Stryker 738 User manual

For Parts or Technical Assistance:
USA: 1-800-327-0770 (option 2)
Canada: 1-888-233-6888
Wide Transport
Stretcher
Model 738
Maintenance Manual
2007/04 0738-009-002 REV B www.stryker.com

www.stryker.com 0738-009-002 REV B 3
Table of Contents
Introduction...............................................................................5
IntendedUse..........................................................................5
Specifications .........................................................................5
Warning/Caution/NoteDefinition..........................................................5
Symbols.................................................................................6
SummaryofSafetyPrecautions................................................................7
PreventativeMaintenance....................................................................8
Checklist.............................................................................8
Cleaning.................................................................................9
Quick Reference Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ServiceInformation........................................................................11
CasterCoverInstallationandRemoval.......................................................11
CasterRemoval.......................................................................11
BrakeRodRemoval....................................................................12
ReleasePedalAdjustment ...............................................................14
FootEndReleasePedalReplacement.......................................................14
FootEndReleasePedalRodRemoval.......................................................14
FifthWheelAssemblyRemoval............................................................15
LitterTopRemoval.....................................................................16
JackDescentRateAdjustment............................................................16
Removal of Excess Air (Vacuum) From The Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Foot End Hydraulic Jack Removal (Base With Dual Controls) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
PneumaticFowlerAdjustment ............................................................18
FoldDownSiderailLatchAdjustment........................................................18
AssemblyDrawings........................................................................19
Retractable 5th WheelBaseAssembly-0853-006-110...........................................19
FifthWheelAssembly-0853-006-130.......................................................20
StandardBrakeAssembly(FifthWheelBase).................................................22
BrakeRodAssembly ...................................................................24
DriveLinkAssembly-0853-003-010........................................................25
DriveLinkAssembly-0853-006-135........................................................26
8”CasterAssembly-0753-010-220........................................................27
SideControlBrakeAssembly .............................................................28
BrakeRod/SideControlAssembly.........................................................31
SideControlBrakeSub-Assembly.........................................................32
StandardBrakeAssembly,ColoredComponents ...............................................33
SideControlBrakeAssembly,ColoredComponents.............................................33
DualSidedHydraulicsAssembly(FifthWheelBase) ............................................34
Standard Hydraulics Assembly, Colored Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
End Control Hydraulics Assembly, Colored Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
LoweringPedalAssembly-0853-004-251....................................................38
HeadEndPumpPedalAssembly-0853-005-285 ..............................................39
Non-Constant Descent Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4 0738-009-002 REV B www.stryker.com
Table of Contents
Non-ConstantJackAssembly-0753-002-170 .................................................41
JackBaseAssembly,VariableDescentJack..................................................42
BaseLabelingAssembly,StandardBrakes....................................................43
BaseLabelingAssembly,4-SidedBrakes.....................................................44
BaseLabeling,ColoredComponents........................................................45
BaseHoodDepartmentLabels............................................................45
LitterAssembly .......................................................................46
FowlertoLitterAssembly................................................................50
SiderailAssembly,Right&Left............................................................52
PneumaticFowlerAssembly..............................................................53
PneumaticFowlerOuterHousingAssembly...................................................54
OptionalKneeGatchAssembly............................................................55
OptionalKneeGatchCrankscrewAssembly ..................................................59
CornerCover,Assembly.................................................................61
CornerCover,PushHandleAssembly.......................................................62
CornerCover,2-StageI.V.PoleAssembly ....................................................63
Corner Cover, 2-Stage I.V. Pole, Push Handle Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
CornerCover,3-StageI.V.PoleAssembly ....................................................65
Corner Cover, 3-Stage I.V. Pole, Push Handle Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
PushHandleAssembly-1211-351-010.......................................................67
Standard, Removable I.V. Pole Assembly - 0390-025-022 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Optional 2-Stage I.V. Pole Assembly - 1211-210-010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
I.V.PoleLatchAssembly-1211-210-026......................................................70
Optional 3-Stage I.V. Pole Assembly - 1211-211-010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Optional 3-Stage I.V. Pole, 3rd StageAssembly.................................................72
Optional Defibrillator Tray Assembly - 0785-045-200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Foot Extension/Defibrillator Tray Assembly - 0785-045-400 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
FootBoard/ChartholderAssembly-0785-045-500..............................................76
Upright Oxygen Bottle Holder Assembly - 1020-130-000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
OptionalOxygenBottleRetainerAssembly ...................................................78
MattressesandSiderailPads.............................................................79
Warranty................................................................................80
LimitedWarranty ......................................................................80
ToObtainPartsandService..............................................................80
ServiceContractCoverage...............................................................80
ServiceContractPrograms...............................................................81
ReturnAuthorization....................................................................81
DamagedMerchandise..................................................................81
InternationalWarrantyClause.............................................................81
Assembly Drawings (Continued)

Return To Table of Contents
Introduction
INTENDED USE
This manual is designed to assist you with the maintenance of the Wide Transport Stretcher, Model 738. Carefully read
this manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe operation of this
equipment, it is recommended that methods and procedures be established for educating and training staff on the safe
operation of this stretcher.
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates
the sum of the patient, mattress, and
accessory weight.
500 pounds 227 Kilograms
Overall Stretcher Length \ Width 83” / 34” 211.65 cm / 86.3 cm
Minimum \ Maximum Bed Height 21.5” / 36” 54.83 cm / 91.8 cm
Fowler Angle 0° to 90°
Knee Gatch Angle 0° to 30°
Trendelenburg \ Reverse Trendelenburg +18° to -18°
Minimum Under Stretcher Clearance 6” (15 cm) nominal
1.75” (4.5 cm) under the hydraulic cylinders and 5th wheel
Stryker reserves the right to change specifications without notice.
Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION, and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also describe
potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to the
user or patient or damage to the equipment or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use or
misuse.
Note
This provides special information to make maintenance easier or important instructions clearer.
www.stryker.com 0738-009-002 REV B 5

Return To Table of Contents
Symbols
Consult accompanying documentation
Type B Equipment: equipment providing a particular degree of protection against electric shock,
particularly regarding allowable leakage current and reliability of the protective earth connection.
Alternating Current
Class 1 Equipment: equipment in which protection against electric shock does not rely on basic insulation
only, but which includes an additional safety precaution in that means are provided for the connection of
the equipment to the protective earth conductor in the fixed wiring of the installation in such a way that
accessible metal parts cannot become live in the event of a failure of the basic insulation.
Protection from liquid splash
Dangerous Voltage Symbol
Protective Earth Terminal
Medical Equipment Classified by Underwriters Laboratories Inc. with respect to Electric Shock, Fire,
Mechanical and Other Specified Hazards Only in Accordance with UL 60601-1, First Edition (2003) and
CAN/CSA C22.2 No. 601.1-M90 with updates 1 and 2.
Safe Working Load Symbol
In accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE), this symbol indicates that the product must not be disposed of as unsorted municipal waste,
but should be collected separately. Refer to your local distributor for return and/or collection systems
available in your country.
Potential Equalization Symbol
~
IPX4
6 0738-009-002 REV B www.stryker.com

Return To Table of Contents
Before operating this stretcher, it is important to read and understand all information in this manual. Carefully read and
strictly follow the warnings and cautions listed on this page.
WARNINGS
Always apply the caster brakes when a patient is getting on or off the stretcher. Push on the stretcher to ensure the
brakes are securely locked. Always engage the brakes unless the stretcher is being moved. Injury could result if the
stretcher moves while a patient is getting on or off the stretcher.
Be sure the siderail latching mechanism is working properly at all times. If it is not, refer to your stretcher maintenance
manual for ”Siderail Latch Adjustment”.
When lowering the siderail to the collapsed position, keep extremities of patients and staff away from the siderail
spindles or injury could occur.
Keep fingers/hands clear of area around the Fowler release handle and the Fowler frame when lowering. Injury
could result if care is not taken when lowering the Fowler.
If the stretcher is equipped with the optional foot end I.V. pole, the I.V. pole must be in the raised position when the
foot extension/defibrillator tray is installed. If the I.V. pole is not raised, the foot extension will not function properly
and injury could occur.
CAUTIONS
To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height.
To avoid injury or damage to the equipment, do not allow the siderail to lower on its own.
The push handles were designed for use while transporting the stretcher. Avoid using other parts of the stretcher as
push/pull devices because damage could occur.
If the Pneumatic Fowler is difficult to operate, refer to the stretcher maintenance manual for “Pneumatic Fowler
Adjustment”.
To avoid damage, the weight of the I.V. bags should not exceed 40 pounds.
To avoid damage while transporting the stretcher, verify the I.V. pole is at a low enough height to allow it to safely
pass through door openings and under light fixtures.
The unit cannot be raised (hydraulics on base) with a patient lift under the stretcher.
The hood may not be used for stepping.
Note
Clean hood storage area regularly.
The bottom of the brake rings should be cleaned regularly to prevent wax and/or floor remnant buildup.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Summary of Safety Precautions
www.stryker.com 0738-009-002 REV B 7

Return To Table of Contents
All fasteners secure.
Siderails move and latch properly.
Engage the brake pedal and push on the stretcher to ensure all casters lock securely.
All casters secure and swiveling properly.
Body restraints working properly.
I.V. pole intact and operating properly.
Oxygen bottle holder intact and operating properly.
Fowler operates and latches properly.
Trendelenburg/Reverse Trendelenburg operating properly.
No rips or cracks in mattress cover
Transfer boards intact and operating properly.
Ground chain intact.
No leaks at hydraulic connections.
Hydraulic jacks holding properly.
Hydraulic drop rate set properly.
Hydraulic oil level sufficient.
Lubricate where required.
Accessories and mounting hardware in good condition and working properly.
______
______
______
______
______
______
______
______
______
______
______
______
______
______
______
______
______
______
CHECKLIST
Preventative Maintenance
Note
Preventative maintenance should be performed at a minimum of annually. A preventative maintenance program should
be established for all Stryker Medical equipment. Preventative maintenance may need to be performed more frequently
based on the usage level of the product.
Stretcher Serial Number:
Completed by: _______________________________________ Date: _________________
8 0738-009-002 REV B www.stryker.com

Return To Table of Contents
Cleaning
Hand wash all surfaces of the stretcher with warm water and mild detergent. Dry thoroughly. Do not steam clean,
pressure wash, hose off or ultrasonically clean the stretcher. Using these methods of cleaning is not recommended and
may void this product’s warranty.
Suggested cleaners for stretcher surfaces:
Quaternary Cleaners (active ingredient - ammonium chloride).
Phenolic Cleaners (active ingredient - o-phenylphenol).
Chlorinated Bleach Solution (5.25% - less than 1 part bleach to 100 parts water).
Avoid over saturation and ensure the product does not stay wet longer than the chemical manufacturer’s guidelines for
proper disinfecting.
CAUTION
SOME CLEANING PRODUCTS ARE CORROSIVE IN NATURE AND MAY CAUSE DAMAGE TO THE PRODUCT IF USED
IMPROPERLY. If the products suggested above are used to clean Stryker patient care equipment, measures must be
taken to insure the stretcher is wiped with a damp cloth soaked in clean water and thoroughly dried following cleaning.
Failure to properly rinse and dry the stretcher will leave a corrosive residue on the surface of the stretcher, possibly
causing premature corrosion of critical components. Failure to follow the above directions when using these types of
cleaners may void this product’s warranty.
For mattress cleaning instructions, please see the tag on the mattress, or contact the mattress manufacturer.
Clean Velcro®after each use. Saturate Velcro®with disinfectant and allow disinfectant to evaporate. (Appropriate
disinfectant for nylon Velcro®should be determined by the hospital).
•
•
•
www.stryker.com 0738-009-002 REV B 9

Return To Table of Contents
Quick Reference Replacement Parts List
Note
The parts and accessories listed on this page are all currently available for purchase. Some of the parts identified on
the assembly drawing parts in this manual may not be individually available for purchase. Please call Stryker Customer
Service USA: 1-800-327-0770 (Option 2), Canada: 1-888-233-6888 for availability and pricing.
Part Name Part Number
Caster Assembly (1 complete) 0753-010-020
Defibrillator Tray/Foot Extension 0785-045-400
Foot Board/Chartholder Combination 0785-045-500
Foot Board (2 per package) 0946-029-100
Hydraulic Jack Assembly, Variable Descent 0753-002-170
I.V. Pole, Standard Removable 0390-025-000
Mattress, 3” x 30”, Enhanced Comfort 0785-034-313
Mattress, 4” x 30”, Enhanced Comfort 0785-034-323
Mattress, 4” x 30”, Ultra Comfort 0785-034-303
Mattress, 5” x 30”, Ultra Comfort 0785-034-333
Oxygen Bottle Holder, Upright 1020-030-000
Paint, Touch-Up, Gloss Black, Bottle w/Brush 7000-001-322
Paint, Touch-Up, Gloss Black, Spray Can 7000-001-319
Paint, Touch-Up, Gray, Bottle w/Brush 7000-001-320
Paint, Touch-Up, Gray, Spray Can 7000-001-317
Pneumatic Cylinder 1010-031-078
Restraint Strap, Ankle 0946-043-100
Restraint Straps, Body 0390-019-000
Restraint Strap, Wrist 0946-044-100
Siderail Pad Set 1010-052-000
10 0738-009-002 REV B www.stryker.com

Return To Table of Contents
CASTER COVER INSTALLATION AND REMOVAL
Tools Required:
9/16” Open End Wrench
Procedure:
Remove the caster cover.
While keeping pressure on the caster bolt with your index finger, use a 9/16” open end wrench to remove the nylock
hex nut on top of the caster assembly.
Using the brake ring, lift up on the base assembly and pull the caster assembly down to remove it.
Reverse steps 1-3 to install the new caster.
•
1.
2.
3.
4.
CASTER REMOVAL
Looking through the larger of the two side cut-outs, align the cover
with the axle nut or bolt head, as shown. Push down on the opposite
side of the cover until the single prong engages the caster horn.
Push on the cover with your palm until the double prongs engage.
To remove the wheel cover, insert a large screwdriver into the
cut-out in the side of the wheel cover and into the space between
the double prongs. Pry up the cover to disengage the double prongs
and push sharply upward to disengage the single prong.
1.
Single Prong
Top View (Cut-Away)
Double Prongs
2.
Properly Attached
Cover
Top View (Cut-Away)
3.
Top View (Cut-Away)
Service Information
www.stryker.com 0738-009-002 REV B 11

Return To Table of Contents
Service Information
BRAKE ROD REMOVAL
Tools Required:
Hammer
7/32” Punch
String or Bungee Cords
Procedure:
Pump the litter up to full height.
Lift the base hood and support it from the litter using string or bungee cords.
Remove the hex head cap screws connecting the brake rod supports to the base frame.
Remove the bolt connecting the drive link assembly to the fifth wheel cam.
Remove the rue ring cotter and clevis pin connecting the rod end link to the side control link.
Remove the rue ring cotter connecting the drive link assembly to the bearing pivot support on the base frame (under
the brake ring weldment).
Remove the three hex washer head screws holding the brake rod assembly to the base frame.
Remove the slotted spring pins connecting the butterfly “V” pedals, drive link assemblies and side control link to the
brake rod.
Reverse steps 1-8 to reinstall the brake rod. When reinstalling the brake rod supports, torque the hex head cap
screws to 5-13 ft. - lbs.
CAUTION
When reattaching the brake rod assembly to the base frame, set the torque specs no higher than 13 ft. - lbs. or damage
could occur to the bolts.
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
12 0738-009-002 REV B www.stryker.com

Return To Table of Contents
SIDE CONTROL BRAKE ROD REMOVAL
Tools Required:
Hammer
7/32” Punch
Needle Nose Pliers
String or Bungee Cords
Procedure:
Pump the litter up to full height.
Lift the base hood and support it from the litter using string or bungee cords.
Remove the rue ring cotter and clevis pin connecting the rod end link to the side control link.
Remove the four bolts holding the brake rod assembly to the base frame and remove the entire assembly.
Using a hammer and 7/32” punch, drive the slotted spring pin out of the butterfly “V” pedal on the patient’s left side
and remove the pedal,
Using a hammer and 7/32” punch, drive the slotted spring pin out of the hard stop in the center of the support
weldment.
Using a hammer and 7/32” punch, drive out the slotted spring pin connecting the side control link to the side control
brake rod on the patient’s right side.
Pull on the butterfly “V” pedal on the patient’s right side to remove the side control brake rod from the base.
Reverse steps 1-8 to reinstall the brake rod. When reinstalling the assembly, torque the hex head cap screws to
5-13 ft. - lbs.
CAUTION
When reattaching the brake rod assembly to the base frame, set the torque specs no higher than 13 ft. - lbs. or damage
could occur to the bolts.
•
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
Service information
www.stryker.com 0738-009-002 REV B 13

Return To Table of Contents
RELEASE PEDAL ADJUSTMENT
Procedure:
Manually disengage the release pedal swivel (item J on Dual Sided Hydraulics Assembly, Fifth Wheel Base section)
from the release pedal assembly.
To increase the release rod engagement with the release valve, turn the release pedal swivel clockwise on the
threaded release rod.
To decrease the release rod engagement with the release valve, turn the release pedal swivel counterclockwise on
the threaded release rod.
Note
If the pedal swivel assembly is threaded too far onto the release rod, the release valve will be partially activated and the
jack will drift.
FOOT END RELEASE PEDAL REPLACEMENT
Tools Required:
Needle Nose Pliers
Procedure:
Apply the stretcher brakes.
Disconnect the release pedal return springs from the foot end release pedals.
Remove the rue ring cotters and the clevis pins connecting the foot end release pedals to the mounting bracket.
Rotate the pedals upward.
Remove the rue ring cotters connecting the head end and foot end release rods to the foot end release pedals and
remove the pedals.
Reverse steps 2 - 5 to install the new pedals.
FOOT END RELEASE PEDAL ROD REMOVAL
Tools Required:
Needle Nose Pliers
Procedure:
Remove the foot end release pedal (see procedure on Foot End Release Pedal Replacement section).
Remove the snap in nyliners holding the foot end pedal release rods in the pedal mounting bracket.
Unsnap the foot end pedal release rods from the white plastic release rod brackets.
Dislodge the side control release pedal swivels from the studs on the side control release pedal weldment.
Remove the foot end pedal release rods.
Reverse steps 1 - 5 to reinstall the pedal rods.
1.
2.
3.
•
1.
2.
3.
4.
5.
6.
•
1.
2.
3.
4.
5.
6.
Service Information
14 0738-009-002 REV B www.stryker.com

Return To Table of Contents
BRAKE RING REMOVAL
Tools Required:
9/16” Socket With Extension
3/8” Drive Ratchet
Needle Nose Pliers
String or Bungee Cord
Procedure:
Pump the litter up to full height.
Lift the base hood and support it from the litter using string or bungee cords.
Using needle nose pliers, unhook the extension springs from the top of the base caster tubes.
Remove the plastic caster covers.
While putting pressure on the caster carriage bolt, use a 9/16” socket and a 3/8” drive ratchet to remove the caster
nut on both sides of the stretcher.
Remove the casters.
Remove the brake rod (see procedure).
Remove the cotter pin from the clevis pin in the center of the brake ring weldment.
Remove the cotter pin from the bearing pivot support.
Remove the 3/4” nylock hex nut from the bearing pivot support.
Remove the drive link assembly.
Pull the brake ring down and out away from the stretcher base frame.
Reverse steps 1 - 12 to reinstall the brake ring.
FIFTH WHEEL ASSEMBLY REMOVAL
Tools Required:
1/2” Socket
3/8” Drive Ratchet
Procedure:
Using a 1/2” socket and 3/8” drive ratchet, remove the 1/2” bolt holding the fifth wheel cam drive link and fifth
wheel drive link to the fifth wheel cam.
Remove the two 1/2” bolts holding the fifth wheel mounting bracket to the base frame weldment.
Remove the fifth wheel assembly.
Reverse steps 1 and 2 to reinstall the fifth wheel. When reinstalling the assembly, torque the hex head cap screws
to 5 - 13 ft. - lbs.
CAUTION
When reattaching the fifth wheel assembly to the base frame, set the torque specs no higher than 13 ft. - lbs. or dam-
age could occur to the bolts.
•
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
•
•
1.
2.
3.
4.
Service information
www.stryker.com 0738-009-002 REV B 15

Return To Table of Contents
Service Information
LITTER TOP REMOVAL
Tools Required:
1/2” Socket W/Extension
3/8” Drive Ratchet
Standard Screwdriver
Procedure:
Using the foot pedal, pump up the litter top to full height.
Remove the stretcher mattress
Remove the round, black hole plugs from the jack supports at each end of the litter to expose the jack support tube
truss head screws.
Using a 1/2” socket, and a 3/8” drive ratchet, remove the truss head screws holding the jack support tubes to the
jack shafts.
Thread a 7/16 - 20 fine thread bolt far enough into the top of the jack supports to separate the litter top from the
jack shaft.
With the assistance of another person, lift the litter straight up to remove it from the jack shafts and set it aside.
JACK DESCENT RATE ADJUSTMENT
Tools Required:
Screwdriver
Bungee Cords (or equivalent)
Procedure:
Pump the litter up to full height.
Lift the base hood, separating the hood from the base frame. Support the hood from the litter using bungee cords
so it is out of the way.
The descent rate needle valve is located on the base of the jack. Turning the needle valve clockwise, with a
screwdriver, will decrease the rate of descent. Turning it counterclockwise will increase the rate of descent.
Note
The larger percentage of a patient’s weight is located in the torso area. Adjust descent rate accordingly.
Remove the bungee cords supporting the base hood and secure the hood to the base frame.
Note
The jack descent rate is preset at the factory and adjustment is not recommended.
REMOVAL OF EXCESS AIR (VACUUM) FROM THE HYDRAULIC SYSTEM
Verify all hydraulic linkages are secure and operating properly.
Using the pump pedal, actuate the system several times to force the air through the system. The jack should now
raise properly.
•
•
•
1.
2.
3.
4.
5.
6.
•
•
1.
2.
3.
4.
1.
2.
16 0738-009-002 REV B www.stryker.com

Return To Table of Contents
HEAD END HYDRAULIC JACK REMOVAL
Tools Required:
1/2” Socket With Extension
3/8” Drive Ratchet
Procedure:
Remove the litter top from the stretcher (see Litter Top Removal section).
Using a 1/2” socket with extension and a 3/8” drive ratchet, remove the two hex head screws holding the jack base
to the stretcher base frame.
Remove the two hex head screws holding the jack reservoir clamp to the base frame and remove the clamps.
Lift straight up on the pump connecting rod and disconnect the pump piston from the connecting rod.
Disconnect the pump pedal swivel from the release pedal mounting plate.
Remove the head end release rod from the release valve assembly.
Using a 1/2” socket with extension and a 3/8” drive ratchet, remove the two hex head screws holding the jack base
to the stretcher base frame.
Lift out the jack assembly.
To reinstall the jack, install the bolts on the jack and reservoir clamp but do not tighten them fully.
Reinstall the pump connecting rod and release rod.
Depress the pump pedal fully (to the floor). This will properly locate the jack onto the base frame.
Tighten the bolts on the jack and reservoir clamp.
Pump up the litter and apply weight to verify the jacks hold and do not drift.
Note
The jack descent rate is preset at the factory and adjustment is not recommended.
FOOT END HYDRAULIC JACK REMOVAL (BASE WITH DUAL CONTROLS)
Tools Required:
1/2” Socket
3/8” Drive Ratchet
Pliers
Procedure:
Remove the litter top from the stretcher (see Litter Top Removal section).
Lift the base hood off the base frame.
Remove the two hex washer head screws and washers connecting the pump pedal link to the foot end pump pedal
assembly and pump connecting rod.
Remove the foot end release rod from the release valve on the jack assembly by dislodging the release pedal swivel
from the pins on the release pedal weldment.
Dislodge the jack pump piston from the pump connecting rod.
Remove the two hex washer head screws holding the reservoir clamp.
Remove the jack assembly.
Reverse steps 1 - 7 to install the new jack.
Note
The jack descent rate is preset at the factory and adjustment is not recommended.
•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
Service information
www.stryker.com 0738-009-002 REV B 17

Return To Table of Contents
Service Information
PNEUMATIC FOWLER ADJUSTMENT
Tools Required:
5/32” Hex Allen Wrench
1/2” Open End Wrench
Procedure:
Refer to the Pneumatic Fowler Assembly drawing for parts reference.
For easier access, raise the Fowler to 75° or higher.
Using a 1/2” open end wrench, loosen the hex nuts (item E) in the actuator arms on the end of the trip bar
(item M).
To adjust the Fowler, use a 5/32” hex Allen wrench to turn the Allen screws (item J) 1 to 2 turns counterclockwise
if the Fowler will not move or 1 to 2 turns clockwise if the Fowler will not hold its position.
Retighten the hex nuts. Be sure the Fowler travels from flat up to 90° and down again and holds its position when
weight is applied before returning the stretcher to service.
FOLD DOWN SIDERAIL LATCH ADJUSTMENT
Tools Required:
1/8” Hex Allen Wrench
WARNING
The siderail latches are preset at the factory, and do not normally need adjustment. If adjustment must be done, it is
important to follow the procedure below. If adjustment is not done properly, injury to the patient or user could result.
Procedure:
Using a 1/8” hex Allen wrench, adjust the hex Allen screw located on the latch assembly opposite the latch. Turning
the screw clockwise will decrease the amount of ”play” in the latching mechanism. Turning counterclockwise will
increase the amount.
Note
The amount of “play” in the siderail, when in full up engaged position, should be approximately 1/8 to 3/16 inches.
CAUTION
Too much “play” when the siderail is in the full up engaged position will give the siderail the appearance of being unstable
and could also cause premature wearing of the latch system.
Too little “play” will obstruct the latch and keep it from engaging completely in the full up position, which may result in
damage to the latch and/or injury to the patient or user
•
•
1.
2.
3.
4.
5.
•
1.
18 0738-009-002 REV B www.stryker.com

Return To Table of Contents
Retractable 5th Wheel Base Assembly - 0853-006-110
Item Part No. Part Name Qty.
A 0023-288-000 Hex Washer Head Screw 2
B 0023-305-000 Hex Head Cap Screw 1
C 0753-006-148 Cam Bearing 1
D 0853-006-130 Fifth Wheel Assembly 1
www.stryker.com 0738-009-002 REV B 19

Return To Table of Contents
Fifth Wheel Assembly - 0853-006-130
20 0738-009-002 REV B www.stryker.com
