Subaru E7110CC000 User manual

1
△00
Usenonaneasa
cleaningagent.
Wastecloth Cleaningagent Maskingtape
（Besuretocheckthecomponentsbeforestartingwork）
E7110CC000GenuinePartNumber：
BRZ（ZD）A〜ApplicableModel：
Thankyouforpurchasingtheairoutletgarnish.
Beforeinstallingthisproduct,pleasereadthis
manualcarefullytoensureproperinstallation.
Installation Manual
AIROUTLETGARNISH
Components
Tools
InstallationCompletionIllustration
Distributor Co.,Ltd.
PartDescription Quantity
AiroutletgarnishRH
AiroutletgarnishLH
PaperPattern
1
1
1
Ｎｏ.
①
②
③
②
③
①
Repairpartmodelnumber
・E7110CC001 RH
・E7110CC002 LH
050mm
02in
Scale
050mm 02in
Scale
R H
L H

2
AIROUTLETGARNISH
Request
Beforeinstallingthisproduct,pleaseensuretoreadthismanualandcarryoutproperinstallation.
Forinstallationworkers
Thismanualexplainshowtoinstallandhandletheairoutletgarnish.
！Precautions
1.Whenattachingthisproducttoacar,parkthecaronaflatsurfaceandsecurelyapply
theparkingbrakebeforecarryingoutthework.
2.Whenattachingthisproducttoacar,handleitwithgreatcareanddonotdropitorstep
onit,otherwiseitmaygetdamaged.
3.Beforestartingtheinstallationwork,washthecarandusenonaneandawasteclothto
wipeoffdirt,oilfilms,etc.adheredtoaroundthefenders.Ifcleaningisinsufficient,it
maycausethisproducttopeel.
4.Theadhesivestrengthofthedouble-sidedtapeattachedtothisproductdecreaseswhen
theairtemperatureis15 °Corlower.Beforeattachingthisproduct,useahairdryerto
warmupthedouble-sidedtapeandthesurfaceoftheareawherethisproductwillbe
attached.
5.Donotusethinnerorothersolventsonthecoatingsurfacesoftheairoutletgarnishes,
orthesurfacesmaybecomedeteriorated.Keepthemawayfromfire;otherwise,they
maybecomedeformed.
6.Donotforciblybendtheairoutletgarnishesorrubthemwithsomethingsharp;
otherwise,thecoatingsurfacesmaybecomedamaged.
7.Theairoutletgarnishdoesnotprovidesufficientadhesivestrengthwhenitis
reattachedtoacar.Therefore,carryouttheworkwithcaretopreventtheneedfor
reattachmentwork.Moreover,absolutelyavoidgettingthecarwetbywashingit,etc.
within24hoursaftertheinstallationworkiscomplete.Otherwise,itmaycausethe
adhesivetopeel.
8.Duringtheinstallationwork,paycarefulattentionnottodamagethecar.
9.Inparticular,weaskyoutostrictlyobservethe" ! Precautions"inordertocarryoutthe
installationworksafelyandsecurelywithoutphysicallydamagingcomponents,etc.
10.Aftercompletingtheattachmentofthisproduct,ensurethatthereisnopeelinginthe
attachedareaornoadhesivejointfailure,includingseparation.
11.Whenacarhasundergoneabodycoatingtreatmentincludingglasscoating,this
productcannotexhibititsoriginaladhesiveperformance.
Pleaseconfirmwhetherornotabodycoatingtreatmentisappliedtothecar.
Moreover,ensuretoremovedirt,oilsandfats,etc.adheringtothesurfaceonwhichthe
productistobeattached,andalsousesufficientpressuretoattachittothecar.
<<Howtoremoveabodycoatingfilmandconfirmtheremoval>>
-Useafine-grainedcompoundagent(soasnottoaffectthecar'spaint)torubthecoating
filmofftheareaonwhichtheproductistobeattached.
-Afterpolishingthearea,spraywateronit.Youcanconfirmthatthecoatingfilmhasbeen
removedwhenthereisnorepellingofwateronthearea.

Removeanydirtbywashingtheentiresurface,
showninthefigureontheleft,onwhichtheair
outlet garnish is to be installed, and degrease
thesurfacewithacleaningdetergent.
Afterdegreasingthesurfacepriortoinstallation,
payattentiontopreventtheadherenceofdirtor
dust. Carry out the installation work after the
surfaceiscompletelydry.[Figure1]
Use a pair of scissors to cut out the paper
patternsprintedonthesuppliedpaper.
(The paper patterns shown in this manual are
identical to those shown in the supplied
paper.）
Place the paper pattern to align its edges with
the fender's edges, and attach it with masking
tape,etc.
3
Whenusingacleaningdetergent,be
carefulwithfireandcarryoutthe
installationworkinawellventilatedarea.
（2）Preparingpaperpatternsandattachingthemtothecar
（1） Cleaninganddegreasingthesurfaceonwhichtheproductistobeinstalled
Installationguidelines
【Figure1】
【Figure2】
Surfaceonwhich
theproductistobe
installed
Caution
Edge
Edge
ThisdrawingshowshowtoinstalltheproductontheLHside.
050mm
02in
Scale
050mm 02in
Scale
R H
L H

4
Temporallypeelthelinersofdouble-sidedtapeattachedtothebackoftheairoutletgarnishasshowninthefigure
below.
PeeloffallthereleasepaperfromⒶ.[Figure4]
（4）Temporarypeelingofthelinersofdouble-sidedtape
【Figure4】
Insert the V-shaped part of the air outlet
garnishwhilealigningitwiththeprojectionof
thelinerdesign.Alignthebottomedgeofthe
garnishwiththetopedgeofthepaperpattern
and confirm that it is correctly positioned.
Also,checkthepositionoftheconvexpart.
（3）Temporaryalignmentoftheairoutletgarnish
【Figure3】
Securethereleasepaper
(furtherthantheconvexpart).
Releaseliner
Releaseliner
Releaseliner
MaskingTape
35mm
Convex
part
MaskingTape
Peeloffallthe
releasepaper.
LH
Ⓑ
Ⓑ
©
Ⓐ
Ⓐ
©
30mm
Topofpaperpattern
Checktheposition
oftheconvexpart.

5
（5）Attachingtheairoutletgarnish
Revisedcontents
△Detailsofthework date
Newlycreateddocument 2021.04.0200
Caution
The installation work is complete when the air
outlet garnish is attached by applying pressure
(approx.5kgf)andsecurelyfixedtothecarbody.
Ensurethatthereisnopeelingintheattached
area or no adhesive joint failure, including
separation.[Figure6]
Avoid getting the car wet by washing it, etc.
within 24 hours after the work is complete.
Otherwise,itmaycausetheadhesivetopeel.
Aftercompletingthepressurebonding,remove
theinstallationsupportfromthecar.
Whenthesurfaceissoiledafterthecompletion
of the work, wipe the surface clean with a
wastecloth.
Dothesamefortherightside.
（6） Pressurebondingandcompletioncheck
Insert the V-shaped part of the air outlet
garnishwhilealigningitwiththeprojectionof
the liner design. Check also the alignment of
the convex part and then attach Ⓐ with the
double-sidedtape.
Temporarily attach Ⓑ and Ⓒ with the
double-sided tape while aligning the bottom
edgewiththetopedgeofthepaperpattern.
[Figure5]
【Figure6】
【Figure5】
Makesurenottomisalignthegarnishwith
or allow it to protrude from the paper
pattern.
Caution
2
1
Ⓑ
©
Ⓐ
Avoiddouble-sidedtapeⒶfrom
touchingtheliner.
Avoid holding this product only by their
ends to prevent it from being twisted or
bent.
Removingthis product fromthelinerafter
temporarily attaching it with the
double-sided tape may cause wrinkles,
breaks,orcracksonitscoatingsurface.
NG
NG
InspectionMethods
Pleaseconfirmthatthereisnotthe
gapandrunoverwiththepaper
pattern.
Intheillustrationrange,please
confirmthatthereisnotagap.
Pressure
bonding
Pressure
bonding
