Mounting instructions for „Abdominal trainer“
Item-No. 551111 401
Diagram 1: Overall view of the tness equipment

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 12/2013 · S. 2
Mounting instructions for „Abdominal trainer“
Item-No. 551111 401
Reinforcement plan: Concrete foundation with rein-
forcement
Main foundation: BSt 500S
Ever 4 stirrups Ø 8 mm lengthwise and cross
Concrete cover h´= 3 cm
Concrete quality class B25
Diagram 2: Side view with dimension details „abdominal trainer“
1. Select the tness equipment location in consideration of the required safety
area (see Diagram 3: Ø 2000 mm).
2. The impact area of sports equipment with an enforced movement is not allo-
wed to overlap the impact area of other equipment. In accordance with DIN
790000:2012-05 sports equipment with a maximum height less than 600mm
does not require shock absorbing underlay over the entire impact zone.
However wood chips or synthetic fall surfacing is recommended.
3. Carry out excavation work for the foundation anchor as shown in Diagram 2.
After excavation, compress the foundation oor. Note: The tness equipment
is built in on the play level.
4. Set up the concrete foundations acc. to the dimensions indicated (LxBxH
1300 x 1300 x 400 mm) with central, horizontal reinforcement (BST 500 S) in
the quality class C 20/25.
1300
150
400
Spielebene
Beton
Concrete
Füllmaterial
Filling
Rev.:
Projekt:
BESTELL-NR:
ZG-NR:
BENENNUNG:
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI + KAISER GMBH DARF DIESE TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT
NOCH DRITTEN MITGETEILT ODER ZUGÄNGLICH GEMACHT WERDEN NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VERWENDET
WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
FREIG:
GEPR:
GEZ:
DATUM: NAME:
WERKSTOFF

MAßSTAB:
OBERFLAECHEN NACH
DIN ISO 1302 REIHE 2
ZUL. ABWEICHUNG
DIN 2768 - mH
+0,3
-0,3
WERKSTUECKKANTEN
NACH DIN 6784
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
A3
0039-00-00
17.03.2015
Abmaße:
Fertigung:
M.Boehm
1x
Gewicht:
Bauchtrainer
Fundamentplan
Rev.:
Projekt:
BESTELL-NR:
ZG-NR:
BENENNUNG:
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI + KAISER GMBH DARF DIESE TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT
NOCH DRITTEN MITGETEILT ODER ZUGÄNGLICH GEMACHT WERDEN NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VERWENDET
WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
FREIG:
GEPR:
GEZ:
DATUM: NAME:
WERKSTOFF

MAßSTAB:
OBERFLAECHEN NACH
DIN ISO 1302 REIHE 2
ZUL. ABWEICHUNG
DIN 2768 - mH
+0,3
-0,3
WERKSTUECKKANTEN
NACH DIN 6784
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
A3
0039-00-00
17.03.2015
Abmaße:
Fertigung:
M.Boehm
1x
Gewicht:
Bauchtrainer
play level

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 12/2013 · S. 3
Mounting instructions for „Abdominal trainer“
Item-No. 551111 401
5. After the setting period of 8 -10 days - depending on weather conditions and
foundation size - place the sports equipment onto the foundation and anchor
with the included heavy-duty dowels.
6. Do not allow to use the equipment before the installation has been nished.
7. Attention: If the tness equipment has been incompletely installed or partly
dismantled when carrying out maintenance and repair work, this may lead to
particular risks of injury for the user. For this reason, make clearly visible that
the equipment shall not be used in such cases.
8. NOTE: Fitness equipment, which contain components made of stainless
steel should not come with „normal“ steel parts in contact. Those steel parts
may rub off and leave small steel particles in combination with moisture
brown rust stains.If such corrosion occur on stainless steel parts, they are
ne with an abrasive (240 grit) to remove.
Please take care when transporting and setting up the fact that the compo-
nents are made of stainless steel with no „normal“ steel parts in contact.
9. Because of the risk of injury, the tness information sign has to be arranged
outside of the minimum zone.
Diagram 3: Top view „abdominal trainer“
Extent of the
minimum zone =
safety area
2000
Grundfläche
Mindestfreiraum=Sicherheitfreisraum
Mindestfreiraum=ø2000mm
Rev.:
Projekt:
BESTELL-NR:
ZG-NR:
BENENNUNG:
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI + KAISER GMBH DARF DIESE TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT
NOCH DRITTEN MITGETEILT ODER ZUGÄNGLICH GEMACHT WERDEN NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VERWENDET
WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
FREIG:
GEPR:
GEZ:
DATUM: NAME:
WERKSTOFF

MAßSTAB:
OBERFLAECHEN NACH
DIN ISO 1302 REIHE 2
ZUL. ABWEICHUNG
DIN 2768 - mH
+0,3
-0,3
WERKSTUECKKANTEN
NACH DIN 6784
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
A3
0039-00-00
17.03.2015
Abmaße:
Fertigung:
M.Boehm
1x
Gewicht:
124160.8
Bauchtrainer
Freiraum

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 12/2013 · S. 4
Mounting instructions for „Abdominal trainer“
Item-No. 551111 401
In order to preserve a good visual appearance of your stilum playground equip-
ment over a long period one should take care of maintenance of the stainless
surface even despite of their corrosion resistance.
Especially areas, which can not be reached by rainfall should be frequently clea-
ned from dirt and deposits due to air pollution and dirt caused by the atmosphere.
Light soiling can easily be romoved by using a high pressure cleaner.
For persistent deposits use a clean cloth moistened with a special liquid cleaner
(e.g. on phosphoric acid) and rinse off with clear water after a short application
time. During cleaning with mild abrasive components, only wipe over stainless
steel surface in polishing direction.
For heavily soiled surfaces, polishes can be used (e.g. for cleaning chrome on
cars) or for greasy and oily dirt alcoholic cleaning agents and solvents (e.g. ethyl
alcohol, isopropyl alcohol or acetone).
However, it should be noted that the dissolved soiling is not spread over the sur-
face again.
Do not use any chlorid or hydrochloric containing cleaning products nor scouring
powder, bleaching - or silver polish cleaner. Cleaning intervals depend on type
and degree of soiling as well as on demands made on optical characteristics.
Therefore cleaning is advisable at intervals of six to twelve months – whereby in
the case of strong soiling it is appropriate to clean the playground equipment at
intervals of 3 to six months.
General Information DIN 79000:2012 05_4. 1:
DIN EN1176 species that tness equipment should not be installed in the imme-
diate vicinity of children’s playground equipment. In cases where they are erected
in playgrounds or similar establishments near children’s playground equipment,
they must be separated by adequate distance, fencing or other structural means
from the general play zone.
Movement area DIN 79000:2012-05_4.3.14.4
The free space allowed as movement area must be a minimum of 2.2m. The
movement area must be clear of fences, and observers should not wait in this
space. The space should be free of all objects that the user could fall on and
be injured. E.g. injuries could be caused by posts that are not ush with adja-
cent parts or by protruding footings. In cases where the equipment has a forced
movement, the free area must be extended about 0.5m. Where tness units are
installed on or adjacent to a wall which is at least as high as the exercise space,
the movement area may be reduced. Movement areas of adjacent equipment
may overlap except for equipment with forced movement.
