Style selections 22BV90034-NT01 Setup guide

1
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Friday.
ITEM #0726714
MODEL # 22BV90034-NT01
PEDESTAL SINK STORAGE CABINET
Français p.18
Style Selections® is a registered trademark
of LF, LLC. All rights reserved.
EB1686

2
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
WARNING:
• Some steps are more easily handled with two adults.
• Assembly and unpacking requires 2 adults.
CAUTION:
• Before installation, carefully use scissors or utility knife to cut and unwrap all parts.
SAVE THESE INSTRUCTIONS.

3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Bottom Panel 1
BBottom Apron 1
C Toe Kick 1
D Left Front Rail 1
E Right Front Rail 1
F Left Side Panel 1
G Top Panel 1
H Right Side Panel 1
ITop Apron 1
J Left Back Panel 1
K Right Back Panel 1
L Left Door 1
M Right Door 1
L
M
A
F
HK
J
G
C
B
D
E
I

4
HARDWARE CONTENTS (not shown to size)
Cam Bolt
Wood Dowel
Hinge Small Screw
Cam Lock
Handle
Long Screw Handle Screw Touch-up Pen
Qty: 30Qty: 30
Qty: 4 Qty: 8
Qty: 30
Qty: 2
Qty: 4 Qty: 4 Qty: 1
BBAA CC
DD
GG HH II
EE FF

5
AA
BB
B
PREPARATION
Before beginning assembly of product, carefully use scissors or utility knife to cut and unwrap all parts.
Make sure all parts are present. Compare parts with package contents list and hardware contents list. If
any part is missing or damaged, do not attempt to assemble the product.
Estimated assembly time: 60 minutes.
Tools required for assembly (not included): Phillips screwdriver, utility knife or scissors.
Helpful tools (not included): Measuring tape, level
ASSEMBLY INSTRUCTIONS
1. Insert wood dowels (AA) into the inside pre-drilled
holes on bottom apron (B).
Using a Phillips screwdriver (not included), insert
cam bolts (BB) into the outside pre-drilled holes on
bottom apron (B).
1
Hardware Used
x 2
x 2
Wood Dowel
Cam Bolt
AA
BB

6
2. Attach bottom apron (B) to bottom panel (A),
securing with cam locks (CC).
3. Insert wood dowels (AA) and cam bolts (BB) into
pre-drilled holes on bottom panel (A) as shown.
2
3
Hardware Used
Hardware Used
CC Cam Lock x 2
B
CC
A
A
x 2
x 2
Wood Dowel
Cam Bolt
AA
BB
AA
BB

7
4. Attach toe kick (C) to bottom panel (A), securing with
cam locks (CC).
5. Insert wood dowels (AA) and cam bolts (BB) into
pre-drilled holes on left front rail (D) and right front
rail (E) as shown.
4
5
Hardware Used
Hardware Used
CC
ED
A
C
AA
CC Cam Lock x 2
AA
BB
x 6
x 6
Wood Dowel
Cam Bolt
AA
BB

8
F
H
6. Insert cam bolts (BB) into pre-drilled holes on left
side panel (F) and right side panel (H) as shown.
7. Attach left side panel (F) to left front rail (D),
securing with cam locks (CC).
Repeat this step to attach right side panel (H) to
right front rail (E).
6
7
Hardware Used
Hardware Used
BB
x 12
Cam Bolt
BB
E
CC
H
D
F
CC Cam Lock x 6

9
H
E
8. Insert wood dowels (AA) into pre-drilled holes on
right side panel (H) as shown.
9. Attach bottom panel (A) to right side panel (H),
securing with cam locks (CC).
8
9
Hardware Used
Hardware Used
CC Cam Lock x 3
AA
x 5
Wood Dowel
AA
A
CC
H

10
10. Attach right back panel (K) to right side
panel (H), securing with cam locks (CC).
Then, attach top apron (I) to right front rail (E) on
right side panel (H).
11. Insert wood dowels (AA) into pre-drilled holes on
bottom panel (A), bottom apron (B), top apron (I)
and toe kick (C) as shown.
10
11
Hardware Used
Hardware Used
I
E
K
H
A
B
I
AA
CC Cam Lock x 3
x 5
Wood Dowel
AA
C

11
12. Attach left side panel (F) to the assembly as shown,
securing with cam locks (CC).
13. Attach left back panel (J) to left side panel (F),
securing with cam locks (CC).
12
13
Hardware Used
Hardware Used
CC Cam Lock x 3
F
B
I
C
J
F
CC Cam Lock x 3
CC
CC

12
14. Secure the left back panel (J) and right back
panel (K) using long screws (GG).
15. Stand the assembled unit upright. Insert wood
dowels (AA) into the pre-drilled holes as shown.
14
15
Hardware Used
Hardware Used
GG Long Screw x 4
I
J
K
J
AA
F
H
K
x 10
Wood Dowel
AA

13
16. On a at surface, turn top panel (G) upside
down. Insert cam bolts (BB) into the pre-drilled
holes as shown.
17. Attach top panel (G) to the assembly as shown,
securing with cam locks (CC).
16
Hardware Used
Hardware Used
BB
G
x 8
Cam Bolt
BB
17
CC Cam Lock x 8
G

14
18. On a at surface, turn left door (L) and right door
(M) upside down. Attach hinges (EE) as shown
using small screws (FF).
19. Attach handle (DD) to left door (L) and right door
(M) using handle screws (HH) from inside the
doors.
18
Hardware Used
Hardware Used
L
x 4
x 8
Hinge
Small Screw
EE
FF
19
HH
DD
Handle Screw
Handle
x 4
x 2
M
FF
EE
L
M
HH
DD

15
20. Attach left door (L) and right door (M) to the front
rails of the assembly using the preassembled
screws on the hinges (EE).
To adjust the doors right or left, loosen/tighten
the screws as in (a).
To adjust the doors forward or backward, change
keyhole slot position as in (b).
To adjust the doors up or down, adjust bracket
height as in (c).
21. Assembly is now complete. With the assistance
 ofanotherperson,moveassemblytoitsnal
location against a pedestal sink (sold separately).
20
21
L
M
EE
Wall
ab c

16
CARE AND MAINTENANCE
• Dust the item regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the item with a gentle, non-abrasive household cleaner.
Make sure to dry the wood immediately with a soft cloth or towel.
• The top can be cleaned using standard stone cleaning agents available at your local supplier.
• Tips for using the touch-up pen (II): For scratches, stroke in direction of scratch. For worn
areas, stroke in direction of wood grain. Rub excess colorant promptly with a soft cloth.
1-YEAR LIMITED WARRANTY
The manufacturer warrants this product to be free from manufacturing and material defects for a period of
one year from date of purchase, subject to the following conditions and limitations.
1. Install and operate this item in accordance with the installation and operating
instructions furnished with the product at all times. Any unauthorized repair, alteration, willful abuse,
accident or misuse of the product shall nullify this warranty.
2. This warranty is non-transferable, and is made to the original owner, provided the purchase was
made through an authorized supplier of the product.
3. The warranty is limited to the repair or replacement of part(s) found to be defective in material or
workmanship, provided that such part(s) have been subjected to normal conditions of use and
service, after said defect is conrmed by the manufacturer’s inspection.
4. The manufacturer may, at its discretion, fully discharge all obligations with respect to this warranty by
refunding the wholesale price of the defective part(s).
5. Any installation, labor, construction, transportation or other related costs/expenses arising from
defective part(s), repair, replacement or otherwise of same, will not be covered by this warranty,
nor shall the manufacturer assume responsibility for same.
6. The owner/user assumes all other risks, if any, including the risk of any direct, indirect or
consequential loss or damage arising out of the use, or inability to use the product, except
as provided by law.
7. All other warranties – expressed or implied – with respect to the product, its components and
accessories, or any obligations/liabilities on the part of the manufacturer are hereby expressly
excluded.
8. The manufacturer neither assumes, nor authorizes any third party to assume on its behalf, any other
liabilities with respect to the sale of the product.
9. The warranties as outlined within this document do not apply to non accessories used in conjunction
with the installation of this product.
10. This warranty gives you specic legal rights, and you may also have other rights which vary from
state to state.
This warranty is void if:
a. Care and maintenance instructions are not followed.
b. Any unauthorized alteration, willful abuse, accident, or misuse of the product.
c. You do not have the original receipt of purchase.
IF WARRANTY SERVICE IS NEEDED
Contact the manufacturer by calling the customer service department at 1-877-888-8225, 8 a.m. - 8 p.m.,
EST, Monday - Friday. Make sure to have the warranty, sales receipt, location of purchase and the model
serial number of the product.

17
For replacement parts, call our customer service department at 1-877-888-8225,
8 a.m. - 8 p.m., EST, Monday - Friday.
REPLACEMENT PARTS LIST
PART DESCRIPTION PART #
1 Floor Glide PH-GLDBRW001
2 Door Bumper PH-BMPBLK002
