Air Fusion (Model XRF)
Circuit Breaker Replacement
2016-03-01
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 1 of 3
Included Parts:
1. Circuit Breaker
(20A P/N: 1-1331 for 120V)
(10A P/N: 1-1331-2 for 220V-240V)
Required Tools:
2. Pliers
3. #2 Phillips Screwdriver
CAUTION: Detach power cord before
proceeding
CAUTION: Detach main air supply line
before proceeding
Remove Left I/O Panel by unscrewing two
#6-32 x 1/4” Screws using #2 Phillips
Screwdriver
1
2
3

Air Fusion (Model XRF)
Circuit Breaker Replacement
2016-03-01
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 2 of 3
Transfer wire terminals one at a time from
old Circuit Breaker to new using #2 Phillips
Screwdriver, noting terminal connections
and circuit breaker orientation are correct as
shown
Remove old Circuit Breaker and discard by
unscrewing silver mounting ring, using pliers
if necessary
Install new Circuit Breaker by screwing on
toothed washer and silver mounting ring,
noting amperage rating orientation as shown
Install Left I/O Panel by screwing in two #6-
32 x 1/4” Screws using #2 Phillips
Screwdriver

Air Fusion (Model XRF)
Circuit Breaker Replacement
2016-03-01
Technical Assistance: 1-(800)-727-8520
Manuals: hotronix.com/heat-press-manuals Page 3 of 3
Repeat process for Right I/O Panel
NOTE: 220V Models Only
Plug in press and turn ON to verify proper
operation
