Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 19, 2019 3:38 PM
Product Diagram (VID2VGATV3)
Front and Side Prole
Rear and Side Prole
Component Function
1Video Input Selection Switch • Select the Source Device Video Signal
2VGA Output Port • Connect a VGA Video Display Device
3Resolution Selection Button • Select the Output Resolution
4Power Port • Connect a Power Source
5Composite Video Input Port • Connect a Composite Video Source Device
6S-Video Input Port • Connect an S-Video Source Device
Composite and S-Video to VGA Video Converter
Requirements
For the latest requirements, please visit www.startech.com/VID2VGATV3.
• Composite Video or S-Video Source Device x 1
• Composite Video or S-Video Cable x 1
• VGA Video Display Device x 1
• VGA Cable x 1
• USB Power Source x 1
Installation and Operation
1. Ensure all of your Devices are powered o.
2. Determine if you are using a Composite or S-Video Source Device. Toggle the
Video Input Selection Switch to match your Source Device video signal.
3. Connect a Composite Video Cable to the Composite Video Input Port.
Or
Connect an S-Video Cable to the S-Video Input Port.
4. Connect the other end of the Composite Video Cable to the Composite Video
Source Device.
Or
Connect the other end of the S-Video Cable to the S-Video Source Device.
5. Connect a VGA Cable to the VGA Output Port on the Video Converter.
6. Connect the other end of the VGA Cable to the VGA Video Source Device.
7. Connect the USB-A to USB Mini Cable to an available USB Power Source and to
the Power Port.
8. Select the output resolution by pressing the Resolution Selection Button until the
desired resolution is met. Each time you press the Resolution Selection Button the
new resolution settings will appear on the On Screen Display (OSD) in the upper
right-hand corner of the screen.
5
6
4
3
2
1
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void
the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
• If product has an exposed circuit board, do not touch the product under power.
