Stenner Pumps ECON LD Manual

ECON LD PUMP SERIES
INSTALLATION AND MAINTENANCE MANUAL
PERISTALTIC METERING PUMPS SINCE 1957
TO BE INSTALLED AND MAINTAINED BY PROPERLY TRAINED
PROFESSIONAL INSTALLER ONLY. READ MANUAL & LABELS
FOR ALL SAFETY INFORMATION & INSTRUCTIONS.
WARNING

2www.stenner.comEcon LD
Warranty and Service Policy ................................................................. 3
Safety Information ....................................... 4-6, 9-12, 14-18, 20-22, 24
Materials of Construction .................................................................... 7
Accessory Checklist............................................................................. 8
Flow Rate Outputs .......................................................................... 9-10
Installation................................................................................... 11-17
Troubleshooting ............................................................................ 18-20
Tube Replacement ........................................................................ 21-23
Cleaning the Point of Injection...................................................... 24-26
Exploded View and Parts ............................................................... 27-28
Mounting Template ............................................................................ 29
IMELD 031017
TABLE OF CONTENTS

LIMITED WARRANTY
Stenner Pump Company will for a period of one (1) year from the date of purchase (proof
of purchase required) repair or replace – at our option – all defective parts. Stenner is not
responsible for any removal or installation costs. Pump tube assemblies and rubber
components are considered perishable and are not covered in this warranty. Pump tube
will be replaced each time a pump is in for service, unless otherwise specified. The cost of
the pump tube replacement will be the responsibility of the customer. Stenner will incur
shipping costs for warranty products shipped from our factory in Jacksonville, Florida. Any
tampering with major components, chemical damage, faulty wiring, weather conditions,
water damage, power surges, or products not used with reasonable care and maintained in
accordance with the instructions will void the warranty. Stenner limits its liability solely to
the cost of the original product. We make no other warranty expressed or implied.
RETURNS
Stenner offers a 30-day return policy on factory direct purchases. Except as otherwise
provided, no merchandise will be accepted for return after 30 days from purchase. To
return merchandise at any time, call Stenner at 800.683.2378 for a Return Merchandise
Authorization (RMA) number. A 15% re-stocking fee will be applied. Include a copy of your
invoice or packing slip with your return.
DAMAGED OR LOST SHIPMENTS
Check your order immediately upon arrival. All damage must be noted on the delivery
receipt. Call Stenner Customer Service at 800.683.2378 for all shortages and damages
within seven (7) days of receipt.
SERVICE & REPAIRS
Before returning a pump for warranty or repair, remove chemical from pump tube by
running water through the tube, and then run the pump dry. Following expiration of the
warranty period, Stenner Pump Company will clean and overhaul any Stenner metering
pump for a minimum labor charge plus necessary replacement parts and shipping. All
metering pumps received for overhaul will be restored to their original condition. The
customer will be charged for missing parts unless specific instructions are given. To return
merchandise for repair, call Stenner at 800.683.2378 or 904.641.1666 for a Return
Merchandise Authorization (RMA) number.
DISCLAIMER
The information contained in this manual is not intended for specific application purposes.
Stenner Pump Company reserves the right to make changes to prices, products, and
specifications at any time without prior notice.
TRADEMARKS
Santoprene®is a registered trademark of Exxon Mobil Corporation.
AquaShield™is a trademark of Houghton International.
3
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
WARRANTY AND CUSTOMER SERVICE

4www.stenner.comEcon LD
IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment,
basic safety precautions should always be followed,
including the following:
1.READ AND FOLLOW
ALL INSTRUCTIONS.
2.WARNING - To reduce the risk of
injury, do not permit children to use
this product unless they are closely
supervised at all times.
3.WARNING - Risk of Electric Shock.
Connect only to a branch circuit
protected by a ground-fault circuit
interrupter (GFCI). Contact a qualified
electrician if you cannot verify that
the receptacle is protected by a GFCI.
4.WARNING - To reduce the risk of
electric shock, replace damaged
cord immediately.
5.SAVE THESE INSTRUCTIONS.

5
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
SAFETY INFORMATION
Warns about hazards that CAN cause death, serious personal
injury, or property damage if ignored.
ELECTRIC SHOCK HAZARD
ELECTRIC SHOCK HAZARD
Pump supplied with grounding power cord and attached plug. To reduce risk of
electrical shock, connect only to a properly grounded, grounding type receptacle.
Install only on a circuit protected by a Ground-Fault Circuit-Interrupter (GFCI). For
locations other than US and Canada, pump must be supplied through a residual
current device (RCD) with a rated residual operating current < 30 mA.
DANGER DE CHOC ÉLECTRIQUE
La pompe est dotée d’un cordon d’alimentation avec mise à la terre muni d'une fiche.
Pour réduire le risque de choc électrique, branchez uniquement sur une prise
correctement mise à la terre. Installez uniquement sur un circuit protégé par un
disjoncteur différentiel. En dehors des États-Unis et du Canada, la pompe doit être
alimentée par un dispositif à courant différentiel résiduel (RCD) fonctionnant à <30 mA.
DO NOT alter the power cord or plug end.
DO NOT use receptacle adapters.
DO NOT use pump with a damaged or altered power cord or plug end. Contact the
factory or an authorized service facility for repair.
HAZARDOUS VOLTAGE
DISCONNECT power cord before removing motor cover for service. Electrical service
by trained personnel only.
EXPLOSION HAZARD
This pump is not explosion proof. DO NOT install or operate in an explosive environment.
RISK OF EXPOSURE
Potential for burns, fire, explosion, personal injury, or property damage. To reduce risk
of exposure, the use of proper personal protective equipment is mandatory.
RISK OF FIRE HAZARD
DO NOT install or operate on any flammable surface.
RISK OF CHEMICAL OVERDOSE
To reduce risk, follow proper installation methods and recommendations. Check your
local codes for additional guidelines.
To reduce the risk of injury, do not permit children to use this
product. This appliance is not to be used by persons with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction.

6www.stenner.comEcon LD
SAFETY INFORMATION continued
Warns about hazards that WILL or CAN cause minor personal
injury or property damage if ignored.
PLUMBING
Metering pump installation must always adhere to your local plumbing codes and
requirements. Be sure installation does not constitute a cross connection. Check
local plumbing codes for guidelines.
NOTICE: Indicates special instructions or general mandatory action.
This metering pump is portable and designed to be removable from the plumbing
system without damage to the connections.
Before installing or servicing the pump, read the pump manual for all safety
information and complete instructions. The pump is designed for installation and
service by properly trained personnel.
Installation and product must adhere to all regulatory and compliance codes
applicable to the area.
This is the safety alert symbol. When displayed in this manual or on the
equipment, look for one of the following signal words alerting you to the
potential for personal injury or property damage.
Acceptable for indoor and outdoor use.
Acceptable pour une utilisation aussi bien à l’intérieur qu’à l’extérieur.
Electrical installation should adhere to all national and local codes. Consult a licensed
professional for assistance with proper electrical installation.
Removing power from pool/spa recirculation pump must also remove power from pump.
The use of an auxiliary safety device (not supplied), such as a flow switch or sensor,
is recommended to prevent feed pump operation in the event of a recirculation
pump failure or if flow is not sensed.
Point of injection should be beyond all pumps, filters, and heaters.
Maximum liquid temperature = 40°C.

7
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
MATERIALS OF CONSTRUCTION
All Housings
Polycarbonate
Pump Tube
Santoprene®*, FDA approved
Pump Head Rollers
Polyethylene
Check Valve Duckbill
Santoprene®*, FDA approved
Suction/Discharge Tubing & Ferrules
Polyethylene, FDA approved
Suction Line Strainer
PVC, NSF listed with ceramic weight
Tube & Injection Fittings
PVC or Polypropylene, NSF listed
Connecting Nuts
PVC, NSF listed
All Fasteners
Stainless Steel
*Santoprene®is a registered trademark of Exxon Mobil Corporation.

8www.stenner.comEcon LD
ACCESSORY CHECKLIST
Contents
3 Connecting Nuts 1/4"
3 Ferrules 1/4" or 6 mm Europe
1 Injection Check Valve
1 Weighted Suction Line Strainer 1/4"
1 20' Roll of Suction/Discharge Tubing
1/4" White or UV Black OR 6 mm White Europe
1 Additional Pump Tube
1 Installation Manual

9
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
Item Number Pump Roller Approximate Ounces Pressure Milliliters Pressure
Prefix Tube Assembly Turndown Ratio per Hour psi per Hour bar
E10LHM M White 50:1 0.04–2.4 80 1.3–70.0 5.5
E10LHF F White 50:1 0.11–8.1 80 3.2–240.0 5.5
Approximate Outputs @ 50/60Hz
FLOW RATE OUTPUTS
The output on the variable speed pump can be adjusted
via the potentiometer on the side of the pump.
Turning the potentiometer fully counterclockwise turns
the pump off.
Turning the potentiometer clockwise gradually increases
the speed to 100% at the full clockwise position.
Graduations are approximate.
DO NOT set
potentiometer in
gray area of scale
NOTICE: The information within this chart is solely intended for use as a guide.The output data is an approximation based on
pumping water under a controlled testing environment. Many variables can affect the output of the pump. Stenner Pump
Company recommends that all metering pumps undergo field calibration by means of analytical testing to confirm their outputs.
NOTE: Injection check valve included with pumps rated 80 psi (5.5 bar) maximum.

INSTALLATION
ADDITIONAL SAFETY INSTRUCTIONS
NOTICE: Indicates special instructions or general mandatory action.
Read all safety hazards before installing or servicing the pump. The pump is
designed for installation and service by properly trained personnel.
Use all required personal protective equipment when working on or near a
metering pump.
Install the pump so that it is in compliance with all national and local plumbing
and electrical codes.
Use the proper product to treat potable water systems, use only additives listed or
approved for use.
Inspect tube frequently for leakage, deterioration, or wear. Schedule a regular pump
tube maintenance change to prevent damage to pump and/or spillage.
Pump is not recommended for installation in areas where leakage can cause
personal injury or property damage.
10 www.stenner.comEcon LD

11
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
INSTALLATION continued
MOUNT PUMP
Select a dry location (to avoid water intrusion and pump damage) above the
solution tank.
To prevent pump damage in the event of a pump tube leak, never mount the
pump vertically with the pump head up.
DO NOT mount pump directly over an open solution tank. Keep tank covered.
Avoid flooded suction or pump mounted lower than the solution container. Draw
solution from the top of the tank. Pump can run dry without damage. If pump is
installed with a flooded suction, a shut-off valve or other device must be provided
to stop flow to pump during service.
To prevent motor damage, verify with a volt meter that the receptacle voltage
corresponds with the pump voltage.
Plug cord into receptacle and turn the pump on.

12 www.stenner.comEcon LD
INSTALLATION continued
ADDITIONAL INSTRUCTIONS FOR CE PUMPS
ADDITIONAL INSTALLATION INSTRUCTIONS
1. All Class II Pumps located in Zone 1 of swimming pool areas require locating where flooding cannot occur.
2. This pump is intended to be installed as “fixed” as opposed to portable.
3. The pump must be installed in a vertical position as shown in the installation diagram.
4. After installation, the power supply plug must be accessible during use.
5. This unit must be scrapped if the supply cord is damaged.
6. Observe and comply with all National Wiring Standards.
ZUSTAZLICHE INSTALLIERUNGSANWEISUNGUN
1. Pumpen die sich in Zone 1 vom Schwimmbecken befinden sollen sind so einzurichten daß
Ueberschwemmungen nicht vorkommen werde.
2. Diese Pumpe ist als fest montierte Ausrustung bedacht und soll nicht umstellbar gebraucht werden.
3. Die Pumpe muss vertikal installiert werden, siehe Zeichnung.
4. Die Stromversorgung muss nach der Installierung noch zuganglich sein.
5. Bei beschadigter Verkabelung ist dieses Gerat nicht mehr zu gebrauchen.
6. Staatliche Vernetzungsvorchriften mussen eingehalten werden.
INSTRUCTIONS SUPPLÉMENTAIRES D’INSTALLTION
1. Toutes les pompes installées dans la Zone 1 du périmètre de la piscine doivent être situées de manière à
ne pas pouvoir être inondées.
2. Cette pompe est prévue pour installation fixe et non pas portative.
3. La pompe doit être installée en position verticale selon le dessin.
4. Après l’installation, la prise électrique doit rester accessible pendant l’utilisation.
5. Cette unité doit être mise au rebut si le cordon électrique est endommagé.
6. Observez et adhérez à toutes les Normes Nationales pour Installations Electriques.
INSTRUCCIONES ADICIONALES PARA INSTALACION
1. Todas las bombas Clase II situadas en la Zona 1 de las áreas de la piscina requieren colocarse donde no
puedan ser inundadas.
2. Esta bomba es para ser instalada “fija” en vez de portátil.
3. La bomba debe ser instalada en posición vertical como se muestra en el diagrama de instalación.
4. Depués de la instalación el enchufe suministrador de energía debe estar accesible durante el uso.
5. Se deberá deshechar la unidad si el cordón de abastecimiento se deteriora.
6. Observe y cumpla con todas las Reglas Nacionales para Instalaciones Eléctricas.
ISTRUZIONI SUPPLEMENTARI PER L’ INSTALLAZIONE
1. Tutte le pompe Classe II localizzate nella Zona 1 della superficie circostante la piscina devono essere
collocate dove gli allagamenti no possono accadere.
2. Questa pompa, é inteso, deve essere installata come ‘fissa’ e non come portatile.
3. La pompa deve essere installata in posizione verticale come mostrato sul disegno.
4. Dopo l’installazione, la spina deve essere accessibile durante l’uso.
5. Questa unitá deve essere gettata via se il filo elettrico é danneggiato.
6. Osservare e aderire a tutte le Norme Nazionali Sugli Impianti Elettrici.
Declaration of Conformity
EN60335-1 EN55014-1 EN61000-3-3
EN60335-2-41 EN61000-3-2 EN62233
Standards Used for Conformity Testing and Certification:

13
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
INSTALLATION DIAGRAM
Duckbill
Suction
Discharge
Disassembled
view of nut
and ferrule
Suction Line
Solution Tank
Shut-Off Valve
Discharge Line
Grounded Power Outlet:
(Grounded-Fault Circuit-
Interrupter GFCI)
Direction of waterflow
Disassembled View
of Injection
Check Valve
26-80 psi
Flow direction
of solution
Injection
Check Valve

14 www.stenner.comEcon LD
INSTALLATION continued
Suction Line
INSTALL SUCTION LINE TO PUMP HEAD
1. Uncoil the suction/discharge line. Use outside of solution tank as a guide to cut
proper length of suction line ensuring it will be 2-3" above the bottom of solution tank.
Allow sufficient slack to avoid kinks and stress cracks. Always make a clean
square cut to assure that the suction line is burr free. Normal maintenance
requires trimming.
Suction lines that extend to the bottom of the tank can result in debris pickup
leading to clogged injectors and possible tube failure.
2. Make connections by sliding the line(s) through connecting nut and ferrule and finger
tighten to the corresponding tube fittings.
3. Finger tighten nut to the threaded tube fitting while holding the tube fitting.
Over tightening the ferrule and nut with a wrench may result in damaged fittings,
crushed ferrules, and air pick up.
DO NOT use thread sealant tape on pump tube connections or tools to
tighten connections.
DO NOT use pliers.
Note: Beveled ends of ferrules
face pump. Tubing should
bottom into all fittings.
Finger tighten
nut
Discharge Line
Ferrules
DO NOT use Teflon tape
on pump tube threads.

15
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
INSTALLATION continued
INSTALL SUCTION WEIGHT TO SUCTION LINE
1. Drill a hole into the bung cap or solution tank lid. Slide the tubing through and
secure the weighted strainer to the line.
2. To attach the strainer, push approximately 3.5" of suction line through the cap on the
strainer body. Pull tubing to make sure it is secure.
3. Suspend slightly above tank bottom to reduce the chance of sediment pickup.
DO NOT mix additives in the solution container. Follow recommended mixing
procedures according to the manufacturer.
DO NOT operate pump unless additive is completely in solution. Turn pump off
when replenishing solution.
3"
Suction Line
3.5"
(9 cm)
Weighted
Suction Line
Strainer

16 www.stenner.comEcon LD
INSTALLATION continued
INSTALL DISCHARGE LINE TO PUMP HEAD AND INJECTION POINT
1. Make a secure finger tight connection on the discharge fitting of the pump head as
instructed in Install Suction Line instructions.
DO NOT use thread sealant tape on pump tube connections or tools to
tighten connections.
HAZARDOUS PRESSURE: Shut off water or circulation system
and bleed off any system pressure.
Locate a point of injection beyond all pumps and filters or as determined by
the application.
2. A 1/4" or 1/2" Female NPT (FNPT) connection is required for installing the injection
fitting. If there is no FNPT fitting available, provide one by either tapping the pipe or
installing FNPT pipe tee fitting.
3. Wrap the Male NPT (MNPT) end of injection fitting with 2 or 3 turns of threading tape.
If necessary, trim the injection fitting quill as required to inject product directly into
flow of water.
Trim injection fitting end
DO NOT use Teflon
tape on pump
tube threads.
DO NOT use pliers. Injection
Check Valve
Shut-Off Valve
1/4" or
1/2" FNPT
Reduction
Bushing
Typical Point of Injection

17
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
INSTALLATION continued
4. Hand tighten the injection fitting into the FNPT fitting.
a. Install connecting nut and ferrule to the pump discharge tubing. Insert discharge
tubing into injection fitting until it reaches base of fitting.
b. Finger tighten connecting nut to fitting.
5. Turn pump on and re-pressurize system. Observe flow as actuated by system and
check all connections for leaks.
6. After suitable amount of dosing time, perform tests for desired readings (e.g., pH or
ppm). If necessary, fine tune dosing levels by rotating potentiometer or by adjusting
solution strength.
The injection point and fitting require periodic maintenance to clean any
deposits or buildup. To allow quick access to the point of injection, Stenner
recommends the installation of shut-off valves.

18 www.stenner.comEcon LD
TROUBLESHOOTING – DRIVE ASSEMBLY
HAZARDOUS VOLTAGE
DISCONNECT power before service. Electrical service should be performed by trained
personnel only.
PROBLEM POSSIBLE CAUSE SOLUTION
Noise is excessively loud Lubrication is insufficient Grease gears and gear posts
Gears or gear posts are worn Inspect/replace gears and gear posts
Drive assembly does not work Electrical supply is faulty Check supply voltage circuit
DC motor is damaged Replace drive assembly
Power cord is damaged Replace drive assembly
Drive assembly runs; Worn or damaged gears Replace gears as needed
output shaft does not
Phenolic gear is stripping Gear posts worn Replace gear posts and phenolic gear
Rusted helical gear Buff off helical gear and replace phenolic gear
Insufficient lubrication Replace phenolic gear and lubricate
with AquaShield™
Output shaft does not turn Worn or damaged roller assembly Replace roller assembly
Worn or damaged gears Replace gears as needed
Damaged circuit board Replace drive assembly

19
USA and Canada 800.683.2378, International 904.641.1666 Econ LD
TROUBLESHOOTING – PUMP HEAD
PROBLEM POSSIBLE CAUSE SOLUTION
Components are cracking Incompatibility with fluid Check compatibility
Visible fluid in pump head Pump tube rupture/leak Replace pump tube and ferrules
No pump output; Depleted solution tank Replenish solution
pump head rotates Pump suction line weight is above solution Maintain suction line 2-3" off bottom of tank
Suction line leak Inspect or replace suction line
Ferrules installed incorrectly or damaged Replace compression ferrules
Injection point is clogged Inspect and clean injection point
Clogged suction/discharge tubing Clean and/or replace as necessary
Life of pump tube is exhausted Replace pump tube
Suction tubing is flush with the nose Pull suction tubing approximately 1" from
of the weighted strainer bottom of strainer; cut bottom of suction
tubing at an angle
Pump cover not secured properly Ensure that pump cover is properly latched
Low pump output; Pump tube is worn Replace pump tube
pump head rotates Rollers worn or broken Install new roller assembly
Injection point is restricted Inspect and clean injection point
Incorrect tube size Replace tube with correct size
High system back pressure Confirm system pressure does not exceed
80 psi (5.5 bar)
Pump cover not secured properly Ensure that pump cover is properly latched
Potentiometer set incorrectly Adjust potentiometer
No pump output; Roller assembly is stripped Replace roller assembly
pump head doesn’t rotate Faulty board Replace drive assembly
Drive assembly problem Refer to Troubleshooting – Drive Assembly
Potentiometer set incorrectly Adjust potentiometer
Pump output is high Incorrect tube size Replace tube with correct size
Roller assembly is broken Replace roller assembly
Potentiometer set incorrectly Adjust potentiometer

20 www.stenner.comEcon LD
TROUBLESHOOTING – PUMP TUBE
NOTICE: A leaking pump tube damages the metering pump. Inspect pump frequently
for leakage and wear. Refer to Tube Replacement section for additional safety
precautions and instructions.
PROBLEM POSSIBLE CAUSE SOLUTION
Tube leaking Pump tube ruptured Replace pump tube and ferrules
Calcium or mineral deposits Clean injection fitting, replace pump tube
and ferrules
Excessive back pressure Ensure system pressure does not exceed
80 psi (5.5 bar)
Tube is twisted Replace pump tube and ferrules
Tube not centered Replace pump tube and ferrules
Tube life is shortened Incompatibility with fluid Check compatibility
Mineral deposits at injection point Remove deposits, replace pump tube
and ferrules
Sediment blockage at injection fitting Maintain suction line 2-3" above bottom of tank
Seized rollers caused abrasion on tube Clean roller assembly or replace
Exposure to heat or sun Do not store tubes in high temperatures or
in direct sunlight
Tube connection is leaking Missing ferrule on suction or discharge line Replace ferrule
Crushed ferrule Replace ferrule
Ferrule in wrong orientation Reverse orientation of ferrule
