Mounting instructions for „Crosstrainer Stepper“
Item-No. 55 1012 401
State: 14/11/2014 · S. 1 · MSö
Diagram 1: Overall view of the tness equipment

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved.
Mounting instructions for „Crosstrainer Stepper“
Item-No. 55 1012 401
State: 14/11/2014 · S. 2 · MSö
Diagram 2: Side view with dimension details „Crosstrainer Stepper“























 
 












1:10


 




1. Select the tness equipment location in consideration of the required safety
area (see diagram 3: 3550 x 3000 mm).
2. The impact area of a sport equipment with an enforced movement is not allo-
wed to overlap the impact area of other equipment.
In accordance with DIN 790000:2012-05 sports equipment with a maximum
height less than 600mm does not require shock absorbing underlay over the
entire impact zone. However wood chips or synthetic fall surfacing is recom-
mended.
3. Carry out excavation work for the foundation anchor as shown in Diagram
2. (1550 x 800 x 400 mm). After excavation, compress the foundation oor.
Note: The tness equipment is built in on the play level.
4. Grout the foundation oor with concrete of quality class B25 up to a height of
appr. 400 mm.
Reinforcement plan: Concrete foundation with reinforcement
Main foundation: BSt 500S
Ever 4 stirrups Ø 8 mm lengthwise and cross
Concrete cover h´= 3 cm
Concrete quality class B25
5. After the setting period of 8 -10 days - depending on weather conditions and
foundation size - clean the surface of the foundation, place the pre-mounted
tness equipment onto it and screw the base plate of the tness equipment
onto the foundation anchor with the included heavy-duty dowel.
400
1550
2180
150
2055
2205
OK
800
1550
Fertigung
Fundamentplan
Crosstrainer Stepper
Utikal
25.11.2013
Maßstab 1:25
Allgemein-
toleranzen
DIN 7168-m
Bl.
A4
Norm
Gepr.
Bearb.
Name
Name
Datum
Datum
Änderung
Zust.

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved.
Mounting instructions for „Crosstrainer Stepper“
Item-No. 55 1012 401
State: 14/11/2014 · S. 3 · MSö
6. Do not allow to use the equipment before the installation has been nished.
Attention: If the tness equipment has been incompletely installed or partly
dismantled when carrying out maintenance and repair work, this may lead to
particular risks of injury for the user. For this reason, make clearly visible that
the equipment shall not be used in such cases.
7. NOTE: Fitness equipment, which contain components made of stainless
steel should not come with „normal“ steel parts in contact. Those steel parts
may rub off and leave small steel particles in combination with moisture
brown rust stains.If such corrosion occur on stainless steel parts, they are
ne with an abrasive (240 grit) to remove.
Please take care when transporting and setting up the fact that the compo-
nents are made of stainless steel with no „normal“ steel parts in contact.
8. The tness information sign has to be arranged outside of the minimum zone
because of the risk of injury.
Diagram 3: Top view „Crosstrainer Stepper“
1550
800
3550
3000
Zust.
Änderung
Datum
Datum
Name
Name
Bearb.
Gepr.
Norm
A4
Bl.
Allgemein-
toleranzen
DIN 7168-m
Maßstab 1:25
27.11.2013
Utikal
Stepper
Mindestfreiraum
Crosstrainer Stepper
Fertigung
Extent of the
minimum zone =
safety area

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved.
Mounting instructions for „Crosstrainer Stepper“
Item-No. 55 1012 401
State: 14/11/2014 · S. 4 · MSö
In order to preserve a good visual appearance of your stilum playground equip-
ment over a long period one should take care of maintenance of the stainless
surface even despite of their corrosion resistance.
Especially areas, which can not be reached by rainfall should be frequently clea-
ned from dirt and deposits due to air pollution and dirt caused by the atmosphere.
Light soiling can easily be romoved by using a high pressure cleaner.
For persistent deposits use a clean cloth moistened with a special liquid cleaner
(e.g. on phosphoric acid) and rinse off with clear water after a short application
time. During cleaning with mild abrasive components, only wipe over stainless
steel surface in polishing direction.
For heavily soiled surfaces, polishes can be used (e.g. for cleaning chrome on
cars) or for greasy and oily dirt alcoholic cleaning agents and solvents (e.g. ethyl
alcohol, isopropyl alcohol or acetone).
However, it should be noted that the dissolved soiling is not spread over the sur-
face again.
Do not use any chlorid or hydrochloric containing cleaning products nor scouring
powder, bleaching - or silver polish cleaner. Cleaning intervals depend on type
and degree of soiling as well as on demands made on optical characteristics.
Therefore cleaning is advisable at intervals of six to twelve months – whereby in
the case of strong soiling it is appropriate to clean the playground equipment at
intervals of 3 to six months.
General Information DIN 79000:2012 05_4. 1:
DIN EN1176 species that tness equipment should not be installed in the imme-
diate vicinity of children’s playground equipment. In cases where they are erected
in playgrounds or similar establishments near children’s playground equipment,
they must be separated by adequate distance, fencing or other structural means
from the general play zone.
Movement area DIN 79000:2012-05_4.3.14.4
The free space allowed as movement area must be a minimum of 2.2m. The
movement area must be clear of fences, and observers should not wait in this
space. The space should be free of all objects that the user could fall on and
be injured. E.g. injuries could be caused by posts that are not ush with adja-
cent parts or by protruding footings. In cases where the equipment has a forced
movement, the free area must be extended about 0.5m. Where tness units are
installed on or adjacent to a wall which is at least as high as the exercise space,
the movement area may be reduced. Movement areas of adjacent equipment
may overlap except for equipment with forced movement.
