Introduction
About this Guide
The information and requirements provided in this document ensure proper installation and operation of
the Stratasys J826 printing system. The customer is responsible for preparing the site as described in this
document, and according to any applicable local regulations.
If you have any questions about the information in this document, contact your Stratasys representative.
All site requirements must be met before the installation date. The Site Preparation Checklist should be
submitted to your Stratasys representative. Shipping will be arranged after the checklist is received by
Stratasys.
Non-compliance with requirements specified in this document may result in additional installation
charges.
Installation and Training Schedule
• Basic installation and adjustment: 1 work day
• Operator training (operation and maintenance): 1 work day
• Product designer training (advanced features and work flow): ½ work day
• Practice under supervision: 1½ work days
Stratasys J826 Introduction
DOC-18005 Rev. E ©2019-2020 Stratasys. All rights reserved. 5

Physical Description
The Stratasys J826 printing systems consist of the following main components:
• printer
• material cabinet
• printer computer (built into the printer)
• client workstation provided by the customer
Figure 1 Stratasys J826 printer
Size and Weight
Unit W × H × D
(cm)
W × H × D (inch) Weight (kg/lb)
Printer 87 × 120 × 73.5 34.2 × 47.2 × 29 234 kg / 516 lbs
Materials cabinet 67 x 110 x 64 26.4 x 43.3 x 25.2 152 kg / 335 lbs
Table 1 Size and weight
• W = Width; H = Height; D = Depth
• The depth measurement does not include the fan adapter assembly. If the fan
adapter is ordered, the depth measurement increases to 80 cm/31.5 inches (see
"Exhaust Adapter" on page 17).
Stratasys J826 Physical Description
DOC-18005 Rev. E ©2019-2020 Stratasys. All rights reserved. 6

Shipment and Delivery
Shipping Information and Customer Responsibility
Shipment to the customer will be arranged by a Stratasys distributor as indicated in the “ship to” part of the
invoice.The customer is responsible for providing detailed delivery information, including, whether or not
there is loading dock at the delivery site.
The customer is responsible for transporting the printer to a suitable installation site. Upon request, your
Stratasys service provider will advise regarding these matters.
Note:
Only Stratasys-certified Customer Support Engineers are authorized to unpack and
install equipment supplied.
Shipping Pallet
The following table shows the approximate size and weight of the printing system mounted on a pallet.
Unit W × H × D (cm) W × H × D (inch) Weight (kg/lb)
Stratasys J826 149 × 159 × 138 58.7 × 62.6 × 54.3 425 kg / 936 lb
Materials cabinet 109 × 139 × 94 42.7 × 54.7 × 37 240 kg / 529 lbs
Table 2 Size and weight of printer on shipping pallet
W = Width; H = Height; D = Depth
Lifting Equipment
• lifting capacity: 500 kg (1100 lb)
• extension: 150 cm (60 in.)
Stratasys J826 Shipment and Delivery
DOC-18005 Rev. E ©2019-2020 Stratasys. All rights reserved. 7

Unloading
The unloading area should be a level surface.
An area of 10 m2 (108 sq ft) is required for the forklift to remove the printer from the delivery truck.
A clearance of 120 cm (4 ft) around the back and sides of the packaging is required for unpacking the
printer.
The installation location must be accessible from the unloading area. The customer is responsible for
unloading the printer from the truck and transferring it to the installation location. Minimum space
requirements for unloading the printer are shown in the figure below.
Figure 2 Unloading dimensions—top view
Note:
Dimensions are shown in centimeters.
Stratasys J826 Shipment and Delivery
DOC-18005 Rev. E ©2019-2020 Stratasys. All rights reserved. 8

Figure 3 Printer center of gravity
Stratasys J826 Shipment and Delivery
DOC-18005 Rev. E ©2019-2020 Stratasys. All rights reserved. 9

Installation Area
The installation area should be free of sources of vibration and electromagnetic interference that could
affect the proper functioning of the printer.
The floor gradient should be less than 0.5% (5 mm per meter).
The floor should be stable and able to bear the load of the printer. The minimum floor load is 630 kg/m2
(129 lb/ft2).
The server workstation and the printer should be located in the same room.
The cable between the server workstation and the printer should not exceed 5 meters (16 feet). The
communication cable provided should not be extended or replaced with a longer cable.
Clearance around and above the printer should ensure convenient access and servicing.
The area around the printer should remain dry at all times. Do not place the cleaning station within
5 meters (16 feet) of the printer.
Shelves and cabinets are recommended near the printer for convenient storage of tools, parts,
accessories, manuals, and materials.
Floor Plan (Printer Area)
The following is a sample floor plan, showing the 3D printing system—the printer, the materials cabinet,
and the workstation. The dimensions shown in the figure are the minimum clearance requirements.
Figure 4 Printer floor plan (sample, not to scale)
Stratasys J826 Installation Area
DOC-18005 Rev. E ©2019-2020 Stratasys. All rights reserved. 10
