Strong SRT 6200 User manual

1
www.strong.tv
1.00
SRT 6202/6205 SRT 6205
Picture similar
User Manual
Digital Satellite Receiver
SRT 6200/SRT 6202/SRT 6205

2

3

4
TABLE OF CONTENTS
1.0 INTRODUCTION 2
1.1 Safety Instructions 2
1.2 Storage 2
1.3 Equipment Set-up 3
1.4 Accessories 3
1.5 Usage of external USB devices 3
2.0 YOUR RECEIVER 3
2.1 Rear Panel 3
2.2 Remote Control Unit 4
2.3 Default PIN code: 0000 5
3.0 CONNECTIONS 5
3.1 Basic connection with SCART cable 5
3.2 Connecting to Satellite Dish 5
3.3 Connecting USB storage device 5
4.0 STARTING UP 5
4.1 Language Selection 5
4.2 Select Satellite 5
4.3 Antenna mode 6
5.0 MAIN MENU 6
5.1 Channel Organiser 6
5.2 Installation 7
5.3 System setting 8
5.4 Timer 10
5.5 Multimedia 11
6.0 WATCHING TV AND LISTENING TO THE RADIO 12
A.1 TROUBLE SHOOTING 13
A.2 SPECIFICATIONS 14
per March 2010
* €0,14/Min. from German wired line
* €0.42/Min. max. from mobile network
* €0,12/Min. from Austrian wired line
* €0,14/Min. from French wired line
STRONG declares that this item complies with the basic
requirements and other relevant regulations of directives
CE 2004/108/EEC and 73/23EEC; RoHS 2002/95EEC
Subject to alterations. In consequence of continuous research
and development technical specifications, design and appearance
of products may change. All product names are trademarks or
registered trademarks of their respective owners.
© STRONG 2011. All rights reserved. 03/2011

5
1.0 INTRODUCTION
1.1 Safety Instructions
DO NOT INSTALL YOUR RECEIVER:
nIn a closed or poorly ventilated cabinet; directly on top of or under any other equipment;
on a surface which might obstruct the ventilation slots.
DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:
nTo direct sunlight or near any other equipment that generates heat; to rain or intense
moisture; to intense vibration and to any shock which may cause permanent damage to
your receiver or to any magnetic objects, such as loudspeakers, transformers, etc.
nDo not use a damaged power cord. It may cause a fire or an electrical shock. Do not
touch a power cord with wet hands. It may cause an electric shock.
nWhen the receiver is not used for a long period of time, you should unplug the power
cord from the wall socket.
nDo not use alcohol or ammonia based liquids to clean the receiver. If you wish, you
may clean your receiver with a soft lint-free cloth slightly made damp with a mild soap
solution, only after disconnecting from the mains voltage supply. Make sure no foreign
objects fall through the ventilation slots because this could cause fire or an electric shock.
nDo not place any objects on top of the receiver because this might prevent proper cooling
of the components inside.
SAFETY PRECAUTIONS
nNever open the receiver cover. It is dangerous to touch the inside of the receiver due to
high voltage currents and possible electrical hazards and your warranty will be void. Refer
all maintenance or servicing to suitably qualified personnel.
nWhen you are connecting cables, be sure that the receiver is disconnected from the
mains supply voltage. Wait a few seconds after switching off the receiver before you move
the receiver or disconnect any equipment.
nIt is a necessity that you only use an approved extension and compatible wiring that
is suitable for the electrical power consumption of the installed equipment. Please
ensure that the electrical power supply corresponds with the voltage on the electrical
identification plate at the back of the receiver.
If the receiver does not operate normally even after strictly following the instructions in this user
manual, it is recommended to consult your dealer or the desired service / support.
1.2 Storage
Your receiver and its accessories are stored and delivered in a packaging designed to protect against
electric shocks and moisture. When unpacking it, make sure that all the parts are included and keep
the packaging away from children. For transporting the receiver from one place to another or if you
are returning it under warranty conditions, make sure to repack the receiver in its original packaging
with its accessories. Failing to comply with such packaging procedures could void your warranty.

6
1.3 Equipment Set-up
We recommend you consult a professional installer to set up your equipment. Otherwise, please
follow the instructions below:
nRefer to the user manual of your TV and your antenna.
nMake sure that the SCART cable and outdoor components are in a good condition and
the SCART connections are well shielded
This manual provides complete instructions for installing and using this receiver. The following
symbols will serve as follow.
WARNING: Indicates a warning message for your necessary attention.
Tips: Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver (Bold Character)
Move to Represents a menu item within the On Screen Display. (Italic Character)
1.4 Accessories
nUser’s Manual
n1 Remote control unit
n2x Batteries (AAA type)
Note: The batteries should not be recharged, disassembled, electrically short-circuited,
be mixed or used with other types of batteries. If rechargeable accumulators
instead of batteries are going to be used, we recommend using (e.g. NiMH) types
with low self-discharge to ensure long time operation of remote control.
1.5 Usage of external USB devices
nIt is recommended to use USB 2.0 storage devices. If your device is not compatible
to USB 2.0 specifications, recording, playback and other multimedia functions of the
receiver would not work properly.
nIf you are going to use external USB HDD (Hard Disk Drive) please consider that it might
be the case that the power specifications exceed the supported output of your receiver
(5V/500mA). If so, please connect your USB HDD to an according external power
adapter.
nTo ensure best performance of your USB storage device please format it by this receiver
(menu “Recording Device”) to FAT32 system. Other file systems are not supported by the
receiver.
nSTRONG cannot guarantee compatibility to all types of USB storage devices.
2.0 YOUR RECEIVER
2.1 Rear Panel
Fig. 2
1. TO TV To connect to your TV using a coaxial cable or if you have a cable
connected to the ANT input from your TV*
2. ANT IN To connect to your terrestrial antenna or cable TV using coaxial cable*

7
3. SAT OUT To connect an extra receiver to the satellite signal from dish
4. SAT IN To connect to the LNB for satellite signal from dish
5. TV SCART To connect to your TV set using a SCART cable.
6. VCR SCART To connect to your DVD or video recorder using a SCART cable.
The video signal will be looped through to your TV set if receiver is
in stand-by mode.**
7. Video RCA To connect to your TV set using RCA cable*
8. Audio L/R RCA To connect to your TV set or amplifier using RCA cinch cable*
9. S/PDIF Digital audio output
To connect to the input of your digital audio amplifier.
10. Power Cord Your receiver requires a power supply of 100~240 V AC (Auto-
selectable), 50/60Hz +/-5%. Make sure to check the power
specification before connecting your receiver to the wall outlet.
* only SRT 6205; ** only SRT 6202 and SRT 6205
2.2 Remote Control Unit
Fig. 3
Turns the receiver On/Stand-by.
Mutes the audio outputs of the receiver.
0~9 Changes channel and controls numeric functions
AV Toggles between TV and receiver (AV) mode
TV/R Toggles between TV or radio mode
MENU Opens the main menu
EXIT Exits from the menu or sub-menu and cancels the progressing function if applicable.
pq Changes the current program to the previous/next program in TV mode.
Moves the cursor up/down in menu mode.
tu Increases/decreases the volume level in viewing mode.
Changes the setting values in specific menu item in menu mode.
OK Activates the highlighted menu item. Displays the channel list in viewing mode
according to the selected list.
FAV Opens the FAV list and toggles the favourite mode.
EPG Shows the EPG (Electronic Program Guide) in viewing mode.
V+ / V- Increases/decreases the receiver volume level
INFO Shows information banner
AUDIO Selects available audio language(s) for the watched channel.
Selects stereo ((•)), left-mono ((• or right-mono •)).
ZOOM Opens Zoom selection for the desired part of watched channel / picture.
P+ / P- Page up and down in all list modes.
SAT/RED Selects satellite list in channel list mode
TEXT/GREEN Opens the current Teletext of a channel (if available).
SUB/YELLOW Shows list of subtitle languages available for the current channel.
RCL/BLUE Opens the list of last watched channels.

8
2Freezes/resumes video or playback (Starts Timeshift in case setting adjusted
accordingly and USB storage device is connected).
:Jump backwards during playback
"Jump forwards during playback
4Record (Starts instant recording in case setting adjusted accordingly and USB
storage device is connected).
1Play (Opens the recorded list in viewing mode in case USB storage device is
connected).
6Fast backward
7Fast forward
3Stop
2.3 Default PIN code: 0000
3.0 CONNECTIONS
3.1 Basic connection with SCART cable
Fig. 4
3.2 Connecting to Satellite Dish
Connecting a fixed satellite dish to your receiver (Fig. 5)
Connecting multiple fixed dishes to your receiver using a DiSEqC 1.0 switch (Fig. 6)
3.3 Connecting an USB storage device
Fig. 7
4.0 STARTING UP
Ensure your satellite signal is of good quality. It is recommended that you perform the first time
installation following the Installation Wizard step by step. It will help you to easily achieve system
configuration and channel installation.
4.1 Language Selection
Press pq to choose your language, press OK to confirm. The Select Satellite menu will appear.
Further installation steps are depending on the satellite where your dish is aimed to.
4.2 Select Satellite
a) Your dish is aimed at Astra 1C, 1E, 1F or HOT BIRD satellite.
Press pq to select the ASTRA or HOTBIRD satellite and press OK. Follow the instructions.
When you have fixed your dish at the correct position choose NEXT and press OK. The Channel
Setup menu will appear.
Note: If OSD language German and satellite Astra 19.2E is chosen, the receiver will
automatically load German pre-installed channels at the beginning of the channel list.
If OSD language Italian and satellite HOT BIRD 13E is chosen, the receiver will
automatically load Italian pre-installed channels at the beginning of the channel list.

9
b) Your dish is aimed at another satellite
Select Other in Select satellite menu and press OK. A list of satellites will be listed. If you select
one out of the satellite list, the Configure Antenna menu will appear. Use this menu to set the LNB
Type, LNB Low Freq, LNB High Freq, Band control, Polarisation control, DiSEqC Switch and Antenna
mode.
4.3 Antenna mode
a) Fixed dish
Set Antenna mode to Fixed, select NEXT and press OK. The Adjust antenna screen appears. Select
a transponder receivable at your location and adjust the antenna position for maximum signal
strength and quality levels. When adjustment is completed, choose NEXT and press OK. The
Channel Setup menu will appear.
b) Dish mounted on DiSEqC 1.2 motor
Set Antenna mode to DiSEqC 1.2, choose NEXT and press OK. The menu Adjust antenna will appear.
Select a transponder receivable at your location (choose Transponder and select with tu). Then
choose the Move Dish to adjust the position of the dish with the tu buttons. Once the dish is
adjusted to the desired position, select Store position and set the number of the position with the tu
keys. Then choose NEXT and press OK. The Channel Setup menu will be opened.
c) Dish mounted on GOTO X motor
Set Antenna mode to GOTO X, choose NEXT and press OK. The Adjust antenna screen appears.
Select a transponder receivable at your location (choose Transponder and select it with tu).
Then select My Longitude and enter the value of your longitude with the numeric keys. Use tu to
select hemisphere East or West. Then select My Latitude and use the numeric buttons to enter it's
value. Use tu to select hemisphere North or South. Select Goto Position and press OK. Your dish
will be turned to the position of the satellite. Select NEXT and press OK. The Channel Setup menu
will be opened.
Select NEXT and press OK to start the scan. When the scan is completed, the receiver will save the
services information automatically and exits to normal viewing mode.
5.0 MAIN MENU
All the important settings and features of your receiver can be operated in Main Menu. It consists
of the sub-menus: Channel Organizer, Installation, System setting, Timer and Multimedia. To open the
MAIN MENU press MENU.
5.1 Channel Organiser
In MAIN MENU press pq to move to Channel Organiser and press OK to enter this menu. It
consists of sub-menus Channel Manager and Favourites Manager.
5.1.1 Channel Manager
You can change the order of the channels, move, delete and edit channels. Use the RED button to
change the satellite,

10
Sort (GREEN button) You can sort channels by Name a~z, Name z~a, Free-CA, Fav–NO Fav or
Frequency Low-High.
Edit (YELLOW button) Select the channel you want to edit and press YELLOW (Edit) to enter
the modification submenu. Here you can edit Program Name, Frequency,
Symbol rate, Video PID and Audio PID.
Move channel Press pq to highlight the desired channel, press tu to highlight Move
and press OK to confirm selection of the channel. Use pq to move the
channel to its new location and press OK to confirm. Repeat this for every
channel you want to move.
Delete channel Press pq to highlight the desired channel, press tu to highlight Del
and press OK to mark the channel for deletion. Press EXIT and confirm
the channel’s deletion by selecting OK and pressing OK.
Delete all channels To delete all the channels from the current satellite, press BLUE (Del All).
You will be asked to confirm this operation.
5.1.2 Favourites Manager
Press pq to select the desired channel and tu to highlight the favourite group. Press OK to add
the selected channel to the favourite group. Repeat this operation to remove the channel from the
favourite list.
5.2 Installation
The installation menu consists of sub-menus “Antenna Installation”, “Auto Scan” and “Manual
Scan”.
5.2.1 Antenna Installation
You can add, edit and delete a satellite in this menu.
Add satellite Press the RED button. A satellite list will appear. Use tu to select the desired
satellite. If the desired satellite is not in the list, select “NEW SAT1”. After
selection of a satellite, the Configure Antenna menu will appear. Use this menu
to set the LNB Type, LNB Low Freq, LNB High Freq, Band control, Polarisation
control, DiSEqC Switch and Antenna mode. Further steps of the installation
process are described in chapter 4.2.
Edit satellite If the parameters of a satellite were changed or if you wish to add a new
satellite, you must set the parameters of the satellite, such as LNB type,
LNB low Freq, LNB High Freq, Transponder, LNB Power, 22k Tone, DiSEqC
and Antenna Mode. The sequence of editing satellite parameters is the
same as the sequence of Add satellite described in chapter 4.2
Delete satellite If you want to delete a satellite from the list, press YELLOW. A warning
message will appear. Select OK and press OK to confirm.
