Stahl FL6S/2 Series User manual

Visual signalling device
Series FL6S/2
Operating instructions
Additional languages r-stahl.com
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN

Contents
2
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
Contents
1 General information .............................................................................................3
1.1 Manufacturer........................................................................................................3
1.2 Information regarding the operating instructions..................................................3
1.3 Further documents...............................................................................................3
1.4 Conformity with standards and regulations..........................................................3
2 Explanation of symbols........................................................................................4
2.1 Symbols used in these operating instructions......................................................4
2.2 Warning notes......................................................................................................4
2.3 Symbols on the device.........................................................................................5
3 Safety notes.........................................................................................................6
3.1 Operating instructions storage.............................................................................6
3.2 Personnel qualification.........................................................................................6
3.3 Safe use...............................................................................................................6
3.4 Modifications and alterations ...............................................................................7
4 Function and device design .................................................................................7
4.1 Function ...............................................................................................................7
4.2 Device design ......................................................................................................8
5 Technical data......................................................................................................9
6 Transport and storage........................................................................................14
7 Mounting and installation ...................................................................................15
7.1 Dimensions/fastening dimensions .....................................................................15
7.2 Mounting/dismounting, operating position .........................................................16
7.3 Installation..........................................................................................................17
8 Commissioning ..................................................................................................28
8.1 Prerequisites......................................................................................................28
8.2 Testing ...............................................................................................................28
9 Operation ...........................................................................................................29
9.1 Troubleshooting .................................................................................................29
10 Maintenance, overhaul, repair ...........................................................................29
10.1 Maintenance and overhaul.................................................................................29
10.2 Repair ................................................................................................................29
10.3 Returning the device..........................................................................................30
11 Cleaning.............................................................................................................30
12 Disposal .............................................................................................................30
13 Accessories and spare parts..............................................................................30

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
General information
3
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
1 General information
1.1 Manufacturer
1.2 Information regarding the operating instructions
The original instructions are the English edition.
They are legally binding in all legal affairs.
1.3 Further documents
• Data sheet
For documents in other languages, see r-stahl.com.
1.4 Conformity with standards and regulations
IECEx, ATEX, EU Declaration of Conformity and further national certificates can be
downloaded via the following link: https://r-stahl.com/en/global/support/downloads/.
IECEx is also available at: http://iecex.iec.ch/
R. STAHL Schaltgeräte GmbH
Business Unit Lighting & Signalling
Nordstr. 10
99427 Weimar
Germany
R. STAHL Schaltgeräte GmbH
Am Bahnhof 30
74638 Waldenburg
Germany
Tel.:
Fax:
Internet:
E-mail:
[phone]
[phone]
r-stahl.com
[e-mail]
Tel.:
Fax:
Internet:
E-mail:
[phone]
[phone]
r-stahl.com
[e-mail]
ID no.: 283929 / FL6S60300050
Publication code: 2022‐03‐04·BA00·III·en·01

Explanation of symbols
4283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
2 Explanation of symbols
2.1 Symbols used in these operating instructions
2.2 Warning notes
Warning notes must be observed under all circumstances, in order to minimise the risk
resulting from design engineering and operation. The warning notes have the following
structure:
• Signalling word: DANGER, WARNING, CAUTION, NOTICE
• Type and source of danger/damage
• Consequences of danger
• Taking countermeasures to avoid the danger or damage
Symbol Meaning
Tips and recommendations on the use of the device
General danger
Danger due to explosive atmosphere
DANGER
Danger to persons
Non-compliance with the instruction results in severe or fatal injuries to
persons.
WARNING
Danger to persons
Non-compliance with the instruction can result in severe or fatal injuries to
persons.
CAUTION
Danger to persons
Non-compliance with the instruction can result in light injuries to persons.
NOTICE
Avoiding material damage
Non-compliance with these instructions can result in material damage to the device
and/or its surroundings.

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Explanation of symbols
5
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
2.3 Symbols on the device
Symbol Meaning
05594E00
CE marking according to the current applicable directive.
02198E00
Device certified for hazardous areas according to the marking.
15649E00
Input
15648E00
Output
11048E00
Safety notes that must always be observed: The corresponding data
and/or safety-related instructions contained in the operating instructions
must be followed for devices with this symbol!
20690E00
Marking according to WEEE Directive 2012/19/EU

Safety notes
6283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
3 Safety notes
3.1 Operating instructions storage
• Carefully read the operating instructions.
• Store the operating instructions at the mounting location of the device.
• Observe applicable documents and operating instructions of the devices to be
connected.
3.2 Personnel qualification
Qualified specialist personnel is required to perform the activities described in these
operating instructions. This primarily applies to work in the following areas
• Project engineering
• Mounting/dismounting the device
• (Electrical) installation
• Commissioning
• Maintenance, repair, cleaning
Specialists who perform these activities must have a level of knowledge that meets
applicable national standards and regulations.
Additional knowledge is required for any activity in hazardous areas!
R. STAHL recommends having a level of knowledge equal to that described in the
following standards:
• IEC/EN 60079-14 (Project engineering, selection and construction of electrical
systems)
• IEC/EN 60079-17 (Electrical Installations Inspection and Maintenance)
• IEC/EN 60079-19 (Equipment repair, overhaul and reclamation)
3.3 Safe use
Before mounting
• Read and observe the safety notes in these operating instructions!
• Ensure that the contents of these operating instructions are fully understood by the
personnel in charge.
• Use the device in accordance with its intended and approved purpose only.
• Always consult R. STAHL Schaltgeräte GmbH if using the device under operating
conditions which are not covered by the technical data.
• Make sure that the device is not damaged.
• We cannot be held liable for damage to the device caused by incorrect or unauthorised
use or non-compliance with these operating instructions.
For mounting and installation
• Have mounting and installation performed only by qualified and authorised persons
(see chapter "Personnel qualification").
• The device is only to be installed in areas for which it is suited based on its marking.
• During installation and operation, observe the information (characteristic values and
rated operating conditions) on the rating, data and information plates located on the
device.
• Before installation, make sure that the device is not damaged.

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Function and device design
7
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
Commissioning, maintenance, repair
• Only have commissioning and repairs performed by qualified and authorised persons
(see chapter "Personnel qualification").
• Before commissioning, make sure that the device is not damaged.
• Perform only maintenance work described in these operating instructions.
3.4 Modifications and alterations
4 Function and device design
4.1 Function
Application range
The series FL6S/2 signalling device is intended for use in explosive or harsh
environments. It is used in gas hazardous areas in Zones 1 and 2, as well as in dust
hazardous areas in Zones 21 and 22.
Mode of operation
When activated, the signalling device emits a visual signal, depending on the
configuration and device version.
DANGER
Explosion hazard due to modifications and alterations to the device!
Non-compliance results in severe or fatal injuries.
• Do not modify or change the device.
No liability or warranty for damage resulting from modifications and
alterations.
DANGER
Explosion hazard due to improper use!
Non-compliance results in severe or fatal injuries.
• Use the device only according to the operating conditions described in
these operating instructions.
• Use the device only for the intended purpose specified in these
operating instructions.

Function and device design
8283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
4.2 Device design
23111E00
1 Enclosure cover 4 Flash cover
2 Enclosure 5 Cheese-head screws
3 PCB
1
3
4
5
2

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Technical data
9
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
5 Technical data
Explosion protection
Global (IECEx)
Gas and dust IECEx EPS 20.0036X
Ex db IIC T.*) Gb
Ex tb IIIC T... °C*) Db
Europe (ATEX)
Gas and dust EPS 20 ATEX 1 076 X
E II 2 G Ex db IIC T.*) Gb
E II 2 D Ex tb IIIC T... °C*) Db
*) Temperature class T6 T4
Max. surface temperature (tb) T80 °C T100 °C
Ambient temperature range -60 to +50 °C 1) -60 to +70 °C 2)
1) Loop in/loop out wiring up to max. 10 A
2) Loop in/loop out wiring up to max. 10 A, connection line and cable entries with
permissible operating temperature ≥ +90 °C required
Special conditions "X"
Repair work on flameproof joints is only permissible in accordance with the
values specified by the manufacturer.
The strength class of the screws used must be at least A2-70.
Certifications and certificates
Certifications IECEx, ATEX

Technical data
10 283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
Technical data
Technical data
Product weight 3.04 kg
Electrical data
Rated operational
voltage
21.1 to 24 V DC
Average input power/
max. current
consumption
Max. current
consumption
[mA]
Average
power
[W]
XENON 5J 350 6.5
LED 400 6.5
In flash mode 1,200 6.5
Class I (PE connection) (internal + external)
Ambient conditions
Functional ambient
temperature range
min. -40 °C
max. ambient temperature see certificate
Mechanical data
Degree of protection IP66 (IEC/EN 60529)
Material
Enclosure Glass fibre reinforced polyester
Enclosure colours Black
Calotte cover Polycarbonate
Mounting Stainless steel
Seal Silicone O-ring seal
Cable entries 2 cable entries, equipped with:
2 x M20 dust cap, red

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Technical data
11
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
Technical data
Visual data
Calculated
max. range
LED disc:
Inform Alert
Function Flashing
1 Hz
Blinking
1 Hz
Flashing
1 Hz
Blinking
1 Hz
Colour red 45 m 58 m 10 m 13 m
amber 69 m 89 m 15 m 20 m
blue 38 m 48 m 8 m 11 m
green 36 m 46 m 8 m 10 m
clear 86 m 111 m 19 m 25 m
opal 74 m 94 m 16 m 21 m
yellow 83 m 106 m 19 m 24 m
magenta 19 m 25 m 4 m 6 m
LED tower:
Inform Alert
Function Flashing
1 Hz
Blinking
1 Hz
Flashing
1 Hz
Blinking
1 Hz
Colour red 52 m 67 m 12 m 15 m
amber 87 m 111 m 19 m 25 m
blue 47 m 61 m 11 m 14 m
green 45 m 57 m 10 m 13 m
clear 109 m 139 m 24 m 31 m
opal 92 m 118 m 21 m 26 m
yellow 104 m 133 m 23 m 30 m
magenta 24 m 31 m 5 m 7 m
XENON:
Inform Alert
Function Flashing 1 Hz Flashing 1 Hz
Colour red 35 m 8 m
amber 62 m 14 m
blue 32 m 7 m
green 32 m 7 m
clear 82 m 18 m
opal 57 m 13 m
yellow 77 m 17 m
magenta 21 m 5 m

Technical data
12 283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
Technical data
Luminous characteristics
Effective luminous
intensity
Type LED disc LED tower XENON
Function Flash-
ing
1 Hz
Blink-
ing
1 Hz
Flash-
ing
1 Hz
Blink-
ing
1 Hz
Flashing
1 Hz
Colour red 41 cd 67 cd 55 cd 90 cd 24 cd
amber 96 cd 157 cd 151 cd 248 cd 76 cd
blue 28 cd 47 cd 45 cd 74 cd 20 cd
green 25 cd 42 cd 40 cd 66 cd 21 cd
clear 150 cd 245 cd 236 cd 387 cd 136 cd
opal 108 cd 178 cd 171 cd 280 cd 66 cd
yellow 138 cd 226 cd 217 cd 356 cd 119 cd
magenta 7 cd 12 cd 12 cd 19 cd 9 cd
Luminous flux Type LED disc LED tower
Function Continuous light Continuous light
Colour red 99 lm 236 lm
amber 233 lm 573 lm
blue 69 lm 170 lm
green 62 lm 152 lm
clear 365 lm 895 lm
opal 264 lm 648 lm
yellow 335 lm 824 lm
magenta 18 lm 45 lm

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Technical data
13
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
Technical data
Pole diagram XENON:
22498E00
LED tower:
22497E00
LED disc:
22496E00
30°
45°
60°
75°
90°
105°
120°
135°
150°
165° 180° 165°
150°
135°
120°
105°
90°
75°
60°
45°
30°
15°
0°
[cd]
C0 - C180
20% 40% 60% 80% 100%
15°
C90 - C270
30°
45°
60°
75°
90°
105°
120°
135°
150°
165° 180° 165°
150°
135°
120°
105°
90°
75°
60°
45°
30°
15°
0°
[cd]
C0 - C90 - C180 - C270
20% 40% 60% 80% 100%
15°
30°
45°
60°
75°
90°
105°
120°
135°
150°
165° 180° 165°
150°
135°
120°
105°
90°
75°
60°
45°
30°
15°
0°
[cd]
C0 - C90 - C180 - C270
20% 40% 60% 80% 100%
15°

Transport and storage
14 283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
For further technical data, see r-stahl.com.
6 Transport and storage
• Transport and store the device only in the original packaging.
• Store the device in a dry place (no condensation) free of vibrations.
• Do not drop the device.
Technical data
Flash energy XENON: 5 J
Signal function LED:
- Continuous light (maximum, dimmed)
- Flashing light (single flash, double flash, triple flash 1 Hz/2 Hz/3 Hz)
- Blinking light (1 Hz/1.5 Hz/2 Hz)
- Rotating light (90rpm, 120rpm, 180rpm)
- Chaos light
XENON:
- Flashing light (single flash, 1 Hz)
Mounting/installation
Connection type PUSH-IN terminal
Connection terminals Solid: 0.5 to 2.5 mm2
Finely stranded: 0.5 to 2.5 mm2
Scope of delivery - Signalling device according to configuration
- L-bracket
- Dust caps

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Mounting and installation
15
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
7 Mounting and installation
7.1 Dimensions/fastening dimensions
Dimensional drawings (all dimensions in mm [inch]) – Subject to change
17149E00
189 [7,44]
[4,61]
117
287,50 [11,32]
95
[3,74]
75
[2,95]
105
[4,13]
ØØ9 [ 0,35]
40 [1,57]
178,50 [7,03]

Mounting and installation
16 283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
7.2 Mounting/dismounting, operating position
DANGER
Explosion hazard due to improper mounting!
Non-compliance results in severe or fatal injuries.
• Only operate the device if it is not damaged.
If the thread is damaged, replace the device immediately.
• Only install the device in a clean and dry operating environment.
• Only mount the device on a wall or on a suitable surface.
• Carefully protect exposed joint surfaces from damage, dust and dirt.
• Install end flanges without applying force (without hammer and tool)
in straight alignment.
• If necessary, fit core end sleeves gas-tight and using a suitable tool.
DANGER
Explosion hazard due to electrostatic discharge!
Non-compliance results in severe or fatal injuries.
Do not use the device in strong charge-generating environments!
The following processes/activities should be avoided:
• Accidental friction
• Particle flows
DANGER
Explosion hazard due to open drilled holes, unused cable entries and cable
glands!
Non-compliance results in severe or fatal injuries.
• Only use cable entries and stopping plugs that have been separately
checked and certified in accordance with Directive 2014/34/EU (ATEX)
and IECEx (CoC), and which technically correspond to the state of
technology given in the certificate.
• The IP level of protection of the cable entries and stopping plugs
must at least correspond to the IP level of protection of the device
(see marking on the device).
• When selecting cable entries, observe the type of thread and thread
size in the component documentation.
• Seal the thread with non-curing thread sealant in order to guarantee the
IP66 degree of protection.
• Always close unused drilled holes, cable entries and cable glands using
approved stopping plugs or plugs. Observe IEC/EN 60079-14 for this.
• Installation of the cable gland must be performed in accordance with the
manufacturer's instructions.
• The cable entry temperature may exceed 70 °C.

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Mounting and installation
17
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
• Select a mounting location that is suitable for the signal effect of the device, as well as
the required mounting and installation parameters (see "Technical data" chapter).
• Mount the device on a flat surface using the L-bracket and screw holes.
• Mount suitable approved electrical lines (see "Technical data" chapter) using a
suitable flameproof cable entry.
• Close unused entries using certified, flameproof stopping plugs.
7.3 Installation
The electrical installation and configuration of the device is performed in the following
sequence:
• Dismounting the device (see chapter 7.3.1)
• Electrical connections (see chapter 7.3.2)
• Configuration (see chapter 7.3.3)
• Mounting the device (see chapter 7.3.4)
• Mounting the earth connection (see chapter 7.3.5)
7.3.1 Dismounting the device
23112E00
• Loosen the six cheese-head screws
(5) and remove them from the flash
cover (4).
23113E00
• Carefully pull the PCB out of the
enclosure.
5
4

Mounting and installation
18 283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
7.3.2 Electrical connections
• Lay the pre-installed cabling in the intended electrical connections – see figure.
DANGER
Explosion hazard due to insufficient protective measures!
Non-compliance results in severe or fatal injuries.
• Select suitable conductors to ensure that the maximum permissible
conductor temperatures are not exceeded.
• When using core end sleeves, attach them using a suitable tool.
• The conductor insulation must be touching the terminal.
• Do not damage the conductor (e.g. nicking) when stripping it.
• Finally, check the conductor to ensure that it is secure (fixed).
22796E00
22797E00
5 Control (A/B signal)
6 Power supply
6
5
LED
0V 24V
6
5
B A

283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
Mounting and installation
19
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
22798E00
Example: Connection diagram for combining multiple devices
When doing so:
• Observe the maximum permissible single wire cross-sections for the connection
terminals – see "Technical data" chapter.
• Only such cable entries and stopping plugs may be installed that have been separately
tested and certified according to Directive 2014/34/EU (ATEX) and IECEx (CoC);
they must also comply technically with the standard version stated in the certificate.
• Use electrical lines with a minimum length of 3 m or a cable gland with compound.
LED
A
LED
A
B
24 V
0 V
0V 24V
BA
0V 24V
B A
0V 24V
B
LED LED

Mounting and installation
20 283929 / FL6S60300050
2022‐03‐04·BA00·III·en·01
DE
EN
FR
IT
ES
RU
NL
DK
SE
FI
PT
GR
PL
CZ
SK
HU
SL
RO
BG
LV
LT
EE
CH
KR
CN
Visual signalling device
Series FL6S/2
7.3.3 Configuration
The configuration of the device is performed by adjusting the DIP switch on the PCB.
The following general/visual configuration options are available:
XENON circuit board
22846E00
"SW1" DIP switch
DIP switch designation Function
7 SW1 General settings
1 2 3 4 5
ON Reserved
OFF Reserved
ON Reserved
OFF Reserved
ON Reserved
OFF Reserved
ON Reserved
OFF Reserved
ON RI ACTIVATION
Active switching via B signal
OFF RI DEACTIVATION
Regular switching
7
