Fusion (Model XF)
Circuit Breaker Replacement
2015-12-03
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 1 of 4
Included Parts:
1. Circuit Breaker with terminal screws,
toothed washer and silver mounting
ring (P/N: 1-1331)
Required Tools:
2. Pliers
3. #2 Phillips Screwdriver
4. Allen Wrenches (3/32” & 9/32”)
CAUTION: Detach power cord before
proceeding
Lower heater but do not lock into place, such
that it rests gently on lower platen
1
2
3
4

Fusion (Model XF)
Circuit Breaker Replacement
2015-12-03
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 2 of 4
Loosen set screw in shaft of pressure
adjustment knob and remove knob
Remove 4 #8-32 x ½” Thumb Screws (right
2 shown) from underside of control housing
using 9/32” Allen Wrench
Lift off control housing and lay it gently on
left side of press

Fusion (Model XF)
Circuit Breaker Replacement
2015-12-03
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 3 of 4
Remove silver mounting ring from circuit
breaker using pliers if necessary, being
careful not to damage the painted finish
Transfer wire terminals one at a time from
old circuit breaker to new using #2 Phillips
Screwdriver, noting terminal connections
and circuit breaker orientation are correct as
shown
Install toothed washer and silver mounting
ring, noting amperage rating orientation as
shown
Replace housing onto press and insert 4
#8-32 x ½” Thumb Screws (right 2 shown),
tightening with 9/32” Allen Wrench

Fusion (Model XF)
Circuit Breaker Replacement
2015-12-03
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 4 of 4
Replace Pressure Adjustment Knob, aligning
set screw with flat of shaft and tightening
with 3/32” Allen Wrench
Raise handle into open position, plug in
press and turn ON to verify proper operation
