Steris Basil 4700 User manual

MAINTENANCE MANUAL
Basil®4700 Cage and Rack Washer
(2008/10/15) P764333-097

OPERATOR MANUAL ......................................................................... P920509-645
MAINTENANCE INSTRUCTIONS ........................................................ P764333-098
ILLUSTRATED PARTS BREAKDOWN ................................................. P764333-099
REFERENCE DRAWINGS
Cycle Description Chart ............................................................................................................ 920509-969
Equipment Drawing ................................................................................................................... 920509-921
Process and Instrument Diagram ............................................................................................. 920510-019
Electrical Drawing ...................................................................................................................... 920509-795
iii
764333-097
TABLE OF CONTENTS
Section Title Document Number

OPERATOR MANUAL
Basil®4700 Cage and Rack Washer
(2008/08/14) P920509-645

i
Introduction Operator Manual 920509-645
A WORD FROM STERIS CORPORATION
This manual contains important information on the proper use of this
equipment. Refer to SECTION 6, ROUTINE MAINTENANCE,for instruc-
tions in routine care of this washer. All personnel and department
heads are urged to carefully review and become familiar with the
Safety Precautions and instructions contained herein. These
instructions are important to protect the health and safety of person-
nel operating this Basil®4700 Cage and Rack Washer and should
be retained in a conveniently accessible area for quick reference.
This equipment is specifically designed only for the uses outlined in
this manual.
Complete instructions for uncrating and connecting utilities, as well
as equipment drawings, have been provided. If they are missing,
contact STERIS for replacement copies, providing the serial and
model numbers of the unit.
Advisory IMPORTANT: A listing of the Safety Precautions to be observed
when operating this washer can be found in SECTION 1. Do not oper-
ate the equipment until you have become familiar with this informa-
tion.
Any alteration of this equipment not authorized or performed by
STERIS will void the warranty. Alteration of equipment which could
adversely affect its operation and efficacy may violate national, state
and local regulations and could jeopardize your insurance coverage.
Indications For Use The Basil 4700 Cage and Rack Washer is specifically designed for
thorough, efficient cleaning of cages, bottles, debris pans and mis-
cellaneous items used in the care of laboratory animals.
This washer is specifically designed to only process goods as out-
lined in this manual. If there is any doubt about a specific material or
product, contact product manufacturer for recommended washing
technique.
©2008, STERIS Corporation. All rights reserved. Printed in Canada.

ii
920509-645 Operator Manual Introduction
Service Information A thorough preventive maintenance program is essential to help
ensure safe and proper equipment operation. Customers are
encouraged to contact STERIS concerning extended service mainte-
nance agreements to give the equipment planned maintenance.
A global network of skilled service specialists can provide periodic
inspections and adjustments to help ensure low-cost peak perfor-
mance. STERIS can provide information regarding the annual main-
tenance agreements.
STERIS carries a complete line of accessories for use in this equip-
ment. Please contact STERIS for details.
Certification This Basil 4700 Cage and Rack Washer meets the applicable
requirements of the following standards:
•Underwriters Laboratories, Inc. (UL)
UL 61010-1, Second Edition.
•Canadian Standards Association (CSA)
CAN/CSA-C22.2 No. 61010-1, Second Edition.
Manufacturer:
Corporation STERIS
Canada
Quebec, Qc, CANADA
ISO 13485
ISO 9001
Certified
Facility
The base language of this document is
ENGLISH. Any translations must be made
from the base language document.
STERIS Limited
STERIS House
Jays Close
Viables
Basingstoke
Hampshire
RG22 4AX
United Kingdom
Sales and Service:
STERIS Corporation
5960 Heisley Road
Mentor, Ohio 44060
440-354-2600 • 800-444-9009
www.steris.com

iii
920509-645 Operator Manual Table of Contents
A WORD FROM STERIS CORPORATION ................................................................ I
Advisory ........................................................................................................................................................... i
Indications For Use........................................................................................................................................... i
Service Information ..........................................................................................................................................ii
Certification ......................................................................................................................................................ii
1 SAFETY PRECAUTIONS .....................................................................................1-1
2 INSTALLATION VERIFICATION ..........................................................................2-1
2.1 Technical Specifications ........................................................................................................................ 2-1
2.1.1 Voltage, Amperage and Power Consumption ................................................................................ 2-1
2.1.2 Permissible Environmental Conditions ........................................................................................... 2-2
2.1.3 Noise Level ..................................................................................................................................... 2-2
2.1.4 Seismic Anchorage System ........................................................................................................... 2-2
2.2 Installation Checklist .............................................................................................................................. 2-2
2.3 Chemical Additives Specifications ........................................................................................................ 2-4
3 COMPONENT IDENTIFICATION ..........................................................................3-1
3.1 Component Identification ...................................................................................................................... 3-1
3.2 Operator Terminal .................................................................................................................................. 3-2
3.2.1 Login Passwords ............................................................................................................................ 3-2
3.2.2 Automatic and Manual Mode ......................................................................................................... 3-2
3.2.3 Supervisor Mode ............................................................................................................................ 3-2
3.2.4 Service Mode ................................................................................................................................. 3-2
3.2.5 Operator Terminal Touch Screen ................................................................................................... 3-3
3.2.6 Audible Signal ................................................................................................................................ 3-4
3.3 LOCK/UNLOCK/INIT Key Switch ........................................................................................................... 3-5
3.4 Printer .................................................................................................................................................... 3-5
3.5 Typical Printouts .................................................................................................................................... 3-6
3.6 Oscillating Jet System ........................................................................................................................... 3-7
3.7 Safety System ........................................................................................................................................ 3-8
3.8 Heat Exchanger ..................................................................................................................................... 3-9
3.9 Automatic Detergent Injection System ................................................................................................ 3-10
3.10 Reusable-Throwaway Detergent System .......................................................................................... 3-10
3.11 Non-Recirculated Final Rinse ............................................................................................................ 3-11
3.12 Feeder Bottle Washing System ......................................................................................................... 3-11
3.13 Automatic Water Flush System for Two Racks .................................................................................. 3-11
3.14 Drain Discharge Cooldown with Side Tank and Temperature Guarantee ........................................ 3-12
3.15 Drain Discharge Cooldown System with Cold Water Injection Only ................................................. 3-12
3.16 Exhaust Fan ....................................................................................................................................... 3-13
TABLE OF CONTENTS
Section
Number Description Page

iv
Table of Contents Operator Manual 920509-645
4 OPERATING INSTRUCTIONS .............................................................................4-1
4.1 Before Operating Washer ...................................................................................................................... 4-1
4.2 How to Load Washer ............................................................................................................................. 4-2
4.3 Cycle Operation ..................................................................................................................................... 4-4
4.4 Review and Print Specific Cycle Program ............................................................................................. 4-8
4.5 Extend Cycle Phase Time ...................................................................................................................... 4-8
4.6 Bypass Phase ........................................................................................................................................ 4-8
4.7 Shutdown Procedure ........................................................................................................................... 4-10
4.8 Manual Control Mode .......................................................................................................................... 4-10
4.8.1 FILL Function ................................................................................................................................ 4-10
4.8.2 DRAIN Function ............................................................................................................................ 4-11
4.8.3 Draining Sump ............................................................................................................................. 4-11
4.8.4 Draining Alkaline Tank ................................................................................................................. 4-11
4.8.5 Draining Acid Tank ....................................................................................................................... 4-11
4.8.6 Draining Cooldown Tank .............................................................................................................. 4-12
4.8.7 PUMP & DRV Function ................................................................................................................. 4-12
4.8.8 DRIVE Function ............................................................................................................................ 4-12
4.9 Responding to a Fault ......................................................................................................................... 4-14
4.10 Pause a Cycle .................................................................................................................................... 4-15
4.11 Abort a Cycle ..................................................................................................................................... 4-15
4.12 Shutdown ........................................................................................................................................... 4-16
4.13 Power Failure ..................................................................................................................................... 4-16
5 CYCLE AND CONTROL VALUE PROGRAMMING ................................................5-1
5.1 General .................................................................................................................................................. 5-1
5.2 Supervisor Mode ................................................................................................................................... 5-3
5.2.1 Supervisor Mode Menus ................................................................................................................ 5-3
5.2.2 Accessing Supervisor Mode .......................................................................................................... 5-3
5.3 Cycles Menu .......................................................................................................................................... 5-4
6 ROUTINE MAINTENANCE ...................................................................................6-1
6.1 Preventive Maintenance Schedule ........................................................................................................ 6-2
6.2 Daily Cleaning Procedures .................................................................................................................... 6-5
6.3 Weekly Cleaning Procedures ................................................................................................................ 6-6
6.3.1 Clean Washer Exterior .................................................................................................................... 6-6
6.3.2 Clean Washer Interior ..................................................................................................................... 6-6
6.3.3 Clean Spray Jets and Headers ...................................................................................................... 6-7
6.3.4 Inspect Self-Cleaning Screen ........................................................................................................ 6-8
TABLE OF CONTENTS (Cont’d)
Section
Number Description Page

v
920509-645 Operator Manual Table of Contents
6 ROUTINE MAINTENANCE (Cont’d)
6.4 Monthly Cleaning Procedures: Remove Hard Water Deposits from Chamber and Accessories ......... 6-9
6.5 Routine Maintenance ........................................................................................................................... 6-10
6.5.1 Grease Exhaust Fan Bearings ..................................................................................................... 6-10
6.5.2 Clean Side Tanks ......................................................................................................................... 6-11
6.5.3 Clean Drain Discharge Temperature Control Probe .................................................................... 6-12
6.5.4 Replace Detergent Squeeze Tube ............................................................................................... 6-13
6.5.5 Replacing Detergent Container ................................................................................................... 6-14
6.6 Printer Paper Roll Replacement .......................................................................................................... 6-15
6.7 Changing Printer Ribbon Cartridge ..................................................................................................... 6-17
7 TROUBLESHOOTING ..........................................................................................7-1
8 REPLACEMENT PARTS AND PRODUCTS ...........................................................8-1
TABLE OF CONTENTS (Cont’d)
Section
Number Description Page

vi
920509-645 Operator Manual Table of Contents
3 COMPONENT IDENTIFICATION
3-1 Basil 4700 Cage and Rack Washer Components ............................................................................. 3-1
3-2 Operator Terminal and Printer ........................................................................................................... 3-5
3-3 Sample Alarm Printout ....................................................................................................................... 3-6
3-4 Sample Printout ................................................................................................................................. 3-6
3-5 Oscillating Jet System ....................................................................................................................... 3-7
3-6 Safety Cables .................................................................................................................................... 3-8
3-7 Heat Exchanger ................................................................................................................................. 3-9
3-8 Non-Recirculated Final Rinse Spray Header ...................................................................................3-11
3-9 Drain Discharge Side Tank (Typical) ............................................................................................... 3-12
3-10 Exhaust Fan ..................................................................................................................................... 3-13
4 OPERATING INSTRUCTIONS
4-1 Manual Drain Valves .......................................................................................................................... 4-1
4-2 Accessories ....................................................................................................................................... 4-3
4-3 Cycle Operation: Display Flowchart (Typical) ................................................................................... 4-9
4-4 Manual Control Mode ...................................................................................................................... 4-13
4-5 Resume or Abort a Cycle ................................................................................................................ 4-15
5 CYCLE AND CONTROL VALUE PROGRAMMING
5-1 Supervisor Mode Flowchart ............................................................................................................... 5-5
6 ROUTINE MAINTENANCE
6-1 Spray Header Flush Plug ................................................................................................................... 6-7
6-2 Self-Cleaning Screen ......................................................................................................................... 6-8
6-3 Exhaust Fan Grease Fittings ............................................................................................................ 6-10
6-4 Manual Drain Valve .......................................................................................................................... 6-12
6-5 Detergent Supply Pump .................................................................................................................. 6-13
6-6 Replacing Detergent Container ....................................................................................................... 6-14
6-7 Open Printer Cover .......................................................................................................................... 6-16
6-8 Open Paper Cover Compartment .................................................................................................... 6-16
6-9 Cut Paper Edge ............................................................................................................................... 6-16
6-10 Install Paper Roll .............................................................................................................................. 6-16
6-11 Changing Printer Ribbon Cartridge ................................................................................................. 6-17
LIST OF ILLUSTRATIONS
Figure
Number Description Page

vii
920509-645 Operator Manual Table of Contents
1 SAFETY PRECAUTIONS
1-1 Definition of Symbols on Unit ................................................................................................................ 1-3
1-2 Definition of Symbols on Identification Nameplate ................................................................................ 1-4
6 ROUTINE MAINTENANCE
6-1 Preventive Maintenance Guide ............................................................................................................. 6-2
7 TROUBLESHOOTING
7-1 Troubleshooting Chart ........................................................................................................................... 7-2
7-2 Fault Chart ............................................................................................................................................. 7-7
8 REPLACEMENT PARTS AND PRODUCTS
8-1 Replacement Parts ................................................................................................................................ 8-1
LIST OF TABLES
Table
Number Description Page

1-1
Safety Precautions Operator Manual 920509-645
1
The following Safety Precautions must be observed when operating and servicing this Basil®4700 Cage and
Rack Washer. WARNING indicates potential for personal injury and CAUTION indicates potential for damage to
equipment. For emphasis, certain Safety Precautions are repeated throughout the manual. It is important to
review ALL Safety Precautions before operating and servicing the unit.
WARNING – PERSONAL INJURY AND/OR EQUIPMENT DAMAGE HAZARD:
WARNING – PERSONAL INJURY HAZARD:
WARNING – CHEMICAL BURN AND/OR EYE INJURY HAZARD:
Only STERIS or STERIS-trained service technicians should make repairs and adjustments to this
equipment. Maintenance done by inexperienced, unqualified personnel or installation of unauthorized
parts could cause personal injury, invalidate warranty or result in costly damage. Contact STERIS
regarding service options.
Regularly scheduled preventive maintenance, in addition to faithful performance of minor maintenance
described in this manual, is required for safe and reliable operation of this equipment. Contact STERIS
to schedule preventive maintenance.
To open doors from inside wash chamber, pull EMERGENCY STOP cables. Washer operation will auto-
matically stop. Then, push firmly on door panel using shoulder and upper arm, applying upper body
force.
Always wear appropriate Personal Protective Equipment (PPE) when cleaning or removing debris from
bottom of wash chamber and over suction plate.
Never perform cleaning of wash chamber until full cycle has been completed. If cycle has not been
completed, contaminated debris or water may remain in the bottom of the wash chamber.
Keep fingers away from door hinges to prevent pinching.
Items in washing cart may move during processing and be filled with residual hot water or protrude from
cart at the end of the cycle. Always wear appropriate Personal Protective Equipment (PPE) and care-
fully remove utensils and items from cart.
To prevent tipping, place biggest and heaviest items on the lower levels of accessory cart.
Washer detergents are caustic and can cause adverse effects to exposed tissues. Do not get in eyes,
on skin or attempt to swallow. Read and follow precautions and instructions on detergent label and in
Material Safety Data Sheet (MSDS) prior to handling detergent, refilling detergent container or servic-
ing detergent injection pump or lines. Wear appropriate Personal Protective Equipment (PPE) when-
ever handling detergent or servicing detergent injection pump and lines.
Wear appropriate Personal Protective Equipment (PPE) when removing clamps and replacing squeeze
tubes. Residual chemicals might remain in used squeeze tubes. If chemical contacts skin or eyes,
immediately flush with running water for at least 10 minutes. If contact was with eyes, seek medical
attention.
Wear gloves and eye protection when using a descaling product. Avoid contact with eyes or skin. If
spilled or splashed, flush with plenty of water for 15 minutes. If swallowed, DO NOT induce vomiting.
Administer an alkali with plenty of water. Seek medical attention immediately.
SAFETY PRECAUTIONS

1-2
920509-645 Operator Manual Safety Precautions
WARNING – ELECTRIC SHOCK HAZARD:
WARNING – BURN HAZARD:
WARNING – SLIPPING HAZARD:
CAUTION – POSSIBLE EQUIPMENT DAMAGE:
Disconnect all utilities to washer before servicing. Do not service washer unless all utilities have been
properly locked out. Always follow local occupational health and safety regulations, as well as electric
and plumbing codes.
Allow unit to cool down before performing any service on mechanical components and on piping. Com-
ponents and piping become very hot during operation.
Inner surfaces of washer are very hot after cycle completion. Operator should wear appropriate Per-
sonal Protective Equipment (PPE) and avoid all contact with inner walls when entering chamber to
unload washer.
Pipes may be extremely hot.
When cycle is complete, partially open chamber door and allow chamber and load to cool. Hot steam
may escape through door opening if door is fully opened after a cycle.
To prevent slips, keep floor dry. Promptly clean up any spills or condensation. If spilled liquids are deter-
gents or other chemicals, follow safety precautions and handling procedures set forth on detergent or
chemical label and/or Material Safety Data Sheet (MSDS).
Always use non-foaming chemical for effective cleaning and proper pump and water level control opera-
tion. Follow manufacturer’s recommendations for amount of chemical to be used.
Always use a silicone lubricant to lubricate squeeze tubes. Petroleum-based lubricants, such as Vase-
line®1 or grease, will cause squeeze tubes to melt.
Avoid product damage. Always select a cycle appropriate for items being processed.
Before operating unit, always position manifolded Bottle Washing Cart over central water inlet connec-
tor. If manifolded accessory is not positioned correctly, damage may result and unit will be unable to
effectively wash load.
Do not process load using Bottle Washing Cart when Automatic Floor Tilting option is activated. If Auto-
matic Floor Tilting is used, manifolded water inlet and washer will be damaged.
Remove all cellulose-type bedding from cages and pans before processing. Cellulose bedding can clog
filters and piping.

1-3
Safety Precautions Operator Manual 920509-645
CAUTION – POSSIBLE EQUIPMENT DAMAGE (Cont’d):
Tables 1-1 and 1-2 define certain symbols which may be on your Basil 4700 Cage and Rack Washer compo-
nents:
Use nonabrasive cleaners when cleaning unit. Follow directions on containers and rub in a back-and-
forth motion (in same direction as surface grain). Abrasive cleaners will damage stainless steel. Clean-
ers rubbed in a circular motion applied with a wire brush or steel wool will scratch and dull stainless
steel. Do not use these cleaners on painted surfaces.
When choosing a detergent, select one with a low chloride content. Detergents with a high chloride con-
tent can corrode stainless steel.
1 Vaseline is a trademark of Cheseborough Pond’s Incorporated.
Table 1-1. Definition of Symbols on Unit
Symbol Definition
Protective Earth (Ground).
Fuse Identification.
Pump Rotation.
Attention, Consult Manual for Further Instructions.
Warning! Risk of Electrical Shock.

1-4
920509-645 Operator Manual Safety Precautions
Table 1-2. Definition of Symbols on Identification Nameplate
Symbol Definition
MODEL Model Number of The Unit.
S/N Serial Number of The Unit.
V3~Volt, Number of Phase (3 or 1), Alternate Current.
WIRE Number of Wires In The Electrical Cable (Ground Not Included).
YEAR Year of Manufacture of The Unit.
kKilovolt-Ampere.
AAmperage.
Hz Hertz – Frequency of The Unit.

2
2-1
Installation Verification Operator Manual 920509-645
2.1 Technical
Specifications
Complete uncrating and installation instructions, as well as an equip-
ment drawing have been furnished. If any of these documents are
missing or misplaced, contact STERIS giving serial, equipment and
model numbers of the unit. Replacement copies will be sent to you
promptly.
These specifications are intended to describe technical information
given on nameplate of your washer and to state other relevant infor-
mation. Check equipment drawing or identification nameplate for
proper voltage and amperage.
2.1.1 Voltage, Amperage and
Power Consumption
Basil®4700 Cage and Rack Washer operates on:
208 V, 60 Hz, 3-phase, 25 Amps;
480 V, 60 Hz, 3-phase, 15 Amps.
A protective ground is required (Class 1 Equipment).
Maximum currents and power consumptions are indicated on
nameplate.
Main supply voltage not exceeding ± 10% of nominal voltage.
Installation category: Overvoltage Category II.
Always follow local electrical installation codes.
Refer to Uncrating/Installation Instructions (P920509-642) for proper
connection.
IMPORTANT: A listing of the Safety Precautions to be observed when operating this Cage and Rack
Washer can be found in SECTION 1. Do not operate equipment until you have become familiar with this
information.
INSTALLATION VERIFICATION

2-2
920509-645 Operator Manual Installation Verification
2.1.2 Permissible
Environmental Conditions
This equipment is designated to give optimal results under the fol-
lowing conditions:
Indoor use only;
Altitude of operation up to: 6,267 ft (2,000 m);
Maximum relative humidity is 80% for temperatures up to: 88ºF
(31ºC) decreasing linearly to 50% relative humidity at 104ºF
(40ºC);
Pollution degree 2.
2.1.3 Noise Level Equivalent Sound Pressure Level: 84 dB (A). Results determined
according to ISO-3746: 1995 Standard: Acoustics Determination of
Sound Power Levels of Noise Sources Survey Method.
2.1.4 Seismic Anchorage
System
A Seismic Anchorage System is available for seismic zone 3 and 4
requirements.
2.2 Installation
Checklist
After your washer has been installed by qualified service techni-
cians, complete the following checklist to assure installation is com-
plete and correct. If you desire, contact STERIS and schedule a
technician to test installation and demonstrate proper equipment
operation.
❑To allow service of unit without shutting off building supply lines,
shutoff valves (not provided by STERIS) for maintenance pur-
poses, are installed on steam and water lines to unit. Shutoff
valves must be capable of being locked in OFF position only.
❑Disconnect switches (not provided by STERIS) are installed in
electric supply lines near washer and within 10' (3 m) of electri-
cal control box. Disconnect switches must be capable of being
locked in OFF position only.
NOTE: If washer is installed next to other equipment, shut-off
valves and disconnect switch should be placed so that service
can be shut off to one piece of equipment at a time.
❑Washer is positioned as shown on equipment drawing with
required service clearance space and in relation to building sup-
ply lines.
❑Washer must be installed between two walls with a key-locked
service door so service side is not accessible to operators.
❑Building steam line provides maximum dynamic steam pressure
and flow rate to washer as specified on equipment drawing.
❑Drip leg with steam trap installed in steam supply line.

2-3
Installation Verification Operator Manual 920509-645
❑Building hot water line supplies water to washer at pressure and
temperature specified on equipment drawing.
❑Building cold water line supplies water to washer at pressure
specified on equipment drawing.
❑Electrical supply for washer is as specified on equipment draw-
ing.
❑Condensate returns are sized as specified on equipment draw-
ing.
❑Vent connections are sized as specified on equipment drawing.
❑Recirculation pump pressure is within 25 to 60 psig.
❑Recirculation pump motor rotating in direction shown by arrow.
❑Self-cleaning screen assembly functioning properly.
❑Carriage drive motor rotating in direction shown by arrow.
❑Carriage drive system functioning properly.
❑Carriage drive motor amperage within rating indicated on the
motor.
❑Optional exhaust fan rotating in direction shown by arrow.
❑All piping is leak-free.
❑Chamber sump steam coil functioning properly.
❑Door safety switch(es) functioning properly.
❑Cabinet joints are completely sealed, no leaks (for verification,
run machine for 1/2 hour).
❑Door(s) easily opens from inside of chamber.
❑Safety cables immediately stop washer operation when pulled.
❑Each gear box plastic cap removed and replaced with air vent
provided.
❑Floor surrounding unit has non-slip surface.
IMPORTANT: After a few weeks of operation, inspect unit for leaks.
Retighten all clamps and connections.

2-4
920509-645 Operator Manual Installation Verification
2.3 Chemical Additives
Specifications
The selection of chemical additives is open for customer preference;
however, in order to achieve optimal performance, the selected
chemical additives must meet as a minimum, the following specifica-
tions:
NOTE: When choosing and using chemicals, take note of the follow-
ing:
1) Follow chemical label recommendations for concentration of
chemical to use.
2) Follow chemical manufacturer's recommendations to determine
the temperature of the WASH treatment.
3) Follow chemical manufacturer's recommendations for the amount
of chemical used according to water hardness.
To achieve maximum cleaning efficiency, select chemical appropri-
ate to soil type being processed. STERIS recommends the following
chemicals:
•Cage-Klenz®100 Alkaline Cage Wash Detergent –
(Alkaline) formulated to remove urine, scale, animal fats, oils and
other organic soils from cage materials.
•Cage-Klenz®200 Acid-Based Cage Wash Detergent –
(Acidic) formulated to remove urine, scale, animal fats, oils and
other organic soils from cage materials.
•Liquid Descaler Acid-Based Scale Remover – for
removing scale and other hard water deposits. For use in animal
care centers.
NOTE: Certain products may not be available in your area. Contact
your STERIS representative for availability of these products and for
ordering information.
IMPORTANT: STERIS does not promote, recommend, nor endorse
the use of any other type of chemical additives in the processing of
articles in the Basil 4700 Cage and Rack Washers, such as drying
agents, strong alkaline detergents (pH>12), alcohol rinses, and liquid
germicides including hypochloric acid (bleach).
Product
Description
Use Dilution
Range oz/gal
(mL/L) Dilution
pH Range
at Use
Other Applicable
Requirements
Alkaline
Chemicals
1/4 - 4
(2 - 32)
9.0 - 12.0 Liquid, non-foaming and
viscosity below 200 SSU
(0.0004623 ft2/sec).
Acidic
Chemicals
1/4 - 4
(2 - 32)
3.0 - 6.0 Liquid, non-foaming, free
rinsing and viscosity
below 200SSU
(0.0004623 ft2/sec).
Descalers 1/2 - 2 <2.5 Liquid, non-foaming,
phosphoric acid-based
and viscosity below
200SSU
(0.0004623 ft2/sec).

3
3-1
Component Identification Operator Manual 920509-645
3.1 Component
Identification
Basil®4700 Cage and Rack Washer is a heavy duty, large capacity
hydrospray washer designed for thorough, efficient cleaning of
cages, racks, debris pans and miscellaneous items used in the care
of laboratory animals.
Washer is equipped with a user-programmable PLC control system
capable of storing up to twelve treatment cycles to process a wide
variety of loads. Computer control system monitors and automati-
cally controls all cycle operations.
Before operating washer, it is important to become familiar with all
control locations and functions (see Figure 3-1).
IMPORTANT: A listing of the Safety Precautions to be observed when operating this Cage and Rack
Washer can be found in SECTION 1. Do not operate equipment until you have become familiar with this
information.
Figure 3-1. Basil 4700 Cage and Rack Washer
Components
Control Console
Reusable-
Throwaway
Detergent
Tank
Chamber
Door and
Viewing
Window
COMPONENT IDENTIFICATION

3-2
920509-645 Operator Manual Component Identification
3.2 Operator Terminal See Figure 3-2.
The Basil 4700 Cage and Rack Washer is equipped with an Allen-
Bradley CompactLogix™Programmable Logic Controller control
system1that features twelve cycles for processing a wide variety of
loads.
System monitors and controls washer operations and functions and
also monitors current status of chamber, including current chamber
temperature and time remaining in phase.
Control system offers four operation modes: Supervisor, Service,
Automatic and Manual. The first two modes are password protected.
Automatic and Manual modes are always available.
There is an operator terminal on load side and an operator terminal
on unload side for double door units. Identical information is dis-
played on both load and unload operator terminals.
3.2.1 Login Passwords Supervisors and service users with appropriate password can
access Supervisor mode.
Only a qualified service technician can access Service mode. A pre-
defined password is required to access Service mode.
3.2.2 Automatic and Manual
Mode
Automatic and Manual mode can be selected from mode selection
screen. No login is required to enter in Automatic or Manual modes.
When accessory rack is in proper position inside wash chamber,
operator closes door, manually selects desired cycle on touch
screen, presses START touch pad and appropriate cycle starts.
3.2.3 Supervisor Mode Supervisor mode allows supervisor to modify preprogrammed cycles,
parameters and options within a range of factory set values such as
date and time and to enable printer functions.
Supervisor mode access is secured by a password. Supervisor
password is configured in Supervisor mode.
3.2.4 Service Mode Service mode allows a qualified service technician to access Service
mode menu to configure washer and to perform preventive mainte-
nance, testing and troubleshooting. Service mode is not accessible
to operator or supervisor.
A predefined password is required to access Service mode.
Passwords
Operators
Cycles
1 CompactLogix™ is a trademark of Allen-Bradley, a Rockwell Automation Company.
