Stryker EOLE Manual

2013/10 A.0 2870-009-001 REV. A www.stryker.com
EOLE Powered Support Surface
2870
Operations/Maintenance Manual

www.stryker.com 2870-009-001 REV. A 3
Table of Contents
Symbols and Denitions................................................................ 4
Symbols ......................................................................... 4
Warning/Caution/Note Denition ...................................................... 5
Technical Specication................................................................. 6
Introduction.......................................................................... 7
Contraindications .................................................................. 7
Intended Use of Product ............................................................ 7
Expected Service Life .............................................................. 7
Product Description ................................................................ 7
Contact Information ................................................................ 8
Product Serial Number Location/Identication ........................................... 8
Summary of Safety Precautions.......................................................... 9
Product Description .................................................................. 10
Control Unit Front................................................................. 10
Control Unit Rear ................................................................. 10
Control Panel .................................................................... 10
Instructions..........................................................................11
Installing the Control Unit............................................................11
Product Functions ................................................................ 12
Transport Mode .................................................................. 13
Storage ........................................................................ 13
Cleaning and Disinfection.............................................................. 14
Trouble Shooting .................................................................... 15
Service Information .................................................................. 16
Top Cover Replacement ........................................................... 16
Base Replacement................................................................ 16
Air Cell Replacement .............................................................. 16
Control Unit Replacement .......................................................... 16
Hose Replacement ............................................................... 16
CPC Tube Replacement ........................................................... 17
Filter Replacement................................................................ 17
Preventative Maintenance ............................................................. 18
Checklist ....................................................................... 18
Appendix A: EMC Information .......................................................... 20
Guidance and Manufacturer’s Declaration - Electromagnetic Emissions:...................... 20
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity: ...................... 20
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity: ...................... 21
Recommended Separation Distances ................................................. 22
Warranty........................................................................... 23
Limited Warranty ................................................................. 23
To Obtain Parts and Service ........................................................ 23
Return Authorization .............................................................. 23
Damaged Merchandise ............................................................ 23
International Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

42870-009-001 REV. A www.stryker.com
Return To Table of Contents
Symbols and Denitions
SYMBOLS
TUV marking
CE marking
Warning / Caution, consult accompanying documentation
Type BF equipment
Double Insulation
Fuse
Temperature Limitation, Operating: 10°C to 40°C, Storage: -15°C to 50°C
Humidity Limitation, 10% - 90%
Refer to instruction manual/ booklet
Disposal: Contact local distributor who will take the necessary steps according to your
national market.
Do Not Iron
maximum washing temperature 60°C, normal process, only for top cover of mattress
Chlorinated Bleach
Do Not Tumble Dry
Do Not Dry Clean
Allow to Completely Air Dry
Manufacturer
IP24
First Digit (Solids) Protected against touch by ngers (>12.5mm); Second Digit (Liquids)
Water splashing against the enclosure from any direction shall have no harmful effect.
Authorized representative in the European community
Catalogue Number (model)
SN
Serial Number
CPR
Do Not Open with Cutter

www.stryker.com 2870-009-001 REV. A 5
Return To Table of Contents
WARNING/CAUTION/NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alert the reader about a situation which, if not avoided, could result in death or serious injury. It may also
describe potential serious adverse reactions and safety hazards.
CAUTION
Alert the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury to the user or patient or damage to the equipment or other property. This includes special care necessary
for the safe and effective use of the device and the care necessary to avoid damage to a device that may
occur as a result of use or misuse.
NOTE
Provide special information to make maintenance easier or important instructions clearer.
Symbols and Denitions
