StudioDesk Enterprise Series User manual

The Desk You Deserve
ASSEMBLY MANUAL
Enterprise Electric Series and Keyboard pull out option
NOTE: In order to avoid injury or damages,
please do not try to assemble your desk alone.
The Beat is massive and heavy desk and requires
at least t o people to carry out assembly.
Please assemble on soft surface to avoid
scratches to the lacquer.
!
.studiodesk.net
Video Assembly manual is also available.
Search for Enterprise Electric desk - Video assembly manual on the YouTube.

The Desk You Deserve
Thank you for making StudioDesk your desk of choice!
Before beginning assembly of your desk, let’s get familiar ith the parts you have received in your package.
Please match the corresponding numbers on this page ith the dra ings.
1. Desk Surface 2. Rack dividers - (Left and right) 3. Speaker shelves
4. Legs (left and right) 5. Rack top shelf 6. Strengthening Bar 7. Top shelf 8 .Armrest 9 .Electric platform
Hardware
Wooden parts
Tools needed (Not included)
Rubber hammer
Phillips Scre driver
Hexagon Wrench
Included
1
7
2
3
4
56
8
9

1
Step One
Place desk top to the soft surface and install desk base as
Sho n on the picture belo . Please note that large holes in the
Middle has to be turned out.
2
Step Two
Fix the metal bridge to the base as sho n on
the right.
8
10
.studiodesk.net
Install legs ith motors as sho n left.
Use M6 scre s ith Hexagon head enclosed
to Electric platform.
3
Step Three
4
Step Four
Slide in the Controller as sho n on the picture on
the right.

5
Step Five
Install the cable management using
Washers and M6 ith cross head scre s.
8
Step Eight
8
10
6
Step Six
Install the stabilizing bridge as sho n on the picture
on the left.
7
Step Seven
Install desk glides as sho n on the picture.
Install the LED controller into the carved
space as sho n left. For more detailed
Explanation, please check video assembly
manual. Find the link on the first page of this
manual.

9
Step Nine
If you purchased optional Keyboard tray follo this step.
Install limiter belt as sho n belo . The belt has function of
Limiting the keyboard pull out farther than you need.
11
Step Eleven
Turn desk to the standing position.
Minimum 2 people is needed to do this step.
Fix the armrest using scre s M6 x 25 scre s.
Do not use electric machines here.
At first insert scre s ith the hand in place
And fasten it using small hexagon rench tool
included in your hard are.
10
Step Ten
Insert ooden do els as sho n on the picture
On the right side. Be gentle hile doing that.
Set rack dividers in place as sho n.
OPTIONAL

12
Step Twelve
Install metal brackets to the top shelf as
sho n on the right, using M6 scre s ith cross head.
If you ordered optional rack rails for another 2U rack’s
Install them no using M6 Scre s.
13
Step Thirteen
Carefully place top shelf on the rack dividers
and fix it to the dividers ith previously
Installed metal brackets
14
Step Fourteen
Insert scre s ith the plastic head as sho n on the right.
Do that on the both sides. This scre ill hold your speaker
Shelves. You ill not be able to insert it later so please do this
No .
15
Step Fifteen
Install sides to desk surface and top shelf
By matching holes on the sides
With ooden do els. Side must be pushed
In all the ay so there is no gap in bet een
Side and desk surface and top shelf.

16
Step Sixteen
Fix sides to the desk surface ith M6 scre s
With cross head as sho n on the right.
17
Step Seventeen
Fix sides to the desk surface ith M6 scre s
Also from the bottom side as sho n on the left.
18
Step Eighteen
Inside rack shelf by pushing it on
The ooden do els.
Step Nineteen
Install electric platform
Controller and connecting it
to the controller underneath.
19
Step Twenty
Install rack rails using M6 Scre s
With Cross head.
20

Step Twenty one
Install cable inlay on the top
Shelf. Use rubber hammer if needed.
21
Step Twenty one
Install Shelf holder to the speaker shelf
using scre s for ood 4x20.
21
Step Twenty two
Fix top shelf holder over metal plate
by scre ing scre ith the plastic head into
the holder. This operation can be performed ith
Hand only.
22
Step Twenty three
If you purchase optional key oard pull out, here is how to assem le it.
23
Put together sides of the pull out
and keyboard main board as sho n
on the left. Ball mechanism is
pre-installed

Step Twenty four
24
Scre vertical board to the keyboard
Desk board using Confirmat scre s.
Leave middle scre s unscre ed.
Step Twenty five 25
Install adjustable brackets to the
sides as sho n on the right on the both sides.
Measure your keyboard height before fixing It to the desk.
Fix all brackets on the same level according to your needs.
IMPORTANT! Use Hexagon M6 Screws here
Step Twenty six 26
Please use help of another two pair of hands here.
While to people fastening pull out to the desk using M6 scre s,
third person helping to hold it into the position.
First, fasten scre (1) on the back and scre on the front (2) on both
sides. This ill allo you to fasten rest of the scre s in place hile pull out
hangs on scre s.
Last step is to fasten the left out confirmat scre (3) from step Nine
trough the hole on the Limiter belt.
1
2
3
Congratulations, your rand new desk is ready!
