early failure of equipment.
The maximum ambient temperature must not be exceeded by external heat sources.
DO NOT OPEN WHEN ENERGIZED
•The luminaire is suitable for wall and ceiling or Pendent mounting.
•Wall mounting must be performed with the central lock directed downwards.
•For outdoor use, we recommend to install a 8162/1 breather from R. STAHL Schaltgeräte GmbH. The breather guarantees
compliance with degree of protection IP64 in all mounting positions.
7.3 Installation
7.3.1 Opening and Closing of the Enclosure
DANGER
•
Risk of electric shock!
•Risk of fatal injuries!
•Luminaires without switch must not be opened when they are supplied with power (see information plate
on the lock)!
•
DO NOT OPEN WHEN ENERGIZED
Recommendation
Opening and closing of the luminaire by using a socket wrench from R. STAHL Schaltgeräte GmbH.
DO NOT FORGET TO CONNECT THE BATTERY TO THE ELECTRICAL CIRCUIT BEFORE
SWITCHING ON THE LUMINIARE

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 11 - of 22
Fixtures
,
6
4
18/1 . . . .
-
. . . .
-
. . . 9
-
. . . will be supplied without the battery,
DO NOT FORGET TO INSTALL THE BATTERY.
Kindly refer the section 10.1.2 of this manual to install the battery.
1. Remove the closing cap of the central lock.
2. To open the fixture, press inward and Turn the central lock using a
socket key M5 hex socket head driver, by 90° anti-clockwise
direction as far as it can go. Before turning, make sure to press the
lock as shown in the picture below.
3. Swivel down the lighting trough (Support the Glass while performing
step no. 2 of this section).
4. Connect the Battery to the Electrical circuit through the connector
provided in the battery chamber / compartment.
5. Proceed in reverse order to close.
6. The seal of the luminaire trough must lie correctly on the sealing
edge.
. Push the closing cap onto the central lock opening (To avoid dust
accumulation).
Note:
a) Version without switch: Disconnect the luminaire from the power supply and secure it against being switched on again.
b) Version with switch: The luminaire is positively disconnected from the power supply by actuating the central lock.
c) In open end position and with lighting trough swiveled down, a restart lock-out device prevents the central lock from being actuated.
d) Please do not use force!
e) When the lighting trough is closed, the central lock is released.
f) While trying to open or close, keep the Allen key pressed to the lock and then turn.
g) To avoid deep discharge of the battery, the Luminaire is supplied without connecting the battery to the electrical circuit.
h) DO NOT FORGET TO CONNECT THE BATTERY TO THE ELECTRICAL CIRCUIT BEFORE SWITCHING ON THE
LUMINIARE.
7.3.2 Opening and closing the reflector plate
1Follow the procedure to Open the Luminaire as explained above, then
open the reflector plate by two (2 No’s) quarter turn screws as shown in
the picture.
2Swivel down the reflector plate as shown.
3When closing, flip up the reflector plate, snap it into place and fix it with
by two (2 No’s) quarter turn screws to Lock the reflector Plate.
7.3.3 Electrical Connections
Observe the maximum clamping possibility of the connecting terminals (see chapter "Technical data").
For optional screw-type terminals, two conductors per clamping unit can be clamped (incoming and outgoing wiring).

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 12 - of 22
Note:
•Clamping must be carried out precisely!
•Do not clamp any part of the conductor insulation!
•Do not interchange the conductors!
•Observe the technical regulations when connecting the conductor!
•Clamp the conductor firmly.
•Optional screw-type terminals: Firmly tighten screws (tightening torque 2 Nm, for unused clamping units 0. Nm)!
•The terminal cover of optional screw-type terminals does not have to be removed to clamp the conductor!
7.3.3.1 Connection terminals
Standard: Spring clamp terminals
up to 4 mm
2
Stripping length:
10 ... 11 mm
Optional: Screw-type terminals
up to 4 mm
2
finely and extra finely
stranded, and 6 mm
2
solid
Stripping length:
10 ... 11 mm
L1, L2, L3 = Phase
L
I
= Switched Phase
N = Nuetral Conductor
PE = Protective conductor
7.3.3.2 Type of Connections for Different Operations:
Stand-by operation
In this condition, The light fixture will be switched OFF. Light Fixture only turns ON during the emergency mode/ when the
mains Fails.

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 13 - of 22
Continuous operation
In this condition, The light fixture is switched ON Continuously as long as the supply is ON and the emergency mode will take
over when the mains Fails.
Normal lighting operation
In this condition, The light fixture is switched ON Continuously as long as the supply is ON and the emergency mode will take
over when the mains Fails.
7.3.3.3 Emergency light blocking
This function is available only with “6418/11..-....-.4..-..” & “6418/11..-....-.5..-..” versions
A remote switch for emergency light blocking can be connected to terminals 9 and 10 of the emergency light electronics.
Remote switch is closed Remote switch is opened
Power supply
operation
Switching on the lamps
depend-ing on
operation mode
Switching on the lamps
depend-ing on operation
mode
Power failure Emergency light
function
No emergency light
function

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 14 - of 22
Through wiring
NOTE
Through wiring with 2.5 mm
2
cross-section for max. 12 A.
7.3.4 Cable Entries
The standard luminaire is delivered with 3 lead-in holes, 1 cable gland, 1 cable gland + red plug and 1 stopping plug.
Please observe the tightening torque for luminaires with installed cable glands and stopping plugs from R. STAHL
Schaltgeräte GmbH.
Tightening torque Connection thread Pressure screw
Cable gland 8161
M20 x 1.5 2.3 Nm 1.5 Nm
M25 x 1.5 3.0 Nm 2.0 Nm
Stopping plugs 8290
M20 x 1.5 1.0 Nm
M25 x 1.5 1.5 Nm
Luminaires with approved cable glands and stopping plugs; not supplied by R. STAHL Schaltgeräte GmbH
WARNING
Using of the Cabl
e
gland
s
an
d
stoppin
g
plug
s
whic
h
ar
e
no
t
approved.
The e plosion protection is impaired!
•
Only use separately certified cable glands and stopping plugs.
Note:
•the required dust resistance!
•the required temperature resistance!
•the required temperature resistance!
•the IP degree of protection according to the rating plate!
•the required tightening torques!
•the operating instructions of the cable glands and stopping plugs!
•the range of the permissible cable diameter!
7.3.5 Complete Charging and discharging of NiCd battery
The Battery is not charged fully when delivered. Hence, it must
be charged at least for 25 Hours continuously for the first time and
charged up & discharged at least for 3 times to reach the full capacity.
On the device, a NiCd battery with a rated voltage of 6V (5 NiCd cells) is connected. The charging technology charges the battery with
a permanent charge current of 200 mA (C / 20 of the battery capacity).
To achieve the longest possible battery life, it is recommended to perform a complete discharge of the battery once a year.
It is recommended, a full discharge only be carried out with an ambient temperature of at least +10° C or higher.

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 15 - of 22
7.3.6 LED Indication and System Status
Priority Description LED display
Models /
Type No.
01 Acknowledge switching
6418/1...-....-.6..-..
&
6418/1...-....-.7..-..
02 Automatic Self-test Function or Duration Test Active
03 Lamp Error or Battery Fault
04 No error , Charging operation of the battery
01 Acknowledge switching
6418/1...-....-.4..-..
&
6418/1...-....-.5..-..
02 Automatic Self-test Function or Duration Test Active
03 Luminaire Failed, Battery not Charging
04 Battery Fault – Needs replacement or Check connection
05 No error , Charging operation of the battery
Please Note:
LED “ON”
(GREEN)
LED “OFF”
LED “ON”
(RED)
The LED is a
Bi
-
color LED so capable of
rendering Green or RED Light.
The LED is driven according to the operating condition of the emergency light:
•After switching ON the emergency light, from the de-energized state, the LED will turn & remain “ON” continuously for approximately
10 seconds.
•When the test is activated, the LED flashes for 10seconds (intermittent for 1s “ON” & 1s “OFF”).
•If the duration test is not enabled, the LED remains “OFF” during this period for 10seconds.
•With proper operation of the lamp and the battery being charged, GREEN LED will be permanently “ON”.
8. Commissioning
WARNING
Explosion hazard due
to incorrect installation!
Non-compliance results in severe or fatal injuries.
Check the device before commissioning!
Explosion protection is impaired!
•Comply with the National regulations.
• Check the device for proper installation and function before commissioning.
NOTE

Condensation
due to specific environmental and operating conditions condensation cannot be avoided completely.
•Operate the luminaire continuously or periodically over extended periods of time!
•Avoid thermal bridges!

Care to be taken with Battery

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 16 - of 22
•To avoid Deep-Discharge of the Battery, disconnected the battery from the supply, through the connector provided in the battery
compartment, when the light fixture is not in use for a period longer than four weeks.
• DO NOT FORGET TO CONNECT THE BATTERY TO THE ELECTRICAL CIRCUIT BEFORE SWITCHING ON THE
LUMINIARE.
Before commissioning, ensure that:
•the device has been installed according to regulations.
•the power supply voltage and the rated operational voltage are identical.
•the required cable diameter for cable glands has been used.
•the cable entries and stopping plugs have been securely tightened.
•the cables are correctly connected.
•the connection has been performed correctly.
•all screws and nuts are tightened according to regulations.
•the connection chamber is clean.
•the device is not damaged.
•no foreign bodies are inside the device.
• the device is sealed according to regulations.
9. Operations
9.1 Operations
9.1.1 Operating Modes
Power supply operation
Stand
-
by operation
The lamps are switched off regardless of normal lighting.
Continuous operation
The
lamps are switched on regardless of normal lighting.
Normal lighting operation
The lamps are operated by normal lighting.
Emergency light operation:
In the event of a power failure, the light fitting switches to emergency light operation. Emergency lamp
•is marked with a green dot on the lamp holder.
•is switched on regardless of the operation mode of the selected emergency light operating time.
If the emergency lamp is defective, the light will be switched to the secondary lamp.
Emergency light operation time
This function is available only with “6418/11..-....-.4..-..” & “6418/11..-....-.5..-..” versions

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 1 - of 22
Emergency light
operation time
Jumper between terminals 11 and 12 of the
emergency light electronics
1.5 hours
open
3.0 hours
closed
Emergency light blocking
This function is available only with “6418/11..-....-.4..-..” & “6418/11..-....-.5..-..” versions
A remote switch for emergency light blocking can be connected to terminals 9 and 10 of the emergency light electronics.
Remote switch is closed Remote switch is opened
Power supply
operation
Switching on the lamps
depend-ing on
operation mode
Switching on the lamps
depend-ing on operation
mode
Power failure Emergency light
function
No emergency light
function
9.1.2 Function and capacity test
With “6418/11..-....-.6..-..” & “6418/11..-....-.7..-..” versions
In fixed intervals automatically test functions are carried out to verify the function of battery and fluorescent lamp for
emergency operation (lamp 1). In the test functions, the lamp 1 is, irrespective of the voltage across the Line, always on. If
both the lamps are switched on at start of the test, they will be automatically switched off and the emergency lamp 1 lights up
with a corresponding reduction in brightness. After the test, the lamps are automatically switched on again, as far as the Line
voltage is still present.
Function Test
Capacity Test
Prerequisites for the test
Time interval for functional test starts after 1 hour
of Power* to the Lamp 1.
Time interval for
capacity test starts after 24 hours of
Power* to the Lamp 1.
Duration of test
For 1 Min
For 60 Min
time interval of tests
Once in days
Once in 182 Days
test criteria
Battery Voltage function & Fluorescent Lamp
Battery Voltage function & Fluorescent
Lamp
Indication during active test
via connected LED
**
via connected LED
**
Indication for a fault
LED will turn OFF after faulty test
**
LED will turn OFF after faulty test
**
Resetting the error
Power OFF / Reset or after a successful function
/ duration test
Power OFF / Reset or after a successful operating
time test
* Charging the battery without power interruption
** Refer Section .3.6 of this Manual
With “6418/11..-....-.4..-..” & “6418/11..-....-.5..-..” versions

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 18 - of 22
To carry out the test, the following prerequisites must be fulfilled:
•The time interval has expired.
•The power supply operation was active for at least 1 hour.
•The remote switch is closed.
The test result is shown on the LED display.
During a test the lamps are switched on.
9.1.2.1 Function test
With “6418/11..-....-.6..-..” & “6418/11..-....-.7..-..” versions
•The function test is automatically activated once a week for 1 min. The fluorescent lamp 1 is, independently of the voltage across the Line,
is turned on. If the battery voltage, during or at the end of the test, is under the Deep Discharge Limit, the test fails and it is recognized as
battery failure.
•When defective fluorescent lamp fault is detected in the emergency light, the green LED is turned OFF
With “6418/11..-....-.4..-..” & “6418/11..-....-.5..-..” versions
•Starts within 24 hours after commissioning.
•Is carried out every days.
•Takes 1 minute.
•Checks the function of the lamps and the battery.
9.1.2.2 Continuous operation test
With “6418/11..-....-.6..-..” & “6418/11..-....-.7..-..” versions
•The duration test is automatically activated every 182 days for 60 min. The fluorescent lamp 1 is, independently of the voltage
across the Line is turned on. If the battery voltage, during or at the end of the test, is under the Deep Discharge Limit, the test
fails and it is recognized as battery failure.
•When defective fluorescent lamp fault is detected in the emergency light, the green LED is turned OFF
•The first duration test will be carried out after Continuous 24-energized hours of the emergency light fixture.
With “6418/11..-....-.4..-..” & “6418/11..-....-.5..-..” versions
•Starts within 44 days after commissioning.
•Is carried out every 365 days.
•Discharges the battery up to the final discharge voltage.
•Checks the function of the lamps and the capacity of the battery.
• Can be deactivated and activated.
9.1.2.3 Deactivating and activating the continuous operation test:
•Switch of the supply voltage.
•Switch on the supply voltage.
•Within 60 seconds, switch the lamps on and off 3 times for 5 seconds each.

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 19 - of 22
•The result will be shown on the LED display for 30 seconds.
9.2 Trouble shooting
Cause
Measure
T
h
e
lam
p
wa
s
incorrectl
y
inse
r
ted.
Inser
t
th
e
lam
p
correctly.
T
h
e
lam
p
i
s
defectiv
e.
R
eplac
e
th
e
lamp.
T
h
e
ballas
t
i
s
defective.
R
eplac
e
th
e
ballast.
T
h
e
power switc
h
i
s
defectiv
e.
R
eplac
e
th
e
switch.
T
h
e
lam
p
reache
d
it
s
en
d
o
f
se
r
vic
e
life.
Replac
e
th
e
lamp.
If the error cannot be eliminated using the mentioned procedures:
•Contact the local representative of R. STAHL Schaltgeräte GmbH.
For fast processing, have the following information ready:
•Type and serial number
•Purchase information
•Error description
•Intended use (in particular input / output wiring)
10. Maintenance, repair & returning of the device ( as per EN60079-17 & as per EN60079-19)
WARNING
Unauthorize
d
wor
k
bein
g
performe
d
o
n
t
h
e
device!
Risk of injuries and material damage!
•Work performed on the device must only be carried out by appropriately authorized and trained personnel.
Risk of electric
shock or malfunctioning of the device due to unauthorized work!
Non-compliance can result in severe injuries and material damage.
•Work performed on the device must only be carried out by appropriately authorized and qualified electricians.
10.1 Maintenance
•
Observe the relevant national regulations in the country of use.
•Periodic Cleaning & Maintenance to be carried out – for details look into the section “10.1.2” of this manual
•To protect the battery from deep discharge, keep the Battery Electrically Disconnected, when the light fixture is not in
use for a longer period (more than 4-Weeks).
•
•
•Consult the relevant national regulations to determine the type and extent of inspections.
•Adapt inspection intervals to the operating conditions.
•To protect the battery from deep discharge, keep the Battery Electrically Disconnected, when the light fixture is
not in use for a longer period (more than 4-Weeks).
The following tests and measures must be carried out during regular maintenance.
Check
M
easures

Operation, Installation and Maintenance Manual for 6418/11 - Series
ID-No.: 226 66 / 6418601300
Publication Code: 201 -08-31:BA00.lll.en.01 Page - 20 - of 22
•
the permissible ambient temperature
•
If exceeding the permissible ambient temperature or falling below the
device must be taken out of operation.
•
the enclosure components for formation
of cracks and damage.
•
Replace the exchangeable enclosure components. If the enclosure
components are non-exchangeable, the device must be taken out of
operation.
•
its intended use
•
If the device is not used according to its intended use, it must be taken
out of operation.
•
the cables for ageing and damage
•
replace damaged or aged cables.
•
the seals for ageing and damage
•
replace damaged, aged and porous seals and completely change
enclosure components with foamed seal.
•if the conductors are clamped properly •clamp loose conductors tightly.
10.1.1 Replacement of lamps
O
nly use fluorescent lamps with pins made of brass.
1. Insert both the lamp bases into the holder guide slots until the stop is reached.
2. Move lamp to its operating position by turning it to the right or the left.
3. Dismounting is carried out in reverse order.
Important notes:
•The lamp bases and pins must be undamaged.
•The holders have a spring-loaded length adjustment facility of 2.5 mm each.
•Make sure that the lamp has been fitted properly. When it has been turned, the lamp
is locked in position.
•Replace the lamps in due time.
•Observe the service life specified by the manufacturer.
•EOL- safety shutdown: The EB switches off the lamp at the end of the service life.
10.1.2 Replacement of Battery
WARNING
Danger due to sparking!
Explosion protection is impaired!
Carry the battery Carefully.
Risk of electric shock or malfunctioning of the device due to unauthorized work!
Non-compliance can result in severe injuries and material damage.
•Work performed on the device must only be carried out by appropriately authorized and qualified electricians.
