Stevens ToT mate TM2336R User manual

1
#0964-3135
3594.TM2336/TM4336.9/25/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
NOTE: ASSEMBLY INSTRUCTIONS REFERENCE
ILLUSTRATIONS AND PART NUMBERS FOR THE TM2336R.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM2336R
TM4336R
TM2336R
Diaper Wall Storage
TM4336R
Diaper Wall Storage
IMPORTANT!
Assembly must be securely attached to
building structure with anchoring devices
of appropriate type, size and quantity in
accordance with applicable codes and
accepted installation practices.
3$5747<,7(0
;;
;;
;;
;;


;;
;;
;;
;;




'(6&5,37,21
(QG8
%RWWRP
6KHOI
6XEGLYLGHU
6WULQJHU
7RS
'LYLGHU
%DFN
&OLS6KHOI'LYLGHU[PP
6FUHZ&RQQ+['F1LPP[PP
6FUHZ&RQQ+[)O=1PP[PP
6FUHZ7DSS3K:K=LQF;
076,QYHQWRU
\
3DUWV/LVW
Parts List
3$5747<,7(0



;;


;;





'(6&5,37,21
7RS
(QG8
%RWWRP
%DFN
6KHOI
'LYLGHU
6XEGLYLGHU
6WULQJHU
&OLS6KHOI'LYLGHU[PP
6FUHZ&RQQ+['F1LPP[PP
6FUHZ&RQQ+[)O=1PP[PP
6FUHZ7DSS3K:K=LQF;
076,QYHQWRU
\
3DUWV/LVW
Parts List

TM2336R – TM4336R
STEP-BY-STEP ASSEMBLY
2#0964-3135
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2336/TM4336.9/25/18
ILLUSTRATIONS AND PART NUMBERS ARE FOR TM2336R.
ASSEMBLY INSTRUCTIONS ARE THE SAME FOR BOTH MODELS.
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported during assembly to avoid damage.
Do not over-tighten screws or it will damage the pre-drilled holes;
snug fit is adequate.
HARDWARE / TOOLS INCLUDED
Confirmat Bolt (10)
(Screw Conn HxDc Ni 7mmx50mm)
Hex Wrench
Back Screw (12)
(Screw Tapp PhWh Zinc #8x1.25)
Flat Head Confirmat Bolt (11)
(Screw Conn HxFl ZN 7mmx50mm)
Shelf Clip (9)
(Clip Shelf/Divider 1/4"x224mm)
channel
channel
3$5747<,7(0
;;
;;
;;
;;


;;
;;
;;
;;




'(6&5,37,21
(QG8
%RWWRP
6KHOI
6XEGLYLGHU
6WULQJHU
7RS
'LYLGHU
%DFN
&OLS6KHOI'LYLGHU[PP
6FUHZ&RQQ+['F1LPP[PP
6FUHZ&RQQ+[)O=1PP[PP
6FUHZ7DSS3K:K=LQF;
076,QYHQWRU
\
3DUWV/LVW
TM2336R Parts List
(Phillips screwdriver required but not included.)

TM2336R – TM4336R
STEP-BY-STEP ASSEMBLY
3
#0964-3135
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM2336/TM4336.9/25/18
Identify Top (6) and Bottom (2). Note that routed
channels on Top (6) and Bottom (2) will face
interior of unit and hold Back (8) in place. To
differentiate the parts, note that Bottom (2) has
more holes than Top (6).
STEP
1
Lay Bottom (2) on floor, with side having the most
holes facing up. Channel will be facing up. Insert
dowels on two Dividers (7) into holes on Bottom
(2), making sure raw edges of Dividers (7) are
facing toward channel on Bottom (2). Press firmly
into place.
STEP
2
channel
raw edge
raw edge
With side of Shelf (3) having the most holes facing
down, align holes on Shelf (3) with dowels on
standing Dividers (7). Make sure all raw edges are
facing same direction. Press firmly into place.
STEP
3
raw edge
raw edge
Secure Shelf (3) and Bottom (2) to Dividers (7)
with four Confirmat Bolts (10), using the included
Hex Wrench.
STEP
4
Insert dowels on remaining Divider (7) into holes
on Shelf (3). Make sure raw edges are facing
same direction. Press firmly into place.
STEP
5
raw edge
raw edge
With side of Top (6) having the most holes facing
down, align holes on Top (6) with dowels on
Divider (7). Make sure channel on Top (6) is
aligned with channel on Bottom (2). Press firmly
into place.
STEP
6
channels
channel channel

TM2336R – TM4336R
STEP-BY-STEP ASSEMBLY
4#0964-3135
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2336/TM4336.9/25/18
Lay one End (1) on floor with side having the most
holes facing up.
STEP
8
Insert dowels on one end of Shelf/Divider
Assembly from Step 7 into holes on End (1).
Make sure raw edges and channels on Shelf/
Divider Assembly are facing toward back (flat)
edge of End (1). Press firmly into place.
STEP
9
Shelf/Divider
Assembly
raw edge
channel
channel
back (flat) edge
Slide Back (8) into channels on Top (6) and
Bottom (2). Seat firmly against End (1). When
seated, make sure holes on Back (8) align with
back edge of Shelf (3).
STEP
10
channel
channel
holes must align
with back edge of
Shelf (3) when
Back (5) is seated
Insert dowels on Stringers (5) into remaining
holes on End (1). Make sure holes on Stringers
(5) align with thru-holes on End (1). Press firmly
into place.
STEP
11
thru-holes
Secure Shelf (3) to Divider (7) with Flat Head
Confirmat Bolt (11). Secure Top (6) to Divider (7)
with Confirmat Bolt (10). This will be referred to
as the Shelf/Divider Assembly in Step 9.
STEP
7

TM2336R – TM4336R
STEP-BY-STEP ASSEMBLY
5
#0964-3135
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM2336/TM4336.9/25/18
Position other End (1) on top of assembly, so
dowels on Top (6), Bottom (2) and Stringers (5)
align with holes on End (1). Press firmly into place.
STEP
12
Secure End (1) to Top (6), Bottom (2) and
Stringers (5) with seven Confirmat Bolts (10).
STEP
13
Carefully turn unit over, so other End (1) is facing
up. Repeat Step 13 to secure other End (1) to Top
(6), Bottom (2) and Stringers (5).
STEP
14
Carefully position unit with front edge on floor and
back facing up.
STEP
15

TM2336R – TM4336R
STEP-BY-STEP ASSEMBLY
6#0964-3135
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2336/TM4336.9/25/18
Insert Shelf Clips (9) into remaining holes on
Bottom (2) and Shelf (3).
STEP
18
Carefully stand unit upright.
STEP
20
Ensure that all joints, bolts and screws are tight.
STEP
21
This completes the assembly.
Carefully lay unit onto its back.
STEP
17
Slide Subdividers (4) into Shelf Clips (9),
ensuring rounded edges are facing front of unit.
STEP
19
rounded
edge
Secure Back (8) to Shelf (3) with two Back
Screws (12). (Phillips screwdriver not included.)
IMPORTANT! Make sure Back Screws are
centered on raw edge of Shelf and inserted
straight into Shelf. This is necessary to prevent
Back Screws from protruding through and
damaging Shelf surface.
STEP
16
