Stevens Tot mate TM2137R User manual

1
#0964-3185
3594.TM2137.9/25/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM2137R
TM2137R
Activity Cube
076,QYHQWRU
\
3DUWV/LVW
3DUWV/LVW
3$5747<,7(0


;;
;;

'(6&5,37,21
(QG/
(QG5
6HDW
%DFN
6FUHZ&RQQ+['F1LPP[PP
2-PERSON ASSEMBLY
RECOMMENDED.
IMPORTANT!
Be sure to keep all parts
supported during assembly
to avoid damage. Do not over-
tighten screws or it will damage
the pre-drilled holes;
snug fit is adequate.
HARDWARE / TOOLS INCLUDED
Confirmat Bolt (5)
(Screw Conn HxDc Ni 7mmx50mm)
Hex Wrench

TM2137R
STEP-BY-STEP ASSEMBLY
2#0964-3185
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2137.9/25/18
Lay Left End (1) flat on floor, with side having the
most holes facing up.
STEP
1
Insert dowels on Seat (3) and Back (4) into holes
on Left End (1). Press firmly into place.
STEP
2
Position Right End (2) on top of assembly, making
sure dowels on Seat (3) and Back (4) align with
holes in Right End (2). Press firmly into place.
STEP
3
Secure Right End (2) to Seat (3) and Back (4)
with four Confirmat Bolts (5), using the included
Hex Wrench.
STEP
4
Carefully turn unit over, so Left End (1) is facing
up. Repeat Step 4 to secure Left End (1) to Seat
(3) and Back (4).
STEP
5
Ensure that all joints and bolts are tight.
STEP
7
This completes the assembly.
Carefully stand unit upright.
STEP
6
