StudioDesk PAK01 User manual

PAK01 PRO Line pull out option White
PAK02 PRO Line pull out option Black
Please assemble your product on soft
surface to avoid scratches and damages
on lacquer.
!
www.studiodesk.net

The Desk You Deserve
ThankyouformakingStudioDeskyourdeskofchoice!
Before beginning assembly of your pull out option keyboard tray, let’s get familiar with the parts you have
received in your package. Please match the corresponding numbers on this page with the drawings.
1. Left divider
2. Right divider
3. Shelf
Hardware
Wooden parts
Tools needed (Not included)
4
Sliding mechanism
5
6
2
1
3
M6 Screw
6
6
5
5
5
5
L Brackets
16 pcs

Before middle portion of the PRO Line desk is
assembled, you should fix pull out option
dividers on the corresponding holes on the
bottom of the main desk surface.
2 Step Two
Place dividers on the bottom surface
over corresponding holes of the Pro
Line main desk surface and fix them
using M6 screws.
1 Step One
Fix metal brackets (5) to
the dividers (1,2) using M6
screws (4) as shown on the
illustration left. Repeat this
procedure on both dividers.
www.studiodesk.net

3 Step Three
Once your Pro line desk will be completely
assembled, carefully put shelf on the sliding
mechanism rails and slowly push it inwards
all the way.
4 Your sliding mechanism is equipped with
safety breaks (10) to prevent movements
of tray while playing and pulling keyboard
tray all the way out. Once locked in open
position, press breaks on both sides
simultaneously to unlock and push tray
inward.
NOTE!
Should you have need to de-assemble
your tray from the desk, press both breaks
simultaneously and pull tray out.
Step 4
NOTE: Maximum safe load is 12 kg.
10
*Sliding mechanism might vary from time to time
