Stratco LG-41301 User manual

RAISED GARDEN BED - SINGLE HEIGHT
RAISED GARDEN BED - SINGLE HEIGHT INSTALLATION GUIDE
INSTALLATION GUIDE
BEFORE YOU START
P rior to installation, choose a suitable location on flat ground for your Garden Bed, a minimum 118cm x 92cm is required.
To ensure the installation of your Stratco Garden Bed proceeds smoothly you should confirm that all the components listed in
this installation guide have been supplied.
Carefully read this installation guide to familiarise yourself with all the steps involved, and ensure that you have the correct
tools and equipment for the job. All required tools are available for purchase at your local Stratco store.
Use heavy gloves when handling steel sheets and parts. Never attempt to assemble the garden bed in windy conditions.
Corner Cap
x4
Corner
x4
COMPONENTS
Bolt & Wing Nut
x32
Panel
x2 - 840mm
x2 - 1100mm
Pliers
Gloves
TOOLS
Phillips-head Screwdriver
Safety Glasses
SAFETY GEAR

ASSEMBLY - STEP 1
Assemble the two short sides of the Raised Garden Bed as illustrated
below. Firstly, assemble the short Panel, Corner and Corner Cap
together. Loosely fasten the Bolts and Wing Nuts to ensure all parts fit
together easily. Once the Panel is assembled, tighten all Bolts. Complete
these steps for both ends of the Panel.
ASSEMBLY - STEP 2
Fasten the two long Panels to the Panels
assembled in step 1.
1100mm Panel
Loosely fasten bolts,
tighten once fully assembled
Corner
840mm Panel
Loosely fasten bolts,
tighten once fully assembled
Corner Cap
GB-8687
