Mocka Zack User manual

E1 E2
E3
E4
mocka.co.nzImocka.com.au
Thank you for your purchase. Please follow the instructions for
correct assembly. While we took great effort to ensure these
assembly instructions were correct at the time of printing,
sometimes updates are required post production. For the most up
to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
A
screw 50mm
x4
B C D
Phillips&Flatheadscrewdriversrequired.
Forquickerassembly,werecommendthe
useofapowerdrillonalow-speedsetting.
WARNING: Anyfurniturethatisnotanchoredtoawallhasthepotentialtotip
overincertaincircumstances,i.e.ifachildattemptstoclimbuponthe
furnitureorintheeventofanearthquake.Accordingly,werecommendthat
allfurnitureisanchoredtoawall.Wesupplyafreesafetywallanchorwithall
furnituresoldandwerecommend theseareusedto preventyourproduct
tipping.Thefixingdeviceprovidedshouldfitmostwalltypes,butpleasenote
thatdifferentwallmaterialsmayrequiredifferentfixingdevicesfromthose
supplied.
bolt & nut
x20
x6
dowel
x8
E
F G H I J
screw 14mm
x12 slide rail
x1
screw 18mm
x6
Zack 
BedsideTable
screw 25mm
x2 x2 x2
wall plug safety strap
brace

mocka.co.nzImocka.com.au
1 2
4
3
E3
E1 DD
D
D
7
67
6
A
A
A
Zack 
BedsideTable
Attach slide rails (E1) and (E3) to panels [3] and [4] with 6 × screws (D). Insert 8 × nuts (A) to panels [6] and [7].
Attach panels [6] to panels [7] with 4 × bolts (A).

mocka.co.nzImocka.com.au
34
A
A
2
A
A
A
A
A
A
7
6
A
B
B
A
A
A
3
4
2
Zack 
BedsideTable
Attach panel [2] to panels [6] and [7] with 4 × bolts (A). Insert 8 × nuts (A) to panels [3] and [4].
Attach panels [3] and [4] to panel [2] with 4 × bolts (A) and 4 × dowels (B).

mocka.co.nzImocka.com.au
56
A
B
A
A
5
4
3
4
3
1
A
B
B
A
A
B
Zack 
BedsideTable
Slide panel [5] into position as shown. Attach panel [1] to panels [3] and [4] with 4 × bolts (A) and 4 × dowels (B).

mocka.co.nzImocka.com.au
78
G
F
5
C
D
C
C
C
12
11
9
10
Zack 
BedsideTable
Insert 6 × braces (G) to panel [5] with 6 × screws (F). Attach panels [9] and [10] to panel [11] with 4 × screws (C).

mocka.co.nzImocka.com.au
910
A
A
A
A
A
A
A
A
A
9
10
A
A
A
A
8
D
D
D
D
E2
E4
10
9
Zack 
BedsideTable
Insert 4 × nuts (A) into panels [9] and [10].
Attach panel 8 to panels [9] and [10] with 4 × bolts (A) . Attach slide rails (E2) and (E4) to panels [9] and [10] with 4 × screws (D) .

mocka.co.nzImocka.com.au
11 12 H
I
J
D
J
JD
Zack 
BedsideTable
Insert the drawer to the cabinet as shown. Once assembled lift furniture into place, do not drag. Use a drill to
create a small hole lining up with the top of the 2 × safety straps (J)
and 2 × screws (D) . Fasten to the wall using 2 × wall plugs (I) and
2 × screws (H). Ensure unit is balanced and steady before use.

mocka.co.nzImocka.com.au
13
Zack 
BedsideTable
You`re done, enjoy!
