Summit SINCFS1 User manual

Write the serial number here:
Serial # _____________________
Felix Storch, Inc.
Summit Appliance Division
770 Garrison Avenue
Bronx, NY 10474
Instruction Manual
For Portable Induction Cooktop
Model SINCFS1

Page 2 SUMMIT APPLIANCE
Thank you for purchasing the SUMMIT Portable Induction
Cooktop. We fully expect this product to bring you many
years of excellent service.
Please read this instruction manual before installing and
using the Cooktop. Keep the manual in a handy spot so
you can check it for reference in the future.
Technical Information
Model #: SINCFS1
Electrical Specifications: 120VAC / 60Hz
Power Rating: 1800W
Temperature Range: 140°F to 464°F
Timer Range: 0 to 120 minutes
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock, do not immerse
cord, plug or main body in water or other liquids.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use and before cleaning.
Allow to cool before putting on or taking off parts.
6. Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions or has been
damaged in any manner. Return appliance to the
nearest authorized service facility for examination, repair
or adjustment.
Technical Information
IMPORTANT SAFEGUARDS

Page 3 SUMMIT APPLIANCE
7. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or
in a heated oven.
11. Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
12. Always attach plug to appliance first, then plug cord
into the wall outlet. To disconnect, turn any control to
Off, then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14. Do Not Cook on Broken Cooktop –If cooktop should
break, cleaning solutions and spillovers may penetrate
the broken cooktop and create a risk of electric shock.
15. Clean Cooktop with Caution –If a wet sponge or cloth
is used to wipe spills on a hot cooking area, be careful
to avoid a steam burn. Some cleaners can produce
noxious fumes if applied to a hot surface.
16. Any servicing should be performed by an authorized
service representative.
17. This appliance is intended for household use only.
18. A short power supply cord (or detachable power supply
cord) should be used to reduce the risk resulting from
becoming entangled in or tripping over a longer cord.
19. Longer detachable power supply cords or extension
cords are available and may be used if care is exercised
in their use.
20. If a longer detachable power supply cord or extension
cord is used:
a) The marked electrical rating of the cord set or

Page 4 SUMMIT APPLIANCE
extension cord should be at least as great as the
electrical rating of the appliance; and
b) The cord should be arranged so that it will not drape
over the countertop or tabletop where it can be pulled
on by children or tripped over.
21.This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet only one
way. If the plug does not fit fully into the outlet, reverse
the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any
way.
22.Built-in mounting should follow the directions in the
installation instructions.
23.To reduce the risk of fire, do not place unit over or near
any portion of a heating or cooking appliance.
24.To reduce the risk of fire, do not store anything directly
on top of the appliance surface when the appliance is in
operation.
25.To reduce the risk of electric shock, do not mount over a
sink.
26. Save these instructions.

Page 5 SUMMIT APPLIANCE
Location of Controls
Before Using the Appliance
 Use a separate socket. The use of an extension cord
could result in overloading the circuit.
 Place the appliance on a flat surface and keep it away
from the wall and from other articles. Leave at least 2"
of clearance on the sides and 6" at the rear. When the
air vents are blocked, the internal temperature of the
appliance rises and this may result in the unit
automatically shutting off during cooking.
 Never heat an empty pot or pan. The appliance will
cease to operate and could be damaged as a result.
 Remember to turn off the appliance after use. If not, the
ventilating fan will continue to operate, resulting in a
waste of energy. (Normally, when the unit is turned off,
the fan continues to operate for 3 minutes before
shutting off automatically.)
 Keep the appliance away from a gas range or electric
oven. If the surrounding temperature is high the unit will
stop heating.
 Be sure to wipe off any water droplets from the bottom
of the cooking pot before heating. If not, the boiling
water may splatter and burn someone.
Cooking surface
TIMER button
Power ON/OFF
switch
TEMP/HEATING
button
Digital display
◄/►buttons LEDs
Location of Controls
Before Using the Appliance

Page 6 SUMMIT APPLIANCE
How to Use the Induction Cooktop
1. Center a suitable pot or pan on the cooktop and plug in
the appliance. The Power On LED (Light-Emitting Diode)
will start to flash.
2. Press the ON/OFF switch to turn on the unit. The
Power ON LED will be on steady.
The ON/OFF switch controls power to the appliance,
while the HEATING/TEMP and TIMER buttons control
the various functions. The digital Display shows
information about the functions.
3. When the Induction Cooktop is turned on, the HEATING
function will be displayed, and that LED will be lit. If you
want to use this function, press the ◄and ►buttons to
adjust the HEATING rate to any of 7 levels, from 500W
to 1800W.
4. Press TEMP if you want to set the temperature. The
default temperature setting is 212°F (100°C), but this
can be adjusted by pressing ◄or ►. The temperature
range of the Induction Cooktop is 140°F to 464°F (60°C
to 240°C).
5. Press TIMER to set the cooking time. The TIMER LED
will be lit and the Display will flash the time. Adjust the
TIMER by pressing ◄or ►(the range is from 0 to 120
minutes). When the TIMER button has not been pressed
for a few seconds, the Display will stop flashing and then
will automatically shift to either TEMP or HEATING. The
corresponding LED will be lit. To see the countdown
time on the Display, press TIMER again and the
remaining time will flash briefly.
WARNING: The appliance will be HOT during use.
6. The unit will automatically shut off after the set time has
elapsed.
NOTE: For frying in oil, used the TEMP function rather than
HEATING.
How to Use the Induction Cooktop

Page 7 SUMMIT APPLIANCE
Tips
 If possible, use a surge protector with this appliance.
 This appliance is for indoor use only.
 Never submerge the appliance in water.
 Never heat an empty pot or pan.
 Never heat any sealed containers such as a can of soup
to avoid a possible explosion due to heat expansion.
 Even after the appliance is turned off, the cooking
surface remains hot. Avoid touching this ceramic
surface until it has had time to cool down.
 Check under the appliance periodically to be sure the air
vents are not obstructed by any paper, glass, etc.
 Metallic objects like knives, forks, spoons and lids
should not be placed on the cooktop since they can get
hot.
 Never use the appliance in high-temperature
environments such as near a stove.
 Do not put flammable objects in the equipment installed
below the Induction Cooktop.
 If the cooking surface is cracked, switch off the
appliance to avoid the possibility of electric shock.
 Do not use cooking vessels with rough or uneven
bottoms which could damage the ceramic surface of the
appliance.
Tips

Page 8 SUMMIT APPLIANCE
Usable and Non-Usable Cooking Utensils
1. Usable Pans
Steel or cast iron, enameled iron, stainless steel, flat-
bottom pots or pans with diameters between 4¾"
(12 cm) and 10¼" (26 cm).
 iron pots
 enameled iron pots
 cast-iron pans
 deep-frying pans
 stainless steel pots
 iron plates
2. Non-Usable Pans
Heat-resistant glass, ceramic, copper, aluminum,
rounded-bottom pans and pots with bottoms measuring
less than 4¾" (12 cm).
 pots with rounded bottoms
 aluminum and copper pots
 pots with bottoms measuring
less than 4¾"
 pots with feet
 ceramic pots
 heat-resistant glass pots
Usable and Non-Usable Cooking Utensils

Page 9 SUMMIT APPLIANCE
Cleaning
 Disconnect plug and wait until the unit is cooled down
completely. Clean after each use.
 If pots and pans are used without being cleaned,
discoloration and cooked-on stains may occur.
 Do not use benzene, paint thinner, scrubbing brush or
polishing powder to clean the appliance.
 Wipe the appliance with a clean, soft cloth dampened
with a solution of dish-washing liquid.
 Use a vacuum cleaner to remove dirt from the air intake
and exhaust vents.
 Never run water over the unit. (Water can get inside
and cause a malfunction.)
Cleaning

Page 10 SUMMIT APPLIANCE
Troubleshooting
Error
Message Cause Solution
E0 No pan or unsuitable
pan Use a suitable pan.
E1 Temperature of inter-
nal circuit is too high
or temperature testing
circuit has failed.
Clear/unblock ventila-
tion slots. Let device
cool off for a few min-
utes. If error message
remains after unit has
cooled off, contact re-
tailer.
E2 Heating an empty
pan. Temperature of
pan is too high or tem-
perature testing circuit
has failed.
Remove the cookware
from the cooktop. Let
the device cool off for a
few minutes. The de-
vice is ready for
opera-
tion afterwards.
E3 Voltage is atypical. Let the device cool off
for a few minutes. It
should be ready for op-
eration afterwards.

Page 11 SUMMIT APPLIANCE
WARRANTY
Call customer service toll-free in the U.S.A. @ 1-800-287-
8799, Monday to Friday 9:00 a.m. –5:00 p.m. ET.
One Year Limited Warranty
Within the 48 contiguous United States, for one year from the
date of purchase, when this appliance is operated and main-
tained according to instructions attached to or furnished with
the product, warrantor will pay for factory specified parts and
repair labor to correct defects in materials or workmanship.
Service must be provided by a designated service company.
Outside the 48 states, all parts are warranted for one year
from manufacturing defects. Plastic parts, shelves and cabi-
nets are warranted to be manufactured to commercially ac-
ceptable standards, and are not covered from damage during
handling or breakage.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance,
to instruct you how to use your appliance, to replace or
repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs or
broken shelves. Consumable parts (such as filter) are
excluded from warranty coverage.
3. Damage resulting from accident, alteration, misuse,
abuse, fire, flood, acts of God, improper installation, in-
stallation not in accordance with electrical or plumbing
codes, or use of products not approved by warrantor.
4. Replacement parts or repair labor costs for units oper-
ated outside the United States.
5. Repairs to parts of systems resulting from unauthorized
modifications made to the appliance.
6. Expenses for travel and transportation for product service
in remote locations.
7. The removal and reinstallation of your appliance if it is
installed in an inaccessible location or is not installed in
accordance with published installation instructions.
Within the 48 contiguous United States, for one year from the
date of purchase, when this appliance is operated and main-
tained according to instructions attached to or furnished with the
product, warrantor will pay for factory specified parts and repair
labor to correct defects in materials or workmanship. Service
must be provided by a designated service company. Outside the
48 states, all parts are warranted for one year from manufactur-
ing defects. Plastic parts, shelves and cabinets are warranted to
be manufactured to commercially acceptable standards, and are
not covered from damage during handling or breakage.

Page 12 SUMMIT APPLIANCE
DISCLAIMER OF IMPLIED WARRANTIES;
LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER
THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR
AS PROVIDED HEREIN. IMPLIED WARRANTIES, INCLUD-
ING WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE
YEAR. WARRANTOR SHALL NOT BE LIABLE FOR INCI-
DENTAL OR CONSEQUENTIAL DAMAGES. SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITA-
TION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR LIMITATIONS ON THE DURATION OF IMPLIED WAR-
RANTIES OF MERCHANTABILITY OR FITNESS, SO
THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY
TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS,
WHICH VARY FROM STATE TO STATE.
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
Phone: [phone]
Fax: [phone]
Web Site:
www.summitappliance.com
