Stirling SUM52 User manual

MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
52cm Undermount Rangehood
INSTRUCTION MANUAL
Issue Date: 04/2018IM Version No.: V1.1
Model Number SUM52

2MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Congratulations on choosing to buy a STIRLING® product.
All products brought to you by STIRLING® are manufactured to the highest standards
of performance and safety and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 3 Year In Home Warranty. We hope you
will enjoy using your purchase for many years to come.
Welcome

3
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Contents
2 Welcome
4 Warranty
5 General Safety Instructions
7 Product Overview
9 Getting Started
9 Installation
12 Cleaning and Maintenance
13 FAQs and Troubleshooting
14 Technical Data
14 Specifications
15 Repair and Refurbished Goods or Parts Notice
16 Warranty Returns

4MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
The product is guaranteed to be free from defects in workmanship and parts for a period
of 36 months from the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion. The
benets conferred by this warranty are in addition to all rights and remedies in respect of
the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
52CM UNDERMOUNT RANGEHOOD

5
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before rst use, even if you are familiar with this type of product. The safety
precautions enclosed herein reduce the risk of re, electric shock and injury when correctly adhered to. Make
sure you understand all instructions and warnings.
Keep the manual in a safe place for future reference, along with the completed warranty card and purchase
receipt. If you sell or transfer ownership of this product, pass on these instructions to the new owner.
Always follow basic safety precautions and accident prevention measures when using an electrical appliance,
including the following:
This rangehood must only be installed in accordance with the instructions provided. Incorrect installation may
cause harm to persons, damage property and void the product’s warranty.
Important
Please ensure that you read the entire instructions before beginning the installation of your rangehood.
Warning
All electrical work must be done in accordance with local and national electrical codes as applicable and
should be undertaken by licensed and qualied persons only.
Usage Conditions and Restrictions
• Domestic use only: This rangehood is designed for domestic household use only.
• Purpose: Do not use this rangehood for anything other than its intended purpose. Other uses are not
recommended and may cause re, electric shock or personal injury.
• Improper use: Damage due to improper use, or repairs made by unqualied personnel will void
your warranty. We assume no liability for any eventual damages caused by misuse of the product or
noncompliance with these instructions. You must read the instructions concerning the method and
frequency of cleaning.
Important!
There is a risk of re if cleaning isn’t carried out in accordance with the instructions.
Electrical Safety
• Voltage: Before connecting and turning on the rangehood, ensure the electrical voltage and circuit
frequency correspond to that indicated on the appliance rating label.
• Earthing: This rangehood should be properly earthed for your safety. The power cord of this rangehood
is equipped with a three-prong plug for use in standard wall outlets to minimise the possibility of electrical
shock. Do not modify the cord and/or plug provided with the appliance. Improper use of the earthed plug
can result in the risk of electric shock.
• Connection: This rangehood requires a standard 220-240 V AC 50Hz electrical outlet. Do not overload the
electrical circuit.
• Power cord: Do not kink or damage the power cord; do not leave it exposed or dangling. Keep the cord
out of reach of children. When moving the appliance, make sure not to damage the power cord.
• Auxiliary Items: Do not use an inverter, adaptor or extension cord with this rangehood. If the cord is too
short, have a qualied electrician install an outlet near the appliance. Use of an extension cord and an
inverter can negatively affect the performance of the unit.
• Protect from moisture: To protect against the risk of electric shock, do not immerse the unit, cord or plug
in water or spray it with any other liquid. Do not connect or disconnect the electric plug when your hands
are wet. Turn the power switch off before removing the plug from the socket.
General Safety Instructions

6MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
• WARNING: Disconnect! To reduce the risk of re, electric shock or personal injury, always unplug the
appliance from the socket when not in use, when moving and before cleaning or servicing. Never unplug the
unit by pulling the power cord. Always grip the plug rmly and pull straight out from the power point.
• Electrical work: Any electrical work required for the installation of this appliance should be carried out by
a qualied electrician.
• WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
• Usage restriction: This rangehood is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instructions concerning use of the appliance by a person responsible for their safety.
• Children: Supervise young children to ensure they do not play with the appliance. Never allow children to
operate or play with the rangehood.
• Never: Flambé under the rangehood
• Damage: Do not use the rangehood if the power cord, plug or the rangehood itself is damaged. If the cord
is damaged, contact the after sales support line and have the cord replaced by qualied personnel in order
to avoid a hazard.
• Do not modify: Do not attempt to alter or modify this rangehood in any way.
• Repair: Do not attempt to repair or replace any part of your rangehood unless it is specically
recommended in this manual. All other servicing should be referred to a qualied technician. Contact the
after sales support line for advice.
Caution! During unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.) should be
kept out of reach of children.
Disposal of the appliance
Old appliances should not simply be disposed of with normal household waste, but should be delivered to
a collection and recycling centre for electric and electronic equipment. A symbol shown on the product, the
instruction manual or the packaging shows that it is suitable for recycling.
Materials used inside the appliance are recyclable and are labelled with information concerning this.
By recycling materials or other parts from used devices you are making a signicant contribution to the
protection of our environment. Information on appropriate disposal centres for used devices can be provided
by your local authority.
There shall be adequate ventilation of the room when the range hood is used at the same time as appliances
burning gas or other fuels (not applicable to appliances that only discharge the air back into the room).
CAUTION: Accessible parts may become hot when used with cooking appliances.

7
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
A. LED Light
B. Push-button Control Panel
C. Decorative Filter
D. Filter Handle
E. Stainless Steel Fascia
Also included but not shown:
1 × Pack of screws
Key:
A
A
D
B
C
D
E
52cm Undermount Rangehood
Product Overview

8MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Control Panel Layout
Key: Off button
Press this button for turning the fan off.
Low Speed button
Used for ventilation on the kitchen. It is suitable for simmering and
cooking which do not make much steam.
Medium Speed button
Airow speed is ideally for ventilation in standard cooking operation.
High Speed button
When high density of smoke or steam produced, press high-speed button
for highest effective ventilation.
Light button
NOTE If Low / Medium / High speed buttons are press at the same time, the unit will
only operate at the highest speed.
Product Overview Cont.
Specifications

9
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Getting Started
Unpacking
• Packaging materials: This rangehood has been packaged to protect it against transportation damage.
Remove all packaging materials from around and inside the rangehood and keep the original packaging
carton and materials in a safe place. It will help prevent any damage if the product needs to be transported
in the future, and you can use it to store the rangehood when it is not in use. In the event the carton is to
be disposed of, please recycle all packaging materials where possible.
• Suffocation: Plastic wrapping can be a suffocation hazard for babies and young children, so ensure all
packaging materials are out of their reach and disposed of safely.
• Power cord: Unwind the power cord to its full length and inspect it for damage. Do not use the
rangehood if it or its cord have been damaged or are not working properly. In case of damage, contact our
after sales support line for advice on examination, repair or return of the damaged product.
• Read the manual: Read this manual to familiarise yourself with the rangehood. Pay particular attention
to the safety instructions on the previous pages.
• Clean: To remove any dust from transit and storage, clean the interior and exterior surfaces of the
rangehood with lukewarm water and a soft cloth. Dry thoroughly.
Installation
• Two person installation: Use two or more able-bodied people to
move and install the rangehood. Failure to do so can result in back or
other injury.
• Please Note: Stainless steel is very easily damaged during
installation. Wherever possible, protect the rangehood with the
cardboard box or plastic wrap during the installation.
• Safety: This rangehood must be earthed and always switch the
power off prior to beginning the installation.
Do NOT install/use the rangehood in the following locations/
situations:
• In a recreational vehicle.
• Outdoors.
• In an area with excessive moisture and high humidity. Make sure it
is protected from elements such as wind, rain, water spray or drips.
• Power: A power point must be located within 1.5m of the power cord
exit from the rangehood, and it should be always accessible to allow
isolation from power during cleaning or maintenance.
• Ducting: All ducting must comply with building codes and local
requirements.
• Re-circulating: Stirling does not recommend installing this
rangehood as re-circulating. However if ducting is not possible, and
you do choose to install your rangehood as re-circulating please
ensure that the side outlet grilles are not obstructed in any way as this
will effect the efciency of the rangehood.
• Level: Ensure that the rangehood is mounted in a level position, both
horizontally and vertically. This is essential to ensure the rangehood
operates correctly and prevents grease build up at one end.
WARNING!
—
All electrical work
associated with the
installation of this rangehood
must be carried out by
a licensed electrician.
This rangehood must be
correctly installed by a
suitably qualied person
in strict accordance with
all applicable rules and
regulations and following the
instructions in this manual.
Do not try to install
the rangehood yourself;
doing so will expose
you to danger and void
the warranty. Improper
installation, adjustment,
alteration or service
can cause injury or
damage. We decline any
responsibility for injury
or damage, to persons
or property, as a result of
improper installation.
Specifications

10 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Installation Cont.
It’s important to carefully read the following installation instructions before beginning the
installation of your rangehood.
Important installation safety
• Always switch the power at the mains off prior to beginning the installation.
• Stainless steel is very easily damaged during installation. Wherever possible, protect the rangehood with
the cardboard box or plastic wrap during the installation.
• For safety reasons, this rangehood must be earthed.
• A power point must be located within 1.5m of the power cord exit from the rangehood, and it should be
always accessible to allow isolation from power during cleaning or maintenance.
• All ducting must comply with building codes and local requirements.
• Ensure that the rangehood is mounted in a level position, both horizontally and vertically. This is essential
to ensure the rangehood operates correctly and prevents grease build up at one end.
Ducting options
Before beginning the installation of your rangehood, the method of ducting should be considered and
selected. The guide below illustrates the various ducting options.
• Into your ceiling cavity and then vented through your eaves. (Fig. 1)
• Straight up and through your tiled or metal roof. (Fig. 2)
• Through your wall. (Fig. 3)
Further to your various ducting options, below are some tips on how to correctly duct your rangehood:
• Always use correctly sized ducting: DO NOT reduce the size of the ducting.
• Always use solid ducting.
• Always use non-ammable ducting.
• Always duct to the outside atmosphere.
• DO NO use exible ducting.
• DO NO duct into the ceiling space: always vent to the outside atmosphere.
• Avoid sharp 90 degree bends as much as possible, use 45 degree bends instead wherever possible.
• Duct to the outside atmosphere using the shortest duct run possible.
• Use cylindrical ducting whenever possible.
Fig. 1 Fig. 2 Fig. 3

11
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Installation Cont.
Positioning the rangehood
Installation heights
• Over gas and electric cookers, this rangehood is recommended to be mounted at a height of between
600–800mm above the cooking surface.
• Electric cooktops must have a minimum height of 600mm from the underside of the rangehood to the
cooktop face.
• Gas cooktops must have a minimum of 650mm from the burner to the underside of the rangedhood.
• Over open ame grillers or barbecues, the Gas Regulations require the lters of the rangehood to be at
least 1200mm above the cooking surface.
Installing the rangehood
The typical installation method for your undermount rangehood is into a purpose built overhead/wall cabinet.
• Using a jigsaw, create the required cut-out for your undermount rangehood: 490 × 250mm
• Make sure the cut-out is at least 35mm from the cabinet edge.
Please refer to Fig. 4 for the following points.
• Remove the grease lter and remove the 4 screws on the fascia panel.
• Screw the rangehood into the cabinet using 8 screws (supplied).
• Re-t the fascia panel with the 4 screws (previously removed).
• Re-t grease lter.
Fig. 4
Grease lter
Fascia panel

12 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Cleaning & Maintenance
By ensuring proper cleaning and maintenance of your Stirling rangehood, you can ensure that it
will have a long and fault free operation.
Cleaning the grease filters
Keeping this lter clean will keep the rangehood extraction performance at an optimum. Please strictly follow
the guidelines below.
• The grease lter mesh is made of high-density stainless steel. Please ensure you never use a corrosive
detergent during cleaning.
• Method 1: Put the mesh into 40-50°C clean water with a small amount of regular dishwashing liquid, and
soak for 2-3 mins. Wear gloves and clean with a soft brush. Please do not apply too much pressure, as the
mesh is delicate and will damage easy.
• Method 2: You can wash your rangehood grease lters in your dishwasher, however please ensure they
aren’t washed at a temperature above 60° C degrees.
Cleaning the cooker hood
• To protect the main body of your rangehood from corrosion or stains, the cooker hood should be cleaned
with hot water with a non-corrosive detergent every two months. For stubborn stains or marks, you can try
using a specic stainless steel cleaner available from most supermarkets.
• WARNING! Please do not use a corrosive detergent, or abrasive clothes, as it will damage the body.
• Keep the motor and other spare parts free from water, as this will cause damage to the appliance.
• Before cleaning the rangehood, always switch the power off at the outlet and unplug the rangehood.
• If your rangehood has a damaged plug or cord, please ensure your rangehood remains unplugged and
contact the Residentia Support team for further assistance. Any electrical work should only be completed
by a suitably licenced and authorised person.
• If you’re using a carbon lter, it should never be exposed to heat.
Changing a light globe
In the event of a blown globe:
• Disconnect the rangehood from the power supply.
• Press the lamp cover and take out the globe in a
counter clockwise direction. (Fig. 5)
• After replacing the bulb, re-install the lamp cover,
turning in a clockwise direction.
Carbon filter (optional)
An optional carbon lter can be purchased separately and installed in your undermount rangehood. Normally
the activated carbon lter should be changed every three to six months according to your volume of cooking.
Activated carbon lter cannot be washed or recycled. The installation procedure of activated carbon lter is
as below.
• Remove the grease lters.
• Insert the rst activated carbon lter into the unit
and turn it in anti-clockwise direction. Then repeat
the same on the other side. (Fig. 6)
• Re-insert the grease lters.
Note: When the activated carbon lter installed,
the suction power will be lowered.
Fig. 5
Fig. 6

13
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
FAQs & Troubleshooting
Operation in case of emergency
In the event of an emergency you should:
• Switch off all rangehood controls.
• Switch the rangehood off at the power outlet and immediately unplug.
• Call After Sales Support on 1300 11 HELP (4357).
Some minor faults can be xed by referring to the instructions given in the Troubleshooting section below.
Important!
If your appliance appears to be operating incorrectly, then you should disconnect it from your electrical
supply and then contact After Sales Support on 1300 11 HELP (4357).
Warning!
Do not attempt to repair the rangehood yourself.
Please note that if an engineer is asked to attend whilst the product is under warranty and nds that the
problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
The appliance must be accessible for the engineer to perform any necessary repair. If your appliance is
installed in such a way that an engineer is concerned that damage will be caused to the appliance or your
kitchen, then they will not complete a repair. This includes situations where the rangehood has been tiled
in or sealed in with a sealant.
Please refer to the conditions of that appear on the warranty card at the rear of this user manual.
Fault Common Cause Common Solutions
The lights work,
however the motor
does not work.
The motor is blocked or jammed. Call After Sales Support for further
guidance.
The capacitor is damaged. Call After Sales Support for further
guidance.
Neither the lights or
the motor works.
Beside the above mentioned, check the following:
Light globes are damaged or blown Call After Sales Support for further
guidance.
The power cord is loose. Ensure that the rangehood is
correctly plugged in and the power
outlet is switched on.
The rangehood is
vibrating against the wall.
The rangehood canopy is not xed to
the wall correctly.
Ensure that the internal safety screws
have been used and are tight.
Insufcient suction. The distance between the rangehood
and your cooktop is too great.
Have your installer re-adjust the
installation position, ensuring that
the minimum distances are observed
as per the building code.

14 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
Technical Data
Specifications
Model Extraction Other features:
SUM52 750m3/hr extraction • 3 speed push button control
• 2 × 2W LED Lamp
• 1 × 5 layer aluminium grease lter with s/steel Facia
Volts/Hz: 220–240V 50Hz
Total: 214W
52cm Undermount Rangehood
Model: SUM52
Motor: 1 x 210WLight: 2 x 2W
S/N:
[e-mail]
AUS
1300 11 4357
YEAR IN HOME
WARRANTY
3
2
W
V1.1
04/2018
Barcode: 2632 9451
Made in: China
PLU: 60143
Residentia Group PTY LTD
283
255
280
244
52
0
480
10

15
MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
1
www.xxxxxxx.com
0000 000 000
60cm/90cm Canopy Rangehood
Unfortunately, from time to time, faulty products are manufactured which need to be
returned to the Supplier for repair.
Please be aware that if your product is capable of retaining user-generated data (such as files
stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs
stored on a portable media player, games saved on a games console or files stored on a USB
memory stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending the product for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1300 11 43 57 or write to us at:
Residentia Group
1/32 Wangaratta St
Richmond VIC 3121
Australia
Email: [email protected]
Repair and Refurbished
Goods or Parts Notice
52CM UNDERMOUNT RANGEHOOD
118 Campbell Street
Collingwood VIC 3066
Australia
Email: [e-mail]
Helpline hours of operation:
Mon–Fri
9:00 AM - 5:00 PM

16 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018
