Star Lab Minicentrifuge User manual

Passionate for science.
This is your
Minicentrifuge
user manual.



2 · Minicentrifuge · Manual

Minicentrifuge · Manual · 3
Authorised Managing Director
Klaus Ambos
Registry Court
Amtsgericht [rst instance court]
Hamburg
Register number: HRB 122020
VAT ID no. pursuant to
§ 27 a German
VAT Act DE 214 891 717
Starlab International GmbH
Neuer Höltigbaum 38
22143 Hamburg, Germany
E-Mail: inf[email protected]
www.starlabgroup.com
Tel.: [phone]
Fax: [phone]
Passionate for science.
Declaration of Conformity
Wir / We / Nous:
Starlab International GmbH
erklären, dass folgendes Produkt / declare that the following product / déclarons que le produit ci-dessous
S8030-5000 Minicentrifuge
auf das sich diese Erklärung bezieht, mit den folgenden Normen oder normativen Dokumenten übereinstimmt: / to which this
declaration relates, is in conformity with the following standards or other normative documents: / auquel se réfère cette décla-
ration est conforme aux normes ou autres documents normatifs:
2014/35/EU Low Voltage Directive (LVD)
EN 61010-1:2010/A1:2019 (Safety requirements for electrical equipment for measurement, control,
and laboratory use; Part 1: General requirements)
EN 61010-2-020:2017 (Safety requirements for electrical equipment for measurement, control, and
laboratory use; Part 2-020: Particular requirements for laboratory centrifuges)
2014/30/EU EMC Directive
EN 61326-1:2013 (Electrical equipment for measurement, control and laboratory use – EMC requirements; Part 1: General
requirements)
EN 55011:2016/A11:2020 (Industrial, scientic and medical equipment - Radio-frequency disturbance characteristics -
Limits and methods of measurement)
2006/42/EC Directive on Machinery
EN ISO 12100:2010 Safety of machinery - General priciples for design - Risk assessment and risk reduction
Country-specic USA / Canada
UL 61010-1:2012/R:2019-07 (Electrical Equipment for Measurement, Control, and Laboratory Use; Part 1: General Require-
ments)
UL 61010-2-020: 2016 (Electrical Equipment for Measurement, Control, and Laboratory Use; Part 2: Particular Require-
ments for Laboratory Centrifuges)
CAN/CSA-C22.2 No. 61010-1:2012/A1:2018-11 (Safety requirements for electrical equipment for measurement, control,
and laboratory use; Part 1: General Requirements)
CAN/CSA-C22.2 No. 61010-2-020:2017 (Safety requirements for electrical equipment for measurement, control, and labo-
ratory use; Part 2: Particular Requirements for Laboratory Centrifuges)
FCC 47 CFR Subpart 15B (EMC requirements)
Additional Legal Requirements
2011/65/EU (RoHS – Directive on the restriction of the use of certain hazardous substances in electrical and electronic
equipment) and Commission Delegated Directive (EU) 2015/863 (Amending Annex II to Directive 2011/65/EU of the Europe-
an Parliament and of the Council as regards the list of restricted substances)
EN IEC 63000:2018 (Technical documentation for the assessment of electrical and electronic products with respect to the
restriction of hazardous substances)
2012/19/EU (WEEE – Directive on waste electrical and electronic equipment)
EN 50419:2006 (Marking of electrical and electronic equipment in accordance with Directive WEEE)
EC 1907/2006 (Directive on REACH)
Additional Requirements
EN ISO 14971:2019 (Medical devices - Application of risk management to medical devices)
Konformitätserklärung
Certied by:
Klaus Ambos
CEO STARLAB International GmbH
Hamburg, 16.08.2022

4 · Minicentrifuge · Manual
Authorised Managing Director
Klaus Ambos
Registry Court
Amtsgericht [fi rst instance court]
Hamburg
Register number: HRB 122020
VAT ID no. pursuant to
§ 27 a German
VAT Act DE 214 891 717
Starlab International GmbH
Neuer Höltigbaum 38
22143 Hamburg, Germany
E-Mail: inf[email protected]
www.starlabgroup.com
Tel.: [phone]
Fax: [phone]
Passionate for science.
UKCA Declaration of Conformity
We
Starlab International GmbH
declare that the following product
S8030-5000 Minicentrifuge
to which this declaration relates, is in conformity with the following standards or other normative documents:
Electrical Equipment (Safety) Regulations 2016
EN 61010-1:2010/A1:2019 (Safety requirements for electrical equipment for measurement, control,
and laboratory use –Part 1: General requirements)
EN 61010-2-020:2017 (Safety requirements for electrical equipment for measurement, control,
and laboratory use - Part 2-020: Particular requirements for laboratory centrifuges)
Electromagnetic Compatibility Regulations 2016
EN 61326-1:2013 (Electrical equipment for measurement, control and laboratory use
–EMC requirements –Part 1: General requirements)
EN 55011:2016/A11:2020 (Industrial, scientifi c and medical equipment - Radio-frequency disturbance
characteristics - Limits and methods of measurement)
The Supply of Machinery (Safety) Regulations 2008
EN ISO 12100:2010 Safety of machinery - General priciples for design - Risk assessment and risk reduction
Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations 2012
EN 63000:2018 (Technical documentation for the assessment of electrical and electronic products
with respect to the restriction of hazardous substances)
Additional Requirements
EN ISO 14971:2019 (Medical devices - Application of risk management to medical devices)
Certifi ed by:
Klaus Ambos
CEO STARLAB International GmbH
Hamburg, 16.08.2022

Minicentrifuge · Manual · 5
Table of contents English
User Manual ____________________________________________________________________5 – 16
 ________________________________________________________ 17 – 28
 ____________________________________________________________29 – 40
 _______________________________________________________________ 41 – 52
Certicates ________________________________________________________________________3 – 4
1 Safety_________________________________________________________________ 6
1.1 About this user manual___________________________________________________ 6
1.2 Intended use___________________________________________________________ 6
1.3 Electric current _________________________________________________________ 6
1.4 Clearance envelope _____________________________________________________ 6
1.5 Moving rotor ___________________________________________________________ 6
1.6 Microcentrifuge tubes____________________________________________________ 6
1.7 Loading of the rotor______________________________________________________ 6
1.8 Manipulation___________________________________________________________ 7
1.9 Product liability_________________________________________________________ 7
2 Product description _____________________________________________________ 8
2.1 Minicentrifuge components _______________________________________________ 8
2.2 Delivery package _______________________________________________________ 9
2.3 Type plate _____________________________________________________________ 9
2.4 Supplied rotors _________________________________________________________ 9
3 Installation ___________________________________________________________ 10
3.1 Positioning the minicentrifuge ____________________________________________ 10
3.2 Connecting the power adapter ____________________________________________ 10
4 Operation_____________________________________________________________ 11
4.1 Switching on the minicentrifuge ___________________________________________ 11
4.2 Removing and mounting a rotor ___________________________________________ 11
4.3 Loading the rotor_______________________________________________________ 11
4.4 Starting the minicentrifuge _______________________________________________ 12
4.5 Stopping the minicentrifuge ______________________________________________ 12
5 Maintenance __________________________________________________________ 13
5.1 Cleaning _____________________________________________________________ 13
5.2 Disinfection___________________________________________________________ 14
5.3 Decontamination before shipment_________________________________________ 14
6 Transport, storage and disposal __________________________________________ 15
6.1 Transport and storage __________________________________________________ 15
6.2 Disposal _____________________________________________________________ 15
7 Troubleshooting _______________________________________________________ 15
8 Technical data_________________________________________________________ 16
9 Tube compatibility _____________________________________________________ 16
10 Ordering information ___________________________________________________ 16

6 · Minicentrifuge · Manual
1 Safety
1.1 About this user manual
Before using the minicentrifuge for the rst time, please read this user manual.
This user manual is part of the minicentrifuge and it should be easily accessible at all times.
If the minicentrifuge is transferred to a third party, this user manual must be included.
1.2 
The minicentrifuge is intended for indoor laboratory use and similar applications requiring
relatively low centrifugal forces, such as microltration, cell separation and quick spin downs
from microcentrifuge tube walls and caps. Any other use is considered as improper.
1.3 Electric current
Do not use the minicentrifuge if it is damaged in any way. If the minicentrifuge, the power
adapter or the power cable is damaged, there is a risk of fatal electric shock. Do not use the
minicentrifuge in this case.
In an emergency, immediately switch off the minicentrifuge or disconnect the power cable at
the back of the minicentrifuge.
Disconnect the minicentrifuge from the power supply to clean it, or if it remains unused for a long
time. Do not immerse the minicentrifuge in water or other liquids or let the power cable come
into contact with water or other liquids.
1.4 Clearance envelope
The clearance envelope is the area around the minicentrifuge (30 cm). Do not stay within the
clearance envelope longer than necessary for operating the minicentrifuge. Do not use or
deposit any potentially hazardous materials near the minicentrifuge.
1.5 Moving rotor
Do not touch the rotor while it is still spinning. Wait until the rotor has completely stopped before
fully opening the lid and removing the tubes.
1.6 Microcentrifuge tubes
Only use plastic microcentrifuge tubes that are designed to withstand centrifugal forces of at
least 2,500 x g. Do not use damaged or deformed tubes. The weight of individual tubes may
not exceed 3.0g.
1.7 
Load the rotor symmetrically to ensure proper balance. Never run the minicentrifuge with only
one tube or one PCR strip in place. Load the rotor only with an even number of tubes or PCR
strips.
Fill the tubes and seal all tube lids carefully before inserting the tubes in the rotor.
Do not centrifuge flammable, explosive or corrosive materials.

Minicentrifuge · Manual · 7
Safety English
1.8 Manipulation
Do not open the housing or manipulate the minicentrifuge or accessories in any way.
Only use the rotors and accessories supplied with the minicentrifuge.
1.9 
In the following cases the protection provided in the minicentrifuge may be impaired.
The liability for the function of the minicentrifuge passes to the operator if:
› The minicentrifuge is not used in accordance with this user manual.
› The minicentrifuge is used outside the range of application described herein.
› The minicentrifuge is used with accessories or consumables (e.g., tubes) which are not
recommended by the manufacturer.
› The minicentrifuge is maintained or repaired by persons not authorized by the manufacturer.
› Unauthorized modifications have been made to the minicentrifuge.

8 · Minicentrifuge · Manual
2 
2.1 Minicentrifuge components
1
3
4
5
2
7 6
Fig. 1 Minicentrifuge
1Lid 5STOP button
2Power input connection 6Tube rotor
3Power switch 7PCR strip rotor
4Drive shaft

Minicentrifuge · Manual · 9
Product description English
2.2 
1Minicentrifuge
1Tube rotor for 8 × 1.5/2.0 ml tubes
1PCR strip rotor for 32 × 0.2 ml PCR tubes or 4 × 8 PCR tube strips
8Adapters for 0.5ml tubes
8Adapters for 0.2ml tubes
1Power adapter with 4 exchangeable plugs (EU, UK, US, AUS)
1User manual
2.3 Type plate
Starlab International GmbH
Neuer Höltigbaum 38
22143 Hamburg
www.starlabgroup.com
LABORATORY EQUIPMENT Made in CHN
Model:
Minicentrifuge
Speed:
Power:
Rating:
2
1
3
4
5
678
Fig. 2 Type plate at the bottom of the minicentrifuge
1Model number 5Disposal for electrical waste
2Rating 6Serial number
3Power 7Barcode area
4Speed 8CE and UKCA marking
2.4 
The minicentrifuge is supplied with two rotors, one for microcentrifuge tubes and one for PCR
tubes.
The tube rotor is designed to centrifuge up to eight individual 1.5/2.0ml microcentrifuge tubes.
It will also accept 0.5ml and 0.2ml tubes with the adapters supplied with the minicentrifuge.
The PCR strip rotor is designed to centrifuge up to four 0.2 ml 8-strip PCR tubes. It will also
accept up to 32 individual 0.2ml tubes.

10 · Minicentrifuge · Manual
3 
3.1 Positioning the minicentrifuge
Choose a place with a flat surface, where the minicentrifuge can remain during centrifugation.
Do not operate the minicentrifuge at altitudes above 2,000m or in the open air.
Avoid long-term exposure to high UV radiation levels as discoloration of the plastic material
might occur.
3.2 
› Select the appropriate plug for your country and connect it to the power adapter.
› Make sure that the power switch is in the off position. Then connect the power cable to the
input connection of the minicentrifuge.
› Connect the power adapter to the wall socket.

Minicentrifuge · Manual · 11
Installation/Operation English
4 Operation
4.1 Switching on the minicentrifuge
Switch on the power switch at the back of the minicentrifuge.
The lid will open automatically.
4.2 
To mount one of the two rotors, push it onto the drive shaft until there is an audible click.
Make sure that the rotor is properly attached to the drive shaft before inserting the tubes.
To remove a rotor, take off the rotor by pulling it up vertically.
click
Fig. 3 Attaching the rotor to the drive shaft
4.3 
To enable safe operation of the minicentrifuge, the rotor must be loaded symmetrically with
identical tubes. Always use the same type of tubes per run.
Each tube should be counterbalanced by another tube. Otherwise the minicentrifuge can be
damaged.
For example, if there is a tube in position 4, a corresponding tube has to be inserted in position 8.

12 · Minicentrifuge · Manual
Fig. 4 Symmetrical positions of the tube rotor
4.4 Starting the minicentrifuge
Once the minicentrifuge has started, it must not be moved. Do not knock against the minicentri-
fuge while it is in operation.
› To start the centrifugation of the samples, simply close the lid. The rotor will start spinning.
If the rotor can not spin properly (for example, if a tube is open and hits against the lid), then the
lid will open after a few seconds and the rotor will stop spinning.
If the power is turned off during operation, the lid will open automatically so you can still access
your samples.
4.5 Stopping the minicentrifuge
› To stop centrifugation, touch the STOP button. The lid will open automatically. Do not touch
the rotor or use other items to stop it.
› Wait until the rotor has completely stopped before fully opening the lid and removing the
tubes.

Minicentrifuge · Manual · 13
Operation/Maintenance English
5 Maintenance
Before using any cleaning or decontamination methods except those recommended, contact the
manufacturer to make sure that the proposed method will not damage the equipment.
For further information and detailed instructions for cleaning and disinfection, contact your local
distributor.
5.1 Cleaning
Regularly check and clean the housing of the minicentrifuge as well as the lid, the rotors and
rotor accessories.
WARNING
Electric shock as a result of penetration of liquid.
› Switch off the minicentrifuge and disconnect it from the power supply before starting to
clean.
› Do not allow any liquids to enter the inside of the housing.
› Do not use spray disinfection.
› Only reconnect the minicentrifuge to the power supply once it is completely dry.
NOTICE
Aggressive chemicals can damage the minicentrifuge and its accessories.
› Do not use any aggressive chemicals on the minicentrifuge and its accessories such as
strong or weak bases, strong acids, acetone, acetonitrile, dichloromethane, ethyl acetate,
halogenated hydrocarbons, phenol, toluene, DMSO 50% and methanol.
› If the minicentrifuge or the accessories becomes contaminated with aggressive chemicals,
clean immediately with a neutral cleaning agent.
› Do not use corrosive cleaning agents, aggressive solvents or abrasive polishes.

› Lint-free cloth.
› Mild, soap-based cleaning solution.
› Distilled water.
Cleaning the minicentrifuge
› Switch off the minicentrifuge and disconnect it from the power supply.
› Clean all surfaces of the minicentrifuge and its accessories with a mild, soap-based
cleaning solution, using a lint-free cloth.
› Wipe off the soap solution with distilled water.
› Dry all cleaned parts.

14 · Minicentrifuge · Manual
5.2 
WARNING
Electric shock as a result of penetration of liquid.
› Switch off the minicentrifuge and disconnect it from the power supply before starting to
disinfect.
› Do not allow any liquids to enter the inside of the housing.
› Do not use spray disinfection.
› Only reconnect the minicentrifuge to the power supply once it is completely dry.
Auxiliary equipment
› Lint-free cloth.
› Disinfectant.

› Switch off the minicentrifuge and disconnect it from the power supply.
› Disinfect the minicentrifuge.
› Select a disinfection method which complies with the legal requirements and regulations
applicable to your range of application.
› Wipe the surfaces with the lint-free cloth and disinfectant.
5.3 
If you are shipping the minicentrifuge to the authorised Technical Service for repairs or to your
local distributor for disposal, please note the following:
WARNING
Risk to health from contaminated minicentrifuge.
› Follow the instructions for the decontamination supplied by your local distributor.
› Decontaminate all the parts you want to dispatch.
› Enclose the fully-completed decontamination certificate for returned goods (incl. the serial
number of the minicentrifuge) with the dispatch.

Minicentrifuge · Manual · 15
Maintenance/Transport, storage and disposal English
6 
6.1 
Ambient temperature for transport and storage: -25–55°C (-13–131°F)
Relative humidity for transport and storage: ≤95%
Air pressure for transport and storage: 30–106kPa
6.2 
In the event of disposing of the product, please observe the applicable legal regulations. Infor-
mation on the disposal of electrical and electronic devices in the European Community: The
disposal of electrical devices is regulated within the European Community by national regula-
tions based on EU Directive 2012/19/EU pertaining to waste electrical and electronic equipment
(WEEE).
In accordance with this, any devices delivered after 13/08/2005 on a business-to-business
basis, which includes this product, may no longer be disposed of in household waste.
To document this, they have been marked with the following identication:
Because disposal regulations may differ from country to country within the EU, please contact
your local distributor for information.
7 Troubleshooting
If the proposed measures to remedy the fault repeatedly do not deliver the desired result,
contact your local distributor.
Problem Cause Solution
Lid can not be opened with
the STOP button.
No power connection. › Check the power connection.
› Switch on the minicentrifuge.
Minicentrifuge can not be
started.
The lid is open. › Close the lid.
Minicentrifuge shakes when
starting the process.
The rotor is not loaded
symmetrically.
› Stop the centrifuge and load
the rotor symmetrically.
› Close the lid to restart the
process.

16 · Minicentrifuge · Manual
8 
Maximum speed: 6,500rpm ± 1%
Maximum g-force: 2,500 x g
Noise level: 55dBA
Ambient temperature for operation: 2–40°C (35–104°F)
Relative humidity for operation: ≤80%
Power adapter operating voltage: 100 – 240 V~, 50 – 60Hz
Unit input: 24VDC 12W
Weight: < 1.2kg
Dimensions (W×D×H): 160 × 130 × 112mm
9 Tube compatibility
Rotor type Adapter Max. length Max. diameter Tube type example
Tube rotor yes – 0.5 ml 45 mm 8mm 0.5ml tubes
Tube rotor yes – 0.2 ml 19 mm 6mm 0.2ml PCR tubes
Tube rotor – 45 mm 11mm 1.5ml/2.0ml tubes with or
without screw cap, 0.5ml
skirted screw cap tubes
PCR rotor – 35 mm 6mm PCR strips and
0.2ml tubes
10 
Article no. Description
S8030-5000 Minicentrifuge
S8030-5010 Tube rotor for 8 × 1.5/2.0 ml tubes
S8030-5011 PCR strip rotor for 32 × 0.2 ml PCR tubes or 4 × 8 PCR tube strips
S8030-5012 Power adapter with 4 exchangeable plugs, 24 V, 1 A
for EU, UK, US and AUS
S8030-5013 Adapter for 0.5ml tubes, 8 pieces
S8030-5014 Adapter for 0.2ml tubes, 8 pieces

Minicentrifuge · · 17
Inhaltsverzeichnis Deutsch
User Manual ____________________________________________________________________5 – 16
 ________________________________________________________ 17 – 28
 ____________________________________________________________29 – 40
 _______________________________________________________________ 41 – 52
Zertikate _________________________________________________________________________3 – 4
1 Sicherheit ____________________________________________________________ 18
1.1 Über diese Bedienungsanleitung __________________________________________ 18
1.2 Bestimmungsgemäßer Gebrauch__________________________________________ 18
1.3 Elektrischer Strom _____________________________________________________ 18
1.4 Sicherheitsabstand_____________________________________________________ 18
1.5 Drehender Rotor _______________________________________________________ 18
1.6 Mikrozentrifugenröhrchen _______________________________________________ 18
1.7 Beladen des Rotors ____________________________________________________ 19
1.8 Handhabung __________________________________________________________ 19
1.9 Produkthaftung________________________________________________________ 19
2 Produktbeschreibung __________________________________________________ 20
2.1 Komponenten der Minizentrifuge __________________________________________ 20
2.2 Lieferumfang__________________________________________________________ 21
2.3 Typenschild___________________________________________________________ 21
2.4 Mitgelieferte Rotoren ___________________________________________________ 21
3 Installation ___________________________________________________________ 22
3.1 Positionieren der Minizentrifuge___________________________________________ 22
3.2 Anschließen des Netzadapters ___________________________________________ 22
4 Betrieb _______________________________________________________________ 23
4.1 Einschalten der Minizentrifuge ____________________________________________ 23
4.2 Entfernen und Einsetzen der Rotoren_______________________________________ 23
4.3 Beladen des Rotors ____________________________________________________ 23
4.4 Starten der Minizentrifuge _______________________________________________ 24
4.5 Stoppen der Minizentrifuge ______________________________________________ 24
5 Wartung______________________________________________________________ 25
5.1 Reinigung ____________________________________________________________ 25
5.2 Desinfektion __________________________________________________________ 26
5.3 Dekontamination vor dem Versand ________________________________________ 26
6 Transport, Lagerung und Entsorgung ______________________________________ 27
6.1 Transport und Lagerung _________________________________________________ 27
6.2 Entsorgung ___________________________________________________________ 27
7 Problembehebung _____________________________________________________ 27
8 Technische Daten ______________________________________________________ 28
9 Gefäßkompatibilität____________________________________________________ 28
10 Bestellinformationen ___________________________________________________ 28

18 · Minicentrifuge · 
1 Sicherheit
1.1 
Vor dem ersten Gebrauch der Minizentrifuge diese Bedienungsanleitung lesen.
Diese Bedienungsanleitung ist Bestandteil der Minizentrifuge und sollte gut erreichbar aufbe-
wahrt werden.
Wenn die Minizentrifuge an Dritte weitergegeben wird, muss diese Bedienungsanleitung mit
weitergegeben werden.
1.2 
Die Minizentrifuge ist für den Innengebrauch in Laboren und ähnliche Anwendungen vorgesehen,
bei denen relativ geringe Zentrifugalkräfte erforderlich sind, wie z.B. Mikroltration, Zelltren-
nung und schnelles Abzentrifugieren von Röhrchenwänden und -deckeln. Jeglicher andere
Gebrauch gilt als nicht bestimmungsgemäß.
1.3 
Die Minizentrifuge nicht benutzen, wenn diese beschädigt ist. Wenn die Minizentrifuge, der Netz-
adapter oder das Netzkabel beschädigt ist, besteht die Gefahr eines tödlichen Stromschlags. Die
Minizentrifuge in diesem Fall nicht benutzen.
Im Notfall die Minizentrifuge sofort ausschalten oder das Netzkabel an der Rückseite der Miniz-
entrifuge ziehen.
Zum Reinigen der Minizentrifuge oder wenn die Minizentrifuge über einen längeren Zeitraum
nicht benutzt wird, die Minizentrifuge von der Stromversorgung trennen. Die Minizentrifuge nicht
in Wasser oder andere Flüssigkeiten tauchen und das Netzkabel nicht mit Wasser oder anderen
Flüssigkeiten in Kontakt kommen lassen.
1.4 
Der Sicherheitsabstand ist der Bereich im die Minizentrifuge herum (30cm). Nicht länger als für
den Betrieb der Minizentrifuge nötig innerhalb des Sicherheitsabstands aufhalten. Keine poten-
ziell gefährlichen Materialien in der Nähe der Minizentrifuge verwenden oder lagern.
1.5 
Den sich drehenden Rotor nicht berühren. Den Deckel erst dann vollständig öffnen und die
Gefäße entnehmen, wenn der Rotor komplett stillsteht.
1.6 
Nur solche Mikrozentrifugenröhrchen aus Kunststoff verwenden, die für Zentrifugalkräfte von
mindestens 2.500×g ausgelegt sind. Keine beschädigten oder verformten Gefäße verwenden.
Das Gewicht der einzelnen Gefäße darf 3,0g nicht überschreiten.

Minicentrifuge ·  · 19
Sicherheit Deutsch
1.7 
Den Rotor symmetrisch beladen, um Unwucht zu vermeiden. Die Minizentrifuge niemals mit nur
einem Gefäß oder einem PCR-Streifen beladen betreiben. Den Rotor stets mit einer geraden
Anzahl Gefäße oder PCR-Streifen beladen.
Die Gefäße vor dem Einsetzen in den Rotor sorgfältig befüllen und mit den Gefäßdeckeln ver-
schließen. Keine brennbaren, explosiven oder ätzenden Materialien zentrifugieren.
1.8 
Das Gehäuse nicht öffnen und keine Veränderungen an der Minizentrifuge oder am Zubehör
vornehmen.
Nur die mit der Minizentrifuge mitgelieferten Rotoren und das mitgelieferte Zubehör verwenden.
1.9 
In folgenden Fällen können die Sicherheitsvorkehrungen der Minizentrifuge beeinträchtigt
werden. Die Haftung für die Funktion der Minizentrifuge geht auf den Nutzer über, wenn:
› die Minizentrifuge nicht gemäß dieser Bedienungsanleitung verwendet wird.
› die Minizentrifuge außerhalb des hier beschriebenen Anwendungsbereichs verwendet wird.
› die Minizentrifuge mit Zubehör oder Verbrauchsartikeln (z.B. Gefäßen) betrieben wird, die
nicht vom Hersteller empfohlen werden.
› die Minizentrifuge von nicht durch den Hersteller autorisierten Personen gewartet oder
repariert wird.
› an der Minizentrifuge nicht autorisierte Änderungen vorgenommen wurden.

20 · Minicentrifuge · 
2 
2.1 
1
3
4
5
2
7 6
Fig. 1 Minizentrifuge
1Deckel 5Stopptaste
2Netzeingangsanschluss 6Gefäßrotor
3Netzschalter 7PCR-Streifen-Rotor
4Antriebswelle
