Stanley STHT77498 User manual

제품을 작동하기 전에 본설명서를 읽으십시오.
STHT77498 & STHT77499
Self-Leveling Cross-line Laser
셀프 레벨링 크로스 라인 레이저
KR
E
Please read these instructions before operating the product.
www.STANLEYTOOLS.co.kr

A
12
< 4º
_
3
English 9
한국어 16

A
12
< 4º
_
3
Figures/그림

C
B
1/4-20
D
1
2
45˚
90˚
a
b
a
_

C
B
1/4-20
D
1
2
45˚
90˚
a
b
a
_. (9m)
Figures/그림

1
2
3
E
ba
c
b
ab
_
ab
. (9m)
1
2
Fa
ab

1
2
3
E
ba
c
b
ab
_
ab
1
2
Fa
ab
Figures/그림
. (1.5m)

1/4-20
360º
1
7
5
2
4
3
6
8
G
Contents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014

E
9
1/4-20
360º
1
7
5
2
4
3
6
8
G
Contents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014

E
10
• Do not operate the laser in explosive atmospheres,
such as in the presence of ammable liquids, gases,
or dust. This tool may create sparks which may ignite the
dust or fumes.
• Store an idle laser out of reach of children and other
untrained persons. Lasers are dangerous in the hands of
untrained users.
• Tool service MUST be performed by qualied repair
personnel. Service or maintenance performed by unqualied
personnel may result in injury. To locate your nearest Stanley
service center go to http://www.2helpU.com.
• Do not use optical tools such as a telescope or transit to
view the laser beam. Serious eye injury could result.
• Do not place the laser in a position which may cause
anyone to intentionally or unintentionally stare into the
laser beam. Serious eye injury could result.
• Do not position the laser near a reective surface which
may reect the laser beam toward anyone’s eyes. Serious
eye injury could result.
• Turn the laser off when it is not in use. Leaving the laser
on increases the risk of staring into the laser beam.
• Do not modify the laser in any way. Modifying the tool may
result in hazardous laser radiation exposure.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury may result.
• Do not remove or deface warning labels. If labels are
removed, the user or others may inadvertently expose
themselves to radiation.
• Position the laser securely on a level surface. If the laser
falls, damage to the laser or serious injury could result.
Personal Safety
• Stay alert, watch what you are doing, and use common sense
when operating the laser. Do not use the laser when you are
tired or under the inuence of drugs, alcohol, or medication.
A moment of inattention while operating the laser may result
in serious personal injury.
• Use personal protective equipment. Always wear eye
protection. Depending on the work conditions, wearing
protective equipment such as a dust mask, non-skid safety
shoes, hard hat, and hearing protection will reduce personal
injury.
Tool Use and Care
• Do not use the laser if the Power/Transport Lock switch
does not turn the laser on or off. Any tool that cannot be
controlled with the switch is dangerous and must be repaired.
• Follow instructions in the Maintenance section of this
manual. Use of unauthorized parts or failure to follow
Maintenance instructions may create a risk of electric shock
or injury.
Battery Safety
WARNING:
Batteries can explode, or leak, and can cause
injury or re. To reduce this risk:
• Carefully follow all instructions and warnings on the battery
label and package.
• Always insert batteries correctly with regard to polarity
(+ and –), as marked on the battery and the equipment.
• Do not short battery terminals.
• Do not charge disposable batteries.
• Do not mix old and new batteries. Replace all batteries at the
same time with new batteries of the same brand and type.
• Remove dead batteries immediately and dispose of per
local codes.
• Do not dispose of batteries in re.
• Keep batteries out of reach of children.
• Remove batteries when the device is not in use.
Installing AA Batteries
Load new AA batteries in the STHT77498 or STHT77499 laser.
1. Turn the laser upside down.
2. On the bottom of the laser, lift up the latch to open the battery
compartment cover (Figure B1).
3. Insert two new, high-quality, name brand AA batteries, making
sure to position the - and + ends of each battery as noted
inside the battery compartment (Figure B2).
4. Push the battery compartment cover closed until it snaps in
place (Figure B3).
When the laser is not in use, keep the Power/Transport Lock
switch in the center (OFF) position (Figure A2) to save
battery power.
Turning the Laser On
1. Place the laser on a smooth, flat, level surface, with the
laser facing straight ahead toward the opposing wall (0º
position).
2. Turn the laser ON to display the horizontal and vertical
laser beams. Either:
• Move the Power/Transport Lock switch to the left to keep
the pendulum locked and display the cross beams in
manual mode (Figure A1).
• Move the Power/Transport Lock switch to the right to
unlock the pendulum and display the cross beams in
self-leveling mode (Figure A3).
3. Check the horizontal and vertical laser beams.
• If the laser is tilted so much that it cannot self-level
(> 4°), or the laser is not level in manual mode, the laser
beams will flash.
• If the laser beams ash, the laser is not level (or plumb)
and should NOT BE USED for determining or marking
level or plumb. Try repositioning the laser on a level
surface.
4. If ANY of the following statements are TRUE, continue with
the instructions for Checking Laser Accuracy BEFORE
USING THE LASER for a project.
• This is the first time you are using the laser (in case the
laser was exposed to extreme temperatures).
• The laser has not been checked for accuracy in a
while.
• The laser may have been dropped.
Checking Laser Accuracy
The laser tools are sealed and calibrated at the factory. It
is recommended that you perform an accuracy check prior
to using the laser for the rst time (in case the laser was
exposed to extreme temperatures) and then regularly to
ensure the accuracy of your work. When performing any of
the accuracy checks listed in this manual, follow these
guidelines:
• Use the largest area/distance possible, closest to the
operating distance. The greater the area/distance, the
easier to measure the accuracy of the laser.
• Place the laser on a smooth, at, stable surface that is
level in both directions.
• Mark the center of the laser beam.
Horizontal Beam - Scan Direction
Checking the horizontal scan calibration of the laser requires
two walls at least 30′ (9m) apart. It is important to conduct
a calibration check using a distance no shorter than the distance
of the applications for which the tool will be used.
1. Place the back of the laser against a wall and facing straight
ahead toward the opposing wall (Figure D1).
2. Move the Power/Transport Lock switch to the right (Figure
A3)to turn the laser ON in self-leveling mode and display
the horizontal and vertical beams.
3. Turn the laser 45º counter-clockwise so that the right-most
end of the laser line is displayed on the wall.
4. Mark a on the center of the beam on the wall.
5. Turn the laser 90º clockwise so that the left-most end of
the laser line is displayed near a(Figure D2).
6. Mark b on the center of the beam on the wall.
7. Measure the vertical distance between aand b.

E
11
• Do not operate the laser in explosive atmospheres,
such as in the presence of ammable liquids, gases,
or dust. This tool may create sparks which may ignite the
dust or fumes.
• Store an idle laser out of reach of children and other
untrained persons. Lasers are dangerous in the hands of
untrained users.
• Tool service MUST be performed by qualied repair
personnel. Service or maintenance performed by unqualied
personnel may result in injury. To locate your nearest Stanley
service center go to http://www.2helpU.com.
• Do not use optical tools such as a telescope or transit to
view the laser beam. Serious eye injury could result.
• Do not place the laser in a position which may cause
anyone to intentionally or unintentionally stare into the
laser beam. Serious eye injury could result.
• Do not position the laser near a reective surface which
may reect the laser beam toward anyone’s eyes. Serious
eye injury could result.
• Turn the laser off when it is not in use. Leaving the laser
on increases the risk of staring into the laser beam.
• Do not modify the laser in any way. Modifying the tool may
result in hazardous laser radiation exposure.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury may result.
• Do not remove or deface warning labels. If labels are
removed, the user or others may inadvertently expose
themselves to radiation.
• Position the laser securely on a level surface. If the laser
falls, damage to the laser or serious injury could result.
Personal Safety
• Stay alert, watch what you are doing, and use common sense
when operating the laser. Do not use the laser when you are
tired or under the inuence of drugs, alcohol, or medication.
A moment of inattention while operating the laser may result
in serious personal injury.
• Use personal protective equipment. Always wear eye
protection. Depending on the work conditions, wearing
protective equipment such as a dust mask, non-skid safety
shoes, hard hat, and hearing protection will reduce personal
injury.
Tool Use and Care
• Do not use the laser if the Power/Transport Lock switch
does not turn the laser on or off. Any tool that cannot be
controlled with the switch is dangerous and must be repaired.
• Follow instructions in the Maintenance section of this
manual. Use of unauthorized parts or failure to follow
Maintenance instructions may create a risk of electric shock
or injury.
Battery Safety
WARNING:
Batteries can explode, or leak, and can cause
injury or re. To reduce this risk:
• Carefully follow all instructions and warnings on the battery
label and package.
• Always insert batteries correctly with regard to polarity
(+ and –), as marked on the battery and the equipment.
• Do not short battery terminals.
• Do not charge disposable batteries.
• Do not mix old and new batteries. Replace all batteries at the
same time with new batteries of the same brand and type.
• Remove dead batteries immediately and dispose of per
local codes.
• Do not dispose of batteries in re.
• Keep batteries out of reach of children.
• Remove batteries when the device is not in use.
Installing AA Batteries
Load new AA batteries in the STHT77498 or STHT77499 laser.
1. Turn the laser upside down.
2. On the bottom of the laser, lift up the latch to open the battery
compartment cover (Figure B1).
3. Insert two new, high-quality, name brand AA batteries, making
sure to position the - and + ends of each battery as noted
inside the battery compartment (Figure B2).
4. Push the battery compartment cover closed until it snaps in
place (Figure B3).
When the laser is not in use, keep the Power/Transport Lock
switch in the center (OFF) position (Figure A2) to save
battery power.
Turning the Laser On
1. Place the laser on a smooth, flat, level surface, with the
laser facing straight ahead toward the opposing wall (0º
position).
2. Turn the laser ON to display the horizontal and vertical
laser beams. Either:
• Move the Power/Transport Lock switch to the left to keep
the pendulum locked and display the cross beams in
manual mode (Figure A1).
• Move the Power/Transport Lock switch to the right to
unlock the pendulum and display the cross beams in
self-leveling mode (Figure A3).
3. Check the horizontal and vertical laser beams.
• If the laser is tilted so much that it cannot self-level
(> 4°), or the laser is not level in manual mode, the laser
beams will flash.
• If the laser beams ash, the laser is not level (or plumb)
and should NOT BE USED for determining or marking
level or plumb. Try repositioning the laser on a level
surface.
4. If ANY of the following statements are TRUE, continue with
the instructions for Checking Laser Accuracy BEFORE
USING THE LASER for a project.
• This is the first time you are using the laser (in case the
laser was exposed to extreme temperatures).
• The laser has not been checked for accuracy in a
while.
• The laser may have been dropped.
Checking Laser Accuracy
The laser tools are sealed and calibrated at the factory. It
is recommended that you perform an accuracy check prior
to using the laser for the rst time (in case the laser was
exposed to extreme temperatures) and then regularly to
ensure the accuracy of your work. When performing any of
the accuracy checks listed in this manual, follow these
guidelines:
• Use the largest area/distance possible, closest to the
operating distance. The greater the area/distance, the
easier to measure the accuracy of the laser.
• Place the laser on a smooth, at, stable surface that is
level in both directions.
• Mark the center of the laser beam.
Horizontal Beam - Scan Direction
Checking the horizontal scan calibration of the laser requires
two walls at least 30′ (9m) apart. It is important to conduct
a calibration check using a distance no shorter than the distance
of the applications for which the tool will be used.
1. Place the back of the laser against a wall and facing straight
ahead toward the opposing wall (Figure D1).
2. Move the Power/Transport Lock switch to the right (Figure
A3)to turn the laser ON in self-leveling mode and display
the horizontal and vertical beams.
3. Turn the laser 45º counter-clockwise so that the right-most
end of the laser line is displayed on the wall.
4. Mark a on the center of the beam on the wall.
5. Turn the laser 90º clockwise so that the left-most end of
the laser line is displayed near a(Figure D2).
6. Mark b on the center of the beam on the wall.
7. Measure the vertical distance between aand b.

E
12
8. If your measurement is greater than the Allowable
Distance Between aand bfor the corresponding
Distance Between Walls in the following table, the laser
must be serviced at an authorized service center.
Distance
Between Walls
Allowable Distance
Between aand b
30′(9m) 15/32” (12mm)
40′(12m) 9/16” (14.4mm)
50′(15m) 23/32” (18mm)
Horizontal Beam - Pitch Direction
Checking the horizontal pitch calibration of the laser requires
a single wall at least 30′(9m) long. It is important to conduct
a calibration check using a distance no shorter than the distance
of the applications for which the tool will be used.
1. Place the laser against the end of the wall (Figure E1).
2. Move the Power/Transport Lock switch to the right (Figure
A3)to turn the laser ON in self-leveling mode and display
the horizontal and vertical beams.
3. At least 30′ (9m) apart along the laser beam, mark aand
b.
4. Move the laser to the opposite end of the wall (Figure E
2).
5. Position the laser toward the rst end of the same wall and
parallel to the adjacent wall.
6. Adjust the height of the laser so the center of the beam is
aligned with b.
7. Directly above or below a, mark calong the laser beam
(Figure E3).
8. Measure the distance between aand c.
9. If your measurement is greater than the Allowable
Distance Between aand cfor the corresponding
Distance Between aand b in the following table, the
laser must be serviced at an authorized service center.
Distance Between
aand b
Allowable Distance
Between aand c
30′(9m) 15/32” (12mm)
40′(12m) 9/16” (14.4mm)
50′(15m) 23/32” (18mm)
Vertical Beam - Plumb
Checking the vertical (plumb) calibration of the laser can be
most accurately done when there is a substantial amount of
vertical height available, ideally 30′ (9m), with one person on
the oor positioning the laser and another person near a ceiling
to mark the position of the beam. It is important to conduct
a calibration check using a distance no shorter than the distance
of the applications for which the tool will be used.
1. On the oor between two walls, mark a 5 ft. (1.5 m) line
that is parallel to the adjacent wall (Figure F1).
2. Move the Power/Transport Lock switch to the right (Figure
A3)to turn the laser ON in self-leveling mode and display
the horizontal and vertical beams.
3. Place the laser at one end of the line on the oor, making
sure the vertical laser beam is aligned and centered on the
line.
4. Where the vertical laser beam appears on the ceiling, mark
a. (This should be directly over the midpoint of the line on
the oor.)
5. Move the laser to the other end of the line on the oor
(Figure F2).
6. Where the vertical laser beam appears on the ceiling, mark
b, directly beside the rst mark a.
7. Measure the distance between aand b.
8. If your measurement is greater than the Allowable
Distance Between aand bfor the corresponding
Ceiling Height Din the following table, the laser must be
serviced at an authorized service center.
Ceiling Height D
Allowable Distance
Between aand b
8′ (2.5m) 5/32" (3.5mm)
10′ (3.0m) 3/16” (4.5mm)
14′ (4.0m) 1/4” (6.0mm)
20′ (6.0m) 3/8” (9.0mm)
30′ (9.0m) 1/2” (13.0mm)
Using the Laser
Operating Tips
• Always mark the center of the beam created by the laser.
• Extreme temperature changes may cause movement of
internal parts that can affect accuracy. Check your accuracy
often while working.
• If the laser is ever dropped, check to make sure it is still
calibrated.
• As long as the laser is properly calibrated, the laser is self-
leveling. Each laser is calibrated at the factory to nd level as
long as it is positioned on a at surface within average ± 4°
of level. No manual adjustments are required.
• Use the laser on a smooth, at, level, surface.
Turning the Laser Off
Slide the Power/Transport Lock switch to the OFF position
(Figure A2) when the laser is not in use. If the switch is not
placed in the OFF position, the laser will not turn off.
Using the Laser with the Bracket
A bracket (Figure G) is included with the laser so you can
easily attach the laser to a stud, ceiling grid, or pole.
1. Securely attach the laser to the bracket.
• Using the 1/4-20 thread on the bottom, side, or back of the
laser (Figure C), position the laser on the 1/4-20 thread
on the bracket arm (Figure G1).
• Turn the laser knob (Figure G2) clockwise to lock the
laser on the 1/4-20 thread on the bracket arm.
2. If needed, change the height or position of the laser on the
bracket.
• Turn the adjustment knob (Figure G3) counter-clockwise
to loosen the bracket arm.
• Slide the bracket arm up or down to the desired height
(Figure G4). To change the bracket from 90°to 180°,
slide the bracket arm to the top of the bracket and then flip
the arm to the right (Figure G5).
• Turn the adjustment knob (Figure G3) clockwise to lock
the bracket arm in place.
3. Use the bracket’s clamp (Figure G6) to hold the laser in
place on a stud, ceiling grid, or pole.
• If necessary, rotate the clamp so it is positioned at the
correct angle for attaching to the object. While holding the
bracket arm with one hand, use your other hand to turn
the clamp (Figure G7).
• Position the bracket’s clamp around the stud, ceiling
grid, or pole.
• Turn the clamp knob (Figure G8) clockwise until the
clamp is tight around the object and the bracket is held
in place.
Using the Laser with Other Accessories
WARNING:
Since accessories other than those offered by
STANLEY have not been tested with this laser, use of
such accessories with this laser could be hazardous.
Only use STANLEY®accessories that are recommended for use
with this model. Accessories that may be suitable for one laser
may create a risk of injury when used with another laser.
The laser is equipped with a 1/4-20 female thread on the
bottom, side, and back (Figure C) to accommodate current or
future STANLEY®accessories.
• Only use STANLEY® accessories specied for use with this
laser and carefully follow the directions included with the
accessory.
Other recommended accessories for use with this laser are
available at extra cost from your local dealer or authorized
service center. If you need assistance locating any accessory,
please contact your nearest STANLEY service center or visit our
website: http://www.STANLEY.com.
Maintenance
• When the laser is not in use, clean the exterior parts with a
damp cloth, wipe the laser with a soft dry cloth to make sure it
is dry, and then store the laser in the kit box provided.
• Although the laser exterior is solvent resistant, NEVER use
solvents to clean the laser.
• Do not store the laser at temperatures below -5 ˚F (-20 ˚C) or
above 140 ˚F (60 ˚C).
• To maintain the accuracy of your work, check the laser often

E
13
8. If your measurement is greater than the Allowable
Distance Between aand bfor the corresponding
Distance Between Walls in the following table, the laser
must be serviced at an authorized service center.
Distance
Between Walls
Allowable Distance
Between aand b
30′(9m) 15/32” (12mm)
40′(12m) 9/16” (14.4mm)
50′(15m) 23/32” (18mm)
Horizontal Beam - Pitch Direction
Checking the horizontal pitch calibration of the laser requires
a single wall at least 30′(9m) long. It is important to conduct
a calibration check using a distance no shorter than the distance
of the applications for which the tool will be used.
1. Place the laser against the end of the wall (Figure E1).
2. Move the Power/Transport Lock switch to the right (Figure
A3)to turn the laser ON in self-leveling mode and display
the horizontal and vertical beams.
3. At least 30′ (9m) apart along the laser beam, mark aand
b.
4. Move the laser to the opposite end of the wall (Figure E
2).
5. Position the laser toward the rst end of the same wall and
parallel to the adjacent wall.
6. Adjust the height of the laser so the center of the beam is
aligned with b.
7. Directly above or below a, mark calong the laser beam
(Figure E3).
8. Measure the distance between aand c.
9. If your measurement is greater than the Allowable
Distance Between aand cfor the corresponding
Distance Between aand b in the following table, the
laser must be serviced at an authorized service center.
Distance Between
aand b
Allowable Distance
Between aand c
30′(9m) 15/32” (12mm)
40′(12m) 9/16” (14.4mm)
50′(15m) 23/32” (18mm)
Vertical Beam - Plumb
Checking the vertical (plumb) calibration of the laser can be
most accurately done when there is a substantial amount of
vertical height available, ideally 30′ (9m), with one person on
the oor positioning the laser and another person near a ceiling
to mark the position of the beam. It is important to conduct
a calibration check using a distance no shorter than the distance
of the applications for which the tool will be used.
1. On the oor between two walls, mark a 5 ft. (1.5 m) line
that is parallel to the adjacent wall (Figure F1).
2. Move the Power/Transport Lock switch to the right (Figure
A3)to turn the laser ON in self-leveling mode and display
the horizontal and vertical beams.
3. Place the laser at one end of the line on the oor, making
sure the vertical laser beam is aligned and centered on the
line.
4. Where the vertical laser beam appears on the ceiling, mark
a. (This should be directly over the midpoint of the line on
the oor.)
5. Move the laser to the other end of the line on the oor
(Figure F2).
6. Where the vertical laser beam appears on the ceiling, mark
b, directly beside the rst mark a.
7. Measure the distance between aand b.
8. If your measurement is greater than the Allowable
Distance Between aand bfor the corresponding
Ceiling Height Din the following table, the laser must be
serviced at an authorized service center.
Ceiling Height D
Allowable Distance
Between aand b
8′ (2.5m) 5/32" (3.5mm)
10′ (3.0m) 3/16” (4.5mm)
14′ (4.0m) 1/4” (6.0mm)
20′ (6.0m) 3/8” (9.0mm)
30′ (9.0m) 1/2” (13.0mm)
Using the Laser
Operating Tips
• Always mark the center of the beam created by the laser.
• Extreme temperature changes may cause movement of
internal parts that can affect accuracy. Check your accuracy
often while working.
• If the laser is ever dropped, check to make sure it is still
calibrated.
• As long as the laser is properly calibrated, the laser is self-
leveling. Each laser is calibrated at the factory to nd level as
long as it is positioned on a at surface within average ± 4°
of level. No manual adjustments are required.
• Use the laser on a smooth, at, level, surface.
Turning the Laser Off
Slide the Power/Transport Lock switch to the OFF position
(Figure A2) when the laser is not in use. If the switch is not
placed in the OFF position, the laser will not turn off.
Using the Laser with the Bracket
A bracket (Figure G) is included with the laser so you can
easily attach the laser to a stud, ceiling grid, or pole.
1. Securely attach the laser to the bracket.
• Using the 1/4-20 thread on the bottom, side, or back of the
laser (Figure C), position the laser on the 1/4-20 thread
on the bracket arm (Figure G1).
• Turn the laser knob (Figure G2) clockwise to lock the
laser on the 1/4-20 thread on the bracket arm.
2. If needed, change the height or position of the laser on the
bracket.
• Turn the adjustment knob (Figure G3) counter-clockwise
to loosen the bracket arm.
• Slide the bracket arm up or down to the desired height
(Figure G4). To change the bracket from 90°to 180°,
slide the bracket arm to the top of the bracket and then flip
the arm to the right (Figure G5).
• Turn the adjustment knob (Figure G3) clockwise to lock
the bracket arm in place.
3. Use the bracket’s clamp (Figure G6) to hold the laser in
place on a stud, ceiling grid, or pole.
• If necessary, rotate the clamp so it is positioned at the
correct angle for attaching to the object. While holding the
bracket arm with one hand, use your other hand to turn
the clamp (Figure G7).
• Position the bracket’s clamp around the stud, ceiling
grid, or pole.
• Turn the clamp knob (Figure G8) clockwise until the
clamp is tight around the object and the bracket is held
in place.
Using the Laser with Other Accessories
WARNING:
Since accessories other than those offered by
STANLEY have not been tested with this laser, use of
such accessories with this laser could be hazardous.
Only use STANLEY®accessories that are recommended for use
with this model. Accessories that may be suitable for one laser
may create a risk of injury when used with another laser.
The laser is equipped with a 1/4-20 female thread on the
bottom, side, and back (Figure C) to accommodate current or
future STANLEY®accessories.
• Only use STANLEY® accessories specied for use with this
laser and carefully follow the directions included with the
accessory.
Other recommended accessories for use with this laser are
available at extra cost from your local dealer or authorized
service center. If you need assistance locating any accessory,
please contact your nearest STANLEY service center or visit our
website: http://www.STANLEY.com.
Maintenance
• When the laser is not in use, clean the exterior parts with a
damp cloth, wipe the laser with a soft dry cloth to make sure it
is dry, and then store the laser in the kit box provided.
• Although the laser exterior is solvent resistant, NEVER use
solvents to clean the laser.
• Do not store the laser at temperatures below -5 ˚F (-20 ˚C) or
above 140 ˚F (60 ˚C).
• To maintain the accuracy of your work, check the laser often

E
14
to make sure it is properly calibrated.
• Calibration checks and other maintenance repairs may be
performed by STANLEY service centers.
Troubleshooting
The Laser Does Not Turn On
• Check the AA batteries to make sure:
• Each battery is installed correctly, according to (+) and (–)
listed inside the battery compartment.
• The battery contacts are clean and free of rust or corrosion.
• The batteries are new, high-quality, name brand batteries
to reduce the chance of battery leakage.
• Make sure the AA batteries are in proper working condition. If
in doubt, try installing new batteries.
• When using rechargeable batteries, make sure the batteries
are fully charged.
• Be sure to keep the laser dry.
• If the laser unit is heated above 120 ˚F (50 ˚C), the unit will
not turn ON. If the laser has been stored in extremely hot
temperatures, allow it to cool. The laser level will not be
damaged by using the Power/Transport Lock switch before
cooling to its proper operating temperature.
The Laser Beams Flash
When in self-leveling mode, the lasers are designed to self-
level up to an average of 4° in all directions. If the laser is tilted
so much that the internal mechanism cannot level itself (or the
laser is not level when in manual mode), the laser beams will
ash indicating that the tilt range has been exceeded.
THE FLASHING BEAMS CREATED BY THE LASER ARE
NOT LEVEL OR PLUMB AND SHOULD NOT BE USED
FOR DETERMINING OR MARKING LEVEL OR PLUMB. Try
repositioning the laser on a more level surface.
The Laser Beams Will Not Stop Moving
The laser is a precision instrument. Therefore, if it is not
positioned on a stable (and motionless) surface, the laser will
continue to try to nd level. If the beam will not stop moving, try
placing the laser on a more stable surface. Also, try to make
sure that the surface is relatively at and level, so that the laser
is stable.
Service and Repairs
Note: Disassembling the laser level will void all warranties on
the product.
To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustment should be performed by
authorized service centers. Service or maintenance performed
by unqualied personnel may result in a risk of injury. To locate
your nearest STANLEYservice center, go to http://www.
STANLEY.com.
Specications
STHT77498 STHT77499
Light Source Laser diodes
Laser Wavelength 630 – 680 nm visible 510 – 530 nm visible
Laser Power ≤1.5 mW CLASS 2 LASER PRODUCT
Working Range 33′(10m) 50′(15m)
Accuracy ±0.25” @ 33′ (±6 mm @ 10m)
Power Source 2 AA (1.5V) size batteries (3V DC)
Operating Temperature 14°F to 104°F (-10°C to 40°C)
Storage Temperature -5°F to 140°F (-20°C to 60°C)

E
15
to make sure it is properly calibrated.
• Calibration checks and other maintenance repairs may be
performed by STANLEY service centers.
Troubleshooting
The Laser Does Not Turn On
• Check the AA batteries to make sure:
• Each battery is installed correctly, according to (+) and (–)
listed inside the battery compartment.
• The battery contacts are clean and free of rust or corrosion.
• The batteries are new, high-quality, name brand batteries
to reduce the chance of battery leakage.
• Make sure the AA batteries are in proper working condition. If
in doubt, try installing new batteries.
• When using rechargeable batteries, make sure the batteries
are fully charged.
• Be sure to keep the laser dry.
• If the laser unit is heated above 120 ˚F (50 ˚C), the unit will
not turn ON. If the laser has been stored in extremely hot
temperatures, allow it to cool. The laser level will not be
damaged by using the Power/Transport Lock switch before
cooling to its proper operating temperature.
The Laser Beams Flash
When in self-leveling mode, the lasers are designed to self-
level up to an average of 4° in all directions. If the laser is tilted
so much that the internal mechanism cannot level itself (or the
laser is not level when in manual mode), the laser beams will
ash indicating that the tilt range has been exceeded.
THE FLASHING BEAMS CREATED BY THE LASER ARE
NOT LEVEL OR PLUMB AND SHOULD NOT BE USED
FOR DETERMINING OR MARKING LEVEL OR PLUMB. Try
repositioning the laser on a more level surface.
The Laser Beams Will Not Stop Moving
The laser is a precision instrument. Therefore, if it is not
positioned on a stable (and motionless) surface, the laser will
continue to try to nd level. If the beam will not stop moving, try
placing the laser on a more stable surface. Also, try to make
sure that the surface is relatively at and level, so that the laser
is stable.
Service and Repairs
Note: Disassembling the laser level will void all warranties on
the product.
To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustment should be performed by
authorized service centers. Service or maintenance performed
by unqualied personnel may result in a risk of injury. To locate
your nearest STANLEYservice center, go to http://www.
STANLEY.com.
Specications
STHT77498 STHT77499
Light Source Laser diodes
Laser Wavelength 630 – 680 nm visible 510 – 530 nm visible
Laser Power ≤1.5 mW CLASS 2 LASER PRODUCT
Working Range 33′(10m) 50′(15m)
Accuracy ±0.25” @ 33′ (±6 mm @ 10m)
Power Source 2 AA (1.5V) size batteries (3V DC)
Operating Temperature 14°F to 104°F (-10°C to 40°C)
Storage Temperature -5°F to 140°F (-20°C to 60°C)

KR
16
목차
• 레이저 정보
• 사용자 안전
• 배터리 안전
• AA 배터리 설치
• 레이저 켜기
• 레이저 정확도 점검
• 레이저 사용
• 유지 보수
• 문제 해결
• 정비 및수리
• 사양
레이저 정보
STHT77498 및STHT77499 레이저는 2등급 레이저 제품입
니다. 레이저는 셀프 레벨링 레이저 공구로 수평(레벨) 및
수직(연직) 정렬 프로젝트에 사용할 수있습니다.
사용자 안전
안전 지침
다음 정의는 각경고 문구의 심각도를 설명합니다. 사용 설
명서를 읽고 다음 기호들에 유의하십시오.
위험: 절박한 위험 상태를 나타내며, 방지하지 않
으면 사망 또는 심각한 부상을 초래합니다.
경고: 잠재적 위험 상태를 나타내며, 방지하지 않
으면 사망 또는 심각한 부상을 초래할 수있습니
다.
주의: 잠재적으로 위험한 상태를 나타내며, 방지
하지 않으면 경미하거나 가벼운 부상을 초래할
수있습니다.
참고: 신체 부상을 초래하지 않는 행위를 나타내며, 방지
하지 않으면 재산상의 손해가 발생할 수 있습니다.
이제품 또는 STANLEY®공구에 대해 궁금한
사항이나 의견이 있을 경우, 인터넷에서
http://www.STANLEYTOOLS.co.kr을방문하십시오.
경고:
모든 지시사항을 읽고 숙지하십시오. 본설명서
의경고와 지시 사항을 준수하지 않으면 심각한
부상을 초래할 수있습니다.
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
본지침을 잘보관해 두십시오.
경고:
레이저 방사선에 노출. 레이저 레벨을 분해하
거나 개조하지 마십시오. 내부에 사용자가 수
리할 수 있는 부품이 없습니다. 심각한 눈 부상
을 당할 수 있습니다.
경고:
위험한 방사선. 여기에서 지정한 것이외의 컨트
롤사용 또는 조정 또는 절차 수행을 하면 위험한
방사선에 노출될 수있습니다.
레이저에 장착된 라벨에 다음 기호가 사용됩니다.
기호 의미
V볼트
mW 밀리와트
레이저 경고
nm 파장(나노미터)
2 Class 2 레이저
경고 라벨
사용자의 편의와 안전을 위해, 레이저에는 다음과 같은 라
벨이 있습니다.
경고: 부상 위험을 줄이려면 사용자는 사용
설명서를 주의 깊게 읽어야 합니다.
경고: 레이저 방사선. 빔을 쳐다보지 마십
시오. 2등급 레이저 제품.
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014

KR
17
•
가연성 액체, 가스 또는 먼지 등이 있는 폭발성 대기
에서 레이저를 사용하지 마십시오. 이공구에서 먼지나
연기를 발화시킬 수있는 불꽃이 튈수있습니다.
•
사용하지 않는 레이저는 어린이 및 기타 훈련을 받지
않은 사람이 접근할 수 없는 곳에 보관하십시오. 레이
저는 훈련을 받지 않은 사용자가 다루면 위험합니다.
•
공구 정비는 유자격 수리 기술자가 수행해야 합니다.
무자격자가 수행한 서비스 또는 유지보수는 부상을 초
해할 수있습니다. 가까운 스탠리 서비스 센터의 정확한
위치를 찾으려면, http://www.stanleytools.co.kr을방문
하여 확인 하십시오.
•
레이저 빔을 보기 위해 망원경과 같은 광확 도구를 사
용하거나 통과시키지 마십시오. 심각한 눈부상을 당할
수있습니다.
•
고의 또는 실수로 다른 사람이 레이저 빔을 공유 할
수 있는 위치에 레이저를 놓지 마십시오. 심각한 눈부
상을 당할 수있습니다.
•
다른 사람의 눈 쪽으로 레이저 빔을 반사할 수 있는
반사면 가까이에 레이저를 놓지 마십시오. 심각한 눈
부상을 당할 수있습니다.
•
사용하지 않을 때는 레이저를 끄십시오. 레이저를 켜
두면 레이저 빔을 응시할 수있는 위험이 증가합니다.
•
레이저를 어떤 방식으로든 절대 개조하지 마십시오.
공구를 개조하면 위험한 방사선이 노출될 수있습니다.
•
어린이 주변에서 레이저를 작동하거나 어린이가 레이
저를 작동하게 두어서는 안됩니다. 심각한 눈부상을
당할 수있습니다.
•
경고 라벨을 제거하거나 훼손하지 마십시오. 라벨을
제거할 경우, 사용자 또는 다른 사람들이 무심코 방사선
에노출될 수있습니다.
•
레이저를 평평한 면에 안전하게 놓으십시오. 레이저가
넘어질 경우 레이저 손상 또는 심각한 부상을 초래할 수
있습니다.
신체 안전 사항
•
레이저 작업을 할때는 방심하지 말고 작업에 주의하십
시오. 피곤한 상태이거나 약물, 술, 치료제를 복용한 상
태일 때는 레이저를 사용하지 마십시오. 레이저 작업 도
중주의력을 잃어 순간적으로 부상을 당할 수있습니다.
•
신 체 보호 장비를 착용하십시오. 항상 보안경을 착용하
십시오. 작업 조건에 따라 방진 마스크, 미끄럼 방지 안
전화, 안전모 또는 청력 보호 기구 등의 보호 장비를 착
용하면 신체 부상 위험이 줄어듭니다.
공구 사용 및관리
•
본제품의 스위치가 온전하게 작동하지 않을 경우 레이
저를 사용하지 마십시오. 스위치로 제어되지 않는 경우
위험한 상황이 발생 할수있습니다.
•
본사용 설명서에서 지시하는 사항을 반드시 따르십시
오. 검증되지 않은 부품을 사용하거나, 본사용 설명서
상지시 내용을 따르지 않을 경우 감전이나 심각한 부상
을입을 위험이 있습니다.
배터리 안전
경고:
배터리는 폭발하거나 누출될 수 있고, 부상 또
는 화재의 위험이 있습니다. 이러한 위험을 줄이
려면:
•
배터리 라벨 및포장에 표시된 모든 지침 및경고를 주
의하여 따르십시오.
•
항상 배터리는 배터리와 장비에 표시된 대로, 극성
(+ 및–)을정확하게 하여 장착하십시오.
•
배터리 단자를 단락시키지 마십시오.
•
일회용 배터리를 충전하지 마십시오.
•
오래된 배터리와 새배터리를 함께 사용하지 마십시오.
동일한 상표 및유형의 새배터리로 한번에 모든 배터
리를 교체하십시오.
•
다쓴배터리는 즉시 제거하여 현지 규정에 따라 처리하
십시오.
•
배터리를 불속에 버리지 마십시오.
•
배터리는 어린이의 손이 닿지 않는 곳에 보관하십시오.
•
장치를 사용하지 않을 때는 배터리를 빼놓으십시오.
AA 배터리 설치
STHT77498 또는 STHT77499 레이저에 새AA 배터리를 장
착하십시오.
1. 레이저를 뒤집어 놓습니다.
2. 레이저 하단에서, 래치를 들어 올려서 배터리 함커버
를엽니다(그림 B 1 ).
3. 배터리 함안쪽에 표시된 것과 같이 각배터리의 - 및+
끝의 위치를 확인하면서 두개의 새고품질 유명 상표
AA 배터리를 끼웁니다(그림 B 2 ).
4. 제자리에 들어갈 때까지 배터리 함커버가 닫히도록
누릅니다(그림 B 3 ).
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014

KR
18
레이저를 사용하지 않을 때는, 전원/운반 잠금 스위치를
중앙 (OFF) 위치(그림 A 2 )로유지해서 배터리 전원을
아낍니다.
레이저 켜기
1. 레이저가 반대쪽 벽쪽으로 똑바로 향하게 한상태에
서레이저를 매끄럽고, 평평한 수평면 위에 놓습니다
(0º 위치).
2. 레이저를 켜서 수평 및수직 레이저 빔을 표시합니다.
양자택일:
• 전원/운반 잠금 스위치를 왼쪽으로 이동해서 펜듈
럼잠금을 유지하고 수동 모드에서 크로스 빔을 표
시합니다(그림 A 1 ).
• 전원/운반 잠금 스위치를 오른쪽으로 이동해서 펜
듈럼 잠금을 풀고 셀프 레벨링 모드에서 크로스 빔
을표시합니다(그림 A 3 ).
3. 수평 및수직 레이저 빔을 확인합니다.
• 레이저가 자체 수평(> 4°)을이룰 수없도록 레이저
가너무 많이 기울어져 있거나, 또는 레이저가 수동
모드에서 수평하지 않을 경우 레이저 빔이 깜박입
니다.
• 레이저 빔이 깜박일 경우 레이저가 수평(또는 수직)
이아니므로 수평 또는 수직을 알아내거나 표시하
는데사용되어서는 안됩니다. 레이저를 수평한 표
면으로 위치를 옮겨 보십시오.
4. 다음의 내용 중해당되는 내용이 있다면, 레이저를 사
용하시기 전에 레이저 정확도 점검 을수행해야 합니
다.
• 레이저를 처음 사용하는 경우 또는 레이저가 극한
기온에 노출된 경우
• 레이저의 정확도를 한동안 확인하지 않은 경우
• 레이저를 떨어뜨렸을 경우
레이저 정확도 점검
레이저 공구는 공장에서 교정되어 포장되었습니다. 레이
저를 처음 사용하기 전에 정확도 점검을 수행한 다음
(레이저가 극한 기온에 노출되어 있는 경우) 정기적으로
작업의 정확도를 확인하는 것이 좋습니다. 본 설명서에
나열된 정확도 점검 중 하나를 수행할 때는 다음 지침을
준수하십시오.
• 가능한 작동 거리에서 가장 가까운 가장 큰 영역/거리
를 사용하십시오. 영역/거리가 클수록 레이저의 정확도
를측정하기가 더쉽습니다.
• 양쪽 방향에서 수평을 이루는 매끄럽고, 평평하며 안
정된 표면에 레이저를 놓습니다.
• 레이저 빔의 중심을 표시해 두십시오.
수평 빔- 스캔 방향
레이저의 수평 스캔 교정을 점검하려면 두개의 벽이 최소
한 9m (30′) 떨어져 있어야 합니다. 공구가 사용될 용도의
거리보다 짧지 않은 거리를 이용해서 교정 점검을 수행해
야합니다.
1. 반대 벽쪽으로 똑바로 향하게 한상태에서 레이저의
뒤쪽을 벽에 기대어 놓습니다(그림 D 1 ).
2. 전원/운반 잠금 스위치를 오른쪽으로 이동해서
(그림 A 3 ) 레이저를 셀프 레벨링 모드에서 켜고 수
평및수직 빔을 표시합니다.
3. 레이저 라인의 가장 오른쪽 끝이 벽에 표시되도록 레
이저를 시계 반대 방향으로 45º 돌립니다.
4. 벽에서 빔의 중심에 a을표시합니다.
5. 레이저 라인의 가장 왼쪽 끝이 a근처에 표시되도록
레이저를 시계 방향으로 90º 돌립니다(그림 D 2 ).
6. 벽에서 빔의 중심에 b를표시합니다.
7. a및b사이의 수직 거리를 측정합니다.

KR
19
8. 측정한 수치가 다음 표에서 해당하는 벽 사이의 거리
에 대한 a및b사이의 허용되는 거리보다 더클경
우, 공인 서비스 센터에서 레이저를 정비해야 합니다.
벽 사이의 거리 a 와 b 사이
허용되는 거리
9m (30′) 12mm (15/32”)
12m (40′) 14.4mm (9/16”)
15m (50′) 18mm (23/32”)
수평 빔- 피치 방향
레이저의 수평 피치 보정을 확인하려면 최소 9m (30′) 길이
의단일 벽이 있어야 합니다. 공구가 사용될 용도의 거리보
다짧지 않은 거리를 이용해서 교정 점검을 수행해야 합니
다.
1. 레이저를 벽의 끝쪽에 기대어 놓습니다(그림 E 1 ).
2. 전원/운반 잠금 스위치를 오른쪽으로 이동해서
(그림 A 3 ) 레이저를 셀프 레벨링 모드에서 켜고 수
평및수직 빔을 표시합니다.
3. 레이저 빔에 따라 최소 9m (30′) 떨어져 a및b를표
시합니다.
4. 벽의 반대 쪽끝으로 레이저의 위치를 이동합니다(그
림E 2 ).
5. 인접하는 벽과 평행하고 동일한 벽의 첫번째 끝쪽으
로레이저의 위치를 정합니다.
6. 빔의 중심이 가장 가까운 b와일치하도록 레이저의
높이를 조정합니다.
7. a바로 위또는 아래에, 레이저 빔에 따라 c를표시
합니다(그림 E 3 ).
8. a와c사이의 거리를 측정합니다.
9. 측정한 수치가 다음 표에서 해당하는 a와b사이의
거리에대한 a와c사이의 허용되는 거리보다 더
클경우, 공인 서비스 센터에서 레이저를 정비해야 합
니다.
a 와b 사이의
거리
허용되는 a 와c
사이의 거리
9m (30′) 12mm (15/32”)
12m (40′) 14.4mm (9/16”)
15m (50′) 18mm (23/32”)
수직 빔- 연직
레이저의 수직 교정 점검은 수직 높이에서 상당한 양을 이
용할 수있을 때가장 정확하게 수행할 수있는데, 이상적
으로 30′ (9m)로, 바닥에서 한사람이 레이저의 위치를 잡고
있고 천장 근처에서 다른 사람이 빔의 위치를 표시할 수있
는상태입니다. 공구가 사용될 용도의 거리보다 짧지 않은
거리를 이용해서 교정 점검을 수행해야 합니다.
1. 두벽사이의 바닥에, 인접하는 벽에 평행하게 1.5 m
(5 ft.)를표시합니다(그림 F 1 ).
2. 전원/운반 잠금 스위치를 오른쪽으로 이동해서
(그림 A 3 ) 레이저를 셀프 레벨링 모드에서 켜고 수
평및수직 빔을 표시합니다.
3. 수직 레이저 빔이 라인에 맞춰 중앙에 오도록 바닥의
라인 끝에 레이저를 놓습니다.
4. 천장에 수직 레이저 빔이 나타나는 곳에, a를표시합
니다. (이는 바닥에서 라인의 중심점 바로 위에 있어야
합니다.)
5. 바닥 라인의 다른 쪽끝으로 레이저를 이동합니다
(그림 F 2 ).
6. 천장에 수직 레이저 빔이 나타나는 곳에,
첫번째 표시 a바로 옆에,b를표시합니다.
7. a와b사이의 거리를 측정합니다.
8. 측정한 수치가 다음 표에서 해당하는 천장 높이 D 에
대한 a와b사이의 허용되는 거리보다 더클경우,
공인 서비스 센터에서 레이저를 정비해야 합니다.
천장 높이 D a 와b 사이
허용되는 거리
2.5m (8′) 3.5mm (5/32”)
3.0m (10′) 4.5mm (3/16”)
4.0m (14′) 6.0mm (1/4”)
6.0m (20′) 9.0mm (3/8”)
9.0m (30′) 13.0mm (1/2”)

KR
20
레이저 사용
작동 팁
• 항상 레이저 빔의 중심을 표시하십시오.
• 극한의 기온 변화는 정확도에 영향을 줄수있는 내부
부품의 움직임을 야기할 수있습니다. 작업하는 동안 종
종정확도를 확인하십시오.
• 레이저를 떨어뜨렸던 적이 있는 경우, 레이저가 그대로
보정되어 있는지 확인하십시오.
• 레이저가 제대로 교정되어 있으면 레이저는 자체적으
로수평을 유지합니다. 각레이저는 평균 ± 4°의수평 내
의평평한 표면에 위치하는 한수평을 유지하도록 공장
에서 조정되어 있습니다. 수동으로 조정할 필요가 없습
니다.
• 매끄럽고, 평평하며 반반한 표면 위에서 레이저를 사용
하십시오.
레이저 끄기
레이저를 사용하지 않을 때는 전원/운반 잠금 스위치를
OFF 위치(그림 A 2 )로밀어 놓습니다. 스위치가 OFF 위
치에 있지 않을 경우 레이저가 꺼지지 않습니다.
레이저에 브라켓 사용하기
레이저를 스터드, 천장 그리드 또는 봉에 쉽게 장착할 수
있도록 브라켓(그림 G )이레이저에 포함되어 있습니다.
1. 레이저를 브라켓에 안전하게 장착합니다.
• 레이저의 하단, 측면 또는 뒤쪽에 있는 1/4-20 스레
드를 사용해서(그림 C ), 브라켓 암의 1/4-20 스레드
에레이저를 놓습니다(그림 G 1 ).
• 레이저 노브(그림 G 2 )를시계 방향으로 돌려서
레이저를 브라켓 암의 1/4-20 스레드에 잠급니다.
2. 필요할 경우, 브라켓에서 레이저의 높이나 위치를 변
경합니다.
• 조정 노브(그림 G 3 )를시계 방향으로 돌려서 브
라켓 암을 풉니다.
• 브라켓 암을 위또는 아래로 밀어서 원하는 높이에
맞춥니다(그림 G 4 ). 브라켓을 90°에서 180°로변
경하려면, 브라켓 암을 브라켓의 위쪽으로 민다음
암을 오른쪽으로 획젖힙니다(그림 G 5 ).
• 조정 노브(그림 G 3 )를시계 방향으로 돌려서 브
라켓 암을 제자리에 잠급니다.
3. 브라켓의 클램프(그림 G 6 )를사용하여 레이저를
스터드, 천장 그리드 또는 봉의 제자리에 고정합니다.
• 필요할 경우 물체를 장착할 수있는 정확한 각도에
위치하도록 클램프를 돌립니다. 브라켓 암을 한손
으로 잡고 있는 동안, 다른 손을 사용해서 클램프를
돌립니다(그림 G 7 ).
• 브라켓의 클램프를 스터드, 천장 그리드 또는 봉주
위에 놓습니다.
• 클램프가 물체 주위로 꽉끼고 브라켓이 제자리에
잡힐 때까지 클램프 노브를 시계 방향(그림 G 8 )
으로 돌립니다.
레이저에 기타 액세서리 사용하기
경고: 알맞지 않은 액세서리를 이레이저와 함께
사용하면 위험할 수있습니다.
이 모델과 함께 사용하도록 권장되는 STANLEY® 액세서
리만 사용하십시오. 한 가지 레이저에 적합한 액세서리
를 다른 레이저와 함께 사용하면 부상을 입을 수 있습니
다.
현재 또는 미래의 STANLEY® 액세서리를 위한 충분한 공간
을제공하기 위해 레이저에는 하단, 측면 및뒤쪽(그림 C)
에1/4-20 암스레드가 설치되어 있습니다.
• 이레이저와 함께 사용하도록 지정된 STANLEY®액세서
리만 사용하고 액세서리에 포함되어 있는 지시 사항을
따르십시오.
본레이저와 함께 사용을 권장하는 기타 액세서리는
해당 지역에 있는 판매점이나 공인 서비스 센터를 통해
구입할 수있습니다. 액세서리를 찾는 데도움이 필요하
면, 가까운 STANLEY 서비스 센터에 문의하거나 웹사이트:
http://www.STANLEYTOOLS.co.kr를방문하십시오.
유지 보수
• 레이저를 사용하지 않을 때는, 젖은 헝겊으로 외부 부품
을청소하고 부드러운 마른 헝겊으로 레이저를 닦아 확
실히 건조시킨 다음 제공된 키트 박스에 레이저를 보관
하십시오.
• 레이저 외관이 용제에 강하더라도 레이저를 청소하는
데절대 사용하지 마십시오.
• -20 ˚C (-5 ˚F) 미만 또는 60 ˚C (140 ˚F) 이상의 온도에서 레
이저를 보관하지 마십시오.
• 작업의 정확성을 유지하려면, 종종 레이저를 점검해 적
절히 보정되었는지 확인하십시오.
EContents
• Laser Information
• User Safety
• Battery Safety
• Installing AA Batteries
• Turning the Laser On
• Checking Laser Accuracy
• Using the Laser
• Maintenance
• Troubleshooting
• Service and Repairs
• Specications
Laser Information
The STHT77498 and STHT77499 lasers are Class 2 laser
products. The lasers are self-leveling laser tools that can
be used for horizontal (level) and vertical (plumb) alignment
projects.
User Safety
Safety Guidelines
The denitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
If you have any questions or comments about this or any
STANLEY®tool, go to http://www.STANLEY.com.
WARNING:
Read and understand all instructions. Failure to
follow the warnings and instructions in this manual
may result in serious personal injury.
SAVE THESE INSTRUCTIONS
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury could
result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments, or performance of procedures, other
than those specied herein may result in hazardous
radiation exposure.
The label on your laser may include the following symbols.
Symbol Meaning
V Volts
mW Milliwatts
Laser Warning
nm Wavelength in nanometers
2 Class 2 Laser
Warning Labels
For your convenience and safety, the following labels are
on your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product.
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
LASER
2
≤1.5mW @630-680nm
IEC 60825-1: 2014
MADE IN CHINA
STHT77498
www.stanleylasers.com www.stanleytools.com
SER.____________ TYPE 1
Complies with 21
CFR 1040,10 and
1040,11 except for
deviations
pursuant to Laser
Notice No. 50,
dated June 24,
2007
3V DC
MADE IN CHINA
STHT77499
www.stanleylasers.com www.stanleytools.com
LASER
2
≤1.5mW @510-530nm
IEC 60825-1: 2014
