Still ECV 10 C User manual

Electric Pallet Stacker
ECV 10 C
ECV 10i C
ECV 10
Original instructions
0342 0343 0344
50028011505 EN - 03/2022 - 06

Address of manufacturer and
contact details
STILL GmbH
Berzeliusstraße 10
22113 Hamburg, Germany
Tel. [phone]
Fax: [phone]
Email: [e-mail]
Website: http://www.still.de
Made in China
Rules for the operating com-
pany of industrial trucks
In addition to these operating instructions, a
code of practice containing additional informa-
tion for the operating companies of industrial
trucks is also available.
This guide provides information for handling
industrial trucks:
●
Information on how to select suitable indus-
trial trucks for a particular area of applica-
tion
●
Prerequisites for the safe operation of in-
dustrial trucks
●
Information on the use of industrial trucks
●
Information on transport, initial commission-
ing and storage of industrial trucks
Internet address and QR code
The information can be accessed at any time
by pasting the address
https://m.still.de/vdma
in a web browser or by scanning the QR code.


Preface
I50028011505 EN - 03/2022 - 06

1 Introduction
Your industrial truck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Conformity marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
Declaration that reflects the content of the declaration of conformity . . . . . . . . . . . . . . .
4
Information about documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Documentation scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Copyright and property rights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
Explanation of symbols used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6
Date of edition and latest update of this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
List of abbreviations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
Drive directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9
Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
Environmental considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disposal of components and batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11
Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Use of the truck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Intended use of the trucks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Unauthorised use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14
Place of use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14
Residual risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Residual risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Special risks associated with using the truck and attachments. . . . . . . . . . . . . . . . . . . .
15
Overview of hazards and countermeasures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16
Danger to employees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
2 Safety
Definition of terms used for responsible persons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Operating company . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Specialist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
Basic principles for safe operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Insurance cover on company premises. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Modifications and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
Warning regarding non-original parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
Damage, faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25
Table of contents
III50028011505 EN - 03/2022 - 06

Medical devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Vibrations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26
Safety tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Carrying out regular inspections on the truck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Insulation testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27
Safety regulations for handling consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Permissible consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Oils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Hydraulic fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30
Battery acid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30
Disposal of consumables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31
Safety devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Damage, faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Battery connection cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
EMC – Electromagnetic compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3Views
Main Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Dataplate and safety labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Load label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Nameplate, variant 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Identification plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Nameplate, variant 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Identification plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4 Operation
Intended use of the trucks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
First use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Daily checks before use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Checking the working environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cleaning the Forklift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
General information on batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Charging and discharging batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Table of contents
IV 50028011505 EN - 03/2022 - 06

Drive operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
51
Forward travel/reverse travel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
52
Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
53
Safety reverser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
54
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
55
Horn operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
55
Using the truck on a slope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
55
Hydraulic operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Use of the mast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Working with loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
59
Emergency lowering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
62
Before leaving the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Putting the equipment back into operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Slinging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Transporting the truck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5 Maintenance
General maintenance information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Servicing and maintenance personnel training and qualification. . . . . . . . . . . . . . . . . . .
70
Battery maintenance staff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
71
Maintenance operations that do not require special training. . . . . . . . . . . . . . . . . . . . . .
71
Technical inspection and maintenance data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
71
Maintenance - 1000 hours / every 12 months . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Maintenance - 2000 hours / every 2 years . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Changing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Lubrication point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
77
Check the hydraulic oil level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
78
Topping up the gear oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
79
Checking the fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
80
Tyre operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Drive Wheel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Load Wheels - Removal and Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
82
Caster - Removal and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
83
Malfunction analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Table of contents
V50028011505 EN - 03/2022 - 06

6 Technical data
ECV 10 Technical Datasheet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
ECV 10i C / ECV 10 C Technical Datasheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Eco-design requirements for electric motors and variable speed drives . . . . . . . . . . . 94
Table of contents
VI 50028011505 EN - 03/2022 - 06

1
Introduction

Your industrial truck
General
The truck described in these operating instruc-
tions corresponds to the applicable standards
and safety regulations.
If the truck is to be operated on public roads, it
must conform to the existing national regula-
tions for the country in which it is being used.
The driving permit must be obtained from the
appropriate office.
The truck has been fitted with state-of-the-art
technology. Following these operating instruc-
tions will allow the truck to be handled safely.
By complying with the specifications in these
operating instructions, the functionality and the
approved features of the truck will be retained.
Get to know the technology, understand it and
use it safely - these operating instructions pro-
vide the necessary information and help to
avoid accidents and to keep the truck ready
for operation beyond the warranty period.
Therefore:
–Before commissioning the truck, read the
operating instructions and follow the instruc-
tions.
–Always follow all of the safety information
contained in the operating instructions and
on the truck.
Introduction
1
Your industrial truck
2 50028011505 EN - 03/2022 - 06

Conformity marking
The manufacturer uses the conformity mark-
ing to document the conformity of the industri-
al truck with the relevant directives at the time
of placing on the market:
●
CE: in the European Union (EU)
●
UKCA: in the United Kingdom (UK)
●
EAC: in the Eurasian Economic Union
The conformity marking is applied to the
nameplate. A declaration of conformity is is-
sued for the EU and UK markets.
An unauthorised structural change or addition
to the industrial truck can compromise safety,
thus invalidating the declaration of conformity.
conformity symbols

Introduction
1
Your industrial truck
350028011505 EN - 03/2022 - 06

Declaration that reflects the content of the declaration of conformity
Declaration
STILL GmbH
Berzeliusstraße 10
22113 Hamburg Germany
We declare that the specified machine conforms to the most recent valid version of the direc-
tives specified below:
Industrial truck type
corresponding to these operating instructions
Model corresponding to these operating instructions
− "Machinery Directive 2006/42/EC"
1)
− "Supply of Machinery Safety Regulations 2008, 2008 No. 1597"
2)
Personnel authorised to compile the technical documents:
See declaration of conformity
STILL GmbH
1)
For the markets of the European Union, the EU candidate countries, the EFTA States and
Switzerland.
2)
For the United Kingdom market.
The declaration of conformity document is
supplied with the industrial truck. The declara-
tion shown explains the conformity with the
provisions of the EC Machinery Directive and
the Supply of Machinery Safety Regulation
2008, 2008 No. 1597.
An unauthorised structural change or addition
to the industrial truck can compromise safety,
thus invalidating the declaration of conformity.
The declaration of conformity must be careful-
ly stored and made available to the responsi-
ble authorities if necessary. It must also be
handed over to the new owner if the industrial
truck is sold on.
Introduction
1
Your industrial truck
4 50028011505 EN - 03/2022 - 06

Information about documentation
Documentation scope
●
Operating instructions
●
Operating instructions for attachment parts
(special equipment)
●
Spare parts list
●
VDMA rules for the proper use of industrial
trucks (EU countries only)
These operating instructions describe all
measures necessary for the safe operation
and proper maintenance of the truck in all pos-
sible variants at the time of printing. Special
designs to meet customer requirements are
documented in separate operating instruc-
tions. If you have any questions, please con-
tact your service centre.
Enter the production number and the year of
production located on the nameplate in the
field provided:
Production no. ...........................................
Year of produc-
tion ...................................................
Please quote these numbers for all technical
enquiries.
Operating instructions are provided with each
truck. These instructions must be stored care-
fully and must be available to the driver and
operator at all times.
If the operating instructions are lost, the oper-
ator must immediately request a replacement
from the manufacturer.
The operating instructions are included in the
spare parts list and can be reordered there as
a spare part.
Personnel responsible for operating and main-
taining the equipment must be familiar with
these operating instructions.
The operating company (see
⇒ Chapter "Defi-
nition of terms used for responsible persons",
Page 22 ) must ensure that all operators
have received, read and understood these in-
structions.
Thank you for reading and complying with
these operating instructions. If you have any
questions or suggestions for improvements, or
if you have found any faults, please contact
your service centre.
Copyright and property rights
This manual - and any excerpts thereof - may
not be reproduced, translated or transmitted in
any form to third parties without the express
written permission of the manufacturer.
Introduction
1
Information about documentation
550028011505 EN - 03/2022 - 06

Explanation of symbols used
DANGER
Compulsory procedure that must be followed to
avoid danger to life or physical harm.
WARNING
Compulsory procedure that must followed to avoid
injury.
CAUTION
Compulsory procedure that must be followed to
avoid material damage and/or destruction.
NOTE
For technical requirements that require special
attention.
ENVIRONMENT NOTE
To prevent environmental damage.
Introduction
1
Information about documentation
6 50028011505 EN - 03/2022 - 06

Date of edition and latest update
of this manual
The publication date of these operating in-
structions is printed on the cover sheet.
The manufacturer makes continuous efforts to
improve its industrial trucks, and therefore re-
serves the right to implement changes and to
accept no claims concerning the information
provided in this manual.
To receive technical assistance, please con-
tact the service centre authorised by your
closest manufacturer.
List of abbreviations
This list of abbreviations applies to all types of
operating instructions. Not all of the abbrevia-
tions that are listed here will necessarily ap-
pear in these operating instructions.
Abbrevi-
ation Meaning Explanation
ArbSchG Arbeitsschutzgesetz German implementation of EU occupation-
al health and safety directives
Betr-
SichV Betriebssicherheitsverordnung German implementation of the EU working
equipment directive
BG Berufsgenossenschaft German insurance company for the com-
pany and employees
BGG Berufsgenossenschaftlicher Grundsatz German principles and test specifications
for occupational health and safety
BGR Berufsgenossenschaftliche Regel German rules and recommendations for
occupational health and safety
DGUV Berufsgenossenschaftliche Vorschrift German accident prevention regulations
CE Communauté Européenne Confirms conformity with product-specific
European directives (CE labelling)
CEE Commission on the Rules for the Approval
of the Electrical Equipment
International commission on the rules for
the approval of electrical equipment
DC Direct Current Direct current
DFÜ Datenfernübertragung Remote data transfer
DIN Deutsches Institut für Normung German standardisation organisation
EG European Community
EN European standard
Introduction
1
Information about documentation
750028011505 EN - 03/2022 - 06

Abbrevi-
ation Meaning Explanation
FEM Fédération Européene de la Manutention European Federation of Materials Han-
dling and Storage Equipment
F
max
maximum Force Maximum power
GAA Gewerbeaufsichtsamt
German authority for monitoring/issuing
regulations for worker protection, environ-
mental protection, and consumer protec-
tion
GPRS General Packet Radio Service Transfer of data packets in wireless net-
works
ID no. Identification number
ISO International Organization for Standardi-
zation International standardisation organisation
K
pA
Uncertainty of measurement of sound
pressure levels
LAN Local Area Network Local area network
LED Light Emitting Diode Light emitting diode
L
p
Sound pressure level at the workplace
L
pAZ
Average continuous sound pressure level
in the driver's compartment
LSP Load centre of gravity Distance of the centre of gravity of the
load from the front face of the fork backs
MAK Maximum workplace concentration Maximum permissible air concentrations
of a substance at the workplace
Max. Maximum Highest value of an amount
Min. Minimum Lowest value of an amount
PIN Personal Identification Number Personal identification number
PPE Personal protective equipment
SE Super-Elastic Superelastic tyres (solid rubber tyres)
SIT Snap-In Tyre Tyres for simplified assembly, without
loose rim parts
StVZO Straßenverkehrs-Zulassungs-Ordnung German regulations for approval of vehi-
cles on public roads
TRGS Technische Regel für Gefahrstoffe Ordinance on hazardous materials appli-
cable in the Federal Republic of Germany
UKCA United Kingdom Conformity Assessed
Confirms conformity with the product-spe-
cific directives that apply in the United
Kingdom (UKCA labelling)
Introduction
1
Information about documentation
8 50028011505 EN - 03/2022 - 06

Abbrevi-
ation Meaning Explanation
VDE Verband der Elektrotechnik Elektronik In-
formationstechnik e. V. German technical/scientific association
VDI Verein Deutscher Ingenieure German technical/scientific association
VDMA Verband Deutscher Maschinen- und Anla-
genbau e. V.
German Mechanical Engineering Industry
Association
WLAN Wireless LAN Wireless local area network
Drive directions
The drive directions of the vehicle are forward
(1), reverse (4), left (2) and right (3).

Introduction
1
Information about documentation
950028011505 EN - 03/2022 - 06

Illustrations
At many points in this documentation the
(mostly sequential) operation of certain func-
tions or operating procedures is explained. To
illustrate these operations, schematic repre-
sentations of an truck are used.
NOTE
These schematic representations do not rep-
resent the design state of the documented
truck. They only serve to illustrate operating
procedures.

Introduction
1
Information about documentation
10 50028011505 EN - 03/2022 - 06

Environmental considerations
Packaging
During delivery of the truck, certain parts are
packaged to provide protection during trans-
port. This packaging must be removed com-
pletely prior to initial start-up.
ENVIRONMENT NOTE
The packaging material must be disposed of
properly after delivery of the truck.
Disposal of components and
batteries
The truck is composed of different materials. If
components or batteries need to be replaced
and disposed of, they must be:
●
disposed of,
●
treated or
●
recycled in accordance with regional and
national regulations.
NOTE
The documentation provided by the battery
manufacturer must be observed when dispos-
ing of batteries.
ENVIRONMENT NOTE
We recommend working with a waste man-
agement company for disposal purposes.
Series
The electric Pallet Stacker is suitable for
stacking operations in narrow aisles and con-
fined spaces.
This series of electric pallet stacker includes
the following models:
●
0342_ECV 10 C: simplex narrow electric
pallet truck with rated load of 1000 kg.
●
0343_ECV 10i C: simplex narrow electric
pallet truck with initial lift and rated load of
1000 kg.
●
0344_ECV 10 duplex narrow electric pallet
truck with rated load of 1000 kg.
Introduction
1
Environmental considerations
1150028011505 EN - 03/2022 - 06

Technical description
This product has a compact chassis, 4-point
ground contact, balanced tiller and a micro-
processor electronic control system.The ma-
chine is lightweight, highly efficient and easy
to handle.
Design
The latest ergonomic and practical design,
adaptable to all operators and working condi-
tions.
The polyurethane cowling provides superior
stability and shock resistance, and has a vari-
ety of storage spaces.
The frame is made of thick steel plate and is
suitable for the harshest working conditions.
Steering system
Extremely smooth steering makes the vehicle
easier to manoeuvre in tight spaces.
A gas spring enables the tiller to quickly return
to the vertical position after it is released.
Tiller
The composite construction tiller head pro-
vides excellent impact resistance.
The ergonomic control layout is suitable for
left-handed and right-handed operators.
The horn, lifting and lowering devices can be
operated using one hand without changing
grip.
The anti-crush button integrated into the tiller
head protects the operator if the vehicle re-
coils.
Driving
The electronic control unit ensures comforta-
ble use and lower costs.
Precise control of driving speed.
Jolt-free starting and smooth acceleration to
maximum speed.
Simply release or turn the drive direction
switch to brake.
Booster circuit prevents the truck rolling back
when starting on a gradient.
Hydraulics
Gear pump driven by fully enclosed air-cooled
motor.
Safety valve and lowering brake protect the
hydraulic system.
Brake system
The electromagnetic brake with dust protec-
tion function can be used as a safety brake
and parking brake.Braking is controlled by the
drive controller, the brake's electromagnet
acts on the motor shaft and automatic braking
is activated when the tiller is in the horizontal
or vertical position (end stop brake).
Battery
It uses a large-capacity battery and the battery
charge can be viewed on the display unit.
Introduction
1
Technical description
12 50028011505 EN - 03/2022 - 06
