STIEBEL ELTRON RHM 300 Instruction Manual

BEDIENUNG UND INSTALLATION
OPERATION AND INSTALLATION
UTILISATION ET INSTALLATION
BEDIENING EN INSTALLATIE
Strahlungsheizung | Radiant heater | Chauffage à chaleur rayonnante |
Stralingsverwarming
» RHB 300
» RHB 500
» RHB 700
» RHB 900
» RHW 300
» RHW 500
» RHW 700
» RHW 900
» RHM 300
» RHM 500
» RHM 700
» RHM 900

12 | RHB, RHW, RHM www.stiebel-eltron.com
CONTENTS | SPECIAL INFORMATION
SPECIAL INFORMATION
OPERATION
1. General information ��������������������������������������� 13
1.1 Safety instructions����������������������������������������������13
1.2 Other symbols in this documentation ���������������������� 13
1.3 Information on the appliance �������������������������������� 13
1.4 Units of measurement ����������������������������������������� 13
2. Safety�������������������������������������������������������� 13
2.1 Intended use����������������������������������������������������� 13
2.2 General safety instructions ����������������������������������� 14
2.3 Test symbols ����������������������������������������������������� 14
3. Appliance description ������������������������������������� 14
3.1 Toughened safety glass plate �������������������������������� 15
4. Settings ����������������������������������������������������� 15
5. Cleaning, care and maintenance ������������������������� 15
6. Troubleshooting �������������������������������������������� 15
INSTALLATION
7. Safety�������������������������������������������������������� 16
7.1 General safety instructions ����������������������������������� 16
7.2 Instructions, standards and regulations ������������������� 16
8. Appliance description ������������������������������������� 16
8.1 Standard delivery����������������������������������������������� 16
8.2 Accessories������������������������������������������������������� 16
9. Installation�������������������������������������������������� 16
9.1 Installation site�������������������������������������������������� 16
9.2 Wall mounting��������������������������������������������������� 16
9.3 Power supply ���������������������������������������������������� 18
10. Handover���������������������������������������������������� 18
11. Maintenance ������������������������������������������������ 18
12. Specification ������������������������������������������������ 18
12.1 Dimensions and connections��������������������������������� 18
12.2 Minimum clearances������������������������������������������� 18
12.3 Data table �������������������������������������������������������� 19
GUARANTEE
ENVIRONMENT AND RECYCLING
SPECIAL INFORMATION
- Keep children under the age of3 away from
the appliance if constant supervision cannot be
guaranteed.
- Children from the age of 3 to 7 may switch the
appliance on and off, provided they are super-
vised or have been instructed in the safe oper-
ation of the appliance and understand any risks
that may result. This is subject to the appliance
having been installed as described.
Children from the age of 3 to 7 must not plug
the power cable into its socket or regulate the
appliance.
- The appliance may be used by children aged8
and older and persons with reduced physical,
sensory or mental capabilities or a lack of expe-
rience and know-how, provided that they are su-
pervised or they have been instructed on how to
use the appliance safely and have understood the
resulting risks.
- Children must never play with the appliance. Chil-
dren must never clean the appliance or perform
user maintenance unless they are supervised.
- The appliance is not equipped with a facility for
controlling room temperature. Ensure constant
supervision if the appliance is operated in a small
room and the persons within that room cannot
leave the room on their own.
- Parts of the appliance can get very hot and may
cause burns.
Particular caution is advised when children or
vulnerable persons are present.
- Never cover the appliance.
- Never install the appliance directly below a wall
socket.
- Install the appliance in such a way that the con-
trol equipment cannot be touched by a person in
the bath or shower.
- In the case of a permanent connection, the ap-
pliance must be able to be separated from the
power supply by an isolator that disconnects all
poles with at least 3mm contact separation.

OPERATION
General information
www.stiebel-eltron.com RHB, RHW, RHM | 13
ENGLISH
- The power cable may only be replaced (for exam-
ple if damaged) by a qualified contractor author-
ised by the manufacturer, using an original spare
part.
- Secure the appliance as described in chapter "In-
stallation/ Installation".
OPERATION
1. General information
The chapters "Special Information" and "Operation" are intended
for both the user and qualified contractors.
The chapter "Installation" is intended for qualified contractors.
Note
Read these instructions carefully before using the appli-
ance and retain them for future reference.
Pass on the instructions to a new user if required.
1.1 Safety instructions
1.1.1 Structure of safety instructions
!
KEYWORD Type of risk
Here, possible consequences are listed that may result
from failure to observe the safety instructions.
 Steps to prevent the risk are listed.
1.1.2 Symbols, type of risk
Symbol Type of risk
Injury
Electrocution
Burns
(burns, scalding)
1.1.3 Keywords
KEYWORD Meaning
DANGER Failure to observe this information will result in serious
injury or death.
WARNING Failure to observe this information may result in serious
injury or death.
CAUTION Failure to observe this information may result in non-seri-
ous or minor injury.
1.2 Other symbols in this documentation
Note
General information is identified by the adjacent symbol.
 Read these texts carefully.
Symbol Meaning
Material losses
(appliance damage, consequential losses and environmen-
tal pollution)
Appliance disposal
 This symbol indicates that you have to do something. The ac-
tion you need to take is described step by step.
1.3 Information on the appliance
Symbol Meaning
Never cover the appliance
1.4 Units of measurement
Note
All measurements are given in mm unless stated oth-
erwise.
2. Safety
2.1 Intended use
This appliance is intended for domestic use. It can be used safely
by untrained persons. The appliance can also be used in a non-do-
mestic environment, e.g.in a small business, as long as it is used
in the same way.
Any other use beyond that described shall be deemed inappropri-
ate. Observation of these instructions and of instructions for any
accessories used is also part of the correct use of this appliance.
!
!

OPERATION
Appliance description
14 | RHB, RHW, RHM www.stiebel-eltron.com
2.2 General safety instructions
!
WARNING Injury
-Keep children under the age of3 away from the
appliance if constant supervision cannot be guar-
anteed.
-Children from the age of 3 to 7 may switch the ap-
pliance on and off, provided they are supervised
or have been instructed in the safe operation of
the appliance and understand any risks that may
result. This is subject to the appliance having been
installed as described.
Children from the age of 3 to 7 must not plug the
power cable into its socket or regulate the appli-
ance.
-The appliance may be used by children aged8 and
older and persons with reduced physical, sensory
or mental capabilities or a lack of experience and
know-how, provided that they are supervised or
they have been instructed on how to use the appli-
ance safely and have understood the resulting risks.
-Children must never play with the appliance. Chil-
dren must never clean the appliance or perform
user maintenance unless they are supervised.
!
WARNING Injury
The appliance is not equipped with a facility for con-
trolling room temperature.
If operated on a time switch, the appliance may continue
to heat the room unchecked.
Ensure constant supervision if the appliance is operated
in a small room and the persons within that room cannot
leave the room on their own.
WARNING Burns
Never operate the appliance when work, such as laying
tiles, grinding, sealing, cleaning with naphtha or floor
maintenance (spray, floor polish), is being carried out in
the installation room.
WARNING Burns
Parts of the appliance can get very hot and may cause
burns. Particular caution is advised when children or
vulnerable persons are present.
WARNING Burns
-Never place any objects on top of the appliance.
-Do not lean any objects against the appliance.
-Never place any objects between the appliance and
the wall.
-Do not place any flammable, combustible or insulat-
ing objects or materials, such as laundry, blankets,
magazines, containers with floor polish or naphtha,
spray cans or similar, in close proximity to the ap-
pliance.
Never cover the appliance
Even covering up a section, forexample with a towel,
can cause overheating and damage the heating element.
- Never cover the appliance.
- Never stick anything onto the appliance (e.g.decora-
tive foil, post-it notes).
!
Material losses
Observe the minimum clearances (see chapter "Specifi-
cation/ Minimum clearances").
!
Material losses
Never operate the appliance when the toughened safety
glass or other components are damaged.
2.3 Test symbols
See type plate on the appliance. The type plate is located on the
outer edge of the appliance near the ON/OFF switch.
3. Appliance description
The appliance is a wall mounted electric heating plate made of
toughened safety glass.
A heating mat is glued to the back of the glass plate which warms
the plate evenly.
The heat stored in the glass plate is delivered as infra-red radia-
tion. Consequently, occupants and objects alike are heated in the
room without any air turbulence.
Note
Never place objects between the appliance and persons
requiring heating. In this case, the objects would be heat-
ed rather than the persons.

OPERATION
Settings
www.stiebel-eltron.com RHB, RHW, RHM | 15
ENGLISH
3.1 Toughened safety glass plate
!
Material losses
Never operate the appliance when the toughened safety
glass is damaged.
The front of the appliance is made of 6mm thick toughened safety
glass.
If damaged, the safety glass will shatter into many small pieces
with blunt edges to minimise any risk of injury. On very rare occa-
sions, safety glass can spontaneously break even without external
influences.
- Avoid any strain on the glass plate, e.g.caused by people or
objects leaning on it.
- When selecting an installation site, ensure that no persons or
objects can come to harm if the toughened safety glass spon-
taneously breaks.
Note
Raw mirror glass and cast glass are subject to special
manufacturing processes. Spherical or linear inclusions
and blisters due to a roll change and pattern offset cannot
be excluded and do not constitute a quality defect.
4. Settings
CAUTION Burns
When pressing the ON/OFF switch, avoid any contact
with the potentially hot glass plate.
Note
Depending on the size and design of the appliance, it may
take some time for it to reach its operating temperature.
Note
When the appliance is first commissioned, it may give off
an odour temporarily.
 Ensure that the room is adequately ventilated (with
a partially open window, forexample).
The ON/OFF switch is located on the outer edge of the appliance.
D0000055943
1
1 ON/OFF switch
 Switch the appliance on or off using the ON/OFF switch.
After reaching the operating temperature, the appliance heats
constantly at around100°C.
You can operate the appliance with an optional wall mounted
room thermostat.
 Observe the operating and installation instructions of the
connected room thermostat.
5. Cleaning, care and maintenance
- After it has cooled down, clean the appliance with a damp
cloth and, if necessary, commercial glass cleaner.
- Never use any abrasive or corrosive cleaning products.
6. Troubleshooting
Problem Cause Remedy
The appliance
does not heat
up.
Fuse or safety switch has
blown/tripped.
Check the respective fuses and
safety switches.
Remove the cause.
Overheating. The high
limit safety cut-out has
tripped.
Remove the cause. The appliance
restarts after it has cooled down
for a few minutes.
If you cannot remedy the fault, notify your qualified contractor.
To facilitate and speed up your request, provide the number from
the type plate (000000-0000-000000).

16 | RHB, RHW, RHM www.stiebel-eltron.com
INSTALLATION
Safety
INSTALLATION
7. Safety
Only a qualified contractor should carry out installation, commis-
sioning, maintenance and repair of the appliance.
7.1 General safety instructions
- We guarantee trouble-free function and operational reliabil-
ity only if original accessories and spare parts intended for
the appliance are used.
- Fit the appliance to a vertical wall that is temperature-resist-
ant to at least 90°C.
- Observe the minimum clearances to adjacent object surfaces
(for minimum clearances see chapter "Specifications/ Mini-
mum clearances").
- Never install the appliance directly below a wall socket.
- Select your installation location so that no sockets are in-
stalled on the surface concealed by the appliance.
- When installing the heating appliance in rooms with a
bath and/or shower, observe the safety zone according to
VDE0100,part701, in accordance with the details on the
appliance type plate. The mains junction box must not be in-
stalled in safety zone1 or 2 in this instance.
- Install the appliance in such a way that switching and control
equipment cannot be touched by a person in the bath or
shower.
- Design all materials in accordance with the rated consump-
tion of the appliances.
- When selecting an installation site; ensure that no persons or
objects can come to harm if the toughened safety glass spon-
taneously breaks.
7.2 Instructions, standards and regulations
Note
Observe all applicable national and regional regulations
and instructions.
8. Appliance description
8.1 Standard delivery
The following are delivered with the appliance:
- 1 retaining bracket
- RH...300-500: 1 wall mounting bracket
- RH...700-900: 2 wall mounting brackets
8.2 Accessories
- Room temperature controller (optional)
9. Installation
9.1 Installation site
!
Material losses
Observe the minimum clearances (see chapter "Specifi-
cation/ Minimum clearances").
!
Material losses
The appliance is not suitable for mounting on ceilings
or inclines.
- The appliance is exclusively designed for installation on a
solid wall.
- Ensure the wall offers adequate load bearing capacity.
- The appliance can be mounted in any room. You may only
mount the appliance within protection zone 2 or higher in
bathrooms.
9.2 Wall mounting
Note
You can mount the appliance both vertically and hori-
zontally.
The ON/OFF switch position can be used to correctly align
the appliance:
- When mounted vertically, the ON/OFF switch is lo-
cated on the bottom edge of the appliance.
- When mounted horizontally, the ON/OFF switch is
located on the left outer edge of the appliance when
viewed from the front.
9.2.1 Wall mounting bracket
RH...300 | RH...500:
The appliance comes with a wall mounting bracket.
- The wall mounting bracket is used to mount the appliance
vertically or horizontally.
RH...700 | RH...900:
The appliance comes with two wall mounting brackets of different
lengths.
- The short wall mounting bracket is used to mount the appli-
ance vertically.
- The long wall mounting bracket is used to mount the appli-
ance horizontally.

www.stiebel-eltron.com RHB, RHW, RHM | 17
ENGLISH
INSTALLATION
Installation
9.2.2 Retaining bracket
The appliance is supplied with a retaining bracket to prevent the
wall mounted appliance from moving or tilting.
Two mounting holes for the retaining bracket are already pre-
punched into the rear panel. These mounting holes are each pro-
vided with a fixing screw for the retaining bracket.
D0000055944
2
3
1
1 Pre-punched mounting hole
2 Retaining bracket
3 Fixing screw
- If you mount the appliance horizontally, attach the retaining
bracket to the long edge of the appliance.
- If you mount the appliance vertically, attach the retaining
bracket to the short edge of the appliance.
9.2.3 Wall mounting bracket installation
Note
Use the wall mounting bracket as a drilling template
when marking the fixing holes.
 Attach the wall mounting bracket to the wall using
one horizontal slot and one vertical slot.
Note
The screws and rawl plugs are not part of the standard
delivery.
 Use appropriate fixing materials.
65
D0000058661
 Determine the position of the appliance. Mark the centre of
the top edge of the appliance on the wall.
 Starting from the centre of the top edge of the appliance,
mark the fixing holes for the wall mounting bracket on the
wall.
 Drill the fixing holes for the wall mounting bracket.
 Secure the wall mounting bracket on the wall.
 Adjust the position of the wall mounting bracket until it is
horizontally level. The horizontal and vertical slots in the wall
mounting bracket enable alignment if drilled holes are not
completely accurate.
9.2.4 Fitting the retaining bracket
D0000058310
1
1 Retaining bracket
 Attach the retaining bracket to the rear panel using the fixing
screw provided.
D0000055941
1
2
1 Wall mounting bracket
2 Retaining bracket
!
Material losses
Ensure that the power cable is not pinched or damaged
when you hook in the appliance.
We recommend that you fully extend the power cable
before wall mounting.
 Hook the appliance centrally onto the wall mounting bracket.
 Mark the fixing hole for the retaining bracket on the wall.
 Lift the appliance off the wall mounting bracket.
 Drill the fixing hole for the retaining bracket.
9.2.5 Hooking the appliance into place
 Hook the appliance centrally onto the wall mounting bracket.
 Lock the appliance in by securing the retaining bracket to the
wall.

18 | RHB, RHW, RHM www.stiebel-eltron.com
INSTALLATION
Handover
9.3 Power supply
WARNING Electrocution
Carry out all electrical connection and installation work
in accordance with relevant regulations.
!
Material losses
The specified voltage must match the mains voltage.
 Observe the type plate.
!
Material losses
This appliance is unsuitable for fixed electrical cables.
 Connect the appliance to a suitable socket.
Note
The power cable may only be replaced (for example if
damaged) by a qualified contractor authorised by the
manufacturer, using an original spare part.
The appliance is delivered fully wired. The following electrical
connections are permissible:
RH...300-900
Connection to a freely accessible standard socket with
matching plug
X
Permanent connection to an appliance junction box with
earth conductor
X
9.3.1 Connection to a standard socket
 Plug the appliance into a standard socket.
Note
You can push excess cable back into the space between
the rear panel and wall.
9.3.2 Permanent connection
WARNING Electrocution
In the case of a permanent connection, the appliance
must be able to be separated from the power supply by
an isolator that disconnects all poles with at least 3mm
contact separation.
!
Material losses
-Trim the power cable so it leads directly to the ap-
pliance connection socket.
-Ensure that, after trimming the power cable, the
appliance can still be removed from the wall with-
out problem.
 Trim the power cable by cutting off the plug.
 Connect the power cable to a suitable socket.
10. Handover
 Explain the functions of the appliance to the user. Draw spe-
cial attention to the safety instructions.
 Hand over the operating and installation instructions to the
user.
11. Maintenance
The appliance contains no serviceable parts.
12. Specification
12.1 Dimensions and connections
a20
a10
a30
D0000055939
RH...300 RH...500 RH...700 RH...900
a10 Appliance Height mm 600 600 600 600
a20 Appliance Width mm 600 1000 1400 1800
a30 Appliance Depth mm 49 49 49 49
12.2 Minimum clearances
≥100
≥100
≥100
≥500 ≥100
D0000055940

www.stiebel-eltron.com RHB, RHW, RHM | 19
ENGLISH
INSTALLATION
Specication
12.3 Data table
RHB 300 RHB 500 RHB 700 RHB 900 RHW 300 RHW 500 RHW 700 RHW 900 RHM 300 RHM 500 RHM 700 RHM 900
234422 234423 234424 234425 234426 234427 234428 234429 234430 234431 234432 234433
Electrical data
Connected load kW 0.28 0.47 0.66 0.85 0.28 0.47 0.66 0.85 0.28 0.45 0.635 0.82
Power supply 1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
1/N/PE ~
230 V 50
Hz
Dimensions
Height mm 600 600 600 600 600 600 600 600 600 600 600 600
Width mm 600 1000 1400 1800 600 1000 1400 1800 600 1000 1400 1800
Depth mm 49 49 49 49 49 49 49 49 49 49 49 49
Weights
Weight kg 7.8 12.9 18.2 23.4 7.8 12.9 18.2 23.4 7.8 12.9 18.2 23.4
Versions
Colour Black Black Black Black White White White White Mirror Mirror Mirror Mirror
IP rating IP24 IP24 IP24 IP24 IP24 IP24 IP24 IP24 IP24 IP24 IP24 IP24
Safety category I I I I I I I I I I I I
Guarantee
The guarantee conditions of our German companies do not
apply to appliances acquired outside of Germany. In countries
where our subsidiaries sell our products a guarantee can only
be issued by those subsidiaries. Such guarantee is only grant-
ed if the subsidiary has issued its own terms of guarantee. No
other guarantee will be granted.
We shall not provide any guarantee for appliances acquired in
countries where we have no subsidiary to sell our products.
This will not aect warranties issued by any importers.
Environment and recycling
We would ask you to help protect the environment. After use,
dispose of the various materials in accordance with national
regulations.
GUARANTEE
ENVIRONMENT AND RECYCLING



Deutschland
STIEBEL ELTRON GmbH & Co. KG
Dr.-Stiebel-Straße 33 | 37603 Holzminden
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.de
Verkauf Tel. [phone] | Fax [phone] | [email protected]
Kundendienst Tel. [phone] | Fax [phone] | [email protected]
Ersatzteilverkauf Tel. [phone] | Fax [phone] | [email protected]
Irrtum und technische Änderungen vorbehalten! | Subject to errors and technical changes! | Sous réserve
d‘erreurs et de modifications techniques! | Onder voorbehoud van ver
g
issin
g
en en technische wi
j
zi
g
in
g
en! |
Salvo error o modificación técnica! | Excepto erro ou alteração técnica | Zastrzeżone zmian
y
techniczne i
ewentualne błędy | Omyly a technické změny jsou vyhrazeny! | A muszaki változtatások és tévedések
j
o
g
át
fenntartjuk! | Отсутствие ошибок не гарантируется. Возможны технические изменения. | Ch
y
b
y
a
technické zmeny sú vyhradené! Stand 9147
Australia
STIEBEL ELTRON Australia Pty. Ltd.
6 Prohasky Street | Port Melbourne VIC 3207
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel.com.au
Austria
STIEBEL ELTRON Ges.m.b.H.
Gewerbegebiet Neubau-Nord
Margaritenstraße 4 A | 4063 Hörsching
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.at
Belgium
STIEBEL ELTRON bvba/sprl
't Hofveld 6 - D1 | 1702 Groot-Bijgaarden
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.be
China
STIEBEL ELTRON (Guangzhou) Electric
Appliance Co., Ltd.
Rm 102, F1, Yingbin-Yihao Mansion, No. 1
Yingbin Road
Panyu District | 511431 Guangzhou
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebeleltron.cn
Czech Republic
STIEBEL ELTRON spol. s r.o.
K Hájům 946 | 155 00 Praha 5 - Stodůlky
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.cz
Finland
STIEBEL ELTRON OY
Kapinakuja 1 | 04600 Mäntsälä
Tel. [phone]
[email protected]
www.stiebel-eltron.fi
France
STIEBEL ELTRON SAS
7-9, rue des Selliers
B.P 85107 | 57073 Metz-Cédex 3
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.fr
Hungary
STIEBEL ELTRON Kft.
Gyár u. 2 | 2040 Budaörs
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.hu
Japan
NIHON STIEBEL Co. Ltd.
Kowa Kawasaki Nishiguchi Building 8F
66-2 Horikawa-Cho
Saiwai-Ku | 212-0013 Kawasaki
Tel. [phone] | Fax [phone]
[email protected]
www.nihonstiebel.co.jp
Netherlands
STIEBEL ELTRON Nederland B.V.
Daviottenweg 36 | 5222 BH 's-Hertogenbosch
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.nl
Poland
STIEBEL ELTRON Polska Sp. z O.O.
ul. Działkowa 2 | 02-234 Warszawa
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.pl
Russia
STIEBEL ELTRON LLC RUSSIA
Urzhumskaya street 4,
building 2 | 129343 Moscow
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.ru
Slovakia
TATRAMAT - ohrievače vody s.r.o.
Hlavná 1 | 058 01 Poprad
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.sk
Switzerland
STIEBEL ELTRON AG
Industrie West
Gass 8 | 5242 Lupfig
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.ch
Thailand
STIEBEL ELTRON Asia Ltd.
469 Moo 2 Tambol Klong-Jik
Amphur Bangpa-In | 13160 Ayutthaya
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebeleltronasia.com
United Kingdom and Ireland
STIEBEL ELTRON UK Ltd.
Unit 12 Stadium Court
Stadium Road | CH62 3RP Bromborough
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron.co.uk
United States of America
STIEBEL ELTRON, Inc.
17 West Street | 01088 West Hatfield MA
Tel. [phone] | Fax [phone]
[email protected]
www.stiebel-eltron-usa.com
A 318113-39932-9240
4<AMHCMO=bibbdc>
