Standby W3 User manual

W3 – Manual
WAM8W3A 1 Standby AB – standbygroup.se
W3
Safety
WARNING
This product contains high intensity L D devices. To prevent eye damage, do not look into the
light beam at close range.
Technical Data
Attribute Units
Lens
Polycarbonate
Color
, lens
Clear
or blue
Color, L D, nd modules
Blue, amber, red or blue/amber
Color, L D, Inboard modules
Blue/amber, blue/red. Blue/white, white/amber, blue/green,
red/empty, white/empty, empty/amber, blue/empty or
red/amber
Cable
4.5 m
Voltage
12
-
24 V
DC
Power consumption
20 A with peak at 30 A
for less than 50 ms
Length
930, 1100, 1270, 1440, 1600, 1770 or 1940 mm
Height
Corner module: 65 mm
Inboard module: 47 mm
Width
280 mm
Interface
CAN bus of a Standby Control System or break out box
Operating temperature
-
40°C
–
+85°C
Approvals
C R6, C R7, C R10, C R65, ICAO
Parts Overview
A.
Front
B.
Rear
1.
Front module
2.
Rear module
3.
Corner module
4.
Alley right
5.
Aerodynamic cover
6.
T
-
rail
4.5 m cable / Cannon connector
(optional)
Controllpanel with fixingsystem
!

W3 – Manual
WAM8W3A 2 Standby AB – standbygroup.se
Dimensions

W3 – Manual
WAM8W3A 3 Standby AB – standbygroup.se
Break out box connection to W3 Lightbar
Color examples:
•Blue/Amber Lightbar, Blue=1 Amber=2
•Red/Amber Lightbar, Red= 1 Amber =2
Note
Input X18 is only used during configuration and should always be set back to 0 when
configuration is done.
Function Input Additional input Cable color
Day/Night (night mode when active)
X01
X18=0
Blue/White
Reset changeable functions to default
X18=1
360° Color 1 Front
Corner light
X02
Green/White
360° Color 1 Rear Corner light
X03
Grey
Front Col
o
r 1 mergency light (inboard modules)
X04
Black
Rear Color 1 mergency light (inboard modules)
X05
Light Green
360° Color 2 Corner light
X06
Brown/White
Front
Color 2 Warning light
X07
Purple
Rear Color 2 Warning light
X08
X18=0
White
Change behavior if color 1&2 are activated at the
same time. Mode 0-1-2
X18=1
Turn Signal Left
X09
Black/White
Turn Signal Right
X10
Grey/White
Running light Left
X11
X22=1
Purple/White(X11)
Brake light
X22=0
Running light Right
X12
X22=1
Pink/White (X12)
Position light
X22=0
Green Warning light (Front & Rear) /Police Stop
inc Takedown
X13
X18=0
Blue
Change function on X13 between Green(default) &
Police
X18=1
Take Down (White Front Light)
X14
Green
Alley light Left
X15
Yellow
Alley light Right
X16
Orange
Work light Rear
X17
Red
nable Config mode
X18
Pink
Airport Mode (ICAO) ***
X19
Red/White
Red Warning light (Front & Rear)
X20
X18=0
Brown
Special vehicle configuration (on negative edge):
Police S
X18=1
Running light Center
X21
X22=1
Yellow/White (X21)
nable Running light
X22
Orange/White
Flash Configuration (on negative edge) mode 0
-
1
-
2-3-4-5
X23
X18=1
Red/Black (X23)
Warning Light (running light)
X22=1 & X18=0
Flash Pattern select (on negative edge) Triple
-
Double-Single-Custom-ICAO
X24
X18=1
Light Green/White
(X24)
Cruise Light (on selected modules)
X18=0
!

W3 – Manual
WAM8W3A 4 Standby AB – standbygroup.se
Connections
Wire Functions Connect to
Black
Power supply
Good and suitable
ground
Red
Power supply
12
-
24 V DC via a 20 A
fuse
Yellow
CAN
CAN bus of a Standby
Control System or
break out box
Green
CAN
CAN bus of a Standby
Control System or
break out box

W3 – Manual
WAM8W3A 5 Standby AB – standbygroup.se
Installation
Table 1. Installation General recommendations
1. Use fixing screws, by hand, to attach the roof brackets on the t
-
rails of the lightbar bottom. Do not tighten.
2. Pre install lightbar with the brackets on the vehicle roof rails.
The Standby label is placed on the lightbar FRONT part.
3. Aline the lightbar with the B
-
pillar.
4. Cabling preparations:
1. Mark a suitable location for the lightbar cables access
hole.
2. Pre drill its center.
5. Pre install the lightbar and brackets on the
vehicle roof
rails. Make sure that the lightbar top line is horizontal.
6. Adjust and tighten the fixing screws (brackets and lightbar).
7. Feed the lightbar cables through the vehicle roof.
8. Fasten the lightbar top and mount the
aerodynamic covers.

W3 – Manual
WAM8W3A 6 Standby AB – standbygroup.se
Table 2. Installation − Cannon connector as an option
1. Use fixing screws, by hand, to attach the roof brackets on the t
-
rails of the lightbar bottom. Do not tighten.
2. Pre install lightbar with the brackets on the
vehicle roof rails.
The Standby label is placed on the lightbar FRONT part.
3. Aline the lightbar with the B
-
pillar.
4. Cabling preparations:
1. Mark the location for the cable connector cables access
hole center.
2. Pre drill its center.
5. Pre
install the lightbar and brackets on the vehicle roof
rails. Make sure that the lightbar top line is horizontal.
6. Adjust and tighten the fixing screws (brackets and lightbar).
7. Mount the Cannon connector. Bring the connector up
through the lightbar bottom hole. Attach the four cables
from the lightbar to the connector.
8. Fasten the lightbar top and mount the aerodynamic covers.

W3 – Manual
WAM8W3A 7 Standby AB – standbygroup.se
Maintenance
Note
Use a mild car wash shampoo and a sponge that is gentle/appropriate to the lightbar surface
as well as the vehicle surface.
CAUTION
When using high-pressure cleaner:
Water pressure at a maximum of 80 bar.
Minimum distance of 80 cm between the gun and the lightbar.
Direct the gun so that the spray pattern hits the surface at a 90° angle.
Always thoroughly rinse with clean water after a high-pressure wash.
Follow the steps above to avoid negative impacts on packing seal, logos and decals.
Caution
Do not use degreaser.
Caution
Machine wash with brushes is acceptable, as long as the brushes are clean. However this will
increase the risk of the plastic becoming matte and scratchy.
!
!
!
!
